Lockly ACCESS TOUCH PRO User manual

INSTALLATION
GUIDE
ACCESS TOUCH PRO
WI-FI CONNECTED
FINGERPRINT DEADBOLT
Enjoy the freedomTM

Welcome!
Reference installation parts overview foldout on back page
This guide will walk you through step-by-step how to install and
get your Lockly Access Touch Pro up and running. Installation
generally takes less than 30 minutes. If you have any questions
please reference our online support at: Lockly.com/support
or call [phone] for help.

To complete installation, you would need the following:
Prepare door and remove existing lock. If necessary, use provided
Installation Template to prepare door.
1-⅜" (35mm)
to 2" (50mm)
1" (25mm)
2-⅜" (60mm)
or 2-¾" (70mm)
2-⅛" (54mm)
2
Preparation
Tape measure or ruler
Flathead Screwdriver
Phillips Screwdriver
*Optional
* Use goggles to protect eyes if you need to drill door holes.

ADJUST DEADBOLT AND INSTALL
Step 1
3
Deadbolt slot must align to the center of the door hole. Adjust as
shown if needed.
The deadbolt comes set to 2-3/4" (70mm). Adjust length to 2-3/8”
(60mm) if necessary (wear gloves to protect from possible pinching).
Hold the metal plate and
twist the deadbolt body
clockwise till it snaps to 2-3/8"
Deadbolt comes set at 2-3/4"
(70mm). To return to default,
while deadbolt is extended,
hold the metal plate and
twist the deadbolt body
counter-clockwise till it snaps
to 2-3/4"
Push the crank to extend
the deadbolt
B
C
D
A
2-3/4" (70mm)
or 2-3/8” (60mm)
BA
CD
C
D
B
C D
B

4
ADJUST DEADBOLT AND INSTALL
Step 1 continued
Extend the deadbolt by inserting
a flat-head screwdriver into the
slot and turning clockwise.
Insert deadbolt to the door edge,
make sure that the right side is up
and the slot is in the vertical position.
Secure with 2 screws.
K
1
2
K

INSTALLING EXTERIOR ASSEMBLY (B)
Step 2
Before mounting exterior lock assembly
(B) make sure torque blade is in the
vertical position while deadbolt is
extended [1].
Place assembly and torque blade
through the deadbolt slot and guide
connection cables through the cross-
bore hole under the deadbolt as shown.
Align and secure until flush to exterior
door surface.
5
EXTERIOR VIEW
[1]
Vertical
Extended
Under

INSTALLING EXTERIOR ASSEMBLY (B)
6
Step 2 continued
TIP: when installing screws by hand, turn screws clockwise several turns then
counterclockwise one turn to ensure smooth threading and no cross threading.
1: Check mounting plate
alignment to door hole before
securing with adhesive strips.
3: Insert, tighten by hand 2
screws located on the left
and right of the blade. Check
alignment and tighten with
screwdriver until mounting plate
is
securely placed on door.
4: Use the key to ensure deadbolt locks
and unlocks smoothly (no binding or
rubbing). IMPORTANT: when finished,
leave the deadbolt extended and
remove the key before proceeding
to the next step.
2: Align and secure mounting plate
with adhesive strips. Guide connection
cable through and secure to the lower
left notched hole.
2X
D
G
Remove key when finished
Leave deadbolt extended
G

7
Lockly Access Touch Pro comes with a pre-wired door sensors consisting
of two parts:
Part (P) - Wired
Sensor
Part (Q) - Sensor
Magnet
About door sensors
Door sensors provide real-time door condition status, such as the
ability to verify if the door is securely closed. It also sends push
notifications to your phone whenever your door opens and enables
voice control with Amazon Alexa or Hey Google.
Removal of Sensor (optional)
There may be circumstances where the sensor cannot be installed
because of molding/door limitations or is not aesthetically desirable.
The sensor wired to the lock is removable by carefully pulling its connector
from the circuit board. If removed, some features and functionality
will not be available, such as real-time condition status.
IMPORTANT: Gap must be less than 3/4”
when installed.
When installed on door, the distance between the
wired sensor and sensor magnet must be less than
3/4” in order for the sensor to work.If door frame is
higher than door, add included foam pads to level
parts (P) and (Q) with each other as much as possible.
PREPARING WIRED DOOR SENSOR
Step 3
TIP: Lockly door sensors comes in Grey (PGA715) and Matte
Black (PGA716) that can be ordered through our customer
hotline: [phone] or by email: [email protected].
Do not install the wired door sensor yet. You will install in Step 6.

8
Right
or
Left
When installing the wired door sensors, make sure the arrow on the
wired sensor Paligns to the arrow of the sensor magnet Qas close
as possible.
The sensors need to be as
close to level as possible. If
needed, use the adhesive
foam pad(s) to adjust the
height of the wired sensor.
Sensors can be positioned
on either left or right side
(see next page).
2-3/4" (70mm)
2-3/8" (60mm)
3/4" (20mm)
Foam pad
(P) (Q)
PREPARING WIRED DOOR SENSOR
Step 3 continued

9
Insert form
pad
The interior assembly comes
with the pre-installed wired
door sensor setup for a right
swing doors with 2 ¾" (70mm)
backset*.
Trim excess part (P) for doors
with 2 ⅜" (60mm) backset as
shown below.
For left swing doors, re-route
the door sensor wire through
the side channel. Pull the
foam
pad then re-insert to secure the
wire. Discard the excess part
(e) for doors with 2 ⅜" (60mm)
backset as shown below:
DO NOT INSTALL THE SENSORS YET
Pull foam pad
PREPARING WIRED DOOR SENSOR
(P)
Step 3 continued
Trim excess here for
2 ⅜" (60mm) backset*
3
2
1
*Backset = distance of the door edge to the center of the cross-bore
door hole.

10
INSTALLING INTERIOR ASSEMBLY (F)
Step 4
Plug into , match
red side of plug with red on
socket- insert tightly.
X
X
Y
Y
Plug the cable coming through mounting plate into the interior
assembly as shown. Tuck cable under eyelet hooks and route to
the right on interior assembly .
D
F
F
1
2
Install Cable Remove Cable
IMPORTANT:
If you need to disconnect
this cable, use a screw-
driver to hold down the
tab (marked red) before
carefully unplugging. DO
NOT FORCE as this may
result in damaging the
lock.

11
Before placing the
interior assembly
onto the mounting
plate, ensure the
thumb turn is vertical.
Secure the interior
assembly to mounting
plate with 2 screws.
I
2X
I
Torque Blade Thumb turn shaft
Align torque blade with thumb
turn shaft, make sure both are in
the vertical position.
INSTALLING INTERIOR ASSEMBLY (F)
Step 4 continued
RESET
PROGRAM
Place the interior assembly
against the mounting
plate and make sure the
torque blade is inserted
to the thumb turn shaft.
RESET
PROGRAM
RESET
PROGRAM
F

12
3: Once self-check completes ensure the
lock operates smoothly by manually
locking and unlocking the door using the
deadbolt should operate smoothly
without any interference or binding. If
necessary, repeat step 2 and ensure
that (a) the deadbolt was extended
and (b) the torque blade was inserted
vertically while the deadbolt was extended.
4: Once self-check is complete, install the
battery cover Hand secure with screw on
top (do not over tighten).
1: With door open and deadbolt fully extended,
place ribbon inside compartment and insert 4
batteries (note correct -/+ polarity).
2: After all batteries are installed, PRESS and HOLD
the program button for 10S. The lock will automati-
cally start self-check (release program button once
check starts). The self-check process determines
right or left swinging door and is very important
to ensure correct installation. IMPORTANT: if lock
is not properly installed it will open and close repea-
tedly.
INSTALLING BATTERIES
PRESS
& HOLD
Step 5
123
4

13
LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor P
for doors with 2-3/8" (60mm) backset. Clean surface of door and
doorframe, remove film from adhesive, attach and secure close to
door edge as shown.
INSTALLING WIRED DOOR SENSOR
Step 6
Make sure you have prepared the door sensors for installation,
see step 3.
2-3/4" ( 70mm)
2-3/8" ( 60mm)
P

14
Step 6 continued
NOTE:
When properly installed, the Lockly logo blinks red when door
opens and closes.
DOOR FRAME SENSOR (Q)
Manually retract deadbolt and close door. Dry fit sensor Qto door
frame and check for alignment. If needed, raise the height of the
sensor to be more level with sensor Pby adding 1 or 2 of the included
adhesive foam pads. Once satisfied both sensors are as level as
possible, remove film from adhesive and install with arrows aligned
to each other with less than a 3/4" gap between each sensor.
INSTALLING WIRED DOOR SENSOR
Q

15
INSTALLING DOOR STRIKE
Use the supplied door strike or use your existing as long as deadbolt
operates smoothly without binding or catching.
IMPORTANT: Because doors and frames vary in design, it may be
necessary to make slight adjustments to your strike plate and/or
dust box in order to ensure smooth deadbolt operation. This is very
important. If the deadbolt is binding or catching in any way the
lock will sound an alarm (rapid beeping) indicating it cannot close
due to misalignment and/or excessive rubbing or binding.
L
K(2X) N
Step 7

DOWNLOAD LOCKLY APP
16
You have completed the Lockly physical lock installation. To enable
live monitoring and voice control with Hey Google or Amazon Alexa,
you will need to setup the included Secure Link Wi-Fi hub and pair it
with the Lockly Access Touch Pro fingerprint deadbolt smart lock and
door sensor.
Before connecting Secure Link Wi-Fi hub, download the Lockly app on
your smartphone. It is required to finish setup and to pair the connection
between hub and lock.
Scan or visit
Lockly.com/app
or
Search & Download
directly on...
Step 8

17
30 Feet (9 meters)
Distance Between
Lockly Smart Lock Secure Link Wi-Fi Hub
You
Using an iOS or Android™
Device with Bluetooth &
Wi-Fi enabled
Step 9
SECURE LINK WI-FI HUB SETUP
TIP: The Secure Link requires a strong wireless signal for optimal perfor-
mance. Make sure the Secure Link will be installed in a location with a
strong 2.4 Ghz wireless signal. Sometimes distances between Wi-Fi hub
and lock can vary due to circumstances. If you are having difficulty
setting up optimal range of 30/ft or less, we’re here to help. Call our
customer care team: [phone], or visit Lockly.com/help for
suggestions and troubleshooting tips.
To set up your Lockly Access Touch Pro, choose an appropriate location
for the Secure Link Wi-fi Hub for optimum performance (see below). For
optimum connectivity, it is recommended that the hub be no further
away from the lock than 30 feet (9 meters).
During the setup process position yourself between the lock and the
Secure Link Wi-Fi Hub—ideally no more than 30 feet (9 meters) apart.
Ensure your iOS or Android device has both Bluetooth and Wi-Fi enabled.

18
Plug the Secure Link Wi-Fi Hub into the 5V 1A USB AC adapter and plug
the AC adapter to your wall socket.
Once you have confirmed that your Secure Link Wi-Fi Hub is ready to
connect to your lock, open the Lockly App from your smartphone.
Make sure you are standing between the Wi-Fi hub and Lockly smart
lock
, then Add New Device and follow the on screen instructions.
USA Outlet Shown
A GREEN LED indicator light will flash
slowly to indicate that the Wi-Fi Hub
is ready to connect.
LED Indicator is located next
to the Setup Button
SECURE LINK WI-FI HUB SETUP
Step 9 continued

Scanning LOCK SERIAL
●●●●● AT&T 9:43 AM 100%
19
The App will take you through the following steps, make sure the smart
lock has been properly installed. You will need your activation card that
is included in the box to proceed.
CONNECTING YOUR LOCKLY ACCESS TOUCH PRO
Step 10
Select A Device
●●●●● AT&T 9:41 AM 100%
ADD NEW DEVICE
●●●●● AT&T 9:41 AM 100%
Plug in your Secure Link
and Click "YES"
AT&T 9:44 AM 100%
Input Activation Code
●●●●● AT&T 9:44 AM 100%
Turn to the
next page
ACC20221223
Activation Card
SAVE
Need help? Email: [email protected] | Support: [phone]
