Double Windrow Attachment (DWA)
for M-Series Self-Propelled
Windrowers
Setup, Operation, and Parts Manual
214049 Revision A
Model Year 2017
Original Instruction

This instruction contains the setup procedures, operation instructions, and parts lists for the MacDon Double
Windrow Attachment (DWA).
Published: October 2016

Introduction
The Double Windrow Attachment (DWA) provides the ability to place two windrows of conditioned material close
together.
The DWA can be mounted on M150, M155, M155E4, M200, and M205 Self-Propelled Windrowers.
The DWA is for use with A-Series Auger Headers, D-Series Draper Headers with HC10 Hay Conditioners, and
R-Series Rotary Disc Headers.
NOTE:
• A DWA should not be used on headers larger than 25 feet.
• The HC10 is not compatible with M205 Self-Propelled Windrowers.
• The HC10 is compatible with M100, M105, M150, M155, M155E4, and M200 Self-Propelled Windrowers. These
windrowers can use both a DWA and the HC10 on draper headers between 15 and 25 feet.
NOTE:
Depending on the windrower model year, a software update may be required for proper function of the auxiliary lift
valve block provided with your DWA. Refer to MacDon Service Bulletin #SB1210 for details.
When the DWA system is engaged, the conditioned crop is deposited onto the side draper and placed to the side
of the windrower. Raising the side delivery disengages the DWA, allowing the crop to be deposited between the
windrower’s wheels.
When setting up the machine or making adjustments, review and follow the recommended machine settings in all
relevant MacDon publications. Failure to do so may compromise machine function and machine life and may result
in a hazardous situation.
MacDon provides warranty for Customers who operate and maintain their equipment as described in this manual.
A copy of the MacDon Industries Limited Warranty Policy, which explains this warranty, should have been provided
to you by your Dealer. Damage resulting from any of the following conditions will void the warranty:
•Accident
•Misuse
• Abuse
• Improper maintenance or neglect
• Abnormal or extraordinary use of the machine
• Failure to use the machine, equipment, component, or part in accordance with the manufacturer’s instructions
A Russian translation of this manual can be ordered from MacDon, downloaded from the MacDon Dealer
Portal (https://portal.macdon.com) (login required), or downloaded from the MacDon International website
(http://www.macdon.com/world).
NOTE:
Keep your MacDon publications up-to-date. The most current version can be downloaded from our website
www.macdon.com or from our Dealer-only site (https://portal.macdon.com) (login required).
214049 iRevision A

List of Revisions
At MacDon, we’re continuously making improvements: occasionally these improvements impact product
documentation. The following list provides an account of major changes from the previous version of this document.
Summary of change Location
Included updated warranty statement to the manual’s
introduction.
Added notes about HC10 and M205 incompatibility and
draper header size limits for DWA and HC10 use.
Introduction, page i
Updated repair parts list and repair parts list illustration
to include hydraulic cylinder part (MD #208966) and
bolt (MD #21484).
5.3 Deck Supports and Linkage (Illustration 1), page 86
Added decal (MD #167903) to Hydraulic Service
Components parts repair list and parts repair list
illustration.
5.6 Hydraulic Service Components, page 96
Corrected figures and descriptions for topic. 1.7 Safety Sign Decals, page 8
Added step telling users how to prevent against
hydraulic system contamination. 2.6 Installing the Hydraulics, page 34
2.6.3 Installing Case Drain Hose: M150/M200 and
D-Series Headers without Reverser, page 37
Clarified in which step the reel return hose was
disconnected from Port T.
2.6.4 Installing Case Drain Hose: M150/M200 and
D-Series Headers with Reverser, page 38
Updated instructions and illustrations. 3.5.1 AdjustingDeckAngleRelativetotheDriveTire,
page 58
Updated information with crop conditions for ideal
performance of tall crop feed plates. 3.9.2 Operating with an R-Series Rotary Disc Header, page 65
Updated illustrations. 4.1.4 Replacing Draper, page 69
Updated topic title. 4.2 Lubricating the Double Windrow Attachment, page
76
Updated topic title and contents to include 25-foot
headers. 3.9.1 Operating with 15-, 16-, 18-, 20-, 25-Foot Headers, page 65
Updated conversion chart. 6.2 Conversion Chart, page 116
Added predelivery checklist. Predelivery Checklist, page 121
214049 ii Revision A

Serial Number Location
Record the serial number of the Double Windrow
Attachment (DWA) in the space provided.
DWA serial number: __________________________
The serial number plate is located on the deck (A).
Figure 1: Serial Number Location
214049 iiiRevision A

TABLE OF CONTENTS
Introduction...................................................................................................................................... i
List of Revisions ...............................................................................................................................ii
Serial Number Location....................................................................................................................iii
1 Safety.................................................................................................................................................... 1
1.1 Safety Alert Symbols........................................................................................................................ 1
1.2 Signal Words................................................................................................................................... 2
1.3 General Safety ................................................................................................................................ 3
1.4 Maintenance Safety......................................................................................................................... 5
1.5 Hydraulic Safety .............................................................................................................................. 6
1.6 Safety Signs.................................................................................................................................... 7
1.6.1 Installing Safety Decals ............................................................................................................ 7
1.7 Safety Sign Decals .......................................................................................................................... 8
2 Assembly/Setup Instructions...............................................................................................................11
2.1 Reworking Frame for Pre-2008 Windrowers ....................................................................................11
2.2 Installing the DWA Draper Drive Manifold........................................................................................ 13
2.3 Installing the Platform Rail.............................................................................................................. 17
2.3.1 Installing the Platform Rail: M155/M155E4/M205 ..................................................................... 17
2.3.2 Installing the Platform Rail: M150/M200................................................................................... 18
2.4 Installing the Linkage ..................................................................................................................... 19
2.4.1 Installing the Linkage: M150/M155/M155E4............................................................................. 19
2.4.2 Installing the Linkage: M200 ................................................................................................... 22
2.4.3 Installing the Linkage: M205 ................................................................................................... 26
2.5 Installing the Deck ......................................................................................................................... 30
2.6 Installing the Hydraulics ................................................................................................................. 34
2.6.1 Installing Case Drain Hose: M150/M200 and A-Series Headers without Reverser ...................... 35
2.6.2 Installing Case Drain Hose: M150/M200 and A-Series Headers with Reverser........................... 36
2.6.3 Installing Case Drain Hose: M150/M200 and D-Series Headers without Reverser...................... 37
2.6.4 Installing Case Drain Hose: M150/M200 and D-Series Headers with Reverser........................... 38
2.6.5 Installing Case Drain Hose: M150/M200 and R-Series Headers................................................ 38
2.6.6 Installing Case Drain Hose: M155/M155E4/M205 with All Headers............................................ 39
2.7 Installing the Auxiliary Valve Block .................................................................................................. 40
2.8 Installing the Electrical System ....................................................................................................... 43
2.8.1 Activating the Double Windrow Attachment (DWA)................................................................... 45
2.9 Installing the Tank Overflow Hose Extension.................................................................................... 47
2.9.1 Installing the Tank Overflow Hose Extension: M150.................................................................. 47
2.9.2 Installing the Tank Overflow Hose Extension: M155/M155E4 .................................................... 49
2.9.3 Installing the Tank Overflow Hose Extension: M200 with Cat Engine ......................................... 51
2.9.4 Installing the Tank Overflow Hose Extension: M205.................................................................. 51
3 Operation ............................................................................................................................................ 53
3.1 Operational Safety......................................................................................................................... 53
3.2 Engaging the Deck Safety Pin........................................................................................................ 54
3.3 Raising and Lowering the Deck ...................................................................................................... 55
3.3.1 Adjusting the Deck Lift Speed ................................................................................................. 56
3.3.2 Adjusting the Draper Shut-Off Switch....................................................................................... 56
3.4 Setting Draper Speed..................................................................................................................... 57
3.5 Adjusting the Deck Angle ............................................................................................................... 58
3.5.1 Adjusting Deck Angle Relative to the Drive Tire........................................................................ 58
3.5.2 Adjusting Deck Angle Relative to the Ground........................................................................... 59
3.6 Adjusting Deck Height.................................................................................................................... 61
3.7 Positioning the Conditioner Forming Shield ..................................................................................... 62
3.8 Positioning the Conditioner Rolls .................................................................................................... 64
3.9 Operating Recommendations......................................................................................................... 65
3.9.1 Operating with 15-, 16-, 18-, 20-, 25-Foot Headers................................................................... 65
214049 vRevision A

TABLE OF CONTENTS
3.9.2 Operating with an R-Series Rotary Disc Header....................................................................... 65
4 Maintenance and Servicing................................................................................................................. 67
4.1 Draper Maintenance ...................................................................................................................... 67
4.1.1 Adjusting Draper Tension........................................................................................................ 67
4.1.2 Checking the Draper Tracking................................................................................................. 67
4.1.3 Adjusting Draper Tracking....................................................................................................... 67
4.1.4 Replacing Draper................................................................................................................... 69
4.1.5 Adjusting Front Skid ............................................................................................................... 70
4.1.6 Adjusting Rear Deflector......................................................................................................... 71
4.1.7 Maintaining the Draper Roller.................................................................................................. 71
Removing and Reinstalling the Drive Roller...................................................................... 71
Removing and Reinstalling the Idler Roller ....................................................................... 73
4.1.8 Replacing Draper Roller Bearing/Seal...................................................................................... 74
4.2 Lubricating the Double Windrow Attachment.................................................................................... 76
4.3 Hydraulics Schematics................................................................................................................... 77
5 Repair Parts ........................................................................................................................................ 79
5.1 Deck, Draper, and Rollers (Illustration 1) ......................................................................................... 80
5.2 Deck, Draper, and Rollers (Illustration 2) ......................................................................................... 82
5.3 Deck Supports and Linkage (Illustration 1)....................................................................................... 86
5.4 Deck Supports and Linkage (Illustration 2)....................................................................................... 90
5.5 Hydraulics and In-Cab Electrical..................................................................................................... 92
5.6 Hydraulic Service Components....................................................................................................... 96
5.7 Decals .........................................................................................................................................100
6 Reference...........................................................................................................................................103
6.1 Torque Specifications....................................................................................................................103
6.1.1 SAE Bolt Torque Specifications..............................................................................................103
6.1.2 Metric Bolt Specifications.......................................................................................................105
6.1.3 Metric Bolt Specifications Bolting into Cast Aluminum..............................................................108
6.1.4 Flare-Type Hydraulic Fittings..................................................................................................108
6.1.5 O-Ring Boss (ORB) Hydraulic Fittings (Adjustable)..................................................................110
6.1.6 O-Ring Boss (ORB) Hydraulic Fittings (Non-Adjustable) ..........................................................112
6.1.7 O-Ring Face Seal (ORFS) Hydraulic Fittings...........................................................................113
6.1.8 Tapered Pipe Thread Fittings .................................................................................................115
6.2 Conversion Chart..........................................................................................................................116
Index ..................................................................................................................................................117
Predelivery Checklist ....................................................................................................................121
214049 vi Revision A

1Safety
1.1 Safety Alert Symbols
This safety alert symbol indicates important safety
messages in this manual and on safety signs on
the machine.
This symbol means:
•ATTENTION!
•BECOME ALERT!
•YOUR SAFETY IS INVOLVED!
Carefully read and follow the safety message
accompanying this symbol.
Why is safety important to you?
• Accidents disable and kill
• Accidents cost
• Accidents can be avoided
Figure 1.1: Safety Symbol
214049 1Revision A

SAFETY
1.2 Signal Words
Three signal words, DANGER, WARNING,andCAUTION, are used to alert you to hazardous situations. The
appropriate signal word for each situation has been selected using the following guidelines:
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury. It
may also be used to alert against unsafe practices.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury. It
may be used to alert against unsafe practices.
214049 2Revision A

SAFETY
1.3 General Safety
CAUTION
The following are general farm safety precautions
that should be part of your operating procedure for
all types of machinery.
Protect yourself.
• When assembling, operating, and servicing machinery,
wear all protective clothing and personal safety devices
that could be necessary for job at hand. Do NOT take
chances. You may need the following:
• Hard hat
• Protective footwear with slip resistant soles
• Protective glasses or goggles
• Heavy gloves
• Wet weather gear
• Respirator or filter mask
Figure 1.2: Safety Equipment
• Be aware that exposure to loud noises can cause
hearing impairment or loss. Wear suitable hearing
protection devices such as ear muffs or ear plugs to
help protect against objectionable or loud noises.
Figure 1.3: Safety Equipment
•Provideafirst aid kit for use in case of emergencies.
• Keep a fire extinguisher on the machine. Be sure fire
extinguisher is properly maintained. Be familiar with its
proper use.
• Keep young children away from machinery at all times.
• Be aware that accidents often happen when Operator
istiredorinahurry.Taketimetoconsidersafestway.
Never ignore warning signs of fatigue.
Figure 1.4: Safety Equipment
214049 3Revision A

SAFETY
•Wearclose-fitting clothing and cover long hair. Never
wear dangling items such as scarves or bracelets.
• Keep all shields in place. NEVER alter or remove safety
equipment. Make sure driveline guards can rotate
independently of shaft and can telescope freely.
• Use only service and repair parts made or approved
by equipment manufacturer. Substituted parts may not
meet strength, design, or safety requirements.
Figure 1.5: Safety around Equipment
• Keep hands, feet, clothing, and hair away from moving
parts. NEVER attempt to clear obstructions or objects
from a machine while engine is running.
•DoNOT modify machine. Unauthorized modifications
may impair machine function and/or safety. It may also
shorten machine’s life.
• To avoid bodily injury or death from unexpected startup
of machine, ALWAYS stop engine and remove key from
ignition before leaving operator’s seat for any reason.
Figure 1.6: Safety around Equipment
• Keep service area clean and dry. Wet or oily floors are
slippery. Wet spots can be dangerous when working
with electrical equipment. Be sure all electrical outlets
and tools are properly grounded.
• Keep work area well lit.
• Keep machinery clean. Straw and chaff on a hot
engine is a fire hazard. Do NOT allow oil or grease to
accumulate on service platforms, ladders, or controls.
Clean machines before storage.
•NEVER use gasoline, naphtha, or any volatile material
for cleaning purposes. These materials may be toxic
and/or flammable.
• When storing machinery, cover sharp or extending
components to prevent injury from accidental contact. Figure 1.7: Safety around Equipment
214049 4Revision A

SAFETY
1.4 Maintenance Safety
To ensure your safety while maintaining machine:
• Review operator’s manual and all safety items before
operation and/or maintenance of machine.
• Place all controls inNeutral, stop engine, set parkbrake,
remove ignition key, and wait for all moving parts to stop
before servicing, adjusting, and/or repairing.
• Follow good shop practices:
– Keep service areas clean and dry
– Be sure electrical outlets and tools are
properly grounded
– Use adequate lighting for job at hand Figure 1.8: Safety around Equipment
• Relieve pressure from hydraulic circuits beforeservicing
and/or disconnecting machine.
• Make sure all components are tight and that steel lines,
hoses, and couplings are in good condition before
applying pressure to hydraulic systems.
• Keep hands, feet, clothing, and hair away from all
moving and/or rotating parts.
• Clear area of bystanders, especially children, when
carrying out any maintenance, repairs or, adjustments.
• Install transport lock or place safety stands under frame
before working under machine.
• If more than one person is servicing machine at
same time, be aware that rotating a driveline or other
mechanically-driven component by hand (for example,
accessing a lube fitting) will cause drive components in
other areas (belts, pulleys, and knives) to move. Stay
clear of driven components at all times.
Figure 1.9: Equipment NOT Safe for Children
• Wear protective gear when working on machine.
• Wear heavy gloves when working on knife components.
Figure 1.10: Safety Equipment
214049 5Revision A

SAFETY
1.5 Hydraulic Safety
• Always place all hydraulic controls in Neutral
before dismounting.
• Make sure that all components in hydraulic system are
kept clean and in good condition.
• Replace any worn, cut, abraded, flattened, or crimped
hoses and steel lines.
•DoNOT attempt any makeshift repairs to hydraulic
lines, fittings, or hosesby using tapes, clamps, cements,
or welding. The hydraulic system operates under
extremely high pressure. Makeshift repairs will fail
suddenly and create hazardous and unsafe conditions.
Figure 1.11: Testing for Hydraulic Leaks
•Wearprop
er hand and eye protection when searching
for high-pressure hydraulic leaks. Use a piece of
cardboard as a backstop instead of hands to isolate
and identify a leak.
•Ifinjur
ed by a concentrated high-pressure stream of
hydraulic fluid, seek medical attention immediately.
Serious infection or toxic reaction can develop from
hydraulic fluid piercing the skin.
Figure 1.12: Hydraulic Pressure Hazard
• Make sure all components are tight and steel lines,
hoses, and couplings are in good condition before
applying pressure to a hydraulic system.
Figure 1.13: Safety around Equipment
214049 6Revision A

SAFETY
1.6 Safety Signs
• Keep safety signs clean and legible at all times.
• Replace safety signs that are missing or
become illegible.
• If original parts on which a safety sign was installed
are replaced, be sure repair part also bears current
safety sign.
• Safety signs are available from your Dealer
Parts Department.
• Safety signs are available from your MacDon Dealer.
Figure 1.14: Operator’s Manual Decal
1.6.1 Installing Safety Decals
1. Clean and dry installation area.
2. Decide on exact location before you remove decal backing paper.
3. Remove smaller portion of split backing paper.
4. Place sign in position and slowly peel back remaining paper, smoothing sign as it is applied.
5. Prick small air pockets with a pin and smooth out.
214049 7Revision A

SAFETY
1.7 Safety Sign Decals
MD #174474
HIGH PRESSURE HYDRAULICS
DO NOT GO NEAR LEAKS
Locatedondeck
• High pressure oil easily punctures skin causing serious
injury, gangrene or death
• If injured, seek emergency medical help. Immediate
surgery is required to remove oil
• Do not use finger or skin to check for leaks
• Lower load or relieve hydraulic pressure before
loosening fittings Figure 1.15: MD #174474
MD #174683
PINCH POINT - MOVING PARTS
STAND CLEAR
Located on linkage arm (both sides)
Figure 1.16: MD #174683
214049 8Revision A

SAFETY
MD #176295
DECK LIFT LOCK
Located on deck linkage
Figure 1.17: MD #176295
214049 9Revision A

2 Assembly/Setup Instructions
NOTE:
The Double Windrow Attachment (DWA) will only fit windrower models listed in the Introduction ( Introduction,
page i). The DWA cannot be installed on the M100 or M105 Self-Propelled Windrower models.
2.1 Reworking Frame for Pre-2008 Windrowers
Before installing the Double Windrow Attachment (DWA) on a windrower built before the 2008 production year, follow
these instructions:
1. If holes are not present, drill four 20 mm (25/32 in.) diameter holes at the locations shown in Figures 2.1:
Rear-Facing Frame, page 11 and 2.2: Forward-Facing Frame, page 12.
IMPORTANT:
Move hydraulic hoses out of the way before drilling into the frame at the rear-facing end of the windrower.
2. Ream/grind rear holes to make them square for square neck bolts.
NOTE:
Slots are only required if holes do not line up with DWA frame.
Figure 2.1: Rear-Facing Frame
A - Hole Locations Rear Frame B - 480 mm (18-7/8 in.) C - 121.5 mm (4-25/32 in.)
D-20 mm (25/32 in.) E-25 mm (1 in.) F-50 mm (1-31/32 in.)
214049 11 Revision A

ASSEMBLY/SETUP INSTRUCTIONS
Figure 2.2: Forward-Facing Frame
A-HoleLo
cations Front Frame B - 402 mm (15-15/16 in.) C - 92.5 mm (3-5/8 in.)
D - 40 mm (1-9/16 in.) E - 20 mm (25/32 in.) F - 28.5 mm (1-1/8 in.)
214049 12 Revision A
