ATMOS 22
SONIC ANEMOMETER
SUPPORT
Have a question or problem? Our support team can help.
We manufacture, test, calibrate, and repair every instrument in house. Our scientists and technicians use
the instruments every day in our product testing lab. No matter what your question is, we have someone
who can help you answer it.
NORTH AMERICA
Email: [e-mail]
Phone: [phone]
EUROPE
Email: [e-mail]
Phone: [phone]

3. Secure the System
Tighten the V-bolt nuts by hand
until hand-tight, and then gently
tighten with a wrench.
CAUTION:Do not overtighten
V-bolt.
1. Mount Toward True North
The ATMOS 41 must be oriented
with the engraved Non the
instrument oriented to true north
(not magnetic north).
2. Level the System
Use the bubble level
underneaththe ATMOS 22 or
aPROCHECK display to level
thesensor. The mounting pole
may need to be leveled or
shimsmay need to be applied.
Installation
ATMOS 22 QUICK START
Connecting
Plug into Data Acquisition System
Connect the stereo plug connector into any METER data logger
and configure it to read the ATMOS 22 (refer to ATMOS 22 User
Manual). Select a nonzero measurement interval to ensure data are
beinglogged.
To connect to a non-METER data logger, see the ATMOS 22
Integrator Guide at metergroup.com/atmos22-support. For non-
METER systems read the information located at
metergroup.com/environment/articles/tech-note-ds-2-to-atmos-22.
Verify Readings
Use the scan function in the software to show a list of readings.
Verifythese readings are within expected ranges.
Preparation
Verify that all ATMOS22 components arrived intact. Installation will
require a 13-mm (1/2-in) wrench and a secure mounting location.
METER recommends a meteorological stand, pole in cement, or
tripod with a 31.8- to 50.8-mm (1.25- to 2-in) diameter.
Set up and test the system (sensors and data loggers) in a lab
or office. Ensure the data loggers are using up-to-date firmware
andsoftware. Verify all sensors read within expected ranges.
Before beginning installation, consider the surroundings and
avoid obstructions. Many installations require the ATMOS 22 to be
mounted 2 m above ground, but this can be adjusted as needed.
Please read the complete ATMOS 22 User Manual at
metergroup.com/atmos22-support.All products have a 30-day
satisfaction guarantee.
4. Plug Sensor In and
Configure Logger
Plug stereo plug connector into
the data logger. Use data logger
software to apply appropriate
settings to the sensors plugged
into each data logger port.
18194-02
8.9.2019
ATTENTION
ATMOS 22 requires the following software and firmware versions. Please make updates as necessary.
ZL6 firmware version 2.02 or higher
PROCHECK firmware version 1.67 or higher
ZENTRA Utility version 1.09 or higher
Go to metergroup.com/environment/downloads to find the current software or firmware version
for the data logger being used.
