Mocka Edmond Four Drawer User manual

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
Hardware Supplied
bolt
x34
AB C D EFG H
J K L N
I
dowel
x8
screw
x40
slide
rail x4
slide
rail x4
slide
rail x4
slide
rail x4
locking
nut x34
M
screw
x20
O
bolt
x16
long
screw
x6
screw
x8
plastic
glide
x4
Allen
Key
x1
P Q
long bolt
x8
bracket
x4
wedge
x8

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
Insert 4x bolts (C) into panel [1]. Tighten with a screwdriver.
Panel layout
C
C
C
C
X4
X4
4
5
7
5
8
1
1
2
40
3
30
31
32
33
35
36
34
1
6

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
23
Attach 4x slide rails (N) to panel [3] and secure with 12x screws (E).
Insert 5x bolts (C) into panel [3]. Tighten with a screwdriver. Attach
4x slide rails (O) to panel [4] and secure with 12x screws (E). Insert
5x bolts (C) into panel [4]. Tighten with a screwdriver.
Attach panels [6], [7] and [8] to panel [3] secure with 5x locking nuts (D).
Tighten with a screwdriver.
CC
C
CC
C
C
C
CC
E
E
E
E
E
N
N
N
N
O
O
O
O
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
3
4
3
6
78
N
E
CL
E
O
CR
DD
D
DD
D

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
54
Attach panel [4] to panels [6], [7] and [8] secure with 5x locking
nuts (D). Tighten with a screwdriver.
Slide panel [5] down along the grooves between the panels [3] and [4]
as shown.
4
678
4
5
3
DD
DD
D

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
6 7
Slide panel [5] down along the grooves between the panels [3] and [4]
as shown.
Attach panel [1] to panels [3] and [4] with 4x dowels (A) and secure with
4x locking nuts (D). Tighten with a screwdriver.
3
4
1
5
4
3
A
A
A
D
D
D

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
8 9
Attach panel [2] to panels [3] and [4] with 4x dowels (A) and secure
with 4x long screws (B). Tighten with a screwdriver. Attach panel [6]
to panel [1] secure with 2x long screws (B). Tighten with a screwdriver
F
F
F
F
F
F
F
F
F
F
front
back
G
G
G
G
G
G
J
G
K
2
2
40
40
40
40
40
40
K
K
K
K
Attach 4x brackets (G) to legs [40] using 8x long bolts (J). Tighten with
a screwdriver. Attach legs [40] to panel [2] using 16x bolt (F) as shown.
Tighten with an Allen key (L). Attach 4x plastic glides (K) to the panels
[40] using a hammer as shown.
L
A
A
A
B
B
B
B
B
B
B
6
3
4
1

Edmond Four Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
10 Drawer x4
Assembly Instructions
Insert 20x bolts (C) into panel [35]/[36]. Tighten with a screwdriver.
C
C
CC
CC
CC
CC
MM
M
MM
30
31
34
32
35
36
Attach panels [30], [31] and [34] to panel [32] as shown. using 20x screws
(M). Tighten with a screwdriver.
x3
11 Drawer x4

12 Drawer x4
Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
Attach panel [35]/[36] to panels [30], [31] and [34] secure with 20x locking
nuts (D). Tighten with a screwdriver.
33
30
31
DD
DD
D
DD
DD
D
35
30
30
31
31
34
34
36
Slide panel [33] down along the grooves between the panels [30]
and [31] to form the back of the unit as shown.
13 Drawer x4
x3

Attach slide rails (P) and slide rails (Q) to the underside of the side
panels as shown. Secure with 16x screws (E) and tighten with a
screwdriver.
Insert the assembled drawers into the corresponding compartments as
shown. Ensure the drawers slide easily along the rails.
Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
14 Drawer x4 15
E
E
P
P
Q
Q
E
E
E
E
E
E
30
30
31
31
35
36
36
36
x3

Edmond Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
16 17
Attach 8x wedges (H) into the corners of the back of the unit and
secure with 8x screws (I). Tighten with a screwdriver. Attach 1x
safety strap (V) to the top of the back side of the unit as shown
using 1x washer (Z) and 1x screw (W). Tighten with a screwdriver.
Once assembled lift furniture into place, do not drag. Use a drill to create a
small hole lining up with the top of the safety strap (V). Fasten to the wall
using 1x washer (Z), 1x wall anchor (X) and 1x wall screw (Y). Ensure
unit is balanced and steady before use.You’re done, enjoy!
H
H
H
H
I
I
I
I
H
H
H
H
I
I
I
I
V
Z
W
V
Z
W
H
IXV
Y
wall
anchor
screw
strap
washer
