MSA PremAire Cadet Escape Respirator Setup guide

PremAire® Cadet
Escape Respirator:
Carrier and Harness
MSA 014 (L) Rev. 0 © MSA 2010 Prnt. Spec. 10000005389 (I) Mat. 10110431
Doc. 10110431
MAINTENANCE AND REPAIR

2
MSA 014 (L) Rev. 0 - 10110431
CARRIER AND HARNESS
TABLE OF CONTENTS
Carrier and Harness...........................................................2
Parts List ............................................................................2
DISASSEMBLY ..................................................................3
Hoses .................................................................................4
Cylinder Carrier ..................................................................4
Harness ..............................................................................5
REASSEMBLY ...................................................................5
Harness ..............................................................................6
Strap Carrier .......................................................................7
Bag Carrier .........................................................................7
Hoses .................................................................................8
Item Part Number Description
1 10037253 Optional Shoulder Pad (Kevlar only)
2
10071047 Nylon Shoulder Strap
10071048 Kevlar Shoulder Strap
3
10071049 Nylon Pull Strap
10071050 Kevlar Pull Strap
4 10022245 Belt Mount
5 10040450 Side Buckle (male only)
6
10071091 Nylon Waist Strap
10071093 Kevlar Waist Strap
10071092 Nylon Waist Strap (large)
10071094 Kevlar Waist Strap (large)
7
10073512 Nylon Hose Strap
10073513 Kevlar Hose Strap
Strap Carrier (Complete)
8
10073516 Nylon Strap Carrier
10073517 Kevlar Strap Carrier
9 10062798 Clamp (2 required)
10
10071095 Strap, Nylon (2 required)
10071096 Strap, Kevlar (2 required)
11
10061349 Nylon Bag Carrier for 5 minute carbon cylinder
10061353 Kevlar Bag Carrier for 5 minute carbon cylinder
10061350 Nylon Bag Carrier for 10 minute carbon cylinder
10061354 Kevlar Bag Carrier for 10 minute carbon cylinder
10078802 Nylon Bag Carrier for 15 minute carbon cylinder
10078803 Kevlar Bag Carrier for 15 minute carbon cylinder
Carrier and Harness Parts List
1
2
3
4
56
7
11
8
9
10

DISASSEMBLY
Hoses
1. If necessary, use an
11/16” wrench to dis-
connect the supply
hose.
2. If necessary, use an
11/16” wrench to dis-
connect the second
stage regulator hose.
Strap Carrier
1. Use the o-ring removal
tool to remove the o-
rings. Discard the o-
rings.
Note: Be careful not to
scratch the o-ring groove.
2. Remove the ring from
the split ring.
3. Disconnect the hose
strap.
4. Disconnect the cylinder
carrier from the shoul-
der strap and pull strap.
5. Use the slot head
screwdriver bit or 9/32”
socket to unscrew the
clamps.
5. Pass the clamps
through the carrier
straps.
3MSA 014 (L) Rev. 0 - 10110431
CARRIER AND HARNESS

CARRIER AND HARNESS
Harness
1. Unweave the waist strap from the male buckle.
2. Remove the belt mount.
3. Pass the waist strap
through the shoulder
strap and pull strap.
4. Remove the waist strap
from the pull strap.
5. Unweave the pull strap
from the friction buckle.
6. Remove the second stage hose from the shoulder
strap.
7. If present, remove the
shoulder pad.
REASSEMBLY
Note: The following procedures reassemble the respirator
for use with the cylinder mounted on the right hip. See
PremAire® Cadet Escape Open-Circuit,
Pressure-Demand, Escape, Self-Contained
Breathing Apparatus or Combination, Open-
Circuit, Pressure-Demand, Escape, Self-
Contained Breathing Apparatus and Type C,
Supplied-Air Respirator, Operation and
Instructions (P/N 10063148) for instructions on
converting to left-hip mounting.
4
MSA 014 (L) Rev. 0 - 10110431

CARRIER AND HARNESS
Harness
Nylon Shoulder Strap 10071047
Kevlar Shoulder Strap 10071048
Nylon Pull Strap 10071049
Kevlar Pull Strap 10071050
Belt Mount 10022245
Side Buckle (Male only) 10040450
Nylon Waist Strap 10071091
Kevlar Waist Strap 10071093
Nylon Waist Strap (Large) 10071092
Kevlar Waist Strap (Large) 10071094
1. Pass the shoulder strap
through the optional
shoulder pad.
2. Weave the pull strap through the friction buckle.
a. Pass the pull strap from back to front through the
buckle.
b. Pass the strap over the bar and from front to back
through the buckle.
Note: Make sure the stiffener is properly oriented.
3. Pass the waist strap through the shoulder strap.
Note: Make sure the
stiffener is properly
oriented.
4. Install the belt mount to
the pull strap.
5. Weave the waist strap through the male
buckle.
Strap Carrier
Nylon Strap Carrier 10073516
Kevlar Strap Carrier 10073517
Nylon Hose Strap 10073512
Kevlar Hose Strap 10073513
1. Position the straps
equal distances to the
left and right of the
centerline.
a. Position the clamps
at the edges of the
label.
5MSA 014 (L) Rev. 0 - 10110431

CARRIER AND HARNESS
b. Use a slot head
screwdriver bit or
9/32” socket and
inch-pound torque
wrench to tighten to
35 ± 10 in.lbs.
2. Attach the carrier to the
shoulder strap and pull
strap.
3. Attach the hose strap to
the shoulder strap.
4. Attach the hose strap to
the ring.
5. If necessary, reconnect the supply and second stage
regulator hoses.
Bag Carrier
Nylon Bag Carrier for 5 minute carbon cylinder 10061349
Kevlar Bag Carrier for 5 minute carbon cylinder 10061353
Nylon Bag Carrier for 10 minute carbon cylinder 10061350
Kevlar Bag Carrier for 10 minute carbon cylinder10061354
Nylon Bag Carrier for 15 minute carbon cylinder 10078802
Kevlar Bag Carrier for 15 minute carbon cylinder10078803
1. Attach the carrier to the
shoulder strap and pull
strap.
2. Attach the hose strap.
Hoses
1. Replace the o-rings.
a. Apply a small amount of Christo-Lube to a new
o-ring.
b. Carefully stretch the
new o-ring onto the
hose.
c. Use the o-ring
removal tool to slide
the o-ring into the
groove.
Note: Be careful not to
scratch the o-ring groove.
6
MSA 014 (L) Rev. 0 - 10110431

CARRIER AND HARNESS
d. If necessary, use an 11/16” crowfoot and inch-pound
torque wrench to connect the supply hose and
tighten to 125 +/- 25 in.lbs.
2. If necessary, use an 11/16” crowfoot and inch-pound
torque wrench to connect the second stage regulator
hose and tighten to 125 +/- 25 in.lbs.
