MSA Rail Slider User manual

MSAsafety.com
User Instructions
MSA Rail Slider™ Anchorage Connector
Doc./Mat.: SSRS001/08
Print Spec.: 10000005389 (F)
CR 800000039441
Model Number / Numero de modelo /
Numero de modele

WARNING!
National standards and state, provincial and federal laws require the user
to be trained before using this product. Use this manual as part of a user
safety training program that is appropriate for the user's occupation. These
instructions must be provided to users before use of the product and
retained for ready reference by the user. The user must read, and under-
stand (or have explained), and heed all instructions, labels, markings and
warnings supplied with this product and with those products intended for
use in association with it. FAILURE TO DO SO MAY RESULT IN SERIOUS
INJURY OR DEATH.
MSA, MSA The Safety Company, and the MSA The Safety Company Logo are Registered Trademarks
of MSA Technology, LLC in the U.S. and/or Other Countries. For all other trademarks see
https://us.msasafety.com/Trademarks
1000 Cranberry Woods Drive
Cranberry Township, PA 16066
USA
Phone 1-800-MSA-2222
Fax [phone]
For your local MSA contacts please go to our website www.MSAsafety.com
© MSA 2020. All rights reserved

MSA Rail Slider™ Anchorage Connector 3
Safety Regulations
US
1 Safety Regulations
1.1 Correct Use
The MSA Rail Slider Anchorage Connector is designed for use by one person working at an elevated
work level. The MSA Rail Slider Anchorage Connector links the user to a rail anchorage point. It allows
the worker to utilize existing rails as temporary anchors, without the need for drilling or permanently
attaching anchorages. It moves with the worker allowing for continuous tie off.
1.2 Compliance
The product may comply with:
• ANSI Z359.18, Type A and / or;
• OSHA requirements
See product label for specific compliance notifications.
Anchorage connectors labeled with ANSI Z359.18 have been tested in compliance with the require-
ments of ANSI/ASSE Z359.7.
NOTICE
ANSI compliance and testing covers only the hardware and does not extend to the anchorage and
substrate to which the anchorage connector is attached.
1.3 Usage Specifications
• The MSA Rail Slider Anchorage Connector is capable of withstanding a load of 5,000 lbf (22.2 kN)
without breaking or permanent deformation.
• The MSA Rail Slider Anchorage Connector is designed for the attachment of a single personal fall
arrest system.
• Weight: 6,0 lbf (2,9 kg)
• Materials of construction: SA516 Grade 70 Steel
• When used as part of a personal fall arrest system, fall arresting forces must not exceed 1,800 lbf
(8 kN).
• The Rail Slider Anchorage Connector is designed for use by one person. See instructions and
labels on each fall protection subsystem component to determine the limiting user weight capacity
of the system.

MSA Rail Slider™ Anchorage Connector 4
Safety Regulations
US
1.4 Safety and Precautionary Measures
WARNING!
DO NOT exceed the allowable free fall distance or exceed the maximum fall arrest forces as spec-
ified by governing standards or subsystem components.
The anchorage to which the MSA Rail Slider Anchorage Connector Strap is attached must be
rated in the direction of intended use. See sections 2.2 "Anchorages and Anchorage Connectors"
and 3 "Use" for details on anchorage strength and loading details.
When installing or removing the MSA Rail Slider Anchorage Connector Strap limit exposure to fall
hazards. A separate independent fall arrest system may be required.
Ensure that fall clearance is sufficient to meet governing standards or subsystem component
requirements.
Prevent swing falls and impact with objects in or adjacent to the fall path. Always remove obstruc-
tions below the work area to ensure a clear fall path. Keep work area free from debris, obstruc-
tions, trip hazards, spills or other hazard which could impair the safe operation of the fall protection
system. DO NOT use the MSA Rail Slider Anchorage Connector Strap unless a qualified person
has inspected the workplace and determined that identified hazards can neither be eliminated nor
exposures to them prevented.
Work directly under the anchorage/anchorage connector at all times. A full body harness is the
only acceptable body holding device that can be used in a fall arrest system.
DO NOT rely on feel or sound to verify proper snaphook or carabiner engagement. Ensure that
gate and keeper are closed before use.
If the MSA Rail Slider Anchorage Connector Strap is damaged or is subjected to fall arrest forces
or impact forces, it must be immediately removed from service and marked as "UNUSABLE" until
it has been destroyed.
DO NOT leave the MSA Rail Slider Anchorage Connector Strap installed in environments which
could cause damage or deterioration to the product. Refer to sections 4 "Care, Maintenance and
Storage" and 5 "Inspection" for care and inspection details. Do not leave unattended loads on the
MSA Rail Slider Anchorage Connector Strap.
DO NOT use where lanyard or shock absorber may be exposed to sharp or abrasive edges or
sheared, expanded metal, or frame cut steel. Sharp edges may cut a lanyard or shock absorber
during a fall. Cover all sharp or abrasive edges with padding or sheathing before working above
edge.
Chemical hazards, heat and corrosion may damage the MSA Rail Slider Anchorage Connector
Strap. More frequent inspections are required in these environments.
DO NOT use MSA Rail Slider Anchorage Connector Strap adjacent to moving machinery, elec-
trical hazards, or in the presence of excessive heat, open flame or molten metal.
DO NOT use fall arrest or rescue equipment in environments with temperatures greater than
130°F (34°C) or temperatures lower than -30°F (-34°C).
DO NOT use the MSA Rail Slider Anchorage Connector Strap near energized equipment or where
contact with high voltage power lines may occur. The metal cable may provide a path for electrical
current to flow, resulting in an electrical shock or electrocution.
Remove any surface contamination such as, but not limited to, concrete, stucco, roofing material,
etc that could accelerate cutting or abrading of attached components.
MSA Rail Slider Anchorage Connector Straps are to be designated and used solely for approved
applications.
Unauthorized alterations, relocations, or additions to the anchorage connector extension are not
permitted.

MSA Rail Slider™ Anchorage Connector 5
Safety Regulations
US
DO NOT alter this equipment or intentionally misuse it. DO NOT use fall protection equipment for
purposes other than those for which it was designed. DO NOT use fall protection equipment for
towing, hoisting or material handling.
If PPE is resold, it is essential that instructions for use, maintenance, and periodic examination are
provided in the language of destination.
DO NOT use MSA Fall Protection products if under the influence of drugs or alcohol.
MSA or persons or entities authorized in writing by the manufacturer, shall make all repairs to the
equipment. No unauthorized repairs and/or modifications are permitted.
RESCUE AND EVACUATION: The user must have a rescue plan and the means at hand to imple-
ment it. The plan must take into account the equipment and special training necessary to effect
prompt rescue under all foreseeable conditions. If the rescue be from a confined space, the provi-
sions of OSHA regulation 1910.146 and ANSI Z 117.1 must be taken into account. Although a
rescue plan and the means to implement it must always be in place, it is a good idea to provide
means for user evacuation without assistance of others. This will usually reduce the time to get to
a safe place and reduce or prevent the risk to rescuers.
Failure to follow these warnings can result in serious personal injury or death.
1.5 Usage Limitations
1.5.1 Environment
Chemical hazards, heat and corrosion may damage the PointGuard Anchorage Connector Strap. More
frequent inspections are required in these environments. Do not use in environments with tempera-
tures greater than 130°F (34°C). Use caution when working around electrical hazards, moving
machinery, abrasive surfaces, and sharp edges.
1.6 Training
Users of MSA Products must be familiar with the User Instructions and be trained by a competent
person in:
• workplace hazard identification, evaluation and control
• selection, inspection, use, storage and maintenance
• usage planning including calculation of free and total fall distance; maximum arresting force
• compatibility and selection of anchorage/anchorage connectors including connection to help
prevent accidental disengagement (rollout)
• proper lanyard/harness connection locations
• evacuation and rescue planning and implementation
• consequences of improper use
For Confined Space applications:
• See OSHA 29 CFR 1910.146 and ANSI Z117.1.
Periodically (at least annually) assess effectiveness of training and determine the need for retraining
or additional training. Contact MSA for training information.
