MyTouch VIM
2011 & up Ford MyTouch radios
Enables viewing of iPod video or A/V-in while in motion, as well as navigation destination input.
What’s in the Box
1. Wire harness
2. MyTouch VIM module
3. USB programming cable
1. 2. 3.
Operation
To enable/disable VIM operation, simply press the REAR DEFROST button 2 times
within 1 second.

Jack Randall
2 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
Installation
Required Tools:
1. Plastic Pry tool
2. 7mm nut driver
3. T20 Torx driver
Radio Removal
1. Using a plastic pry tool, gently pry up side trim panel that
runs the length of the radio bezel and center console.
2. Once the trim is removed, there are T20 Torx screws
holding the shifter plate and radio bezel in place. Remove
these screws.
3. Place the vehicle in Drive or lower. Pry up the shifter plate
and move back.
4. With the shifter plate moved, the radio bezel will easily
come out. Disconnect all wiring attached to the bezel.
5. Remove the (4) 7mm screws holding the screen in place.
6. Disconnect all wiring and set the screen aside.
7. All connections will be made at the 54-pin plug behind the
screen.
8. Using a pick tool, remove the shield to gain access to the
wiring. There is a clip on either side of the shield.
9. Locate the power, ground and CAN wires.
Screen harness
Pin 1
Battery
Pin 18
CAN Lo
Pin 19
CAN Hi
Pin 34
Ground
10. Find the power and ground connections and strip back the
insulation. With the wire exposed, twist the power
connections of the VIM to their corresponding wires on
the screen harness.
11. Find the CAN wires, and cut them in half. Connect the VIM
wiring to the corresponding wires on the screen harness
and make sure to observe proper wire directions. The wire
orientation is very important; if not correct the radio may
still work, but VIM may not work properly.
MyTouch VIM harness
Pin 18
CAN Lo - Vehicle Side
Pin 17
CAN Lo - Radio Side
Pin 9
CAN Hi - Vehicle Side
Pin 8
CAN Hi - Radio Side
ALL CONNECTIONS NEED TO BE SOLDERED!!!
12. After all connections are made, reassemble and test.
CAN Wires
CAN Hi- Pin 19 Blue/Gray
CAN Lo- Pin 18 Purple/Gray
Pin numbers
VIM connector
1. 12v Battery power –Yellow
2. N/C
3. N/C
4. N/C
5. N/C
6. N/C
7. N/C
8. CAN Hi –Radio Side –White/Blue
9. CAN Hi –Vehicle Side –White/Brown
10. Ground –Black
11. N/C
12. N/C
13. N/C
14. N/C
15. N/C
16. N/C
17. CAN Lo –Radio Side –Blue
18. CAN Lo –Vehicle Side –Brown
16
123456789
10111213141518 17
