Nav TV V2P-II User manual

BM
05/09/14
NTV-DOC179
1 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
Video RCA I/O Harness
NTV-HAR258
3950 NW 120th Ave, Coral Springs, FL 33065 TEL [phone] FAX [phone]
www.nav-tv.com i[email protected]m
V2P-II
NTV-KIT493
Overview
The V2P-II is NAV-TV’s Video to Power module. Whenever a video is present on either RCA, the
attached red wire will output 12v (+). This would be helpful in various situations:
Powering on an aftermarket headrest/flip-down monitor when a video source is present
Activating the NAV-TV AVSW to automatically switch to the active video source in a
multi-AV device setup
Automatically displaying a trailer camera instead of the factory rear cam, when a trailer
is physically connected with no external switches required
Kit Contents
V2P Board
NTV-ASY177

BM
05/09/14
NTV-DOC179
2 | P a g e
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
Connector pin outs
Installation Overview
Black: Ground (-)
Yellow: 12v (+) Ignition (or accessory)
Red: Video triggered output (12v)
Female RCA: Supply video signal
Male RCA: Connect to monitor
PIN #
Description
Color
2
Constant 12v (+) input
Yellow
3
12v (+) output
Red
6
Ground (-) & RCA Shields
Black
7
RCA Video Signals
White
Wire Side
12v (+)
IGN or ACC
input
