Emergency Services and Safety Precautions PL-1
Emergency Services and Safety Precautions
Emergency services
To make an emergency call in any country
1Ensure that your e606 is on and in service.
2Press C to return to the standby screen if needed.
3Press 112 (or 999 within UK or 000 in Australia) followed by the Start key. (When the USIM card is not
inserted or when the dial lock function is on, just press the SK1 (Emrgncy) key.)
4Follow instructions received and do not end call until told to do so.
Tell the operator which service you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain
Rescue Service. Give your position and, if possible, remain stationary to maintain contact.
The 112 emergency number service is available on every digital network service whilst in the UK an
alternative is 999 and in Australia 000. Note that these can only be used with a valid USIM.
Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed.
General care
A handset contains delicate electronic circuitry, magnets, and battery systems. You should treat it with care
and give particular attention to the following points:
•Do not allow the handset or its accessories to come into contact with liquids or moisture at any time.
•Do not place anything in the folded handset.
•Do not paint the handset.
•Do not drop or subject the handset to rough treatment.
•Do not place the handset alongside computer disks, credit cards, travel cards and other magnetic media.
The information contained on disks or cards may be affected by the handset.
•Do not leave the handset or the battery in places where the temperature could exceed 60 ºC, e.g. on a
car dashboard or a window sill, behind glass in direct sunlight, etc.
•Do not remove the handset’s battery while the handset is switched on.
•Take care not to allow metal objects, such as coins or key rings to contact or short-circuit the battery
terminals.

PL-2 Emergency Services and Safety Precautions
•Do not dispose of battery packs in a fire. The handset’s Li-ION batteries may be safely disposed of at a
Li-ION recycling point. For more specific battery and power supply information, see pages 6 and 7.
•Do not put the handset’s battery in your mouth, as battery electrolytes may be toxic if swallowed.
•Do not attempt to dismantle the handset or any of its accessories.
•This equipment is fitted with an internal battery that can only be replaced by a qualified service engineer.
There is a risk of explosion if the battery is replaced with an incorrect battery type. Dispose of the used
battery in accordance with the manufacturer’s instructions.
•Do not put battery into a microwave oven, dryer, or high-pressure container.
•Do not contact battery directly to an electric outlet or cigarette lighter charger.
•Do not pierce battery with a sharp object such as a needle.
•Do not hit with a hammer, step on, throw or drop to cause strong shock.
•When the battery is thrown away, be sure it is non-conducting by applying vinyl tape to the (+) and (-)
terminals.
•Do not immerse in water.
•Do not disassemble or modify the battery.
•Do not solder a battery directly.
•Stop using the battery if abnormal heat, odor, discolouration, deformation, or abnormal condition is
detected during use, charge, or storage.
•Do not use with a damaged or deformed battery.
In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes or
skin. If the leakage does come into contact with the eyes or skin, please flush thoroughly in clean water
and consult with a doctor.
•Remove the battery whose life cycle has expired from equipment immediately.
•The earpiece may become warm during normal use. Also, the handset itself may become warm while the
battery is being charged.
•When a handset is set to Vibration mode, the vibration can sometimes cause the e606 handset to move.
Be careful not to place the handset near heat sources (such as a heater) or too close to the edge of the
table.
•Use a damp or anti-static cloth to clean the handset. Do not use a dry cloth or electrostatically charged
cloth. Do not use chemical or abrasive cleaners as these could damage the case.
•Remember to recycle: the cardboard packing supplied with this handset is ideal for recycling.
•Remember to make backup copies of all important data on your handset.

Emergency Services and Safety Precautions PL-3
•Third party equipment
The use of third party equipment, cables or accessories, not made or authorised by NEC, may invalidate
the warranty of your cellphone and also adversely affect the phone’s safety/operation.
Aircraft safety
•Switch off your handset when inside or near aircraft. The use of handsets in aircraft is illegal, as it may be
dangerous to the operation of the aircraft and it may disrupt the aircraft communication system. Failure to
observe this instruction may lead to suspension or denial of the offender’s handset service, or legal
action, or both.
•Do not use the handset on the ground without the permission of the ground staff.
General safety
•Observe "Turn off 2-way radio" signs, such as those near petrol stations, chemicals or explosives and
turn off handset/device.
•If you have a heart condition, be careful with the settings of call vibration or tone volume.
•Do not allow children to play with the handset, charger or batteries.
•Do not use the handset where blasting is in progress.
•The operation of some medical electronic devices, such as hearing aids and pacemakers, may be
affected if a handset is used next to them. Observe any warning signs and the manufacturer’s
recommendations.
Road safety
•You MUST exercise proper control of your vehicle at all times. Give your full attention to driving.
•Observe all of the recommendations contained in your local traffic safety documentation.
•Pull off the road and park before making or answering a call, if driving conditions so require.
•You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an
emergency.
•Switch off your handset at a refuelling point, such as a petrol station, even if you are not refuelling your
own car.
•Do not store or carry flammable or explosive materials in the same compartment as a radio transmitter.

PL-4 Emergency Services and Safety Precautions
•Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not
normally affected by radio transmissions. The manufacturer of such equipment can advise if it is
adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio
transmissions consult your dealer and do not switch on the handset until it has been checked by qualified
approved installers.
•Check if local laws and/or regulations restrict the use of handsets while driving.
Vehicles equipped with an air bag
An air bag inflates with great force. Do not place objects, including either installed or portable wireless
equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.
Third party equipment
The use of third party equipment, cables or accessories, not made or authorised by NEC, may invalidate the
warranty of your handset and also adversely affect the handset’s operation. For example, use only the NEC
mains cable supplied with the AC charger.
Service
The handset, batteries and charger contain no user-serviceable parts. We recommend that your NEC
handset be serviced or repaired by an NEC authorised service centre. Please contact 3or NEC for advice.
Efficient use
The handset has the internal antenna. For optimum performance with minimum power consumption, please
do not cover the internal antenna area with your hand. Covering the internal antenna affects call quality, may
cause the handset to operate at higher power level than needed, and may shorten talk and standby times.
Radio frequency energy
Your handset is a low-power radio transmitter and receiver. When it is turned on, it intermittently receives and
transmits radio frequency (RF) energy (radio waves). The system that handles the call controls the power
level at which the handset transmits.

Emergency Services and Safety Precautions PL-5
Exposure to radio frequency energy
The handset is designed not to exceed the limits for exposure to RF energy set by national authorities and
international health agencies.* These limits are part of comprehensive guidelines and establish permitted
levels of radio wave exposure for the general population. The guidelines were developed by independent
scientific organizations such as ICNIRP (International Commission on Non-ionizing Radiation Protection)
through periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health, and to account for any variations
in measurements.
*Examples of radio frequency exposure guidelines and standards that the handset is designed to conform to:
•ICNIRP, "Guidelines for limiting exposure to time-varying electric, magnetic, and electromagnetic fields
(up to 300 G Hz)-International Commission on Non-Ionizing Radiation Protection (ICNIRP). Health
Physics, vol.74. pp, 494-522, April 1998.
•99/519/EC, EU Council Recommendation on the limitation of exposure to the general public to
electromagnetic fields 0 Hz-300 GHz. Official Journal of the European Communities, July 12, 1999.
•ANSI/IEEE C95.1-1992. "Safety levels with respect to human exposure to radio frequency
electromagnetic fields, 3kHz to 300 GHz". The Institute of Electrical and Electronics Engineers Inc., New
York, 1991.
•FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications Commission (FCC),
August 1996.
•Radiocommunications (Electromagnetic Radiation Human Exposure) Standard 1999, Australian
Communications Authority (ACA), May 1999.
Declaration of conformity
We declare under our sole responsibility that the product(s) detailed in this manual, and in combination with
our accessories, conform with the essential requirements of European Union Directive 1999/5/EC Radio and
Telecommunications Terminal Equipment Directive requirements 3.1(a), 3.1(b), 3.2.
Con la presente NEC dichiara, sotto la propria responsabilità, che il prodotto descritto in questo manuale (e
in combinazione con i propri accessori), è conforme ai requisiti essenziali e alle disposizioni pertinenti
stabilite dalla direttiva radio 1999/5/CE e ai requisiti 3.1(a), 3.1(b), 3.2 stabiliti dalle direttive per i terminali di
telecomunicazioni.
Nous déclarons sous notre unique responsabilité que le(s) produit(s) présentés dans ce manuel et leurs
accessoires sont conformes aux conditions de la Directive de l’Union Européenne 1999/5/EC sur les
équipements de terminaison radioélectriques et de télécommunications, 3.1(a), 3.1(b), 3.2.

PL-6 Emergency Services and Safety Precautions
Wir erklären in alleiniger Verantwortung, dass die in diesem Handbuch aufgeführten Produkte allein und in
Verbindung mit den von uns hergestellten Zubehörerzeugnissen den grundlegenden Vorschriften und
Bestimmungen der EG-Richtlinie 1999/5/EC, Funkund Telekommunikationsendgeräte, Abschnitte 3.1(a),
3.1(b) und 3.2 entsprechen.
Vi tar ansvar för att produkten/produkterna som beskrivs i manualen, också i kombination med våra tillbehör,
överenstämmer med de väsentliga krav som beskrivs i 3.1(a), 3.1(b), 3.2 i Rådets direktiv om radioutrustning
och teleterminalutrustning (1999/5/EG).
A copy of the “Declaration of Conformity” certificate can be found on www.neceurope.com.
Bluetooth™
•This product complies with Bluetooth™ Specification Ver1.1. It can establish a dialup connection using
Bluetooth™ technology.
•In countries where the use of Bluetooth wireless technology is not allowed, you must ensure that the
Bluetooth™ function is set to OFF.
•Bluetooth™ can be used within the temperature range of -10 to 40 ºC. (This product can be used within a
range of -10 to 55 ºC.)
•Use of Bluetooth™ technology is prohibited on board aeroplanes.
•Bluetooth is a trademark owned by its proprietor and used by NEC under licence.
•Bluetooth™ can be used within a range of approximately 10m. Because of the nature of the radio wave,
this range varies depending on location and the receiver.
•Note that when the settings of this product are reset, Bluetooth™ registration information is also deleted.
•This product can communicate with a Windows® PC/PDA that supports Dialup-Networking profile.
•Note that the handset must be switched on to use Bluetooth™. Before use always ensure that the use of
a handset is not prohibited and will not cause interference or danger.

Contents -CL-1-
Contents
Emergency Services and Making and Receiving a Video Call ................... 18
Safety Precautions ....................................... PL-1 To Make a Video Call to
What’s e606? ......................................................1 a Video Capable Handset ............................. 18
Views, Keys, and Display of e606 .......................1 To Make a Video Call to a PC with Webcam . 19
Setup ...................................................................4 To Receive a Video Call ................................. 19
USIM Card ...........................................................4 Settings During a Video Call .............................21
Battery .................................................................6 Showing and Hiding Your CLI ........................... 22
Charging ..............................................................6 Text Entry ......................................................... 23
Low Battery Alarm ...............................................7 Multitap Text (ABC) Input .................................. 24
Power On/Off ......................................................8 T9® Text Input ................................................... 24
Power On/Off .......................................................8 Numeric Input .................................................... 25
Entering PIN Code ...............................................8 Symbol Input ..................................................... 26
Setting Clock .......................................................9 Text edit ............................................................. 26
Making and Receiving Calls .............................9 Display Information ............................................ 29
Making a Voice Call ...........................................10 Contacts ........................................................... 29
Receiving a Voice Call .......................................12 Contact Entries .................................................. 29
During a Voice Call ............................................15 Contacts Menus ................................................ 32
To Make a Second Call ...................................15 Browser ............................................................ 37
To Receive a Second Call...............................16 Browser Menus ................................................. 37
To Switch to a Grouptalk .................................16 Basic Operations ............................................... 41
Other Possible Operations During a Call ...........17 Advanced Features ......................................... 43

-CL-2- Contents
Video Call ..........................................................43 Phone ................................................................ 81
Photo/Video Camera .........................................44 VT Settings ........................................................ 82
Multi-call/Multi-task ............................................44 Profile ................................................................ 83
High-Speed Data Communications ...................45 Time .................................................................. 84
Other Features of e606 .....................................48 Display ............................................................... 84
Messaging ......................................................48 Clock ................................................................ 85
Java™ Application .........................................48 Security ............................................................ 86
Images ...........................................................48 Services ............................................................ 87
Video/Audio Player ........................................49 Provisioning ....................................................... 90
Data Transfer to/from a PC ............................49 Network ............................................................ 91
How to Use Menu Function .............................50 Bluetooth™ ........................................................ 92
Menu Functions Operations ..............................51 Other ................................................................. 93
Menu Functions List ..........................................55 Multimedia ........................................................ 94
Service (SAT) ....................................................59 Video ................................................................. 95
External Connect .............................................60 Image .............................................................. 100
Bluetooth™ ........................................................60 Audio Player ..................................................... 103
USB ...................................................................62 Voice Recorder ................................................ 106
Message ...........................................................63 Accessories ................................................... 106
Message Menus .................................................64 Calendar .......................................................... 106
Writing and Sending a New Message ................66 ToDo .................................................................111
Receiving and Reading a Message ...................71 Alarm Clock ..................................................... 112
Replying and Forwarding ...................................75 Calculator ........................................................113
Java™ ...............................................................78 Currency Calculation ....................................... 114
Settings ............................................................80 Voice Notes .....................................................115

Contents -CL-3-
Text Notes ........................................................ 116 Used Memory .................................................. 119
User Data ........................................................ 117 Data Transfer ................................................. 120
Contacts .......................................................... 117 To/From USIM ................................................. 120
Owner Info ....................................................... 117 To/From PC ..................................................... 123
Calls Received ................................................. 118 Shortcut Keys ................................................ 124
Calls Made ....................................................... 118 Index ............................................................... 130
Ringtune .......................................................... 118

What’s e606? -1-
What’s e606?
The e606 combines a wide range of features into a technologically advanced handset, capable of operating
in both UMTS (Universal Mobile Telecommunication System), also known as 3G, as well as GSM (Global
System for Mobile Communications) or 2G.
3G will allow much greater data speeds than 2G networks and will enable you to make video calls, send
multimedia messages and view photos and videos and much more.
Views, Keys, and Display of e606
Views
Camera (Back/Away from me)
Stereo headset connector
I/O connector for USB cable or charger
LED indicator

-2- What’s e606?
Keys
Triangle key
End (On-Off) key
Keypad characters
Internal antenna (0-9, Qand #)
SK2 (Softkey 2) key
4-Way navigation
Display (Refer to the next page.)
Enter key
Camera (Front/Towards me)
SK1 (Softkey 1) key
MENU key
C (Clear) key
Start key
(Up/Down/Left/Right) key Microphone

What’s e606? -3-
Display
Battery level
Vibrate on
Call diverting
Voice message
Text message/Multimedia message Signal strength
2G/3G roaming mode
Packet switched connect
Circuit switched connect
External connect
Multitask
SK1 key SK2 key
4-Way navigation (Up/Down/Left/Right)** Enter key**
Profile*
Missed call/
Date
Local time
Remote time
Operator name
Bluetooth™ is connected.
USB is connected.
Area setting mode
** The 4-Way navigation indicator and the Enter key indicator are replaced with (shutter icon)
or (dial lock indicator) that indicates whether the video capture, or image capture function is on
or a dial lock function is on.
Schedule or Alarm on
Service provider name
* Profile indicates the following handset operation modes: normal, meeting, pocket, and car. Pressing
and holding the Qkey will allow you to set a profile. (Refer to Profile on page 83.)

-4- Setup
Setup
Before you use your handset you will need to carry out the following actions:
•Valid USIM (Universal Subscriber Identity Module) card inserted
•Battery charged
•Set the date and time
This section will guide you through this step by step.
USIM Card
When you become a subscriber to 3, you are issued a USIM card with a security code or PIN (Personal
Identification Number). The USIM card contains your personal subscriber data and must be inserted into your
handset.
If the USIM card is removed then the handset becomes unusable until a valid USIM is inserted. The holder
for the USIM card is located underneath the battery.
Always disconnect the charger and other accessories from your handset before inserting and removing
your USIM card.
To Insert the USIM Card
1Ensure that the power is off. If the power is on, press and hold the End (On-Off) key until power is off.
2Remove the battery. (Refer to the illustration on the next page.)
3Slide the USIM card into the USIM card holder.
4Replace the battery.
To Remove the USIM Card
1Ensure that the power is off. If the power is on, press and hold the End (On-Off) key until power is off.
2Remove the battery. (Refer to the illustration on the next page.)
3Slide the USIM card out of the USIM card holder.

Setup -5-
.
1Remove the battery. 2Slide and release the USIM card holder lock.
3Open the USIM card holder. 4Insert the USIM card into the USIM card holder.
5Slide and lock the USIM card holder.

-6- Setup
Battery
To Insert the Battery
Place the bottom of the battery into position and then push down on the upper section of the battery until it
clicks into place.
To Remove the Battery
1Ensure that your handset is switched off. If the handset is switched on, press and hold the End (On-
Off) key until power is off.
2Push up the release catch at the top of the battery and lift the battery away from the handset.
The battery is not fully charged when you buy your handset but there may be enough power in the battery to
turn the handset on. A battery that has not been used for a long period of time needs to be completely
discharged and then recharged two or three times before reaching full capacity. Charge the battery by
following the procedure indicated below.
The battery can also be charged whenever you wish without affecting the performance of the handset.
The e606 automatically switches off if the battery voltage is too low.
Batteries have a life cycle. If the time that the battery powers equipment becomes much shorter than
usual, the battery life is coming to an end. Replace the battery with a new one of the same type.
When not using the battery for a long period, remove it from the e606 and store in a place with low
humidity and low temperature.
Charging
Charge the battery by using the charger supplied with your handset. When the battery is fully charged, a full
battery power level icon will be displayed. Refer to Low Battery Alarm on the next page for details.
To Charge the Battery Using the Charger
1Make sure that the battery is attached to your handset.
2Connect the charger plug to the e606 I/O connector. See the diagram on the next page.
3Plug the charger into a power socket. The red LED indicator on the outside of your e606 will light up
when charging is in progress and go off when charging is completed.
4After charging the battery, tilt the charger plug upward and pull it away from the e606 I/O connector.

Setup -7-
Even if the handset remains connected to the charger, battery residual capacity may decrease when the
handset is used.
The battery must be charged in the room temperatures between 0°C and 45°C. Ensure that your handset
is switched off. If the handset temperature is high, wait until it returns to a normal temperature.
The recommended battery charge time is approximately 2 hours.
Stop charging the battery if charging is not completed within 5 hours.
When charging the battery, always fold and close the handset. If the handset is left open while charging,
it may take longer to complete the charge.
Low Battery Alarm
The battery power level (3 levels) is indicated by the following icons:
When the battery runs out, the following image will blink on the display. A low-power warning alarm sound will
come on for approximately 10 seconds. Press the End key to turn off the alarm. After approximately one
minute, the power will be turned off.
Low Battery Medium Battery Full Battery

-8- Power On/Off
During a call, the image and a discontinuing alarm sound indicate low-power. After approximately 20
seconds the call will be disconnected.
When the ringing volume level is set to Level 0 (silent), the low-power warning alarm will turn on at Level 1
(the softest level). When the volume level is between 1 and 6, it will come on at Level 3 (medium level).
Date and Time
When using your e606 for the first time, please remember to set the date and time. This will ensure that all of
your e606 functions are accessible. For further instructions, refer to Setting Clock on page 9 and Date &
Time on page 85.
Power On/Off
You can use your handset after set up of the e606 is completed. This section describes how to turn the power
on/off, how to enter the PIN code, and how to set the clock to use the e606.
Power On/Off
You can power on or off on the e606. Proceed as described below.
To Power On
1Ensure that your USIM card is in your e606 and that the battery is charged.
2Press and hold the End (On-Off) key until power is on.
The term “press and hold” is equivalent to a key press time of approximately 2 seconds.
To Power Off
In standby mode, press and hold the End (On-Off) key until power is off. There may be some delay while the
handset powers down. Do not repower the handset during this time.
Entering PIN Code
You can enter your PIN code. Proceed as described below.
To Enter PIN
1Ensure that your USIM card is in your e606 and that the battery is charged.
2Press and hold the End (On-Off) key until power is on.
3If Enter PIN is displayed, enter your PIN.

Making and Receiving Calls -9-
If you make a mistake while entering your PIN, erase the wrong number by pressing the Ckey. The code
you enter appears as asterisks (Q).
4Press the SK1 (OK) key or Enter key.
When connecting to the network, the name 3will appear. If you are connecting onto another network,
the name of another operator will appear.
If you enter your PIN incorrectly three times in a row, the USIM card will be locked. You can unlock it by
using your Personal Unlock Key (PUK). Please contact 3for your PUK code.
Power Saver
The power saver function turns the screen off when the handset is left without any operation for a certain
period of time. By pressing any key, you can turn the screen on.
Setting Clock
When using your e606 for the first time you will be prompted to set the current date and time.
To Set Clock
1Press the MENU key, select the Settings icon, select Clock, and press the SK1 (Select) key or Enter
key.
2Enter the current date and time. Refer to Date & Time on page 85 for details.
You cannot use some functions (e.g. date and time display on the standby screen, calendar display,
schedule setting, ToDo setting, alarm setting, etc.) without setting the clock. Also, if the clock is not set,
the date and time are not displayed for the messages in Inbox/Sent Items/Draft.
Making and Receiving Calls
To make and receive calls, e606 must first be turned on. When the power turns on and the PIN number is
entered, e606 automatically searches for the network registered in the USIM card. When the network signal
is detected by e606, it is indicated by the network name and the radio signal strength icon on the display
screen.
When the stereo headset is plugged in, you can make/receive calls hands-free, using the earphones and
the microphone attached.
When using the stereo headset, you can start/end a voice call by the switch placed on the microphone.
When the stereo headset is plugged in, you cannot end a voice call by closing the handset.
Pressing the Ckey while receiving a call will turn the ringtune off.
