New Holland MegaCutter 512 User manual

Part number 47937741
1st edition English
February 2016
SERVICE MANUAL
MegaCutter™512
MegaCutter™530
Tractor Mounted
Disc Mower-Conditioner
PIN YFZDG0007 and above
Printedin U.S.A.
© 2016 CNH Industrial America LLC. All Rights Reserved.
NewHolland is a trademark registered in the United States and many other countries,
owned by or licensed to CNH Industrial N.V., its subsidiaries or affiliates.

SERVICEMANUAL
MegaCutter™512
MegaCutter™530[YFZDG0007-]
4793774110/02/2016
EN
Find manuals at https://best-manuals.com

Contents
INTRODUCTION
Maingearboxanddrive...............................................................14
[14.100]Maingearboxanddrive............................................................14.1
PowerTake-Off(PTO).................................................................31
[31.201]PowerTake-Off(PTO)driveshaft..................................................31.1
[31.214]SecondaryPowerTake-Off(PTO).................................................31.2
[31.225]Clutches............................................................................31.3
Hydraulicsystems.......................................................................35
[35.000]Hydraulicsystems..................................................................35.1
[35.100]Mainliftsystem.....................................................................35.2
[35.300]Reservoir,cooler,andlters........................................................35.3
[35.359]Maincontrolvalve..................................................................35.4
[35.410]Headerorattachmentheightsystem..............................................35.5
[35.947]Framepositioningswinging........................................................35.6
Framesandballasting.................................................................39
[39.110]Drawbarandhitchassembly.......................................................39.1
Electricalsystems.......................................................................55
[55.000]Electricalsystem...................................................................55.1
[55.036]Hydraulicsystemcontrol...........................................................55.2
[55.048]RearPowerTake-Off(PTO)controlsystem.......................................55.3
[55.100]Harnessesandconnectors.........................................................55.4
[55.404]Externallighting....................................................................55.5
[55.860]Framepositioningsystem..........................................................55.6
Attachments/Headers..................................................................58
[58.110]Attachment/Headercuttingmechanism............................................58.1
[58.130]Attachment/Headerframe..........................................................58.2
4793774110/02/2016
Find manuals at https://best-manuals.com

Productfeeding..........................................................................60
[60.630]Flailconditioning...................................................................60.1
Platform,cab,bodywork,anddecals.............................................90
[90.116]Fendersandguards................................................................90.1
[90.119]Guardsandshields.................................................................90.2
4793774110/02/2016
Find manuals at https://best-manuals.com

4793774110/02/2016
Find manuals at https://best-manuals.com

INTRODUCTION
4793774110/02/2016
1
Find manuals at https://best-manuals.com

Contents
INTRODUCTION
Foreword-Importantnoticeregardingequipmentservicing....................................3
Safetyrules.....................................................................................4
Safetyrules–Personalsafety..................................................................5
Safetyrules-Ecologyandtheenvironment..................................................12
Torque-Nominaltighteningtorquesfornormalassembly....................................13
Basicinstructions-Shopandassembly......................................................18
Generalspecication–MegaCutter™512(*)................................................20
Generalspecication–MegaCutter™530(*)................................................21
Capacities.....................................................................................22
Productidentication–MegaCutter™512(*)................................................23
Productidentication–Machineorientation–MegaCutter™512(*)........................24
Productidentication–MegaCutter™530(*)................................................27
Productidentication–Machineorientation–MegaCutter™530(*)........................28
(*)Seecontentforspecicmodels
4793774110/02/2016
2
Find manuals at https://best-manuals.com

INTRODUCTION
Foreword-Importantnoticeregardingequipmentservicing
Allrepairandmaintenanceworklistedinthismanualmustbecarriedoutonlybyqualieddealershippersonnel,
strictlycomplyingwiththeinstructionsgiven,andusing,wheneverpossible,thespecialtools.
Anyonewhoperformsrepairandmaintenanceoperationswithoutcomplyingwiththeproceduresprovidedherein
shallberesponsibleforanysubsequentdamages.
Themanufacturerandalltheorganizationsofitsdistributionchain,including-withoutlimitation-national,regional,or
localdealers,rejectanyresponsibilityfordamagescausedbypartsand/orcomponentsnotapprovedbythemanu-
facturer,includingthoseusedfortheservicingorrepairoftheproductmanufacturedormarketedbythemanufacturer.
Inanycase,nowarrantyisgivenorattributedontheproductmanufacturedormarketedbythemanufacturerincase
ofdamagescausedbypartsand/orcomponentsnotapprovedbythemanufacturer.
Themanufacturerreservestherighttomakeimprovementsindesignandchangesinspecicationsatanytimewithout
noticeandwithoutincurringanyobligationtoinstallthemonunitspreviouslysold.Specications,descriptions,and
illustrativematerialhereinareasaccurateasknownattimeofpublicationbutaresubjecttochangewithoutnotice.
Incaseofquestions,refertoyourNEWHOLLANDSalesandServiceNetworks.
4793774110/02/2016
3
Find manuals at https://best-manuals.com

INTRODUCTION
Safetyrules
Personalsafety
Thisisthesafetyalertsymbol.Itisusedtoalertyoutopotentialpersonalinjuryhazards.Obeyall
safetymessagesthatfollowthissymboltoavoidpossibledeathorinjury.
ThroughoutthismanualyouwillndthesignalwordsDANGER,WARNING,andCAUTIONfollowedbyspecialin-
structions.Theseprecautionsareintendedforthepersonalsafetyofyouandthoseworkingwithyou.
Readandunderstandallthesafetymessagesinthismanualbeforeyouoperateorservicethemachine.
DANGERindicatesahazardoussituationthat,ifnotavoided,willresultindeathorseriousinjury.
WARNINGindicatesahazardoussituationthat,ifnotavoided,couldresultindeathorseriousinjury.
CAUTIONindicatesahazardoussituationthat,ifnotavoided,couldresultinminorormoderateinjury.
FAILURETOFOLLOWDANGER,WARNING,ANDCAUTIONMESSAGESCOULDRESULT
INDEATHORSERIOUSINJURY.
Machinesafety
NOTICE:Noticeindicatesasituationthat,ifnotavoided,couldresultinmachineorpropertydamage.
ThroughoutthismanualyouwillndthesignalwordNoticefollowedbyspecialinstructionstopreventmachineor
propertydamage.ThewordNoticeisusedtoaddresspracticesnotrelatedtopersonalsafety.
Information
NOTE:Noteindicatesadditionalinformationthatclariessteps,procedures,orotherinformationinthismanual.
ThroughoutthismanualyouwillndthewordNotefollowedbyadditionalinformationaboutastep,procedure,or
otherinformationinthemanual.ThewordNoteisnotintendedtoaddresspersonalsafetyorpropertydamage.
4793774110/02/2016
4
Find manuals at https://best-manuals.com

INTRODUCTION
Safetyrules–Personalsafety
Generalsafetyrules
Usecautionwhenyouoperatethemachineonslopes.Raisedequipment,fulltanksandotherloadswillchangethe
centerofgravityofthemachine.Themachinecantiporrolloverwhennearditchesandembankmentsoruneven
surfaces.
Neverpermitanyoneotherthantheoperatortorideonthemachine.
Neveroperatethemachineundertheinuenceofalcoholordrugs,orwhileyouareotherwiseimpaired.
Whendiggingorusingground-engagingattachments,beawareofburiedcables.Contactlocalutilitiestodetermine
thelocationsofservices.
Payattentiontooverheadpowerlinesandhangingobstacles.Highvoltagelinesmayrequiresignicantclearance
forsafety.
Hydraulicoilordieselfuelleakingunderpressurecanpenetratetheskin,causingseriousinjuryorinfection.
•DONOTuseyourhandtocheckforleaks.Useapieceofcardboardorpaper.
•Stoptheengine,removethekey,andrelievethepressurebeforeyouconnectordisconnectuidlines.
•Makesurethatallcomponentsareingoodcondition.Tightenallconnectionsbeforeyoustarttheengineorpres-
surizethesystem.
•Ifhydraulicuidordieselfuelpenetratestheskin,seekmedicalattentionimmediately.
•Continuouslongtermcontactwithhydraulicuidmaycauseskincancer.Avoidlongtermcontactandwashthe
skinpromptlywithsoapandwater.
Keepclearofmovingparts.Looseclothing,jewelry,watches,longhair,andotherlooseorhangingitemscanentangle
inmovingparts.
Wearprotectiveequipmentwhenappropriate.
DONOTattempttoremovematerialfromanypartofthemachinewhilethemachineisoperating,anyofthebaler
componentsareinmotion,orwhilethetractorengineisrunning.
Beforeyouoperatethemachine,installandsecurelycloseallofthemachineguardsandshields.Makesurethatall
theguardsandthatalltheshieldsareingoodcondition.Neveroperatethemachinewithshieldsopenorremoved.
Alwaysclosetheaccessdoorsand/oraccesspanelsbeforeoperatingthemachine.
Makesurethatnobystandersorpetsarewithinthemachineoperatingarea.Themachineand/ormovingcomponent
onthemachinecanstrikeorcrushbystandersorpets.DONOTallowanyonetoentertheworkarea.
Dirtyorslipperysteps,ladders,walkways,andplatformscancausefalls.Makesurethesesurfacesremaincleanand
clearofdebris.
Apersonorpetwithintheoperatingareaofamachinecanbestruckorcrushedbythemachineoritsequipment.DO
NOTallowanyonetoentertheworkarea.
Raisedequipmentand/orloadscanfallunexpectedlyandcrushpersonsunderneath.Neverallowanyonetoenter
theareaunderneathraisedequipmentduringoperation.
Alwayskeepwindows,mirrors,alllighting,andSlow-MovingVehicle(SMV)emblemcleantoprovidethebestpossible
visibilitywhileyouoperatethemachine.
Operatecontrolsonlywhenseatedintheoperator’sseat,exceptforthosecontrolsexpresslyintendedforusefrom
otherlocations.
4793774110/02/2016
5
Find manuals at https://best-manuals.com

INTRODUCTION
Beforeyouleavethemachine:
1.Parkthemachineonarm,levelsurface.
2.Putallcontrolsinneutralorparklockposition.
3.Engagetheparkingbrake.Usewheelchocksifrequired.
4.Lowerallhydraulicequipmentsuchasimplementsandheaders.
5.Turnofftheengineandremovethekey.
WARNING
Somecomponentsmaycontinuetorundownafterdisengagingdrivesystems.
Makesurealldrivesystemsarefullydisengaged.
Failuretocomplycouldresultindeathorseriousinjury.W0113A
When,duetoexceptionalcircumstances,youwoulddecidetokeeptheenginerunningafteryouleavethe
operator’sstation,thenyoumustfollowtheseprecautions:
1.Bringtheenginetolowidlespeed.
2.Disengagealldrivesystems.
3.Shiftthetransmissionintoneutral.
4.Applytheparkingbrake.
Hydraulicsystemsafety
Hydraulicoilordieselfuelleakingunderpressurecanpenetratetheskin,causingseriousinjuryorinfection.
•DONOTuseyourhandtocheckforleaks.Useapieceofcardboardorpaper.
•Stopengine,removekeyandrelievethepressurebeforeconnectingordisconnectinguidlines.
•Makesureallcomponentsareingoodconditionandtightenallconnectionsbeforestartingtheengineorpressur-
izingthesystem.
•Ifhydraulicuidordieselfuelpenetratestheskin,seekmedicalattentionimmediately.
•Continuouslong-termcontactwithhydraulicuidmaycauseskincancer.Avoidlongtermcontactandwashthe
skinpromptlywithsoapandwater.
Thehydraulichosesandttingsonyourmachinemeetengineeringspecicationsfortheparticularfunction.When
replacingdamaged,blownorwornhosesorttings,useonlymanufacturerauthorizedserviceparts.
Careinhydraulichoseinstallationisamust:
•Makesurepressureisrelievedbeforestartinginstallationprocedure.
•DONOTkinkortwistahose,failuremayoccur.
•Properlyroutethehose.
•Removeairfromthehydraulicsystemafterinstallinganyhydrauliccomponent.
Periodicallycheckhydraulicsystemforleaksordamage.checkfor:
•Leaksathosettingorinhose.
•Damagedhosesand/orttings.
•Kinked,crushed,attened,hardblistered,heatcracked,charred,twisted,softorloosecoveredhoses.
•Corrodedordamagedttings.
•Leakingports.
•Excessivedirtanddebrisaroundhosesand/orttings.
•Damagedormissinghoseretainingclamps,guards,shields,etc.
DONOTstandonoruseahoseasastep.DONOTpullorapplyexternalforcestothehose.Thehosemayfailand
causeinjury.
4793774110/02/2016
6

INTRODUCTION
Keepallpersonsawayfromtheworkingarea.Mechanismscontrolledbyuidpowercanbecomehazardousifahose
fails.Liftedmechanismscanfalltotheground,machinesteeringmayfail,etc.
Stayclearofapressurizedhoseassemblythathasblownapart.Hosettingscanbethrownoffathighspeedanda
loosehosecanwhiparoundwithgreatforce.
Hydraulicuidcanreachhightemperatures.Allowuidtocoolbeforeservicingthesystem.
Escapinguidunderpressuremayformamistornespraywhichcanashorexplodeuponcontactwithanignition
source
Vibrationcanreducehoseservicelife.Makesureallretainingclampsand/ordevicesaresecured.
Environmentalconditionscancausehoseandttingstodeteriorate.Inspecthydraulichosesperiodically.Replace
wornordamagedhosesandttings.
Generalmaintenancesafety
Keeptheareausedforservicingthemachinecleananddry.Cleanupspilleduids.
Onlyservicethemachineonarmlevelsurface.
Installguardsandshieldsafteryouservicethemachine.
Closeallaccessdoorsandinstallallpanelsafterservicingthemachine.
Donotattempttoclean,lubricate,clearobstructions,ormakeadjustmentstothemachinewhileitisinmotionorwhile
theengineisrunning.
Alwaysmakesurethatworkingareaisclearoftools,parts,otherpersonsandpetsbeforeyoustartoperatingthe
machine.
Unsupportedhydrauliccylinderscanlosepressureanddroptheequipment,causingacrushinghazard.Donotleave
equipmentinaraisedpositionwhileparkedorduringservice,unlesstheequipmentissecurelysupported.
Jackorliftthemachineonlyatjackorliftpointsindicatedinthisoperator’smanual.
Incorrecttowingprocedurescancauseaccidents.Whentowingadisabledmachinefollowthetowingproceduresin
thisoperator’smanual.Useonlyrigidtowbars.
Stoptheengine,removethekey,andrelievepressurebeforedisconnectingorconnectinguidlines.
Stoptheengineandremovethekeybeforedisconnectingorconnectingelectricalconnections.
Replacedamagedorworntubes,hoses,electricalwiring,etc.
Someelectricalcomponentsand/orsomehydrauliclinesmaybecomehotduringoperation.Takecarewhenservic-
ingsuchcomponents.Allowthecomponentsurfacestocoolbeforehandlingthecomponentsordisconnectinghot
components.Wearprotectiveequipmentwhenappropriate.
Whenweldingonorincloseproximitytothismachine,followtheinstructionsinthisoperator’smanual.See“Wheels
andtires”safetyrulesthatfollowinthischapter.
Alwaysdisconnectthebatterybeforeweldingonthemachine.Alwayswashyourhandsafterhandlingbatterycom-
ponents.
Drivingonpublicroadsandgeneraltransportationsafety
Complywithlocallawsandregulations.
Useappropriatelightingtomeetlocalregulations.
4793774110/02/2016
7

INTRODUCTION
MakesurethattheSlow-MovingVehicle(SMV)reector
emblemisvisible.
NHIL15HT00709AA1
Usesafetychainsfortrailedequipmentwhenprovidedwithmachineorequipment.
Whentransportingthemachineonatransporttrailer,makesurethatyousecurethemachineproperlyforsafetrans-
portandthatyoucovertheheSMVonthemachine.
Beawareofoverheadstructuresorpowerlinesandmakesurethemachineand/orattachmentscanpasssafely
under.
Maintaincompletecontrolandmachinestabilitybycarefulregulationofthetravelspeedatalltimes.
Slowdownandsignalbeforeturning.
Pullovertoallowfastertrafctopass.
Followthecorrecttowingprocedureforequipmentwithorwithoutbrakes.
Generalbatterysafety
Alwaysweareyeprotectionwhenworkingwithbatteries.
Donotcreatesparksorhaveopenamenearbattery.
Ventilatewhenchargingorusinginanenclosedarea.
Disconnectallconnectionsfromthebattery'snegative(–)terminalrst.Connecttheremovedbattery'snegative(–)
terminalconnectionstothebatterylast.
Whenweldingonthemachine,disconnectbothterminalsofthebattery.
Donotweld,grind,orsmokenearabattery.
Whenusingauxiliarybatteriesorconnectingjumpercablestostarttheengine,usetheprocedureshownintheoper-
ator’smanual.Donotshortacrossterminals.
Followmanufacturer’sinstructionswhenstoringandhandlingbatteries.
Batterypost,terminals,andrelatedaccessoriescontainleadandleadcompounds.Washhandsafterhandling.This
isaCaliforniaProposition65warning.
Batteryacidcausesburns.Batteriescontainsulfuricacid.Avoidingestionorcontactwithskin,eyes,orclothing.
Antidotes:
•Externalcontact:Flushwithwater.
•Eyescontact:Flushwithwaterfor15minutesandseekmedicalattentionimmediately.
•Internalcontact:Drinklargequantitiesofwaterormilk.Donotinducevomiting.
Seekmedicalattentionimmediately.
Keepthebatteryoutofthereachofchildrenandotherunauthorizedpersons.
4793774110/02/2016
8

INTRODUCTION
PowerTake-Off(PTO)
PowerT ake-Off(PTO)-drivenmachinerycancausedeathorseriousinjury.BeforeworkingonornearthePTOshaft
orservicingorclearingthedrivenmachine,putthePTOleverinthedisengageposition,stoptheengine,andremove
thekey.
WheneveraPTOisinoperation,aguardmustbeinplacetopreventdeathorinjurytotheoperatororbystanders.
WhendoingstationaryPTOwork,keepclearofallmovingpartsandmakesureappropriateguardsareinplace.
ForcorrectPTOtotractorhitchgeometry,alwaysrefertothemachineoperator’smanual.
Neveruseasplineadaptor:
•MatchtherighttractorPTOsplineandspeedwiththePTOdriveshaftprovidedwithanimplement.Thiswillassure
propergeometryandoperatingspeed.
•Neveroperate540RPMimplementsat1000RPM.
•Neveroperate1000RPMimplementsat540RPM.
•UseofPTOadaptorswillvoidthewarrantyofthedriveshaft,andthePTOdrivetrainofthemachineandimplement.
Reectorsandwarninglights
Youmustuseashingamberwarninglightswhenyouoperateequipmentonpublicroads.
Trailinglightsandreectorsarelocatedontheinsideof
bothcuttingunits.TheSlow-MovingVehicle(SMV)iscen-
teredonthemachineassembly.
Trailinglights:
•(3)–Amber
•(4)–Red
Reectors:
•(1)–Red
•(2)–Amber
•(5)–Slow-MovingVehicle(SMV)
NHIL15HT00446AA2
PersonalProtectiveEquipment(PPE)
WearPersonalProtectiveEquipment(PPE)suchaspro-
tectiveclothing,eyeprotection,hearingprotection,dust
mask,hardhat,heavygloves,workboots,and/orany
otherPPEthatprovidesforthesafetyandprotectionof
theindividualoperatingthisequipment.
NHIL13RB00001AA3
4793774110/02/2016
9

INTRODUCTION
DoNotOperatetag
WARNING
Maintenancehazard!
Beforeyoustartservicingthemachine,alwaysattachaDONOTOPERATEwarningtagtothemachine
inavisiblearea.
Failuretocomplycouldresultindeathorseriousinjury.W0004B
Beforeyoustartservicingthemachine,attacha‘DoNotOperate’warningtagtothemachineinanareathatwillbe
visible.
1.ObtainDONOTOPERATEtagsfromyourNEWHOLLANDServicePartsDealer.
2.AttachaDONOTOPERATEtagtothemachineinanareathatisclearlyvisiblewheneverthemachineisnot
operatingproperlyand/orrequiresservice.
3.CompletetheDONOTOPERATEtaginformationforthereasonormaintenancehazardfortheDONOTOPER-
ATEtagthatyouareattaching.Describethemalfunctionorservicerequired.Validatethereasonforattachingthe
DONOTOPERATEtagbysigningyournameinthedesignatedareaontheDONOTOPERATEtag.
4.OnlythepersonwhosignedandattachedtheDONOTOPERATEtagshouldremovetheDONOTOPERATE
tag,aftervalidatingtherepairsorservicesarecomplete.
Hazardouschemicals
Ifyouareexposedtoorcomeincontactwithhazardouschemicalsyoucanbeseriouslyinjured.Theuids,lubricants,
paints,adhesives,coolant,etc.requiredforthefunctionofyourmachinecanbehazardous.Theymaybeattractive
andharmfultodomesticanimalsaswellashumans.
MaterialSafetyDataSheets(MSDS)provideinformationaboutthechemicalsubstanceswithinaproduct,safehan-
dlingandstorageprocedures,rstaidmeasuresandprocedurestobetakenintheeventofaspilloraccidental
release.MSDSareavailablefromyourdealer.
BeforeyouserviceyourmachinechecktheMSDSforeachlubricant,uid,etc.usedinthismachine.Thisinformation
indicatestheassociatedrisksandwillhelpyouservicethemachinesafely.FollowtheinformationintheMSDS,on
manufacturercontainers,aswellastheinformationinthismanualwhenservicingthemachine.
Disposeofalluids,lters,andcontainersinanenvironmentallysafemanneraccordingtolocallawsandregulations.
Checkwithlocalenvironmentalandrecyclingcentersoryourdealerforcorrectdisposalinformation.
Storeuidsandltersinaccordancewithlocallawsandregulations.Useonlyappropriatecontainersforthestorage
ofchemicalsorpetrochemicalsubstances.
Keepoutofreachorchildrenorotherunauthorizedpersons.
Additionalprecautionsarerequiredforappliedchemicals.Obtaincompleteinformationfromthemanufactureror
distributorofthechemicalsbeforeusingthem.
Utilitysafety
Makesurethatthemachinehassufcientclearancetopassinalldirections.Payspecialattentiontooverheadpower
linesandhangingobstacles.Highvoltagelinesmayrequiresignicantclearanceforsafety.Contactlocalauthorities
orutilitiestoobtainsafeclearancedistancesfromhighvoltagepowerlines.
Retractraisedorextendedcomponents,ifnecessary.Removeorlowerradioantennasorotheraccessories.Should
acontactbetweenthemachineandanelectricpowersourceoccur,thefollowingprecautionsmustbetaken:
•Stopthemachinemovementimmediately.
•Applytheparkingbrake,stoptheengine,andremovethekey.
•Checkifyoucansafelyleavethecaboryouractualpositionwithoutcontactwithelectricalwires.Ifnot,stayinyour
positionandcallforhelp.Ifyoucanleaveyourpositionwithouttouchinglines,jumpclearofthemachinetomake
surethatyoudonotmakecontactwiththegroundandthemachineatthesametime.
4793774110/02/2016
10

INTRODUCTION
•Donotpermitanyonetotouchthemachineuntilpowerhasbeenshutofftothepowerlines.
Electricalstormsafety
Donotoperatethemachineduringanelectricalstorm.
Ifyouareonthegroundoroperatingamachineduringanelectricalstorm;
•Stayawayfrommachineryandequipment.
•Seekshelterinapermanent,protectedstructure.
•Remaininthecabduringoperationifanelectricalstormstrikes.
•Donotleavethecaboroperator’splatform.
•Donotmakecontactwiththegroundorobjectsoutsidethemachine.
4793774110/02/2016
11

INTRODUCTION
Safetyrules-Ecologyandtheenvironment
Soil,air,andwaterqualityisimportantforallindustriesandlifeingeneral.Whenlegislationdoesnotyetrulethe
treatmentofsomeofthesubstancesthatadvancedtechnologyrequires,soundjudgmentshouldgoverntheuseand
disposalofproductsofachemicalandpetrochemicalnature.
Familiarizeyourselfwiththerelativelegislationapplicabletoyourcountry,andmakesurethatyouunderstandthis
legislation.Wherenolegislationexists,obtaininformationfromsuppliersofoils,lters,batteries,fuels,anti-freeze,
cleaningagents,etc.,withregardtotheeffectofthesesubstancesonmanandnatureandhowtosafelystore,use,
anddisposeofthesesubstances.
Helpfulhints
•Avoidtheuseofcansorotherinappropriatepressurizedfueldeliverysystemstolltanks.Suchdeliverysystems
maycauseconsiderablespillage.
•Ingeneral,avoidskincontactwithallfuels,oils,acids,solvents,etc.Mostoftheseproductscontainsubstances
thatmaybeharmfultoyourhealth.
•Modernoilscontainadditives.Donotburncontaminatedfuelsandorwasteoilsinordinaryheatingsystems.
•Avoidspillagewhenyoudrainuidssuchasusedenginecoolantmixtures,engineoil,hydraulicuid,brakeuid,
etc.Donotmixdrainedbrakeuidsorfuelswithlubricants.Storealldraineduidssafelyuntilyoucandisposeof
theuidsinaproperwaythatcomplieswithalllocallegislationandavailableresources.
•Donotallowcoolantmixturestogetintothesoil.Collectanddisposeofcoolantmixturesproperly.
•Theair-conditioningsystemcontainsgasesthatshouldnotbereleasedintotheatmosphere.Consultanair-condi-
tioningspecialistoruseaspecialextractortorechargethesystemproperly.
•Repairanyleaksordefectsintheenginecoolingsystemorhydraulicsystemimmediately.
•Donotincreasethepressureinapressurizedcircuitasthismayleadtoacomponentfailure.
•Protecthosesduringwelding.Penetratingweldsplattermayburnaholeorweakenhoses,allowingthelossofoils,
coolant,etc.
Batteryrecycling
Batteriesandelectricaccumulatorscontainseveralsubstancesthatcanhaveaharmful
effectontheenvironmentifthebatteriesarenotproperlyrecycledafteruse.Improper
disposalofbatteriescancontaminatethesoil,groundwater,andwaterways.NEW
HOLLANDstronglyrecommendsthatyoureturnallusedbatteriestoaNEWHOLLAND
dealer,whowilldisposeoftheusedbatteriesorrecycletheusedbatteriesproperly.In
somecountries,thisisalegalrequirement.
Mandatorybatteryrecycling
NOTE:ThefollowingrequirementsaremandatoryinBrazil.
Batteriesaremadeofleadplatesandasulfuricacidsolution.Becausebatteriescontainheavymetalssuchaslead,
CONAMAResolution401/2008requiresyoutoreturnallusedbatteriestothebatterydealerwhenyoureplaceany
batteries.Donotdisposeofbatteriesinyourhouseholdgarbage.
Pointsofsaleareobligedto:
•Acceptthereturnofyourusedbatteries
•Storethereturnedbatteriesinasuitablelocation
•Sendthereturnedbatteriestothebatterymanufacturerforrecycling
4793774110/02/2016
12

INTRODUCTION
Torque-Nominaltighteningtorquesfornormalassembly
NOTE:Inthemetrictables,nominalsizesM4throughM8hardwaretorquespecicationsareshownasaNewton
meters(pound-inches)numericalvalue.
NominalsizesM10throughM24hardwaretorquespecicationsareshownasaNewtonmeters(pound-feet)numer-
icalvalue.
Metrichexhead(non-ange)hardware
Plain(PLN)–anunplatedhardwarenishwithresidualmanufacturingoils
Zinc-dichromate(ZND)–ayellowcoloredchemicalplatingformulayellowappliedtothehardware
Nominalsize
Class(CL)8.8
boltandClass
(CL)8nut
Class(CL)10.9
boltandClass
(CL)10nut
Locknut
CL8
w/CL8.8bolt
Locknut
CL10
w/CL10.9bolt
PLNandZNDPLNandZNDZNDZND
N·m(lbin)N·m(lbin)N·m(lbin)N·m(lbin)
M43.5(31)5.0(44)1.4(13)2.8(25)
M57.0(62)10(88)2.9(26)5.5(49)
M611.8(104)17(150)4.9(43)9.4(83)
M828.8(255)41.3(366)11.9(105)23(204)
N·m(lbft)N·m(lbft)N·m(lbft)N·m(lbft)
M1057(42)82(60)24(17)45(33)
M12100(74)143(105)41(30)79(38)
M14159(117)227(168)66(48)125(92)
M16248(183)354(261)102(75)195(144)
M18352(260)487(359)145(107)268(198)
M20500(369)690(509)206(152)380(280)
M24865(638)1195(882)357(263)657(485)
Metricangeheadhardware
Plain(PLN)–anunplatedhardwarenishwithresidualmanufacturingoils
Zinc-dichromate(ZND)–ayellowcoloredchemicalplatingformulayellowappliedtothehardware
Nominalsize
Class(CL)8.8
boltandClass
(CL)8nut
Class(CL)10.9
boltandClass
(CL)10nut
Flangelocknut
CL8
w/CL8.8bolt
Flangelocknut
CL10
w/CL10.9bolt
PLNandZNDPLNandZNDZNDZND
N·m(lbin)N·m(lbin)N·m(lbin)N·m(lbin)
M43.8(34)5.5(49)4.2(37)6.1(54)
M57.7(68)11(97)8.5(75)12(106)
M613(115)18.7(166)14.3(127)20.6(182)
M831.7(281)45.5(403)35(310)50(443)
N·m(lbft)N·m(lbft)N·m(lbft)N·m(lbft)
M1063(47)90(66)69(51)99(73)
M12110(81)157(116)121(89)173(128)
M14175(129)250(184)193(142)275(202)
M16272(201)389(287)299(221)428(316)
M18387(286)535(395)426(315)589(435)
M20550(406)759(560)605(447)835(616)
M24951(702)1315(970)1046(772)1447(1067)
4793774110/02/2016
13

INTRODUCTION
Identicationmarkings
Metrichexhead,angehexheadandcarriagebolts,Classes(CL)5.6andupward
NHIL14RB00662AA1
Metricboltidenticationmarkings
1.Manufacturer'sidentication
2.Propertyclass
Metrichexnutsandlocknuts,Classes(CL)05andupward
NHIL14RB00663AA2
Metrichexnutidenticationmarkings
•(1)–Manufacturer'sidentication
•(3)–Propertyclass
•(2)–Clockwisetypemarkingsindicatepropertyclassandmayincludemanufactureridentication(ifapplied),
Example:propertymarks240°apart(shown)attheeighto’clockpositionindicateaClass8property,andmarks
300°apartattheteno’clockpositionindicateaClass10property.
4793774110/02/2016
14

INTRODUCTION
NOTE:IntheImperialunitstables,thenominalsizes,1/4(0.25)in(inch)and5/16(0.3125)in(inch)hardwaretorque
specicationsareshownasaNewtonmeters(pound-inches)numericalvalue.
Nominalsizes3/8(0.375)in(inch)through1(1.0)in(inch)hardwaretorquespecicationsareshownasaNewton
meters(pound-feet)numericalvalue.
Inchhexhead(non-ange)hardware
Plain(PLN)–anunplatedhardwarenishwithresidualmanufacturingoils
Zinc-dichromate(ZND)–ayellowcoloredchemicalplatingformulayellowappliedtothehardware
Nominalsize
SAEGrade
(GR)5
boltandnut
SAEGrade
(GR)8
boltandnut
Locknut
GRB
w/GR5bolt
Locknut
GRC
w/GR8bolt
PLNandZNDPLNandZNDZNDZND
N·m(lbin)N·m(lbin)N·m(lbin)N·m(lbin)
1/4(0.25)in13(115)18(159)7.2(64)10(89)
5/16(0.3125)in27(239)38(336)14.9(132)21(186)
N·m(lbft)N·m(lbft)N·m(lbft)N·m(lbft)
3/8(0.375)in47(35)67(49)26(19)37(27)
7/16(0.4375)in76(56)107(79)42(31)59(44)
1/2(0.50)in116(85)164(121)64(47)90(67)
9/16(0.5625)in167(123)236(174)92(68)130(96)
5/8(0.625)in231(170)326(240)127(94)179(132)
3/4(0.75)in410(302)578(426)226(166)318(234)
7/8(0.875)in660(486)931(687)363(267)512(378)
1(1.0)in989(729)1396(1030)544(401)768(567)
Inchangeheadhardware
Plain(PLN)–anunplatedhardwarenishwithresidualmanufacturingoils
Zinc-dichromate(ZND)–ayellowcoloredchemicalplatingformulayellowappliedtothehardware
Nominalsize
SAEGrade
(GR)5
boltandnut
SAEGrade
(GR)8
boltandnut
Flangelocknut
GRF
w/GR5bolt
Flangelocknut
GRG
w/GR8bolt
PLNandZNDPLNandZNDZNDZND
N·m(lbin)N·m(lbin)N·m(lbin)N·m(lbin)
1/4(0.25)in14(124)20(177)15.4(136)22(195)
5/16(0.3125)in29(257)42(372)32(283)46(407)
N·m(lbft)N·m(lbft)N·m(lbft)N·m(lbft)
3/8(0.375)in52(38)74(54)57(42)81(9)
7/16(0.4375)in84(62)118(87)92(68)130(96)
1/2(0.50)in127(94)180(133)140(103)198(146)
9/16(0.5625)in184(136)259(191)202(150)285(210)
5/8(0.625)in254(187)358(264)279(206)394(290)
3/4(0.75)in450(332)636(469)495(365)700(516)
7/8(0.875)in725(535)1024(755)798(589)1126(831)
1(1.0)in1088(802)1536(1133)1197(882)1690(1246)
4793774110/02/2016
15
