Nuna triv next User manual

IM-001036C
IM-001036C

IM-001036C

Designed
around your life

2TRIV next instructions 3TRIV next instructions
Contents
Product Information 4
Warranty
Contact
Child Usage Requirements 5
Warnings 6
Parts List 10
Product Set up 12
Product Use 16
Accessories 26
Care and Maintenance 32
IMPORTANT!
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE:
READ CAREFULLY

4TRIV next instructions 5TRIV next instructions
Contact
For replacement parts, service, or additional warranty
questions, please contact our customer service department.
Distributed by Nuna Baby Australia Pty Ltd
ACN: 642 240 140
Unit 1, 35 Lyn Parade Prestons, NSW Australia 2170
For after-sales & warranty service, contact:
1800 951 070
[e-mail]
Child Usage Requirements
This stroller is suitable for use with children who meet the
following requirements:
Weight: up to 22.7 kg maximum
When using the stroller frame with TRIV or LYTL bassinet or
KLIK plus infant carrier, refer to the child usage requirements
listed in those instruction manuals.
TRIV or LYTL bassinet
Weight: up to 9 kg maximum
KLIK plus infant carrier
Weight: up to 13 kg maximum
Product Information
Model Number:____________________________________________________________________________________________________________________________________
Manufactured Date:_______________________________________________________________________________________________________________________
The model number and the manufactured in date are located
on a label on the stroller frame.
Warranty
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation
for any other reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does
not amount to a major failure.
We have purposely designed our high-quality products so
that they can grow with both your child and your family.
Because we stand by our product, our gear is covered by
a custom warranty per product, starting from the day it
was purchased. Please have the proof of purchase, model
number and manufactured in date available when you
contact us.
For warranty information please visit:
www.nunababy.com

6TRIV next instructions 7TRIV next instructions
WARNING
FOLLOW THE MANUFACTURER’S
INSTRUCTIONS. PUT ON ALL THE BRAKES
WHENEVER YOU PARK THE PRAM/STROLLER.
DO NOT LEAVE CHILDREN UNATTENDED.
ALWAYS KEEP CHILD IN VIEW WHILE IN PRAM/
STROLLER.
DO NOT USE THE SEAT WITH ANY OTHER
MODELS OF PRAM/STROLLER.
USE THIS HARNESS AT ALL TIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ON
THIS PRAM/STROLLER.
MAKE SURE CHILDREN ARE CLEAR OF ANY
MOVING PARTS IF YOU ADJUST THE PRAM/
STROLLER. OTHERWISE THEY MAY BE INJURED.
TO AVOID SERIOUS INJURY FROM FALLING
OR SLIDING OUT, ALWAYS USE THE HARNESS
CORRECTLY.
USE THIS TETHER STRAP TO STOP THE PRAM/
STROLLER ROLLING AWAY.
DO NOT USE THIS BASSINET ONCE THE CHILD
CAN SIT UP UNAIDED.
DO NOT USE FOR UNSUPERVISED SLEEPING.
Ensure that all the locking devices are engaged
before use.
Do not let your child play with this product.
Never leave the harness buckled when not fitted
to a child in the stroller because the harness
can form loops which may pose a strangulation
hazard.
The use of accessories not approved by the
vehicle manufacturer is unsafe.
Adult assembly required.
Use of this stroller with a child weighing more
than 22.7 kg will cause excessive wear, and stress
on the stroller, and could create an unstable
condition. Use the pram/stroller with only one
child at a time.
To prevent a hazardous, unstable condition, do
not place more than 4.5 kg in the storage basket
before use.
To prevent a hazardous, unstable condition, do
not place more than 0.45 kg in the storage pocket
on the back of the seat.
Overloading, folding incorrectly, or using
component parts from other manufacturers may
cause the pram/stroller to be damaged, broken
or unsafe. Please read the instruction manual
carefully.
Please read all the instructions in the manual
before using the product. Please save instruction
manual for future use. Failure to follow these
warnings and instructions may result in serious
injury or death.
Safety belts and restraint system must be used
correctly.

8TRIV next instructions 9TRIV next instructions
Child may slip into leg openings and be strangled
if the harness is not used.
Never use pram/stroller on stairs or escalators.
The pram/stroller is not to be used near an open
fire or exposed flame.
Never allow your child to stand on the pram/
stroller or sit in the pram/stroller with head toward
front of pram/stroller.
Never place the pram/stroller on roads or
dangerous area.
The vehicle is designed for use on flat or gently
sloping surfaces and may be unstable on higher
sloping and uneven surfaces, resulting in the
possibility of the vehicle tipping over.
Do make sure all parts are assembled and
fastened properly before using the pram/stroller.
To avoid strangulation, do not place items with a
string around your child’s neck, suspend strings
from this product, or attach strings to toys.
To prevent tipping, do not put anything on the
handle. Always lift the child in and out of the pram/
stroller.
Do not lift pram/stroller while child is in pram/
stroller.
Do not use storage basket as a child carrier.
To prevent tipping, never let child climb the pram/
stroller.
To avoid finger entrapment or injury to the body,
use care when folding and unfolding the pram/
stroller.
Be sure the pram/stroller is fully open or folded
before allowing child near the pram/stroller.
Check that the infant child restraint attachment
device is correctly engaged before use.
To avoid strangulation, do make sure your child is
clear from the canopy.
Discontinue using your pram/stroller if it is
damaged or broken.
Pram/stroller to be used only at walking speed.
This product is not intended for use while jogging.
To avoid suffocation, remove plastic bag and
packaging materials before using this product. The
plastic bag and packaging materials should then
be kept away from babies and children.
This product is not suitable for running or skating.
Stroller designed to be used from birth shall
recommend the use of the most reclined position
for new born babies.
The parking device must be engaged when placing
and removing children.
Please ensure that the storage latch has been
properly locked, before lifting or moving the
vehicle.
The vehicle is not to be used as an unsupervised
sleeping environment.
The brakes must always be applied when the
pram/stroller is not moving.

10 TRIV next instructions 11TRIV next instructions
Parts List
Make sure all parts are available before assembly.
If any part is missing, please contact Nuna. No tools are
required for assembly.
1 Stroller Frame
2 Canopy
3 Front Wheel (x2)
4 Rear Wheel (x2)
5 Seat Pad
6 Insert
7 Arm Bar
8 Calf Support
9 Swivel Lock
10 Storage Basket
11 Calf Support Adjustment
Button
12 Buckle
13 Seat Release Button
14 Shoulder Harness Pad
15 Handle
16 Handle Adjustment
Button
17 Storage Mount
18 Storage Latch
19 Brake Lever
20 Carry/Fold Strap
21 Storage Pocket
(maximum load =
0.45kg)
22 Tether Strap
23 Recline Adjustment
Lever/Folding Release
Button
24 Canopy Window
25 Post Adaptors
26 Rain Cover
1
x2
3
x2
4
26
25
4
19
15
16 23
21
20
24
6
8
5
2
7
9
10
12
13
11
3
14
22
18
17

12 TRIV next instructions 13TRIV next instructions
Product Set up
Open Stroller
1 - Take the stroller frame out and then open the storage
latch.
2 - Rotate the handle up to open the stroller frame.
3 - Pull the seat to open it.
A“click” sound means the seat is open.
Check that the stroller is completely latched open before
continuing.
Switch Seat
Please switch seat if you needed.
4 - Press the seat release buttons (1) and lift the seat up (2).
5 - Reverse the seat, and then attach it to the frame.
A“click” sound means the seat is attached completely.
2
1
1
click
click
1
2
3
4
5

15TRIV next instructions
4
2
3 6
5
1
14 TRIV next instructions
Front Wheels
1 - Insert the front wheel into the front leg.
A “click” sound means the front wheel is assembled
completely.
Check the wheel is securely attached by pulling out.
Repeat on opposite side.
2 - To remove the front wheel, press the release button (1)
and detach the front wheel from the front leg (2).
Rear Wheels
3 - Insert the rear wheel into the rear leg.
A “click” sound means the rear wheel is assembled
completely.
Check the wheel is securely attached by pulling out.
Repeat on opposite side.
4 - To remove the rear wheel, press the release button (1)
and detach the rear wheel from the rear leg (2).
Arm Bar
Always secure the child with the harness. The arm bar is
not a restraint device.
5 - Align the arm bar ends with the arm bar mounts, and
insert until it clicks into place.
A “click” sound means the arm bar is assembled
completely.
6 - To remove the arm bar, press the arm bar release
buttons (1) and remove the arm bar (2).
2
1
2
1
click
click
1
1
2
click

16 TRIV next instructions 17TRIV next instructions
1 1
22
Product Use
Securing Your Child
1 - Push the center button on the buckle to release the buckle
clasps, remove the clips and place your child in the stroller.
2 - Connect the shoulder clasp and waist clasp.
3 - Secure the shoulder clasp and waist clasp to the buckle
and repeat on the opposite side.
4 - Fit the harness snugly to your child by pulling the
adjustment straps to tighten (1) . Then pull the waist
adjustment straps out (2).
Shoulder Harness Position
5 - The upper shoulder harness adjustor buckles can be
moved up and down for added adjustment.
To avoid serious injury from falling or sliding out, always
secure your child with the harness.
Make sure the harness is adjusted properly and your child
is snugly secured. The space between the child and the
shoulder harness should be about the thickness of one
finger.
DO NOT cross the shoulder belts. This will cause pressure
on child’s neck.
Check Set Up
Stroller frame is latched open
Stroller seat securely attached
Rear and front wheels securely attached
Arm bar securely attached
4
2
3
1
5

18 TRIV next instructions 19TRIV next instructions
Canopy
1 - To open the canopy, pull the canopy toward the front of
the seat, and to fold, push it back.
2 - Open the zipper on the canopy for extra shade.
3 - For added ventilation, flip the canopy window cover up.
DO NOT remove the canopy when stroller is in use.
Keep the zipper between the canopy and seat pad
closed when stroller is in use.
Recline
There are 3 recline positions for the backrest.
4 - To raise or lower the backrest, squeeze the recline
adjustment lever (1), and pull the backrest up or down
(2).
Please do not press the button (3) on the middle of the
recline adjustment lever when adjusting the angle for the
recline.
Make sure the recline is adjusted properly for use.
Calf Support
The calf support has 2 use positions.
5 - To raise the calf support, lift up.
To lower the calf support, press the adjustment button
(1), and push down (2).
1
2
3
1
2
1
4
2
3 6
1

20 TRIV next instructions 21TRIV next instructions
Handle
The handle has 5 positions.
1 - To adjust the height of the handle, pull the handle
adjustment button (1) and pull the handle up or down (2).
Tether Strap
2 - Use the tether strap to prevent the stroller inadvertently
rolling away. Check that when your hand is through the
loop, it allows you to easily control the stroller.
Brake
3 - To lock the rear wheels, step down on the brake lever.
4 - To unlock the rear wheels, step down the brake lever
again.
Always apply the brake when the pram/stroller is
stopped. Push the pram/stroller slightly to ensure the
brake is engaged.
Front Swivel Locks
In Use Position:
It is recommended to use the front swivel locks on uneven
surfaces.
5 - Pull the front swivel lock up to lock the front wheel.
6 - Push the front swivel lock down to unlock.
2
1
1
4
2
3 6
5
1

22 TRIV next instructions 23TRIV next instructions
Fold with SEAT
The stroller can be folded with forward facing seat or rear
facing seat or without the seat. Before folding the stroller,
adjust the handle to the lowest position and the front swivel
locks are locked.
1 - Fold the canopy.
2 - Press the folding release button (1) on the middle of the
recline adjustment button and then squeeze the recline
adjustment lever (2).
3 - Fold the seat.
1
2
3
2
1

24 TRIV next instructions 25TRIV next instructions
4 - Pull the carry/fold strap of the seat to fold the stroller.
5 - Rotate the storage latch. Secure the storage latch to the
storage mount. The stroller can stand by having front
swivel wheels locked.
6 - You can carry the stroller by lifting its carry/fold strap.
5
4
6

26 TRIV next instructions 27TRIV next instructions
Fold without seat
1 - Press the folding buttons of the seat mounts.
2 - Fold the stroller and secure the storage latch to the
storage mount.
The stroller without seat can stand by handle and the
front wheels.
Accessories
Insert
3 - To assemble the insert, place the insert over the seat and
thread the shoulder, waist and crotch harnesses through
their respective slots.
Not all accessories are included on some models.
1
2
3

28 TRIV next instructions 29TRIV next instructions
Post Adaptors
For TRIV or LYTL bassinet and KLIK plus infant carrier
assembly and usage, please refer to the infant carrier and
bassinet instruction manual.
1 - To attach the post adaptors, place the post adaptors on
the seat mount.
2 - A “click” sound means the post adaptors are attached.
3 - To attach infant carrier, place the infant carrier on the
post adaptors. A “click” sound means the infant carrier is
attached.
4 - To attach bassinet, place the bassinet on the post
adaptors. A “click” sound means the bassinet is
attached.
click
click
click
RL
41
3
2

30 TRIV next instructions 31TRIV next instructions
1
1
2
1 - To remove the infant carrier, push the release buttons on
the infant carrier (1) and lift up (2).
2 - To remove bassinet, press the release buttons on the
side of the bassinet (1) and lift up (2).
3 - To remove the post adaptors, pull the adaptor release
buttons (1) and lift up (2).
Remove the infant carrier and bassinet before folding.
Fold the Stroller with Post Adaptors
Before folding the stroller with post adaptors, adjust the
handle to the lowest position and suggest the front swivel
locks are locked.
4 - Pull the carry/fold strap of the post adaptors to fold the
stroller.
The stroller with the post adaptors can stand by handle
and the front wheels.
TRIV Series Rain Cover
Check that the canopy is completely open before attaching
the rain cover.
5 - To assemble the rain cover, place it over the stroller.
ALWAYS check ventilation when the rain cover is on the
product.
ALWAYS check that the rain cover has been cleaned and
dried before folding.
DO NOT fold the stroller when the rain cover is attached.
DO NOT place your child in the stroller in hot weather
with the rain cover attached.
1
2
1
1
2
2
3 5
4
1

32 TRIV next instructions
Care and Maintenance
Clean the frame, plastic parts, and fabric with a damp
cloth, but do not use abrasives or bleach. Do not use silicon
lubricants as they will attract dirt and grime. Do not store
your stroller in a damp place.
Clean the stroller wheels regularly with water and remove
any dirt.
To ensure long-lasting use:
clear out debris, sand, hair, solids, etc from frame joints
and wheels.
wipe this product dry with a soft absorbent cloth after
using it in rainy weather or from any spills.
Refer to the care label attached to the fabric for washing and
drying instructions.
It is normal for fabric to color from sunlight and to show wear
and tear after a long period of use, even when used normally.
For reasons of safety, only use original Nuna parts.
Check regularly if everything functions properly. If any parts
are torn, broken, or missing, stop using this product.
Nuna International B.V. NUNA and all associated logos are trademarks.
