Océ CS2024
Océ User manual
Quick Start Guide

Edition 2005-10 AB7-5318-V1, Printed in Japan GB
Océ Technologies B.V.
Copyright
2005, Océ-Technologies B.V. Venlo, The Netherlands.
All rights reserved. No part of this work may be reproduced, copied, adapted, or
transmitted in any form or by any means without written permission from Océ.
Océ-Technologies B.V. makes no representation or warranties with respect to the
contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose.
Further, Océ-Technologies B.V. reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation to notify
any person of such revision or changes.

3
Contents
Contents
Chapter 1
Read this first. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setup Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Make Sure You Have Everything. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Assembling the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting Up the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing the Output Stacker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Removing the Packing Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connecting the Power Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installing the Printhead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing the Ink Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Loading Roll Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Adjusting the Condition of the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4
Contents

5
Chapter 1
Read this first

6 Chapter 1 Read this first
Setup Flow
Setup Flow
Overview
1. Make Sure You Have Everything
[1]
2. Assembling the Stand
[2]
3. Setting Up the Printer
[3]
4. Installing the Output Stacker
[4]

7
Setup Flow
5. Removing the Packing Material
[5]
6. Connecting the Power Cord
[6]
7. Installing the Printhead
[7]
8. Installing the Ink Tanks
[8]
[9]

8 Chapter 1 Read this first
Setup Flow
9. Loading Roll Media
[10]
10. Adjusting the Condition of the Printer
Perform the automatic adjustment for the printhead and the amount of media feed.
[11]
11. Installing the Software
[12]
Note: For USB connections, do not connect the cable before installing the printer
driver.
[13]
For more details about network connections, refer to Chapter 5 of the User’s Guide,
“Using the Printer in a Network Environment.”

9
Make Sure You Have Everything
Make Sure You Have Everything
Printer Set
[1]
[14]
Printer
[15]
Power Cord
[16]
Ink Tanks
■Bk
■C
■PC
■M
■PM
■Y
[17]
Roll holder
[18] Cleaner Brush
[19]
Printhead
[20]
Hex driver
Quick Start Guide (This guide)

10 Chapter 1 Read this first
Make Sure You Have Everything
Reference Guide
[21]
■User Software CD-ROM
■User Manuals CD-ROM

11
Make Sure You Have Everything
Stand Set
[2]
[22]
■Stand Foot L
■Stand Foot R
[23]
■Stand Leg L
■Stand Leg R
[24]
Stand Stay
[25]
■Hex Screws ×8
■M4 Hex Screws ×4
■Hex Wrench
[26]
Output Stacker Cloth
[27]
Output Stacker Arms A, B
[28]
Stabilizers (×2)
[29]
■Arm Stopper (×2)
■Arm Holder (×2)

12 Chapter 1 Read this first
Make Sure You Have Everything
Space Requirements
When you set up the printer, make sure that there is at least as much space around
the printer (more space is recommended) as shown by the dimensions in the drawing.
[30]
[30] Height
[31]
[31] Width and Depth
)
.ni
7.
87(
mm
00
02
mm6831
).ni
5.
45(
mm20
9
)
.
ni
5.5
3
(
2000 mm (78.7 in.)
)
.ni8.67(m
m2
591
mm006
)
.
n
i
6
.
3
2
(
m
m
006
).n
i6.
3
2(
2000 mm (78.7 in.)
600 mm
(23.6 in.)
200 mm (7.8 in.)

13
Assembling the Stand
Assembling the Stand
1. Position the stand leg L (a) as shown, then with the stand foot L (b) aligned with the
inside groove, insert the projections into the holes and fasten with the 4 hex screws.
[32]
2. Position the stand leg R (c) as shown, then with the stand foot R (d) aligned with the
inside groove, insert the tabs into the holes and fasten with the 4 hex.
[33]

14 Chapter 1 Read this first
Assembling the Stand
3. After you use the hex driver (provided) to loosen the hex screws of the stand stay (e),
remove the tape from the left and right end of the stay, hold the stay as shown, then
insert it into the grooves of stand leg L (a) and stand leg R (c).
[34]
4. Secure the stand stay by tightening the left and right hex screws with the provided
hex wrench.
[35]
e
a
c

15
Setting Up the Printer
Setting Up the Printer
Illustration
[36]
[36] To prevent painful back or other injury
[37]
[37] Firmly grasp the handles (a)

16 Chapter 1 Read this first
Setting Up the Printer
Stand Configuration
1. Move the stand to where you want to set up the printer, then lock the front casters.
[38]
2. Hold the printer by the handles provided on the bottom of both sides of the printer,
align the round part on bottom of the printer (b) with the round part on top of the
stand (c), then set the printer onto the stand.
[39]

17
Setting Up the Printer
3. From the bottom of the stand support plate, attach and tighten two hex screws to both
sides of the printer.
[40]

18 Chapter 1 Read this first
Installing the Output Stacker
Installing the Output Stacker
1. With the front side (the side without lapels) of the output stacker cloth facing up, use
the holes on both ends of the cloth to attach the cloth to output stacker arm A (a) and
the output stacker arm B (b).
[41]
2. From the rear as shown in the illustration, hook the holder (d) to the shaft of the
screw (c) on the top edge of the rear side of the stand stay, then insert the bottom of
the arm holder to the shaft of the screw (e) on the bottom of the stand stay.
[42]
c
e
d

19
Installing the Output Stacker
3. From within the left and right of rear output stacker arm B (b), insert firmly into the
installation holes of the arm holder (f), then insert the arm securely into the groove.
[43]
4. Insert both ends of the output stacker arm A (a) into the center holes (g) of the stand
foot.
[44]
5. Fasten the output stacker arm A with the arm stopper (h), fit the stabilizer (i) to the
back of output stacker arm A, and insert into the holes of the arm stopper (h).
[45]

20 Chapter 1 Read this first
Removing the Packing Material
Removing the Packing Material
1. Remove all tape attached to printer and roll holder.
[46]
[47]
2. Open the upper cover.
[48]
Attention: The upper cover stopper (a) is attached to the upper cover. The upper
cover stopper is important because it prevents the upper cover from falling
unexpectedly. To close the upper cover, just lift and hold the stopper up with one
hand, then close it.
