CC-Link Communication Unit for
Digital Displacement Sensors
SC-HG1-C
User’s Manual
WUME-SCHG1C-4

WUME-SCHG1C-42
(MEMO)

WUME-SCHG1C-4 3
INTRODUCTION
Thank you for purchasing a CC-Link communication unit SC-HG1-C.
Before using this product, read and understand this User’s Manual. Use the product correctly
and in the optimum manner.
Keep this manual in a safe location for reference whenever necessary.
Types of Manuals
The following user’s manuals are available for the SC-HG1-C series. Refer to the appropriate
manual according to your need.
The user’s manuals are also available for download from our website (https://panasonic.net/id/
pidsx/global).
Unit name or purpose of use Manual name Manual code
CC-Link communication unit for
digital displacement sensors SC-HG1-C User’s Manual WUME-SCHG1C
Contact-type digital displacement
sensor HG-S series HG-S User’s Manual WUME-HGS
Thru-beam type digital displacement
sensor HG-T series HG-T User’s Manual WUME-HGT
Please note
1) Unauthorized reproduction of part or all of this manual is prohibited.
2) The contents of this manual are subject to change without notice.
3) This manual has undergone strict quality control procedures; however, in the event that you
discover any problems or points of concern, please contact your local dealer.
4) CC-Link is a registered trademark of Mitsubishi Electric Corporation and is a trademark managed
by CC-Link Partner Association.

WUME-SCHG1C-44
Structure of this manual
1 Before Using This Product
Cautions for safe use of the product, terminology, contents
of the package, and names and functions of the parts of
the product.
2 System Conguration Types of controllers that can be connected to the product
and restrictions.
3 Installation and Connections
Mounting, connecting controllers, connecting external de-
vices, and conguring communication settings.
4 CC-LINK Network Com-
munication Communication methods.
5 Specications Specications and dimensions.
6 Warranty Warranty information.
7 Maintenance Maintenance and inspection.
8 Troubleshooting Troubleshooting and error codes.

WUME-SCHG1C-4 5
Frequently asked questions
I want to learn about communication
commands 4-10 Commands 4-34 page
Question Section Page
I want to set threshold values 4-10-3 Command sending proce-
dure 4-50 page
I want to acquire controller output 4-6 Judgment output reading 4-30 page
I want to acquire measured values
from a controller
4-8 Continuous reading of mea-
surement data 4-31 page
I want to learn the data acquisition
time
4-13 Communication response
speed 4-67 page

WUME-SCHG1C-46
Contents
INTRODUCTION ···············································································3
Types of Manuals···············································································3
Structure of this manual ······································································4
Frequently asked questions··································································5
1 Before Using This Product ·····························································1-1
1-1 Safety rules ·············································································· 1-2
1-2 Safety information ······································································ 1-3
1-3 Glossary ·················································································· 1-5
1-4 Contents of package··································································· 1-6
1-5 Description of parts ···································································· 1-7
2 System Conguration····································································2-1
2-1 Communication unit system ························································· 2-2
2-2 Unit types················································································· 2-4
3 Installation and Connections···························································3-1
3-1 Steps prior to operation ······························································· 3-2
3-2 Settings ··················································································· 3-3
3-2-1 CC-Link communication settings ···············································3-3
3-2-2 Communication unit settings·····················································3-4
3-3 Installation················································································ 3-6
3-3-1 Mounting ··············································································3-6
3-3-2 Connection ···········································································3-7
3-3-3 Pin layout ·············································································3-9
3-3-4 Host communication cable connection ········································3-9
3-3-5 Procedure for connecting the CC-Link connector ························ 3-10
3-3-6 Attachment and removal of termination resistor ·························· 3-12
4 CC-LINK Network Communication······························································ 4-1
4-1 Overview of communication ························································· 4-2
4-1-1 Communication with master station············································4-2
4-1-2 SC-HG1-C and controller communication ····································4-3
4-2 Explanation of modes ································································· 4-4
4-3 Memory map············································································· 4-5
4-3-1 CC-Link mode 1·····································································4-5
4-3-2 CC-Link mode 2··································································· 4-14
4-3-3 CC-Link mode 3··································································· 4-21
4-4 Memory map and controller assignments ······································ 4-28
4-5 Initial operation after power is turned ON ······································ 4-29
4-6 Judgment output reading ··························································· 4-30
4-7 External input·········································································· 4-30
4-8 Continuous reading of measurement data ····································· 4-31
4-9 Error mode ············································································· 4-33

WUME-SCHG1C-4 7
4-10 Commands ··········································································· 4-34
4-10-1 HG-S series command list ···················································· 4-34
4-10-2 HG-T series command list ···················································· 4-39
4-10-3 Command sending procedure ··············································· 4-50
4 -11 Reading received light waveforms (For the HG-T only) ·················· 4-54
4-11-1 Format of received light waveform ·········································· 4-54
4-11-2 Reading measured waveforms ·············································· 4-56
4-11-3 Reading reference waveforms ··············································· 4-59
4-12 Registering the reference waveform (For the HG-T only) ················ 4-62
4-13 Communication response speed ··············································· 4-67
4-14 Self-monitoring Function ·························································· 4-68
4-14-1 Using the Self-monitoring Function········································· 4-68
4-14-2 Statuses and Measures ······················································· 4-69
4-15 Other precautions··································································· 4-71
5 Specications··············································································5-1
5-1 Specications············································································ 5-2
5-2 Dimensions··············································································· 5-3
6 Warranty ····················································································6-1
6-1 When you purchase and use the product ········································ 6-2
7 Maintenance ···············································································7-1
7-1 Maintenance and Inspection························································· 7-2
7-1-1 Maintenance cautions ·····························································7-2
7-1-2 Main inspection items······························································7-2
8 Troubleshooting ···········································································8-1
8-1 Command error ········································································· 8-2
8-2 Communication errors································································· 8-5
8-3 Description of indicators ······························································ 8-6
8-4 What to do when a problem occurs················································ 8-7

WUME-SCHG1C-48
(MEMO)

1-1
1 Before Using This Product
1-1 Safety rules ·············································································1-2
1-2 Safety information ·····································································1-3
1-3 Glossary ·················································································1-5
1-4 Contents of package··································································1-6
1-5 Description of parts ···································································1-7

Before Using This Product
WUME-SCHG1C-41-2
1-1 Safety rules Always observe
This section explains important rules that must be observed to prevent human injury and prop-
erty damage.
■The hazards that may occur if the product is used incorrectly are described and classied by
level of harm.
WARNING Risk of death or serious injury.
CAUTION Risk of minor injury or property damage.
■The following symbols are used to indicate safety information that must be observed.
Indicates an action that is prohibited.
Indicates an action that must be taken.
Indicates a matter that requires caution.
<Reference> Indicates supplemental information.

Before Using This Product
WUME-SCHG1C-4 1-3
1-2 Safety information
WARNING
●Never use this product as a sensing device for personnel protection.
●When using sensing devices for personnel protection, use products that meet the laws and stan-
dards for personnel protection that apply in each region or country, such as OSHA, ANSI and IEC.
Specications
●This product has been developed / produced for industrial use only.
●Do not use this product under conditions outside the specied ranges. Risk of an accident
and product damage.There is also a risk of a signicant reduction of service life.
Power supply
●Incorrect wiring will damage the internal circuitry. Check the wiring before turning ON the
power.
● Verify that power supply uctuations are within the rating.
●Risk of damage and burning if a voltage over the rating is applied, or AC power is directly ap-
plied.
●If power is supplied from a commercial switching regulator, ensure that the frame ground
(F.G.) terminal is connected to an actual ground.
● Ensure that there is su󰀩cient leeway in the voltage source capacity.
●Do not use during the initial transient time after the power supply is switched ON
For details, refer to “4-5 Initial operation after power is turned ON”.
●Use an isolation transformer in the DC power supply. Risk of short-circuiting and damage to
the product or power supply if an auto transformer is used.
●If surges occur in the power supply, connect a surge absorber to the source to absorb the
surges.
Wiring
●Make sure that the power is OFF while performing wiring or connection work. Risk of electric
shock or product damage.
●Risk of damage and burning if the load is incorrectly wired or short-circuiting occurs.
●When noise generating equipment (switching regulator, inverter motor, etc.) is used in the vi-
cinity of this product, connect the frame ground (F.G.) terminal of the equipment separately to
ground.
●To avoid noise, keep the wiring as short as possible.
●Do not wire in parallel with a high-voltage line or power line, or run through the same conduit.
Risk of malfunctioning due to induction.
● For the communication cable, use a dedicated cable that is certied by CC-Link Partner As-
sociation.
●For detailed grounding specications, refer to the installation manual published by the CC-
Link Partner Association.
Usage environment
●This product is suitable for indoor use only.
●Avoid dust, dirt, and steam.
●Do not use in locations where there are corrosive or other harmful gases.
●Ensure that the product does not come into contact with organic solvents such as thinner.
●Ensure that the product does not come into contact with strong acid or alkaline.
●Ensure that the product does not come into contact with oil or grease.
● This product cannot be used in an environment that contains ammable or explosive gases.
● Performance may not be satisfactory in a strong electromagnetic eld.
●Do not drop or otherwise subject to shock. Risk of product damage.

Before Using This Product
WUME-SCHG1C-41-4
Other matters
●Never attempt to disassemble, repair, or modify the product.
●When the product becomes unusable or unneeded, dispose of the product appropriately as
industrial waste.
●Design the system so that system trouble protection and safety circuits are located externally.
●If your product, which incorporates our product, requires compliance with the EMC Directive,
install our product in a conductive box in accordance with the "PLC User's Manual" (pub-
lished by Mitsubishi Electric Corporation).

Before Using This Product
WUME-SCHG1C-4 1-5
1-3 Glossary
Term Meaning
System
terms
Transient transmission
A function in Data Link for communication with other stations using
peripheral devices, including reading or writing data from / to another
station by means of a read / write command in the program of the local
station.
Cyclic transmission
A function in Data Link for periodic data communication between stations
on the same network.
Memory map
This assigns functions of a communication unit to a link device. By ac-
cessing a link device that supports memory map, the master station can
use the functions of a communication unit.
Station number
This number is assigned to identify each network unit connected to a
network.
The same number cannot be assigned to more than one network unit in a
network.
RX[*]
Remote input
Information input from a slave station to the master station in units of
bits.
[*]: Indicates the bit number in hex.
RY[*]
Remote output
Information output from the master station to a slave station in units of
bits.
[*]: Indicates the bit number in hex.
RWw[*]
Remote register (output)
Information output from the master station to a slave station in units of
words (16 bits).
[*]: Indicates the word number in hex.
RWr[*]
Remote register (input)
Information input from a slave station to the master station in units of words
(16 bits).
[*]: Indicates the word number in hex.
Unit name
Master station
This station controls the overall network. The master station can com-
municate with all stations by cyclic transmission and transient transmis-
sion.
Slave station A general name for stations other than the master station (local station,
remote I/O station, remote device station, intelligent device station).
Remote I/O station
Exchanges input / output signals in units of bits with the master station by
cyclic transmission.
Remote device station
Sends information in units of bits and information in units of words by
cyclic transmission. Returns a response to a transient transmission from
another station.
Intelligent device sta-
tion
Sends input / output signals in units of bits and input / output data in
units of words to the master station by cyclic transmission. Returns a re-
sponse to a transient transmission (request) from another station.
Local station
Communicates with the master station and other local stations by cyclic
transmission and transient transmission.
Controller - Master unit A controller equipped with power supply, external I/O, and analog cur-
rent output wires, and which can be used on a standalone basis.
Controller - Slave unit A controller that is connected to a master unit.
CC-Link dedicated
cable
Cable certified by CC-Link Partner Association (shielded 3-conductor
twisted-pair cable).
End plates or commer-
cially available ttings
When the product is connected to a controller, the end plates secure
the units at both ends to prevent the connector from disconnecting and
causing a communication failure.

Before Using This Product
WUME-SCHG1C-41-6
1-4 Contents of package
The following accessories are included in the product package. Before using the product, make
sure that no items are missing.
●Communication unit: 1 pc. ●Instruction manual
●General Information
for Safety,Compliance,
and Instructions

Before Using This Product
WUME-SCHG1C-4 1-7
1-5 Description of parts
1 2 3
457 68
10
9
11
<Switch cover removed>
Name Function
1Station number setting
switch
Set the CC-Link station number to a value from 1 to 64.
(Do not set to 0, or 65 or higher.)
[Factory default state: 1]
2Communication speed
setting switch
Set the CC-Link communication speed.
0: 156 kbps, 1: 625 kbps, 2: 2.5 Mbps, 3: 5 Mbps, 4: 10 Mbps
[Factory default state: 156 kbps]
3CC-Link connector Connect to the master station or another slave station.
4Male connector Connect to a master controller or slave controller.
5ERR. indicator (Red) Lights up when CC-Link communication is interrupted. Blinks when a communi-
cation error occurs.
6Power indicator (Green) Lights up when power is supplied.
7RD indicator (Green) Lights up during data reception.
8L RUN indicator (Green) Lights up during data link execution.
9SD indicator (Green) Lights up during data sending.
10 L ERR. indicator (Red)
Lights up if the station number setting switch and communication speed setting
switch are in an invalid setting position when the power is turned on.
Blinks if the switch type setting is changed while the power is on.
11 Mode setting switch
Set the communication method and number of occupied stations.
[Factory default state: CC-Link mode 1]
• CC-Link mode 1
SW No. 1 2 3 4 5 6 7 8
ON / OFF ON OFF Not used (Note)
Remarks CC-Link Ver. 1.10, number of occupied stations: 4
• CC-Link mode 2
SW No. 1 2 3 4 5 6 7 8
ON / OFF OFF ON Not used (Note)
Remarks
CC-Link Ver.2.00, Number of occupied stations: 2
stations
Expanded cyclic transmission speed: x8
• CC-Link mode 3
SW No. 1 2 3 4 5 6 7 8
ON / OFF ON ON Not used (Note)
Remarks
CC-Link Ver.2.00, Number of occupied stations: 4
stations
Expanded cyclic transmission speed: x4
Note: Always keep unused switches in the OFF position.

WUME-SCHG1C-41-8
(MEMO)

2-1
2 System Conguration
2-1 Communication unit system ························································· 2-2
2-2 Unit types················································································· 2-4

System Conguration
WUME-SCHG1C-42-2
2-1 Communication unit system
This product is a communication unit for the purpose of monitoring sensor ON / OFF output and
detected quantities using CC-Link communication between controllers and a master station.
This product can connect a maximum of 15 controllers (one master controller, 14 slave controllers).
The CC-Link operation mode can be set to Ver. 1.10 or Ver. 2.00 (2 stations x8 / 4 stations x4)
using the mode setting switch.
The power that drives this product is supplied from a connected controller / master controller.
To master
station
To power supply
To power supply
SC-HG1-C
Controller - master
(optional)
Controllers - slave (optional)
(Maximum of 14 units are
connectable)
MS-DIN-E end plate (optional)
or commercially available tting
Dedicated cable certied by CC-Link
Partner Association
(shielded 3-conductor twisted-pair cable).
(Please obtain separately)

System Conguration
WUME-SCHG1C-4 2-3
<Reference>
●If HG-SC series and HG-TC series controllers are used in combination, connect the slave con-
trollers of the same series as the master controller on the near side of the master controller and
connect the slave controllers of di󰀨erent series from the master controller on the far side of the
master controller.
Example: When the master controller is HG-SC□
Controller - Slave unit
HG-SC□
Controller - Slave unit
HG-TC□
Controller - Master unit
HG-SC□
SC-HG1-C
●If HG-SC series and HG-TC series controllers are used in combination, there are limitations on
the functions below.
Item Description of limitation
1Calculation function
Calculation is only performed when the slave unit is the same series as
the master unit.
Calculation is not performed when the slave unit series is di󰀨erent from
the master unit series. "CALC" does not appear in the displays of a slave
unit of a di󰀨erent series.
2Input all
The master unit only performs input all when the slave unit is the same
series.
A Slave unit of a di󰀨erent series than the master unit are not input even
when the external input settings match those of the master unit.
3Copy function
Copying is only performed when the slave unit is the same series as the
master unit.
"NOW COPY" appears on the displays of the master unit and slave unit
when the slave unit is di󰀨erent series from the master unit, but copying is
not performed.
4Interference prevention This function is only available on the HG-TC series controller. The func-
tion is not executed on the HG-SC series controller.

System Conguration
WUME-SCHG1C-42-4
2-2 Unit types
Communication unit
Product name Appearance Model
CC-Link communication unit
SC-HG1-C
Controller
●HG-SC series
Type Appearance Model Output
Contact-type digital displacement sensor
Master unit
High-performance
type
Analog current
+
I/O
HG-SC101 NPN open-collector transistor
HG-SC101-P PNP open-collector transistor
Slave unit
High-performance
type
Analog current
+
I/O
HG-SC111 NPN open-collector transistor
HG-SC111-P PNP open-collector transistor
Standard type
(I/O)
HG-SC112 NPN open-collector transistor
HG-SC112-P PNP open-collector transistor
Wire-saving type HG-SC113 —
●When connecting slave units to a master unit, connect only NPN output types, or only
PNP output types. Dissimilar output types cannot be connected together.
●If an HG-SC series controller manufactured in January 2019 or earlier is connected to an
HG-TC series controller, operation will not take place normally. If they are used together,
use an HG-SC series controller manufactured in February 2019 or later.
