PROAIM Victor User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Victor Video Producon Camera Cart
(CT-VTBS-36)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Assemb ly Manua l
Top shelf Boom Shelf
4 x (31” Length) Rods
Crossbar
Carrying Handle 2 x Pneumac Tires
without Break 2 x Handles
4mm
Allen Key
2 x Pneumac Tires
with Break

2
• Take out all the parts, as shown in image.
• To keep the cart in stac posion, lock the
wheels by pushing down the lever.
Feature: The wheels have brakes that keep
the cart stable and secure for reliable parking.
• Aer sliding the wheels, lock them with the
knob on top.
• Unlock 4 Pneumac Wheels and slide onto
cart Boom Shelf, as shown in image.
Feature: One wheelset features a 360° swivel
caster complemented by an ecient foot
brake.
• Loosen all the 4 ratchet knobs of lower
shelf’s corner hole as shown in the picture.
Victor Cart Setup
NOTE: Victor Cart comes packed in a compact
rollable suitcase for easy transport. You will
receive all parts of the Cart in one complete
package.
• Open all the lock of the cart.
Pneumac Tires with Break Assembly

3
• Now, ghten all the knobs to ensure proper
aachment of all the rods.
• Loosen the handle to open the clamp.
• Tighten all the 4 corner Rachet knobs of top
shelf so that top shelf doesn't fall down.
• Mount the top shelf on the top of the rods
by aligning it in the corners.
NOTE: Two peoples are needed to assemble
the cart.
• Aach the handle through clamp on the rod
and adjust the handle accordingly.
NOTE: It helps create the leverage needed
while liing the cart quickly over obstacles,
stairs or other incline surfaces.
• Insert all the 4 Rods into 4 corners of
Boom Shelf.
31” (Length) Rod Assembly
Handle Assembly

4
• Loosen the knob to open the clamp of
crossbar.
• Loosen the handle screw using a 4mm Allen
key.
Feature: The cart features dual crossbars that
aach securely to the side for dynamic
accessory mounng, with free and 3/8"
threaded holes.
• Now, the crossbar is xed on the rods, as
shown in the image.
• Tighten the knobs of the crossbar to
securely posion it.
• Set the desired height posion as shown in
image.
Feature: The Ergonomically designed and
rubber-coated handle quickly mounts to the
rods of the Cart without any addional tools.
Crossbar Assembly
Carrying Handle Assembly

5
• Aer aaching the handle put the bolt
ghten the bolts with the help of Allen key.
Feature: Carrying Handle at the side of the
Cart that facilitates ease of movement even
when the Cart is fully loaded.
• All the screws have been removed from the
handle as shown in the image.
• Aach the carrying handle matching the
thread of the lower shelf.
YOUR PROAIM VICTOR VIDEO PRODUCTION CAMERA CART
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
