protech PA-6222 User manual

USER’S
MANUAL
PA-6222
12” Waterproof True Flat
Touch POS Terminal
Powered by Intel®Celeron®
J1900 Quad-Core
PA-6222M2

PA-6222
12” Waterproof True Flat
Touch POS Terminal
Powered by Intel®Celeron®
J1900 Quad-Core
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the property of their
respective owners.
This manual is copyrighted in Feb. 2017. You may not reproduce or transmit in any
form or by any means, electronic, or mechanical, including photocopying and
recording.
DISCLAIMER
This user’s manual is meant to assist users in installing and setting up the system. The
information contained in this document is subject to change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not expressly
approve by the party responsible for compliance could void your authority to operate
such equipment.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And
therefore we strongly recommend that qualified engineers can open and disassemble the
system. The LCD and Touchscreen are easily breakable, please handle them with extra
care.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual…...................................................................
2
1-2 POS System Illustration…............................................................
3
1-3 System Specifications...................................................................
5
1-4 Safety Precautions…....................................................................
9
CHAPTER 2 SYSTEM CONFIGURATION
2-1 System External I/O Port & Pin Assignment……………………
11
2-2 Main Board Component Locations & Jumper Settings………….
16
2-3 VFD Board Component Locations & Pin Assignment.................
31
2-4 MSR Board Component Locations & Pin Assignment.................
33
2-5 Secondary Cash Drawer...............................................................
35
CHAPTER 3 SOFTWARE
3-1 Driver……..…..............................................................................
38
3-2 Embedded Peripheral Devices………..........................................
44
3-3 API………………………………................................................
70
3-4 BIOS Operation….……...............................................................
78
3-5 Watchdog Timer Configuration…………………………………
114
3-6 BIOS Update Instructions……………………………………….
117
3-7 System Resource Map…………………………………………...
121
CHAPTER 4 SYSTEM DIAGRAMS
Exploded Diagram for Cable cover..……………………………………
138
Exploded Diagram for Storage….………………………........................
139
Exploded Diagram for Back Cover………………………......................
140
Exploded Diagram for LCD & Touch Panel…………………..………..
143
Exploded Diagram for Inside Case……………………….......................
145
Exploded Diagram for MSR……...………………………......................
147
Exploded Diagram for 2nd Display…...……………………....................
149
Exploded Diagram for Stand………………............................................
150
Exploded Diagram for PPC Packing……………....................................
152
Exploded Diagram for POS Packing……………....................................
154
Exploded Diagram for Stand Packing……...……...................................
155

PA-6222 SERIES USER  S MANUAL
Page: 1
INTRODUCTION
This chapter gives you the information for the PA-6222. It also outlines
the system specifications.
Sections included:
About This Manual
POS System Illustration
System Specifications
Safety precautions
Experienced users can jump to chapter 2 on page 2-1
for a quick start.
CHAPTER
1

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 2
1-1. ABOUT THIS MANUAL
Thank you for purchasing our PA-6222 Series System. The PA-6222 is an updated
system designed to be comparable with the highest performance of IBM AT personal
computers. The PA-6222 provides faster processing speed, greater expandability and
can handle more tasks than before. This manual is designed to assist you how to install
and set up the whole system. It contains four chapters. Users can configure the system
according to their own needs.
Chapter 1 Introduction
This chapter introduces you to the background of this manual. It also includes
illustrations and specifications for the whole system. The final section of this chapter
indicates some safety reminders on how to take care of your system.
Chapter 2 System Configuration
This chapter outlines the location of motherboard, printer, VFD, MSR components
and their function. You will learn how to set the jumpers and configure the system to
meet your own needs.
Chapter 3 Software
This chapter contains detailed information for driver installations of the Intel® Utility,
VGA, LAN, Sound, Touch Screen, embedded peripheral devices, BIOS setup &
update, Watchdog timer and resource map.
Chapter 4 System Diagrams
This chapter shows the exploded diagrams and part numbers of PA-6222 components.

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 3
1-2. POS SYSTEM ILLUSTRATION
Small stand type
Front View
Rear View
Top View
Side View
Unit: mm

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 4
Stand-less type
Front View
Side View
Unit: mm

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 5
1-3. SYSTEM SPECIFICATIONS
System
CPU
Intel® Celeron® J1900
Memory
DDR3L SO-DIMM(up to 8GB)
OS Support
Windows POSReady7
Windows 8.1
Windows 10 IoT Enterprise LTSB 2016
LAN
1 x RJ45
VGA
1 x DB-15
Wireless LAN (Optional)
802.11 b/g/n
AP distance
0˚
90˚
180˚
270˚
5M
-48 dB
-45 dB
-49 dB
-43 dB
10M
-46 dB
-50 dB
-52 dB
-50 dB
Note:
1. Test tolerance: ± 5dB
2. AP: ASUS RT-N56U (2 x internal antenna with 3.8
dBi gain)
Angle: 0° Angle: 270°Angle: 180°Angle: 90°
AP
(Distance)
AP

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 6
Audio
2W speaker
System Weight
5kg, PPC only：3.2kg
Dimension (W x H x D)
320 x 303 x 236 mm
Network
10/100/1000M
Mounting Type
Support VESA 75/100
Line Out
1 x phone jack
Cash Drawer
1 x RJ11(+12/24V selectable)
DC-in
1 x 4pin DC Power Jack
Viewing Angel
24~30˚
Serial Ports
3 x RJ45, 1 x RJ45 optional(+5V/12V selectable)

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 7
Power Supply: 72 Watt power adapter
Power Consumption
(AC):
System
Status
CPU/
HDD/ Memory
COM & USB Ports to supply
power of Rear I/O
Consumption
OFF
Off
Without
1.6W
IDLE
Turns on, but not to
execute extra AP
14.7W
Full
Loading
100% loading of burn-
in test
18.7W
USB dummy load 500mA x4
29.5W
Certificate: CE/ FCC
Type
Standard
Description
EMI
EN 55022 Class A
-
EMS
EN 55024
-
IEC 61000-4-2
ESD
8kV air discharge
4kV contact discharge
IEC 61000-4-3
RS
80~1000MHz, 3V/m, 80% AM(1kHz)
IEC 61000-4-4
EFT
AC Power Port: 1kV
DC Power Port: 0.5kV
Signal Ports & Telecommunication
Ports: 0.5kV
IEC 61000-4-5
Surge
AC Power Port:
Line to line: 1kV
Line to earth(GND): 2kV
DC Power Port:
Line to earth(GND): 0.5kV
Signal and Telecommunication Port:
Line to GND: 1kV
IEC 61000-4-6
CS
0.15~80MHz, 3Vrms, 80% AM, 1kHz
IEC 61000-4-8
PFMF
50Hz, 1A/m
IEC 61000-4-11
Voltage Dips
> 95% reduction for 0.5 periods
30% reduction for 25 periods
Voltage Interruptions
> 95% reduction for 250 periods

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 8
Display
Customer Display
12” TFT LCD
Resolution: 1024 x 768
Touchscreen
Bezel-Free 5-wire resistive touch
Brightness
500 cd/m2 LED Backlight
Environment
Temperature
Operating: 0~35°C (32 ~ 95°F)
Storage: -5~60°C (-4 ~ 140°F)
Humidity
20~90%
Optional accessories
MSR & i-Button
JIS-I or II, ISO Track1+2+3
Fingerprint
8-bit grayscale reader
2nd Display
8” LCD or 10.4” LCD
Customer Display
VFD, 20 columns and 2 lines, each column is 5 x 7 dots

Chapter 1 Introduction
PA-6222 SERIES USER  S MANUAL
Page: 9
1-4. SAFETY PRECAUTIONS
The following messages are safety reminders on how to protect your systems from
damages, and extending the life cycle of the system.
1. Check the Line Voltage
a. The operating voltage for the power supply should be within the range of
100V to 240V AC; otherwise the system may be damaged.
2. Environmental Conditions
a. Place your PA-6222 on a sturdy, level surface. Be sure to allow enough
space around the system to have easy access needs.
b. Avoid installing your PA-6222 Series POS system in extremely hot or cold
places.
c. Avoid exposure to sunlight for a long period of time (for example, in a
closed car in summer time. Also avoid the system from any heating device.).
Or do not use the PA-6222 when it has been left outdoors in a cold winter
day.
d. Bear in mind that the operating ambient temperature is between 0C and
35C (32F and 95F).
e. Avoid moving the system rapidly from a hot place to a cold place, and vice
versa, because condensation may occur inside the system.
f. Protect your PA-6222 against strong vibrations, which may cause hard disk
failure.
g. Do not place the system too close to any radio-active device. Radio-active
device may cause signal interference.
h. Always shutdown the operation system before turning off the power.
3. Handling
a. Avoid placing heavy objects on the top of the system.
b. Do not turn the system upside down. This may cause the hard drive to
malfunction.
c. Do not allow any objects to fall into this product.
d. If water or other liquid spills into the product, unplug the power cord
immediately.

PA-6222 SERIES USER’S MANUAL
Page: 10
SYSTEM
CONFIGURATION
Helpful information that describes the jumper and connector settings,
component locations, and pin assignment.
Sections included:
External I/O Port Pin Assignment
How to Set Jumpers
Component Locations & Jumper Settings
-Mainboard
-VFD Board (peripheral device)
-MSR Board (peripheral device)
Secondary Cash Drawer Port
CHAPTER
2

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page: 11
2-1. SYSTEM EXTERNAL I/O PORT & PIN ASSIGNMENT
Rear I/O
Side I/O
Power USB4
button

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page:12
Power Button
To turn on the system, press the power button on the side
of the system briefly.
ACTION
ASSIGNMENT
Click
0V
Release
+3.3V
DC-IN Port
DC-IN: DC Power-In Port (rear IO)
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
GND
3
+24V
2
GND
4
+24V
VGA Port
VGA: VGA Port, D-Sub 15-pin (rear IO)
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
RED
9
+5V
2
GREEN
10
GND
3
BLUE
11
NC
4
NC
12
DDCA DATA
5
GND
13
HSYNC
6
GND
14
VSYNC
7
GND
15
DDCA CLK
8
GND
3 4
1 2
DC-IN
Power
Button
15 610 1115
VGA

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page: 13
COM Port
COM1, COM2, COM3: COM Ports (rear IO)
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
DCD1/2/3
6
DSR1/2/3
2
RXD1/2/3
7
RTS1/2/3
3
TXD1/2/3
8
CTS1/2/3
4
DTR1/2/3
9
RI/+5V/+12V
selectable
(Maximum
current: 1A)
5
GND
10
NC
USB Port
USB0, USB1, USB2, USB3, USB4: USB Port Type A Ports
USB0~3: Real I/O
USB4: Side IO
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
+5V(Maximum
current: 0.5A)
3
D+
2
D-
4
GND
101
COM1/
COM2/
COM3
1 4
USB0/
USB1/
USB2/
USB4/
1 4
USB3

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page:14
LAN Port
LAN: LAN RJ45 Port (rear IO)
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
MDI_0P
5
MDI_2N
2
MDI_0N
6
MDI_1N
3
MDI_1P
7
MDI_3P
4
MDI_2P
8
MDI_3N
LAN LED Indicator:
Left Side LED
Yellow Color Blinking
LAN Message Active
Off
No LAN Message Active
Right Side LED
Green Color On
10/100Mbps LAN Speed Indicator
Orange Color on
Giga LAN Speed Indicator
Off
No LAN switch/ hub connected.
2nd Display Power Port (Optional)
2nd DIS PWR: DV12 Power Supply of 2nd Display
PIN
ASSIGNMENT
1
VCC12
2
GND
3
VCC12
Yellow Green
8 1
LAN
1 3
2ND DIS PWR

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page: 15
DC 24V Port (Optional)
DC 24V Port: DC24V power supply for the stand-printer
PIN
ASSIGNMENT
P1
GNDV
P2
+24V
P3
NA
Cash Drawer Port
DRW1, DRW1-1, DRW1-2: Signal from M/B GPIO (rear I/O)
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
GND
4
+12V/+24V (Max. current: 1A)
2
Drawer Open
5
NC
3
Drawer Sense
6
GND
DRW1
Open
Close
PB-6822RA, RB
Write
To
Write
To
700h
588h
000h
588h
PB-6822RC
Write
To
Write
To
02h
SIO LDN
06h’s 90h
00h
SIO LDN
06h’s 90h
16
DRW1
DC 24V Port

Chapter 2 System Configuration
PA-6222 SERIES USER’S MANUAL
Page:16
2-2. MAINBOARD COMPONENT LOCATIONS & JUMPER
SETTINGS
M/B: PB-6822
SW1_2
SPK2
PS/2_1
1
5
TOUCH1
LED1_1
LED1_3
1
LVDS1 USB7 J3
JP_VDD1
JP_12 JP_8 JP_9
USB1
JP32
SW1_3
JP19
JP30
USB2
COM1_1
COM4_1 COM2_1 COM3_1
JP_COM4 JP_COM3 JP_COM2
JP_COM1
PRT_PWR1
PWR_IN1 VGA1 USB8LAN1 LINE-OUT1
JP31
USB4
SW1
USB6
JI_BUTTON1
PS/2_2
SP1
SPK1
SLOT1
COM4_2
JP20 JP21 JP22
COM2
COM3
DC5V_PWR1
JP37
JP29
JP5
DC12V_PWR1
LPT1
J2 SATA2
SATA1
JPWR_4P2
JPWR_4P1
JP14
JP15
JINV4
JINV1
JP4
JP3
JP38JP39
30
291
2
Battery
1
1
1
1
1 31 4
1
6
5
10
14
1
1
111 21 21 2
5 65 65 6
5
2
6
1
1
1
1
1
12
910
6
11
6
1
1
15 15
1
5
115 17 51
216 18 52
1
4
1
1
27 8
1
10
5
6
1
6
111
22
5
56
5
6
6
1
1
4
1
2
6
10
5
10
5
26
13
14
1
1 4
1 4
1 7
1 7 Intel®
Celeron®J1900
Quad-Core DIMM1
1
2
71
72
73
74
203
204
ESATA1 DRW1
15
1
61
1
PB-6822 Mainboard Component Locations
