Qlight SAOL1 User manual

1
5030
56
SAOL1 - 12/24 - R
[Model number] [Voltage] [Color]
| | |
• SAOL1 • 12-DC12V
• 24-DC24V
• 110/220-AC110V-220V
R-Red
Low Intensity LED Aviation Obstruction Light
SAOL1
Please scan the QR code for more
detailed product information.
www.qlight.com
Ordering Specications
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
    ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
    malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
    follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
    follow this may cause damage to property, ¿re, electric shock and loss of life.)
All manuals and user guides at all-guides.com

2
Model number SAOL1
Type
Low intensity A type
Light source High intensity light emitting diodes(LED)
Light color RED
Luminous
intensity 17cd ±25%
Housing color Black
Light function Steady
Rated voltage
DC12V, DC24V, AC110V-220V
Power consumption
9W
Materials
Lens : PC, Housing : PC, Lens ring : STS316L, Pole : STS304, Bracket : Al
Weight(Approx.)
0.98Kg
Cable entry
Ø20
Certi¿cate
, ICAO
Protection rating
IP56
Ambient operating
temperature
-30°C to +50°C
※CE compliant
: DC24V
■
General Product Specications
■
Classication of Aviation Obstruction Lights
■
Application Areas of Aviation Obstruction Lights
Objects inside the
Obstacle Restriction Area
Obstacle certi¿ed for use at night that is 60m from the ground and is located within the Obstacle Restriction Area of
an airport
Objects outside the
Obstacle Restriction Area
Obstacle that is 150m from the ground
Chimneys, steel towers, poles, frame structures, electricity pylons, or wind turbines that are 60m from the ground
Product Specications
Low intensity A type
or low intensity B type
obstruction light
Obstacle that is 150m from the ground and is located within the Obstacle RestrictionArea
Low intensityAtype model is installed on ab obstacle that has limited mobility such as a boarding bridge
Low intensity C type
obstruction light
Low intensity C type model(Blue/ashing) is installed on an emergency vehicle or security vehicle operated inside the airport
Low intensity C type model(Yellow/ashing) is installed on a normal vehicle or mobilize object that is operated inside the airport
Low intensity D type
obstruction light
Low intensity D type model(Yellow/ashing) is installed on escort vehicles that are operated inside the airport
Medium intensity A type
obstruction light
Medium intensity A type warning light(White/ashing) is installed in areas where trees or buildings are widespread
Obstacle that is 45m from the ground and is located within the Obstacle Restriction Area or an obstacle that is 150m from
the ground and is located outside the Obstacle RestrictionArea
Medium intensity B type
obstruction light
Medium intensity B type warning light(Red/ashing) is installed in areas where trees or buildings are widespread.
Obstacle that is 45m from the ground and is located within the Obstacle Restriction Area or an obstacle that is 150m from
the ground and is located outside the Obstacle RestrictionArea
Medium intensity C type
obstruction light
Medium intensity C type warning light(Red/steady) is installed in areas where trees or buildings are widespread
Obstacle that is 45m from the ground and is located within within the Obstacle RestrictionArea or an obstacle that is 150m
from the ground and is located outside the Obstacle RestrictionArea
Medium intensity C type warning light(Red/stead) cannot be used with other warning lights
All manuals and user guides at all-guides.com

3
Dimensions Wiring Instructions
• External power line - UL2464 AWG18(0.75sq) 400mm
• This product can be wired regardless of polarity.
(Units : mm)
Ø115
Ø90
275
18155 39
4-Ø5 FITTING HOLES
Ø20 CABLE ENTRYPCD 73
Red
Black
White
Black
Power
Power
Fuse
Fuse
DC
AC
SAOL1
Parts Denition/ Installation/ Mounting Hole Specications
■
Parts Denition
• First, machine taps or holes on the mounting surface ①.
• The mounting hole of this product is 5mm in diameter.
• When machining taps, fasten the bolt through the mounting hole of the product.
• When machining holes, insert the bolt through the hole of the product, and tighten the nut from the opposite side of the mounting surface.
■
Installation
①
■
Mounting Hole Specications
• Machine holes on the mounting surface referring
to the diagram below.
4-Ø5.5 HOLES
Min.Ø5 CABLE ENTRY
PCD 73
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP56.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
  indicated(IP56), it may cause malfunction or damage to the product.
• For further information, please visit our website (www.qlight.com).
Lens(PC)
Housing(PC)
Pipe(AI)
Bracket(AI)
All manuals and user guides at all-guides.com

Qlight Co., Ltd. www.qlight.com | [email protected]
Head O-ce | Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea
                       Tel. +82-2-2679-6152(Toll free. +82-80-328-2222)  Fax. +82-2-2679-6154
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. +82-55-328-1111(Toll free. +82-80-328-1111)
Qlight OverSEAs Sales Dept | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : +82-51-620-4100
Qlight Public Relations & Marketing Team O-ce | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel. +82-51-245-0017
Qlight USA, Inc. www.qlight.com www.qlightusa.com | [email protected]
3003 North First Street, Suite #341, San Jose, CA 95134 USA Tel. +1 - 408 - 519 - 5740  Fax. +1 - 408 - 519 - 5739
SHANGHAI Qlight Electronic Co., Ltd. www.qlight.com www.qlightcn.com | [email protected]
China Factory/ Shanghai Sales O-ce | #19, Nanda Road, Baoshan Area, Shanghai, China Tel. +86 - 21 - 6651 - 7100 Fax. +86 - 21 - 6315 - 3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China  
Tel +86 - 513 - 8384 - 9999 Fax +86 - 513 - 8384 - 9910
Product Operation Inquiry / Customer Support [phone]
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
    RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea ( Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea ( Postal Code : 50805)
For your safety
Speci¿cation and dimensions listed in this catalogue subject to change without notice for product quality improvement.
The newest product information is available on our website.(www.qlight.com)
Please read the instruction manual attached to the product carefully before installation and use.
