Qlight QWSL150 User manual



Thank you for purchasing QLight product. Please read this manual
carefully before installing the product for safe and long use.
▪As taking the source of SMD type LED light, the product has a low
power consumption and economical cost of maintenance.
▪Aluminum die casting product is strong against the vibration, impact
and has excellent heat-resistant effect.
▪Direct Mounting or bracket mounting types are available.
▪The product has a protection class IP67 and perform stably under
the hazardous environment where exits cutting oil, dust and shaving
chip.
▪Material: Body-AL, Bracket-SUS430, Lens-Tempered glass
▪Protection class: IP67
▪
General Specification
Model
Voltage
Current
Weight
Brightness
(Lux)
Color
QWSL150,
QWSL150-
QBK03
DC24V
0.550A
0.90Kg
450 Lux
White-
W
QWSL250,
QWSL250-
QBK03
DC24V
1.150A
1.00Kg
950 Lux
(The weight information above is only for QWSL150/QWSL250.)
1) QWSL150

2)
QWSL150-QBK03

3) QWSL250


4)
QWSL250-QBK03

OPERATING MANUAL
LED Work Light
Product Specification
External View Drawing
QWSL150(QBK)/QWSL250(QBK)
www.microlectra bv. [email protected]

The product has a power line, LAPP KABEL CLASSIC 400P 0.75sq X
2C 400mm, coming out from the product.
▪In case of using DC voltage, the product has a bridge circuit inside,
therefore lines can be connected regardless of the polarity(Ref. wire
color).
▪The structure of the product is manufactured for indoor use. Installation
in any direction is okay for indoor use.
▪Mount at a place where exists low vibration, impact, moisture and dust
as long as possible.
▪Refer to below information and drill the hole in a suitable part of the
product. (Make sure the PCD from the external view drawing.)
▪QWSL150/QWSL250: Fix the product by using extra mounting bolt
(M4-4EA).
QWSL150
QWSL250
▪QWSL150-QBK03 / QWSL250-QBK03: Fix the product by using the
attached mounting bolt(M6-3EA).
QWSL150-QBK03 / QWSL250-QBK03
▪For left/right side angle adjustment, loose the fixing bolt ①on the
bracket and adjust the angle. (Refer to the product structure drawing)
▪For up/down side angle adjustment, loose the fixing bolt ②on the
bracket and adjust the angle. (Refer to the product structure drawing)
▪The product is designed for an explosion proof, water proof and dust
proof product. When disassembling and assembling the product, please
make sure all the parts are well connected and check the bolts are
completely airtight.
▪If voltage goes seriously higher or lower than the rated voltage, it can
cause the reduction of the life span of the product or cause an operating
problem. Make sure the voltage does not exceed +/-5% of the rated
voltage.
▪Please keep the product from chemical substance such as thinner or
benzene. Lens or body of the product can be damaged, discolored or
deformed by chemicals.
Product Structure
Wiring Instruction
Mounting
Caution
www.microlectra bv. [email protected]

Situation
Main reason
Solution
Partly Non- Lighting
LED is partly damaged
or supplied higher
voltage than a rated
voltage.
Check the using voltage
Dim Lighting
Supplied lower voltage
than a rated voltage
Check the using voltage
No Lighting
Wrong Wiring
Check the wiring
No Power Supply
Check the power supply
Trouble shooting
