Qlight STDL User manual
1
5030
54
105
HORN
LED Steady/Flashing Tower Light and Alarm Sounder Combinations
STDL(F)
Ordering Specications
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the Power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the Power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, ¿re, electric shock and loss of life.)
STDL - WA - 3 - 24 - R
[Model number]
[Sound]
[Layer] [Voltage] [Color]
| | | | |
• STDL
• STDLF • WS- Warning sounds
• WM- Melodies
• WA- Alarms
• WV- Customizable sounds
• Layer1-1
• Layer2-2
• Layer3-3
• Layer4-4
• Layer5-5
• 12-DC12V
• 24-DC24V
• 110- AC110V
• 220- AC220V
R-Red
A-Amber
G-Green
B-Blue
W-White
Please scan the QR code
for more
detailed product information.
www.qlight.com
2
Model number
Layer Voltage
Current
Sound pattern and volume
Certi¿cate
Weight
Color
STDL
steady
STDLF
steady/ashing
1
DC12V 0.380A
•
WS-5
Warning sounds
: Max.105dB
• WM-5
Melodies
: Max.105dB
• WA-5
Alarms
: Max.103dB
• WV-5
Customizable sounds
:91-100dB
0.80kg
R-Red
DC24V 0.330A 0.80kg
AC110V 0.115A
1.39kg
AC220V 0.058A
1.39kg
2
DC12V 0.490A
0.91kg
R-Red
A-Amber
DC24V 0.440A
0.91kg
AC110V 0.121A
1.36kg
AC220V 0.061A
1.36kg
3
DC12V 0.600A
1.05kg R-Red
A-Amber
G-Green
DC24V 0.550A
1.05kg
AC110V 0.127A
1.49kg
AC220V 0.064A
1.49kg
4
DC12V 0.710A
1.16kg R-Red
A-Amber
G-Green
B-Blue
DC24V 0.660A
1.16kg
AC110V 0.133A
1.61kg
AC220V 0.067A
1.61kg
5
DC12V 0.820A
1.30kg R-Red
A-Amber
G-Green
B-Blue
W-White
DC24V 0.770A
1.30kg
AC110V 0.139A
1.74kg
AC220V 0.070A
1.74kg
STDL/ STDLF
Product Specications
Dimensions
(Units : mm)
L
70
15
112
152
Ø119
10
Ø80
PCD70
360°/3-M5 BOLT
Ø8 CABLE ENTRY
LAYER
1
2
3
4
5
L
232
302
372
442
512
• Protection rating : IP54
• Ambient operating temperature : -30°C to +50°C
※CE compliant : DC24V
※Max. built-in volume feature is based on WS-Ch3 / WM-Ch4 / WA-Ch1.
※ In case of customized WV 5 tone type, there may be di-•erence of volume depending on user’s audio ¿le type
3
Wiring Instructions
STDL-DC/AC(
steady
) STDLF-DC/AC(
steady/ashing
)
Ch 1
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
Ch 1
Layer1 Layer1
External Contact External Contact
Ch 2 Ch 2
Layer2 Layer2
Ch 3 Ch 3
Layer3 Layer3
Ch 4 Ch 4
Layer4 Layer4
Ch 5 Ch 5
Layer5 Layer5
Fuse Fuse
Flash
Steady
Steady
Common
Common
Common
Power Power
• External Power line - UL1015 AWG18(0.75sq) x 2C 400mm
External signal line - UL1007 AWG22(0.3sq) 400mm
• This product can be wired regardless of polarity.
STDL-DC/AC(
steady
) STDLF-DC/AC(
steady/ashing
)
Fuse Fuse
Steady
Steady
Common
Common
Common
Power Power
External transistor-NPN External transistor-NPN
Layer1
Layer2
Layer3
Layer4
Layer5
Layer1
Layer2
Layer3
Layer4
Layer5
Layer1
Layer2
Layer3
Layer4
Layer5
Ch 1
Ch 2
Ch 3
Ch 4
Ch 5
Ch 1
Ch 2
Ch 3
Ch 4
Ch 5
Flash
White(W)
or Red(R)
Black(BK)
Black(BK)
Red( R)
Amber(A)
Green(G)
Blue(B)
White(W)
Gray/Red(GR/ R)
Gray/Amber(GR/A)
Gray/Blue(GR/ B)
Gray/Green(GR/ G)
Gray/White(GR/ W)
Violet(VI)
White(W) or Red( R)
Black(BK)
Black(BK)
Red( R)
Amber(A)
Green(G)
Blue(B)
White(W)
Gray/Red(GR/ R)
Gray/Amber(GR/A)
Gray/Blue(GR/ B)
Gray/Green(GR/ G)
Gray/White(GR/ W)
White(W) or Red( R)
Black(BK)
Black(BK)
Red( R)
Amber(A)
Green(G)
Blue(B)
White(W)
Gray/Red(GR/ R)
Gray/Amber(GR/A)
Gray/Blue(GR/ B)
Gray/Green(GR/ G)
Gray/White(GR/ W)
White(W) or Red( R)
Black(BK)
Black(BK)
Violet(VI)
Red( R)
Amber(A)
Green(G)
Blue(B)
White(W)
Gray/Red(GR/ R)
Gray/Amber(GR/A)
Gray/Blue(GR/ B)
Gray/Green(GR/ G)
Gray/White(GR/ W)
4
• First, remove the ange nuts from bolts and place the
product through the mounting surface holes.
• Fasten the ange nuts on the opposite side of the mounting
surface until the product is tightened securely.
STDL/ STDLF
Cover(ABS)
Lens(AS)
Long bolt
Rubber spacer
Housing(ABS)
Cover connector
(ABS)
Resonator(ABS)
Flange nut
3-
Ø
6 HOLES
Min.Ø5 CABLE ENTRY
PCD70
※ Caution when dealing with lens kit
• Lens kits are connected with connector pins each other. Bad connection
may be experienced when the connector pins are touched with a foreign
substance.
•
If the lens kits are not turned on or not ashed after lens kits replacement,
please make sure status of lens kit connection.
How to Change Lens Kit
Parts Denition/ Installation
• When rearranging or replacing the lens kits, please be aware of the
contact point ① and the connector pin ②marked in the diagram on
the left.
• Press down to assemble the lens kits while making sure that connector
pin ②and connector ③aligns correctly.
• Please make sure that the rubber spacer placed on the top of each
lens kit is tightly secured to the bottom of the other lens kit.
Mounting Hole Specications
• Machine holes on the mounting surface refer-
ring to the diagram below.
②
③
①
5
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP54.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP54), it may cause malfunction or damage to the product.
• In case of outdoor applications, install the product in the upright position. Do not install the product horizontal or upside down posi-
tions where water can potentially penetrate into the product and impact it’s operation.
• For further information, please visit our website (www.qlight.com).
Dimensions
STDL(F)
SWP125 SWM125
Ø22
PCD60~70
PCD50
PCD85
Ø10 CABLE ENTRY
360°/ 3-
Ø5.5 HOLES
6-Ø5.5 HOLES
4-Ø5.5 HOLES
26.511.5
115
70
90
65
Ø22
PCD60~70
PCD50
PCD85
Ø10 CABLE ENTRY
360°/ 3-
Ø5.5 HOLES
6-Ø5.5 HOLES
4-Ø5.5 HOLES
26.511.5
117
70
94
69
Mounting Accessories (Sold Separately)
• Please refer to the dimensions below for installation of mounting brackets
• The volume output of this product
is adjustable.
• Turn the volume dial clockwise to
increase the volume, and turn
counter clockwise to decrease the
volume.
• There will be no sound when the
dial is put at MIN.
Volume Dial
VOL.
MAX. MIN.
Volume Adjustment
Category
Sound pattern
Channel Sound tone Volume
(Max.)
WS
5 Warning
sounds
Ch1
Fire
Max.
105dB
Ch2
Emergency
Ch3
Ambulance
Ch4
Machinery Fault
Ch5
High Expansion
WM
5 Melodies
Ch1
Sweet Home
Max.
103dB
Ch2
For Elise
Ch3
Cuckoo's Waltz
Ch4
Piano Sonata
Ch5
Turkish March
WA
5 Alarms
Ch1
Beep Intermittent
Max.
103dB
Ch2
Door Chime
Ch3
Phone Ring
Ch4
PI.PI.PI Short
Ch5
Tripping Beat
WV
5
Customizable
sounds
Ch1-
Ch5
Available upon
request(customized
voice type)
91-
100dB
• The standard type product has a tone setting switch and volume
control built-in inside the product.
• Select the desired channel using the channel selection switch
• For tone group settings, refer to the website [Customer Support] -
[Technical Data] - [Types of Tone and Combination of General
Tone products].
Sound Type by Group
Sound group switch
Volume Dial
※ In case of customized WV 5 tone type, there may be di-•erence of
volume depending on user’s audio ¿le type.
■ Sound Type by Group
Product installation direction
■ Install the product in accordance with the manual. Otherwise rainwater or moisture may penetrate into the product.
ㆍ ELECTRONIC SOUNDER/SIGNAL HORN
Sounder part shall not be facing the sky.
Sounder part shall not be facing the sky.
ㆍBEACON/SIGNALING LIGHT
Power cord inlet part shall not be facing the sky.
Power cord inlet part shall not be facing the sky.
ㆍSIGNAL TOWER LIGHTS
ㆍHEAVY-DUTY & EXPLOSION PROOF SIGNALINGS
※For products with a protection rating of less than IPX4, please install it vertically.
※For products with a protection rating of less than IPX4, please install it vertically.
MEMO
Head O-ce | Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea
Tel. +82-2-2679-6152(Toll free. +82-80-328-2222) Fax. +82-2-2679-6154
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. +82-55-328-1111(Toll free. +82-80-328-1111)
Qlight Overseas Sales Dept |
704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : +82-51-620-4100
Qlight Public Relations & Marketing Team O-ce | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel. +82-51-245-0017
China Factory/ Shanghai Sales O-ce | #Room 333 Building B, #11, Lane 450, Zhenda Road, Baoshan District, Shanghai, China
Tel. +86
-
21
-
6651
-
7100 Fax. +86
-
21
-
6315
-
3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China
Tel +86
-
513
-
8384
-
9999 Fax +86
-
513
-
8384
-
9910
Product Operation Inquiry / Customer Support +82-51-620-4100
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea ( Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea ( Postal Code : 50805)
For your safety
Speci¿cation and dimensions listed in this catalogue subject to change without notice for product quality improvement.
The newest product information is available on our website.(www.qlight.com)
Please read the instruction manual attached to the product carefully before installation and use.
www.qlight.com
EN - STDL - 2401A
This manual suits for next models
1
Other Qlight Lighting Equipment manuals
Qlight
Qlight MTG60 Series User manual
Qlight
Qlight QWHL150 User manual
Qlight
Qlight ST45ML Series User manual
Qlight
Qlight ST45ML-Ex User manual
Qlight
Qlight S60LR User manual
Qlight
Qlight SAMP User manual
Qlight
Qlight SMCL80 User manual
Qlight
Qlight ST45ML Series User manual
Qlight
Qlight QT50L-USB-BZ User manual
Qlight
Qlight S80ADR User manual
Qlight
Qlight SESA User manual
Qlight
Qlight STA35SL Series User manual
Qlight
Qlight SHD User manual
Qlight
Qlight ST45L-ETN-BZ User manual
Qlight
Qlight SAOL1 User manual
Qlight
Qlight QTG-WIZ User manual
Qlight
Qlight QWCD35-TI User manual
Qlight
Qlight S80AR User manual
Qlight
Qlight ST45ML-NEC User manual
Qlight
Qlight SH1S User manual
Popular Lighting Equipment manuals by other brands
Chimera
Chimera 1652 Instructions for care and use
ColorKey
ColorKey Kraken FX user manual
Ubiquiti
Ubiquiti ULED-AT quick start guide
Lightolier
Lightolier Lighting Systems CD7-2 Specification sheet
B-K lighting
B-K lighting SQUARE ADJUSTABLE WELL STAR installation instructions
Lexing
Lexing LX-LD105P-ADS quick start guide
