FITTING INSTRUCTIONS FOR CP0522 AERO CRASH PROTECTORS
HONDA CB125R 2021-
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE.
SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
PLEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING.
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
PLEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
MOUNTING TO THE BIKE.
IN THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS,
THESE RUBBER WASHERS CAN BE THROWN AWAY.
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM

Page 2of 15 CP0522
R&G Racing
Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: [phone] Fax: [phone] www.rg-racing.com Email: [e-mail]
TOOLS REQUIRED
•SOCKET & WRENCH SET INCLUDING 13mm TO
17mm SOCKETS.
•TORQUE WRENCH (UP TO 50Nm)
•SUITABLE SUPPORT JACK
GENERAL TORQUE SETTINGS
M4 BOLT = 8Nm
M5 BOLT = 12Nm
M6 BOLT = 15Nm
M8 BOLT = 20Nm
M10 BOLT = 40Nm
M12 BOLT = 40Nm
LEGEND
ITEM NO. DESCRIPTION QTY
ITEM 1
B0431
AERO BOBBINS (BOTH SIDES)
2
ITEM 2
BC0002
BOBBIN CAPS (BOTH SIDES)
2
ITEM 3
S1134
TWO Ø SPACER 57.6mm LONG (BLACK) (BOTH SIDES)
2
ITEM 4
EB102 (M10x375mm)
ENGINE BAR
1
ITEM 5
M10x1.25
NYLOC NUTS (BOTH SIDES)
2
ITEM 6
M10 WASHERS
19mm OD
2
ITEM 7
LW0001
LOCKING WASHERS (BOTH SIDES)
2
AERO-STYLE CRASH PROTECTOR ORIENTATION

Page 3of 15 CP0522
R&G Racing
Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: [phone] Fax: [phone] www.rg-racing.com Email: [e-mail]
EXPLODED ASSEMBLY VIEW
FITTING PICTURES
Picture 1
4
1
3
2
5
6
7
3
1
6
2
5
7

Page 4of 15 CP0522
R&G Racing
Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: [phone] Fax: [phone] www.rg-racing.com Email: [e-mail]
FITTING INSTRUCTIONS
Before removing engine bolts, ensure the bike is upright and supported by a suitable engine
stand or jack placed under the sump of the motorbike to support the partial weight of the
engine, this will prevent the engine from moving during fitting.
PREPARATION:
•Place a suitable jack beneath the engine in a central position using a piece of wood or plastic
between the jack and engine.
•Apply very light pressure to the underside of the engine to support the engine during the
fitment process.
Assemble the crash protectors before removing the engine bolts to limit the amount
of time the engine is partially un-supported.
•Place one of the nyloc nuts (ITEM 5) on the engine bar (ITEM 4), followed by a penny washer
(ITEM 6) and shake proof washer (ITEM 7).
•Insert the engine bar (ITEM 4) with washers into the aero bobbin (ITEM 1) followed a spacer
(ITEM 3), as shown in Picture 2.
INSTALLATION:
•Remove the OEM engine mounting nut highlighted in Picture 1.
•Using the partially assembled engine bar (ITEM 4), push out the OEM engine mounting bolt
until the inner face of the spacer (ITEM 3) is touching the frame.
NOTE: To avoid cross threading apply forward pressure to the bolt and rotate counter-
clockwise until a click is heard then begin to turn clockwise & tighten.
•Now to assemble the LHS, slide the remaining spacer (ITEM 3) onto the engine bar (ITEM 4),
followed by the remaining aero bobbin (ITEM 1), next the locking washer (ITEM 7) and lastly
the penny washer (ITEM 6).
•To secure the bobbin in place, wind on the remaining nyloc nut (ITEM Using a torque wrench,
tighten the bolt to 45 Nm. You may need to hold the bobbin in position to prevent it turning
while tightening the bolt.
•Once completed, double check torque settings & the position/orientation of the bobbins then
push the bobbin caps (ITEM 2) into place then remove the jack.
