Raven RS1 User manual

Raven RS1™/SC1™ with DirecSteer
Installation Manual for Case IH
MXM, Farmall, JX U, TM, T50##, TL,
TL A, TS
Case IH New Holland
lMXM 120, MXM 130, MXM 140, MXM
155, MXM 175, MXM 190
lFarmall: 85U, 95U, 105U
lJX 80U, JX 90U, JX 100U
lJX 1080U, JX 1090U, JX 1110U
lTM 120, TM 130, TM 140, TM
155, TM 175, TM 190
lT5040, T5050, T5060, T5070
lTL70, TL80, TL90, TL100
lTL70A, TL80A, TL90A, TL100A
lTS90, TS100, TS110, TS115
P/N 016-5030-301-A Jun 2023 E45532
Copyright © 2023

Disclaimer
While every effort has been made to ensure the accuracy of the information presented on
this site, Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained herein.
Raven Industries shall not be responsible or liable for incidental or consequential damages
or a loss of anticipated benefits or profits, work stoppage or loss, or impairment of data
arising out of the use, or inability to use, this system or any of its components. Raven
Industries shall not be held responsible for any modifications or repairs made outside our
facilities, nor damages resulting from inadequate maintenance of this system.
As with all wireless and satellite signals, several factors may affect the availability and
accuracy of wireless and satellite navigation and correction services (e.g. GPS, GNSS, SBAS,
etc.). Therefore, Raven Industries cannot guarantee the accuracy, integrity, continuity, or
availability of these services and cannot guarantee the ability to use Raven systems, or
products used as components of systems, which rely upon the reception of these signals or
availability of these services. Raven Industries accepts no responsibility for the use of any of
these signals or services for other than the stated purpose.
a

Table of Contents
Disclaimer a
Table of Contents i
Important Safety Information 1
Field Computers, Displays, and Control Consoles 2
Hydraulic Safety 2
Electrical Safety 3
Touch Screen 4
Recommendations and Best Practices 5
Point of Reference 5
Preparing for Install 5
Aerials and Signal Interference 5
Hose Routing 6
Harness Routing 7
Introduction 11
Kit Components 11
Updates 14
Install the DirecSteer System 17
Prepare for the Installation 17
Recommendations 17
Tools Needed 18
Point of Reference 18
Remove the Steering Wheel 19
Install the Anti-Rotation Bracket 21
Install the DirecSteer Assembly 26
Prepare the DirecSteer Assembly 26
Attach the DirecSteer Assembly to the Steering Column 27
i

Install the DirecSteer System Components 31
Mount the (Optional) Foot Switch 31
Install the Field Computer 32
Install RS1™ with DirecSteer 35
Install the RS1™ Unit 36
Insert a SIM Card in the RS1™ 36
Assemble the Mounting Brackets 37
Prepare the Roof 37
Connect RS1™ Cabling to DirecSteer 38
Best Mounting Practices 39
Route the RS1™ Cabling to DirecSteer 40
Connect to Power 48
RS1™ and DirecSteer System Diagrams 49
Install SC1™/TC1™ with DirecSteer 55
Install the SC1™/TC1™ Unit 56
Install the Antenna 58
Install the 500S™ Receiver 58
Install the 700S™ Receiver 59
Connect SC1™ Cabling to DirecSteer 59
Best Mounting Practices 60
Route the SC1™ Cabling to DirecSteer 61
Connect the 500S™/700S™ Antenna 69
Connect to Power 69
SC1™ and DirecSteer System Diagrams 71
Limited and Extended Warranties 75
Limited Warranty 75
What does this warranty cover? 75
How long is the coverage period? 75
ii

How can I get service? 75
What will Raven Industries do? 75
What is not covered by this warranty? 75
Extended Warranty 76
What does this warranty cover? 76
Do I need to register my product to qualify for the extended warranty? 76
Where can Iregister my product for the extended warranty? 76
How long is the extended warranty coverage period? 77
How can I get service? 77
What will Raven Industries do? 77
What is not covered by this warranty? 77
iii

Important Safety Information
NOTICE
Follow the operation and safety instructions included with the implement and/or controller
and read this manual carefully before installing, servicing, or operating this Raven system.
lPark the machine where the ground is level, clean, and dry.
lBleed pressure from the hydraulic system and leave the machine turned off for the dur-
ation of the installation or maintenance process.
Follow the operation and safety instructions included with the implement and/or controller.
Before installing or operating this Raven system, review and understand the information
presented on this site.
lFailure to follow safety instructions may lead to equipment damage, personal injury, or
death.
lReview equipment operation with your local dealer and follow all safety information
presented on this site.
lContact a local Raven dealer for assistance with any portion of the installation, service,
or operation of Raven equipment.
lFollow all safety labels affixed to system components. Be sure to keep safety labels in
good condition and replace any missing or damaged labels. Contact a local Raven
dealer to obtain replacements for safety labels.
Observe the following safety measures when operating the implement after installing this
Raven system:
lDo not operate this Raven system or any agricultural equipment while under the influ-
ence of alcohol or an illegal substance.
1
Chapter 1:
Important Safety Information

Chapter1
lBe alert and aware of surroundings while operating this Raven system.
lDetermine and remain a safe working distance from obstacles and bystanders.
The operator is responsible for disabling the system when a safe working dis-
tance has diminished.
lDo not operate the implement on any public road with this Raven system
enabled.
lMaintain control of the vehicle at all times during operation. For example,
lRemain in the operator seat while the system is enabled and disable auto-
mated Raven controls before exiting the operator seat.
lMaintain control of safety devices such as E-Stops at all times during oper-
ation.
lDisable this Raven system prior to starting any maintenance work on the imple-
ment or components of this Raven system.
lDo not attempt to modify or lengthen any of the system control cables. Extension
cables are available from a local Raven dealer.
Field Computers, Displays, and Control Consoles
lIf the display will not be used for an extended period, it is best to remove the display
from the machine and store it in a climate controlled environment. This may help to
extend the service life of electronic components.
lTo prevent theft, secure the display and GNSS antenna when leaving the machine unat-
tended.
WARNING
Hydraulic Safety
When installing or servicing a hydraulic system or hydraulic components, be aware that
hydraulic fluid may be extremely hot and under high pressure. Caution must be exercised.
lAlways wear appropriate personal protective equipment when installing or servicing
hydraulic systems.
lNever attempt to open or work on a hydraulic system with the implement running.
lAlways take care when servicing or opening a system that has been pressurized.
2

Important Safety Information
lThe implement or machine must remain stationary and switched off with booms or
implement sections unfolded and supported during installation or maintenance.
lAny work performed on the hydraulic system must be done in accordance with the
machine manufacturer’s approved maintenance instructions.
lBefore installing hydraulic components, ensure there are no issues with the machine
hydraulic system (e.g. pump issues, faulty hydraulic motors, fine metal deposits in the
hydraulic lines, etc.).
lTake precautions to prevent foreign material or contaminants from being introduced
into the implement hydraulic system. Contaminants that are able to bypass the
hydraulic filtration system will reduce performance and may damage hydraulic com-
ponents.
lVerify that the hydraulic system is using fresh oil and the filters have been
changed.
lStand clear of the implement when starting the system for the first time after installing
or servicing hydraulic components in case a hose has not been properly connected or
tightened.
CAUTION
Electrical Safety
lAlways verify that power leads are connected to the correct polarity as marked. Revers-
ing the power leads could cause severe damage to the Raven system or other com-
ponents.
lTo prevent personal injury or fire, replace defective or blown fuses with only fuses of
the same type and amperage.
lDo not connect the system power cable to the vehicle ignition or battery until all sys-
tem components are mounted and all electrical connections are completed.
lAlways start the machine before initializing this Raven system to prevent power surges
or peak voltage.
lTo avoid tripping and entanglement hazards, route cables and harnesses away from
walkways, steps, grab bars, and other areas used by the operator or service personnel
when operating or servicing the equipment.
3

Chapter1
Touch Screen
lOnly touch the touch-screen with your finger or by using a special touch-screen stylus
or pen. Operating the touch-screen with sharp objects may cause permanent damage
to the screen.
lOnly clean the screen using a damp cloth. Never use caustic or other aggressive sub-
stances.
4

Important Safety Information
Recommendations and Best Practices
Point of Reference
Instructions provided generally assume you are standing behind the machine facing toward
the cab. More specific orientation may be provided as necessary to complete procedures.
Preparing for Install
lEnsure there are no issues with the machine hydraulic system (e.g., pump issues, faulty
hydraulic motors, fine metal deposits in the hydraulic hoses, etc.).
lVerify that the machine hydraulic system is using fresh oil and that the filters have
been recently changed.
lEnsure there are no issues with the steering system (e.g., worn bushings, faulty tie rod
ends, improperly adjusted steering components, etc.)
Aerials and Signal Interference
Due to the relatively low broadcast power from satellites, all GNSS receivers and aerials tend
to be susceptible to sources of signal noise and interference as compared to terrestrial
signals (i.e. radio or cellular).
Note: Poor GNSS signal reception may cause other systems which rely on GNSS solutions
(e.g. auto-steer systems, rate control systems, etc.) to disengage or may cause undesired
operation or results.
The following recommendations are intended to provide an optimal environment for GNSS
systems and provide the best up-time results, even as sources of interference may spike
throughout the day.
5

Chapter1
lMount GNSS antennas with a clear, unobstructed view of the sky.
lA minimum clearance of 1 m [39 in] is recommended around the GNSS antenna
to help avoid common issues with signal interference. Do not mount cellular,
radio, or other GNSS antennas within this area.
lMount the GNSS antenna to the tallest point of the machine. Avoid mounting the
antenna in a location where obstructions (e.g. bins/hoppers, cab roof lines, equip-
ment frame or structural elements, etc.) may rise into the antenna view.
Note: The antenna view typically starts 5° to 10° above horizontal from the base
of the antenna and extends over the skyward face of the receiver/antenna.
lGNSS is a line-of-sight system. A clear path must exist between the satellite and the
GNSS antenna.
lObstructions such as buildings, tree branches and limbs, as well as components
of the vehicle such as a fiberglass or metal roof, and etc. may cause signal multi-
path or completely block the GNSS receiver.
lElectrical and magnetic fields can interfere with GNSS or L-Band signals.
lAvoid mounting GNSS receivers or antennas near components such as radio or
cellular antennas, electrical motors, generators, alternators, strobe lights, radio
transmitters, radio or cellular antennas, etc.
lOver-head power lines, microwave dishes, radar, other active antennas, etc. can
interfere with GNSS signal.
lMount the Field Hub cellular and diversity antennas at least 1 m [39 in] apart. Avoid
mounting other cellular, radio, or GNSS aerials within this area.
Hose Routing
The word “hose” is used to describe any flexible, fluid carrying components. Use the
following guidelines and recommendations when connecting and routing hoses while
installing or maintaining this Raven system:
lLeave protective caps/covers over hose ends until connecting the end into the
hydraulic system to help prevent contaminants from entering the system.
6

Important Safety Information
lFollow existing hose runs already routed on the implement as much as possible.
Proper hose routing should:
lSecure hoses and prevent hoses from hanging below the implement.
lProvide sufficient clearance from moving components and operational zones
around shafts; universal joints and suspension components; pulleys, gears, belts,
and chains; moving linkages, cylinders, articulation joints, etc.
lProtect hoses from field debris and surrounding hazards (e.g. tree limbs, fence
posts, crop stubble, dirt clumps or rocks that may fall or be thrown by the imple-
ment).
lProtect hoses from sharp bends, twisting, or flexing over short distances and nor-
mal implement operation.
lEnsure sufficient length for free movement of the implement during normal oper-
ation and prevent pulling, pinching, catching, or rubbing, especially in artic-
ulation and pivot points. Clamp hoses securely to force controlled movement of
the hose.
lAvoid abrasive surfaces and sharp edges such as sheared or flame cut corners,
fastener threads or cap screw heads, hose clamp ends, etc.
lAvoid areas where the operator or service personnel might step or use as a grab
bar.
lDo not connect, affix, or allow hoses to come into contact with components with high
vibration forces, hot surfaces, or components carrying hot fluids beyond the tem-
perature rating of hose components.
lHoses should be protected or shielded if routing requires the hose to be exposed
to conditions beyond hose component specifications.
lAvoid routing hoses in areas where damage may occur due to build up of material (e.g.
dirt, mud, snow, ice, etc.).
Harness Routing
The word “harness” is used to describe any electrical cables and leads, both bundled and
unbundled. Use the following guidelines and recommendations when connecting and
routing harnesses while installing or maintaining this Raven system:
lLeave protective caps/covers over harness connectors until needed to avoid dirt and
moisture from contaminating electrical circuits.
7

Chapter1
lSecure the harness to the frame or solid structural members at least every 12 in [30
cm].
lFollow existing harness runs already routed on the implement as much as possible.
Proper harness routing should:
lSecure harnessing and prevent the harness from hanging below the implement.
lProvide sufficient clearance from moving components and operational zones
around shafts; universal joints and suspension components; pulleys, gears, belts,
and chains; moving linkages, cylinders, articulation joints, etc.
lProtect harnessing from field debris and surrounding hazards (e.g. tree limbs,
fence posts, crop stubble, dirt clumps or rocks that may fall or be thrown by the
implement).
lProtect harnessing from sharp bends, twisting, or flexing over short distances and
normal implement operation.
lConnectors and splices should not be located at bending points or in harness sec-
tions that move.
lEnsure sufficient length for free movement of the implement during normal oper-
ation and prevent pulling, pinching, catching, or rubbing, especially in artic-
ulation and pivot points. Clamp harnessing securely to force controlled
movement of the harness.
lAvoid abrasive surfaces and sharp edges such as sheared or flame cut corners,
fastener threads or cap screw heads, hose clamp ends, etc.
lDo not connect, affix, or allow harnessing to come into contact with components with
high vibration forces, hot surfaces, or components carrying hot fluids beyond the tem-
perature rating of harness components.
lHarnessing should be protected or shielded if routing requires the hose to be
exposed to conditions beyond harnessing component specifications.
lAvoid routing harnesses in areas where damage may occur due to build up of material
(e.g. dirt, mud, snow, ice, etc.).
lAvoid routing harnesses in areas where the operator or service personnel might step or
use as a grab bar.
Note: Avoid applying direct spray or pressure washing of electrical components and
connections. High pressure streams and sprays can penetrate seals, cause corrosion, or
otherwise damage electrical components. When performing maintenance:
8

Important Safety Information
lInspect electrical components and connectors for corrosion, damaged pins or hous-
ings, etc. Repair or replace components or harnessing as necessary.
lEnsure connectors are kept clean and dry. Apply dielectric grease to the sealing sur-
faces of all connections exposed to moisture, dirt, debris, and other contaminates.
Repair or replace harnessing as necessary.
lClean electrical components with pressurized air, aerosol electrical cleaning agent, or
low pressure rinse.
lRemove visible surface water from electrical components and connections using pres-
surized air or an aerosol cleaning agent. Allow components to dry thoroughly before
reconnecting cables.
9

Chapter1
10

Introduction
NOTICE
Depending upon the make and model of the machine, the steps
required to complete the installation of the RS1™/SC1™ with
DirecSteer auto-steer system may differ from the instructions
provided in the following procedure.
The DirecSteer steering system is designed to provide automated steering of agricultural
equipment using an electric drive unit mounted to the steering column.
The instructions in this manual are intended to help with installation of the DirecSteer
steering system on the following machines.
Case IH New Holland
lMXM 120, MXM 130, MXM 140, MXM 155,
MXM 175, MXM 190
lFarmall: 85U, 95U, 105U
lJX 80U, JX 90U, JX 100U
lJX 1080U, JX 1090U, JX 1110U
lTM 120, TM 130, TM 140, TM 155,
TM 175, TM 190
lT5040, T5050, T5060, T5070
lTL70, TL80, TL90, TL100
lTL70A, TL80A, TL90A, TL100A
lTS90, TS100, TS110, TS115
Kit Components
This section contains a list of the components that are included in the kit. Before beginning
the installation, compare the items in the kit with the components on this list. If you have
questions about the kit, contact a local Raven dealer.
11
Chapter 2:
Introduction

Chapter2
DirecSteer Steering Installation Kit for Case IH FARMALL/LUXXUM/MXM/JXU and New Hol-
land T4/T5/T5000/TL/TM/TS/T6 (BRA) (P/N 117-5030-301 Rev. B)
DirecSteer Steering Installation Kit with SC1™ and w/o IBBC (P/N 117-5030-310 Rev. A)
12

Introduction
DirecSteer Steering Installation Kit with SC1™ and IBBC (P/N 117-5030-311 Rev. A)
DirecSteer Steering Installation Kit with RS1™ and w/o IBBC (P/N 117-5030-312 Rev. A)
13

Chapter2
DirecSteer Steering Installation Kit with RS1™ and IBBC (P/N 117-5030-313 Rev. A)
DirecSteer Motor and Anti-Rotation Bracket Kit (P/N 117-5030-314 Rev. B)
Updates
Software and manual updates are available on the Raven Applied Technology website.
https://portal.ravenprecision.com
Sign up for email alerts and you will be automatically notified when updates for Raven
products are available.
14
