Raven SmarTrax User manual

SmarTrax, Case Trident 5550, Non-
Steer Ready Installation Manual
P/N 016-5032-045 Rev. A 04/17 E29354
Copyright 2017

While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be responsible or liable for incidental or consequential
damages or a loss of anticipated benefits or profits, work stoppage or loss, or
impairment of data arising out of the use, or inability to use, this system or any of
its components. Raven Industries shall not be held responsible for any
modifications or repairs made outside our facilities, nor damages resulting from
inadequate maintenance of this system.
As with all wireless and satellite signals, several factors may affect the availability
and accuracy of wireless and satellite navigation and correction services (e.g.
GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the
accuracy, integrity, continuity, or availability of these services and cannot
guarantee the ability to use Raven systems, or products used as components of
systems, which rely upon the reception of these signals or availability of these
services. Raven Industries accepts no responsibility for the use of any of these
signals or services for other than the stated purpose.
Disclaimer

Table of Contents
P/N 016-5032-045 Rev. A i
Chapter 1 Important Safety Information................................................. 1
Instructions for Wire Routing .....................................................................................................2
Instructions for Hose Routing ....................................................................................................3
Chapter 2 Introduction............................................................................. 5
Preparing for Installation ...........................................................................................................5
Recommendations ..............................................................................................................5
Point of Reference ...............................................................................................................6
Kit Contents ...............................................................................................................................7
Chapter 3 Hydraulic System Installation.............................................. 11
Install Fittings on the SmarTrax Valve .....................................................................................12
Install Fittings on the Flow Switch ...........................................................................................13
Mount the SmarTrax Valve ......................................................................................................13
Install the Pressure Hose ........................................................................................................14
Install the Tank Hose ...............................................................................................................15
Install the Left and Right Steering Hoses ................................................................................16
Hydraulic System Diagram ......................................................................................................18
Chapter 4 Cab Component Installation................................................ 19
Install the SmarTrax Node .......................................................................................................19
Mount the SmarTrax Node ................................................................................................19
Node Mounting Locations ..................................................................................................20
Install the Node Harness .........................................................................................................21
Install the Valve Harness .........................................................................................................23
Install the Foot Switch .............................................................................................................24
System Diagrams ....................................................................................................................25
Chapter 5 Startup Procedures .............................................................. 29
Remove Air from the Hydraulic System ...................................................................................29
Verify the Hydraulic System Installation ..................................................................................29
Calibrate the SmarTrax System ..............................................................................................30

Table of Contents
ii SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual

CHAPTER
1
P/N 016-5032-045 Rev. A 1
CHAPTER1 IMPORTANT SAFETY
INFORMATION
Read this manual and the operation and safety instructions included with your implement and/or controller
carefully before installing the SmarTrax™ system.
• Follow all safety information presented within this manual.
• If you require assistance with any portion of the installation or service of your Raven equipment, contact your
local Raven dealer for support.
• Follow all safety labels affixed to the SmarTrax system components. Be sure to keep safety labels in good
condition and replace any missing or damaged labels. To obtain replacements for missing or damaged safety
labels, contact your local Raven dealer.
When operating the machine after installing SmarTrax, observe the following safety measures:
• Be alert and aware of surroundings.
• Do not operate SmarTrax or any agricultural equipment while under the influence of alcohol or an illegal
substance.
• Remain in the operator’s position in the machine at all times when SmarTrax is engaged.
• Disable SmarTrax when exiting the operator’s seat and machine.
• Do not drive the machine with SmarTrax enabled on any public road.
• Determine and remain a safe working distance from other individuals. The operator is responsible for disabling
SmarTrax when the safe working distance has diminished.
• Ensure SmarTrax is disabled prior to starting any maintenance work on SmarTrax or the machine.
• When starting the machine for the first time after installing SmarTrax, be sure that all persons stand clear in
case a hose has not been properly tightened.
• The machine must remain stationary and switched off during SmarTrax installation or maintenance.
NOTICE
WARNING
CAUTION

CHAPTER 1
2 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
INSTRUCTIONS FOR WIRE ROUTING
The word “harness” is used to mean all electrical leads and cables, bundled and unbundled. When installing
harness, secure it at least every 30 cm (12in) to the frame. Follow existing harness as much as possible and use
these guidelines:
Harness should not contact or be attached to:
• Lines and hoses with high vibration forces or pressure spikes
• Lines and hoses carrying hot fluids beyond harness component specifications
Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:
• Sheared or flame cut edges
• Edges of machined surfaces
• Fastener threads or cap screw heads
• Ends of adjustable hose clamps
• Wire exiting conduit without protection, either ends or side of conduit
• Hose and tube fittings
Routing should not allow harnesses to:
• Hang below the unit
• Have the potential to become damaged due to exposure to the exterior environment. (i.e. tree limbs, debris,
attachments)
• Be placed in areas of or in contact with machine components which develop temperatures higher than the
temperature rating of harness components
• Wiring should be protected or shielded if it needs to route near hot temperatures beyond harness component
specifications
Harnessing should not have sharp bends
Allow sufficient clearance from machine component operational zones such as:
• Drive shafts, universal joints and hitches (i.e. 3-point hitch)
• Pulleys, gears, sprockets
• Deflection and backlash of belts and chains
• Adjustment zones of adjustable brackets
• Changes of position in steering and suspension systems
• Moving linkages, cylinders, articulation joints, attachments
• Ground engaging components
For harness sections that move during machine operation:
• Allow sufficient length for free movement without interference to prevent: pulling, pinching, catching or
rubbing, especially in articulation and pivot points
• Clamp harnesses securely to force controlled movement to occur in the desired harness section
• Avoid sharp twisting or flexing of harnesses in short distances
• Connectors and splices should not be located in harness sections that move

P/N 016-5032-045 Rev. A 3
Important Safety Information:
Protect harnesses from:
• Foreign objects such as rocks that may fall or be thrown by the unit
• Buildup of dirt, mud, snow, ice, submersion in water and oil
• Tree limbs, brush and debris
• Damage where service personnel or operators might step or use as a grab bar
• Damage when passing through metal structures
IMPORTANT:Avoid directly spraying electrical components and connections with high pressure water. High pressure water
sprays can penetrate seals and cause electrical components to corrode or otherwise become damaged.
When performing maintenance:
•Inspect all electrical components and connections for damage or corrosion. Repair or replace
components, connections, or cable as necessary.
•Ensure connections are clean, dry, and not damaged. Repair or replace components, connections,
or cable as necessary.
•Clean components or connections using low pressure water, pressurized air, or an aerosol electrical
component cleaning agent.
•Remove visible surface water from components, connections, or seals using pressurized air or an
aerosol electrical component cleaning agent. allow components to dry completely before
reconnecting cables.
INSTRUCTIONS FOR HOSE ROUTING
The word “hose” is used to mean all flexible fluid carrying components. Follow existing hoses as much as possible
and use these guidelines:
Hoses should not contact or be attached to:
• Components with high vibration forces
• Components carrying hot fluids beyond component specifications
Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:
• Sheared or flame cut edges
• Edges of machined surfaces
• Fastener threads or cap screw heads
• Ends of adjustable hose clamps
Routing should not allow hoses to:
•Hang below the unit
• Have the potential to become damaged due to exposure to the exterior environment. (i.e. tree limbs, debris,
attachments)
• Be placed in areas of or in contact with machine components which develop temperatures higher than the
temperature rating of hose components
• Hoses should be protected or shielded if it needs to route near hot temperatures beyond hose component
specifications
Hoses should not have sharp bends
Allow sufficient clearance from machine component operational zones such as:

CHAPTER 1
4 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
• Drive shafts, universal joints and hitches (i.e. 3-point hitch)
• Pulleys, gears, sprockets
• Deflection and backlash of belts and chains
• Adjustment zones of adjustable brackets
• Changes of position in steering and suspension systems
• Moving linkages, cylinders, articulation joints, attachments
• Ground engaging components
For hose sections that move during machine operation:
• Allow sufficient length for free movement without interference to prevent: pulling, pinching, catching or
rubbing, especially in articulation and pivot points
• Clamp hoses securely to force controlled movement to occur in the desired hose section
• Avoid sharp twisting or flexing of hoses in short distances
Protect hoses from:
• Foreign objects such as rocks that may fall or be thrown by the unit
• Buildup of dirt, mud, snow, ice, submersion in water and oil
• Tree limbs, brush and debris
• Damage where service personnel or operators might step or use as a grab bar
• Damage when passing through metal structures
•High pressure wash

CHAPTER
2
P/N 016-5032-045 Rev. A 5
CHAPTER2 INTRODUCTION
This manual applies to the following machines:
MAKE: Case IH
MODEL: Trident 5550, Non-Steer Ready
FIGURE 1. Case IH Patriot 5550
PREPARING FOR INSTALLATION
Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the
machine and leave it turned off for the duration of the installation process.
During the installation process, follow good safety practices. Be sure to carefully read the instructions in this
manual as you complete the installation process.
RECOMMENDATIONS
Raven Industries recommends the following best practices when installing or operating the SmarTrax system for
the first time, at the start of the season, or when moving the SmarTrax system to another machine:

CHAPTER 2
6 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
• Install the GPS antenna in the recommended location. Refer to the following table for the machine-specific
antenna mounting location.
• Ensure the machine’s hydraulic filters have been recently changed and there are no issues with the machine’s
hydraulic system (e.g., pump issues, faulty hydraulic motors, fine metal deposits in the hydraulic hoses, etc.).
• Ensure the machine’s hydraulic system is using fresh oil and debris is flushed from the hydraulic hoses, valves,
and filters.
Raven Industries recommends the following best practices when installing the SmarTrax system:
• Use part numbers to identify the parts.
• Do not remove the plastic wrap from a part until it is necessary for installation.
• Do not remove plastic caps from a part until it is necessary for installation.
POINT OF REFERENCE
The instructions in this manual assume that you are standing behind the machine, looking toward the cab.
Machine Preset Antenna X Position
(left to right) Antenna Y Position (fore/aft offset)
Antenna Z Position
(ground to bottom
of antenna)
Case IH Trident Centered 14 ft. 4 in/4.369 m 12 ft.4 in/3.759 m
At Raven Industries, we strive to make your experience with our products as rewarding as
possible. One way to improve this experience is to provide us with feedback on this manual.
Your feedback will help shape the future of our product documentation and the overall service we
provide. We appreciate the opportunity to see ourselves as our customers see us and are eager
to gather ideas on how we have been helping or how we can do better.
To serve you best, please send an email with the following information to
[e-mail]
-SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
-P/N 016-5032-045 Rev. A
-Any comments or feedback (include chapter or page numbers if applicable).
-Let us know how long have you been using this or other Raven products.
We will not share your email or any information you provide with anyone else. Your feedback is
valued and extremely important to us.
Thank you for your time.

2
P/N 016-5032-045 Rev. A 7
Introduction:
KIT CONTENTS
This section contains a list of the components that are included in the SmarTrax kit. Before beginning the SmarTrax
installation, compare the items in the kit with the components on this list. If you have questions about the kit,
contact your Raven dealer.
NOTE: The SmarTrax node (P/N 063-0173-228) is sold separately. Contact your local Raven dealer for
ordering information.
TABLE 1. Case IH Trident 5550 SmarTrax Installation Kit (P/N 117-5032-045)
Picture Item Description Part Number Qty.
Not Pictured Manual - SmarTrax and SmartSteer
Calibration & Operation 016-0171-277 1
Not Pictured Manual - Case IH Trident SmarTrax
Installation 016-5032-045 1
Valve - SmarTrax Hydraulic 334-0003-088 1
Switch - Flow 334-0003-085 1
Bracket, Mounting, SmarTrax Valve 107-0172-534 1
Cable - Node 115-4001-110 1
Cable Adapter, CAN 32XX/33XX Patriot
Sprayer with ISO 115-4001-254 1
Assembly - SmarTrax Enable Switch 063-0172-470 1
Cable, Valve 115-4001-111 1

CHAPTER 2
8 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
TABLE 2. Hydraulic Installation Kit (P/N 117-0199-156)
Picture Item Description Part Number Qty.
Fitting: -8 ORFS M/M/F Swivel Run Tee
Adapter 333-0012-028 4
Fitting: -4 SAE O-Ring Plug 333-0012-051 1
Fitting: -6 ORFS M/M/F Swivel Run Tee
Adapter 333-0012-069 3
Fitting: -6 ORFS (M) to -6 SAE O-Ring (M)
Straight Adapter 333-0012-084 6
Fitting: -6 SAE O-Ring Plug 333-0012-104 2
Fitting: -6 ORFS (M) to -8 SAE O-Ring (M)
Straight Adapter 333-0012-199 2
Fitting: -6 ORFS (M) to -10 SAE O-Ring
(M) Straight Adapter 333-0012-233 2
Fitting, Elbow, 90° Swivel, -8 ORFS M/F 333-0012-067 1
Fitting, Elbow, 90° Swivel, -6 ORFS M/F 333-0012-065 5
Hydraulic Hose: -6 ORFS (F) 90° to - 8
ORFS (F) - 64” 214-1001-171 1
Hydraulic Hose: -6 ORFS (F) to -8 ORFS (F)
- 84” 214-1000-630 2

2
P/N 016-5032-045 Rev. A 9
Introduction:
Hydraulic Hose: -6 ORFS (F) 90° to -8
ORFS (F) - 98” 214-1001-172 1
Hydraulic Hose: -8 ORFS (F) 90° to -6
ORFS (F) -98” 214-1001-173 1
Hydraulic Hose: -8 ORFS (F) 90° to -6
ORFS (F) - 84” 214-1001-174 1
TABLE 3. Node Mounting Kit (P/N 117-0197-078)
Picture Item Description Part Number Qty.
Plate - SmarTrax Node Mounting 107-0172-084 1
Standoff - M6 x 40mm M/F x 13 mm Hex 305-8000-008 2
Nut, Nylon Lock, 3/8” - 16 UNC 312-4000-061 3
TABLE 2. Hydraulic Installation Kit (P/N 117-0199-156)
Picture Item Description Part Number Qty.

CHAPTER 2
10 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual

CHAPTER
3
P/N 016-5032-045 Rev. A 11
CHAPTER3 HYDRAULIC SYSTEM
INSTALLATION
WARNING
Hydraulics are under pressure. Care should
always be taken with a system that has been
pressurized.
Before beginning the SmarTrax hydraulic
installation, turn off the machine and relieve
pressure by turning the steering wheel left and
right.
When disconnecting or purging hydraulic hoses,
be aware that the hydraulic fluid within the
machine’s system may be extremely hot and
under high pressure.
Tampering with hydraulic valves may cause
serious injury or death, and will void the warranty.
CAUTION
When installing SmarTrax hydraulics or
performing diagnostics, maintenance, or routine
service, ensure precautions are taken to prevent
any foreign material from being introduced into
the machine’s hydraulic system.
Objects or materials that are able to bypass the
machine’s hydraulic filtration system will reduce
performance and possibly cause damage to the
SmarTrax hydraulic valve.

CHAPTER 3
12 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
INSTALL FITTINGS ON THE SMARTRAX VALVE
Before mounting the SmarTrax valve (P/N 334-0003-088) on the machine, install the proper fittings in the valve.
This prepares the valve for installation and simplifies the hose connection process later in the procedure.
FIGURE 1. Fittings Installed on the SmarTrax Valve
NOTICE
The appearance of the SmarTrax hydraulic valve
may vary slightly from the images contained in
this manual. However, the fittings, hose
connections, and cable connections remain the
same.
Fitting Part Number Port
Fitting - -6 SAE O-Ring Plug 333-0012-104 LSPV,
LS STEER
Fitting - -4 SAE O-Ring Plug 333-0012-051 PS
Fitting - -6 ORFS (M) to -8 SAE O-Ring (M) Straight Adapter 333-0012-199 P, T
Fitting - -6 ORFS (M) to -10 SAE O-Ring (M) Straight Adapter 333-0012-233 A, B
Fitting, Elbow, 90° Swivel, -8 ORFS M/F 333-0012-067 As Needed
Fitting, Elbow, 90° Swivel, -6 ORFS M/F 333-0012-065 P

3
P/N 016-5032-045 Rev. A 13
Hydraulic System Installation:
INSTALL FITTINGS ON THE FLOW SWITCH
FIGURE 2. Fittings Installed on the Flow Switch
1. Install a -6 ORFS (M) to -6 SAE O-ring (M) straight adapter fitting (P/N 333-0012-084) in Ports A2 and B2 of the
flow switch (P/N 334-003-085).
2. Install the pressure transducers in Ports A1 and B1 of the flow switch.
MOUNT THE SMARTRAX VALVE
FIGURE 3. Mounting Location
1. Remove the bolts used to secure the machine’s radar bracket (beneath the cab).

CHAPTER 3
14 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
FIGURE 4. SmarTrax Valve Installed on Mounting Plate
2. Mount the SmarTrax valve (P/N 334-0003-088) to the hydraulic valve mounting bracket (P/N 107-0172-534)
using four 5/16” hex bolts (P/N 311-0052-104) and four 5/16” lock washers (P/N 313-1000-019).
3. Mount the flow switch (P/N 334-0003-085) to the valve mounting bracket using two 1/4”-20 x 2” screws (P/N
311-0050-109), two 1/4” flat washers (P/N 313-2300-009), two 1/4” split lock washers (P/N 313-1000-016), and
two 1/4”-20 hex nuts (P/N 312-1001-074).
FIGURE 5. SmarTrax Valve Mounted on the Machine
4. Mount the hydraulic valve mounting bracket to the machine’s radar bracket using the bolts removed in step 1.
NOTE: If needed, the bolts attaching the radar to the bracket may be removed and flipped to make room for
the valve bracket.
INSTALL THE PRESSURE HOSE
1. Locate the machine’s steel pressure line.
NOTE: The pressure line runs on the inside of the frame from the rear of the machine. The line bends 45° just
before the hydraulic hose connection. Trace it to the P port on the steering orbital if necessary.
2. Disconnect the machine’s pressure hose from the steel pressure line.

3
P/N 016-5032-045 Rev. A 15
Hydraulic System Installation:
FIGURE 6. Pressure Hose Installed
3. Install a -8 ORFS M/M/F swivel run tee adapter fitting (P/N 333-0012-028) on the block above the rear of the
front axle.
4. Connect the machine’s pressure hose to the opposite end of the installed tee fitting.
5. Install the supplied hydraulic hose (P/N 214-1000-630) on the 90° end of the installed tee fitting.
6. Connect the straight end of the installed hydraulic hose to the 90° fitting (333-0012-065) on Port P of the
SmarTrax valve.
INSTALL THE TANK HOSE
1. Locate the machine’s tank line.
NOTE: The pressure and tank line connect to a block above the front axle on the rear side.
2. Disconnect the machine’s tank hose from the block.
FIGURE 7. Tank Hose Installed
3. Install a -8 ORFS M/M/F swivel run tee adapter fitting (P/N 333-0012-028) on the machine’s hydraulic block.
4. Connect the machine’s tank hose to the opposite end of the installed tee fitting.
5. Install the -8 end of the supplied hydraulic hose (P/N 214-1000-630) on the 90° end of the installed tee fitting.
6. Connect the other end of the installed hydraulic hose to Port T of the SmarTrax valve.

CHAPTER 3
16 SmarTrax, Case Trident 5550, Non-Steer Ready Installation Manual
7. Remove the existing overflow hose and replace it with the new overflow hose (P/N 214-1001-171).
INSTALL THE LEFT AND RIGHT STEERING HOSES
1. Locate and disconnect the machine’s left steering hose from the left steering cylinder.
NOTE: The left steering hose is connected to the fitting located closest to the center of the machine.
2. Route and connect the left steering hose to the Port A2 of the installed flow switch (P/N 334-0003-214).
3. Install the 90° Swivel Elbow (P/N 333-0012-067) to the hose coming from the machine.
FIGURE 8. Installed Left Steering Hose
4. Install a -8 ORFS M/M/F swivel run tee adapter fitting (P/N 333-0012-028) on the hydraulic block.
5. Install the straight end of the supplied hydraulic hose (P/N 214-1000-173) on the opposite end of the installed
tee fitting.
6. Connect the other end of the installed hydraulic hose to the fitting installed in Port B3 (P/N 333-0012-067) of
the installed flow switch.
7. Install the 90° end of the supplied hydraulic hose (P/N 214-1000-172) on the 90° end of the installed tee fitting.
8. Connect the straight end of the installed hydraulic hose to Port A of the SmarTrax valve.
FIGURE 9. Installed Right Steering Hose
9. Locate and disconnect the machine’s right steering hose from the right steering cylinder.
Right
Steering
Hose
Left
Steering
Hose
