User guide
USER GUIDE
P

English 1
ENGLISH
A
Elbow
1
Vent
B
Elbow ring
2
QuietAir vent
C
Headgear
3
Standard vent
D
Frame
4
Sleeve
E
P30i pillows cushion
5
Side buttons
F
N30i nasal cushion
Note: These masks may not be available in all countries.
Intended use
The AirFit N30i and AirFit P30i masks are is intended to be used by
patients weighing more than 30 kg who have been prescribed non-
invasive positive airway pressure (PAP) therapy such as CPAP or bi-level
therapy. The masks are intended for single patient re-use in the home and
multi-patient re-use in the hospital/institutional environment.
Please read the entire guide before use.
Clinical benefits
The clinical benefit of vented masks is the provision of effective therapy
delivery from a therapy device to the patient.

2
Intended patient population/medical conditions
Obstructive pulmonary diseases (eg, Chronic Obstructive Pulmonary
Disease), restrictive pulmonary diseases (eg, diseases of the lung
parenchyma, diseases of the chest wall, neuromuscular diseases), central
respiratory regulation diseases, obstructive sleep apnoea (OSA) and
obesity hypoventilation syndrome (OHS).
Before using your mask
Remove all packaging and inspect each mask component for visible
deterioration.
Use the fitting template to assist in selecting the right size cushion and
frame.
Fitting your mask
1. Pull the frame and headgear over your head until the elbow is
positioned on top and the headgear is behind your head.
2. Place the cushion under your nose.
For the AirFit P30i mask, align the pillows into your nostrils.
3. Tighten or loosen the headgear until the cushion fits comfortably
under your nose.
4. Squeeze the side buttons on the elbow and detach from the frame.
Connect the air tubing from your device to the elbow, then reattach to
the frame.

English 3
Adjusting your mask
•When using the mask, air will flow out of the vents in the cushion and
elbow. If air leaks from the side or top of the cushion, adjust the mask
fitting to improve the seal.
•You can position the top of the frame forward or backwards over your
head until the mask feels comfortable.
Sizing the mask frame
If the mask frame falls back over your head or sits too close to your ears,
try a small frame size. If the mask falls forward on your head or sits too
close to your eyes, try a standard frame size.
Disassembling your mask for cleaning
If your mask is connected to a device, disconnect the device air tubing
from the mask elbow.
1. Pull the cushion from the frame.
2. Undo the fastening tabs on the headgear strap and pull it from the
frame.
3. Squeeze the side buttons on the elbow and detach from the frame.
Note: The QuietAir or standard vent can be removed to allow inspection
of the vent holes.

4
Cleaning your mask
After each use: Cushion
Weekly: Headgear, frame and elbow
1. Soak the components in warm water with a mild liquid detergent.
Ensure that there are no air bubbles while soaking.
2. Hand wash the components with a soft bristle brush. Pay particular
attention to the vent holes.
3. Thoroughly rinse the components under running water.
4. For the frame sleeves, squeeze with a clean towel to remove excess
water. Shake the QuietAir or standard vent to remove any excess
water. Leave the components to air dry out of direct sunlight.
If the mask components are not visibly clean, repeat the cleaning steps.
Reassembling your mask
1. Connect the elbow into the top of the frame until it clicks.
2. Insert the headgear strap into the frame and fold the fastening tabs
backwards.
3. Insert the ends of the frame into the cushion, ensuring that the arrows
on the cushion and frame are aligned.
Note: If the elbow ring detaches, re-insert into the top of the frame.

English 5
Removing/inserting the QuietAir/standard vent
1. To remove the vent, gently pull the cushion away and slide the vent
out.
2. To insert the vent, align the tab (a) on the cushion with the notch (b)
on the vent, and then gently pull the cushion over the vent.
WARNING
•The mask is not suitable for patients requiring life support ventilation.
•To avoid affecting the safety and quality of therapy, the mask vents must be kept clear
to protect against rebreathing. Regularly inspect the vents to ensure they are kept
clean, undamaged and clear of blockages.
•The mask must be used under qualified supervision for patients who are unable to
remove the mask by themselves. The mask may not be suitable for those prone to
aspiration.
•Regularly clean your mask to maintain the quality of your mask and to prevent the
growth of germs that can adversely affect your health.
•Visual criteria for product inspection: If there is any visible deterioration of a mask
component (cracking, crazing, tears etc.), the component should be discarded and
replaced.
•Only use compatible CPAP or bi-level therapy devices. The technical specifications of
the mask are provided for healthcare professionals to determine compatible devices.
Use with incompatible devices may affect the performance or safety of the mask.
•Discontinue using the mask if you have ANY adverse reaction and consult your
physician or sleep therapist.

6
•The mask is not intended to be used simultaneously with nebulizer medications that
are in the air path of the mask/tube.
•Follow all precautions when using supplemental oxygen.
•Oxygen flow must be turned off when the CPAP or bilevel device is not operating, so
that unused oxygen does not accumulate within the device enclosure and create a risk
of fire.
•Oxygen supports combustion. Oxygen must not be used while smoking or in the
presence of an open flame. Only use oxygen in well ventilated rooms.
•At a fixed rate of supplemental oxygen flow, the inhaled oxygen concentration varies,
depending on the pressure settings, patient breathing pattern, mask, point of
application and leak rate. This warning applies to most types of CPAP or bilevel
devices.
CAUTION
•Remove all packaging before using the mask.
•Using a mask may cause tooth, gum or jaw soreness or aggravate an existing dental
condition. If symptoms occur, consult your physician or dentist.
•When fitting the mask, do not overtighten the headgear as this may lead to skin
redness or sores around the mask cushion.
•The mask should not be used unless the device is turned on. Once the mask is fitted,
ensure the device is blowing air to reduce risk of rebreathing exhaled air.
•As with all masks, some rebreathing may occur at low pressures.
•Always follow cleaning instructions and only use a mild liquid detergent. Some
cleaning products may damage the mask, its parts and their function, or leave harmful
residual vapours. Do not use a dish washer or washing machine to clean the mask.
•Do not iron the headgear as the material is heat sensitive and will be damaged.
Note: For any serious incidents that occur in relation to this product, these should be
reported to ResMed and the competent authority in your country.

English 7
Technical specifications
Compatible devices
For a full list of compatible devices for this mask, see the Mask/Device Compatibility List
at ResMed.com/downloads/masks. SmartStop may not operate effectively when using this
mask with some CPAP or bi-level devices.
Pressure-flow curve:
Pressure
(cm H2O)
Flow
(L/min)
4
20
9
31
15
41
20
49
25
55
AirFit N30i
AirFit P30i
Mask setting options:
For AirSense, AirCurve or S9
Therapy Pressure:
Pillows
4 to 25 cm H2O
Pillows
4 to 25 cm H2O
Resistance: Drop in pressure measured (nominal)
at 50 L/min
0.5 cm H2O
0.4 cm H2O
at 100 L/min
1.7 cm H2O
1.5 cm H2O
Sound:
Declared dual-number noise emission values in accordance with ISO4871:1996
and ISO3744:2010. A-weighted sound power level and A-weighted sound pressure level at
a distance of 1 m, with uncertainty of 3 dBA, are shown
Sound power level (QuietAir vent)
Sound pressure level (QuietAir vent)
Sound power level (Standard vent)
Sound pressure level (Standard vent)
21 dBA
14 dBA
25 dBA
18 dBA
21 dBA
14 dBA
24 dBA
17 dBA
Environmental conditions:
Operating temperature: 5°C to 40°C
Operating humidity: 15% to 95% non-condensing
Storage and transport temperature: -20°C to +60°C
Storage and transport humidity: up to 95% non-condensing
Service life: The service life of the mask system is dependent on the intensity of usage,
maintenance, and environmental conditions to which the mask is used or stored. As this
mask system and its components are modular in nature, it is recommended that the user
maintain and inspect it on a regular basis, and replace the mask system or any
components if deemed necessary or according to the ‘Visual criteria for product inspection’
in the ‘Warning’ section of this guide.
Note: The manufacturer reserves the right to change these specifications without notice.

8
Storage
Ensure that the mask is thoroughly clean and dry before storing it for any length of time.
Store the mask in a dry place out of direct sunlight.
Disposal
This mask and packaging do not contain any hazardous substances and may be disposed of
with your normal household refuse.
Reprocessing the mask between patients
This mask should be reprocessed when used between patients. Cleaning, disinfection and
sterilisation instructions are available on ResMed.com/downloads/masks. If you do not
have internet access, please contact your ResMed representative.
Symbols
The following symbols may appear on your product or packaging:
Nasal cradle mask Nasal pillows mask
QuietAir vent Device setting - Pillows
Cushion size - small Cushion size - medium
Cushion size - large Cushion size - wide
Cushion size - small wide Standard frame
Small frame Importer
Medical device
Not made with natural
rubber latex
Caution, consult accompanying documents.
See symbols glossary at ResMed.com/symbols.
Consumer Warranty
ResMed acknowledges all consumer rights granted under the EU
Directive 1999/44/EC and the respective national laws within the EU for
products sold within the European Union.

Български 1
БЪЛГАРСКИ
A
Водач
1
Вентилационен отвор
B
Пръстен за водач
2
Отдушник QuietAir
CКолан за глава 3Стандартен отдушник
D
Рамка
4
Ръкав
EВъзглавничка P30i тип
Pillows
5Странични бутони
FВъзглавничка N30i тип Nasal
Забележка: Тези маски може да не се предлагат във всички
държави.
Предназначение
Маските AirFit N30i и AirFit P30i са предназначени за употреба от
пациенти с тегло над 30 kg (66 lb), на които е предписана неинвазивна
терапия с положително налягане на дихателните пътища (PAP), като
CPAP или bi-level терапия. Маските са предназначени за многократна
употреба от един пациент в домашни условия и в
болнична/институционална среда.
Моля, прочетете цялото ръководство преди употреба.
Клинични предимства
Клиничното предимство на маските с вентилация се състои в
осигуряването на ефективна терапия от терапевтичното изделие към
пациента.
