Sauder Embassy Point 414706 User manual

Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
English.................... Page 1-10
Français...............Pages 11-12
Espanol.............Páginas 13-14
414706
Full/Queen Headboard
Embassy Point Collection
Lot #: 354081 07 / 24 / 13
Date Purchased: ____________________

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
ADULT ASSEMBLY REQUIRED
TABLE OF CONTENTS
Part Identification.......................2
Hardware Identification .............3
Assembly Steps....................4-10
Français.............................. 11-12
Espanol...............................13-14
Warranty...................................15
PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A RIGHT END 1
B LEFT END 1
C TOP 1
D BOTTOM 1
E TOP PANEL 1
F MIDDLE PANEL 1
G BOTTOM PANEL 1
H RIGHT FRONT MOLDING 1
I LEFT FRONT MOLDING 1
J PANEL MOLDING 6
K MIDDLE PANEL MOLDING 3
Page 2 www.sauder.com/services 414706
A
B
C
D
E
F
G
H
I
J
J
J
J
J
J
K
K
K

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
Page 3
www.sauder.com/services414706
BLACK 1-7/8" FLAT HEAD SCREW - 5
2S
HIDDEN CAM - 29
1F CAM DOWEL - 19 2F
CAM SCREW - 10
8F
BLACK 1-1/8" PAN HEAD SCREW - 18
9S
BLACK 9/16" LARGE HEAD SCREW - 16
1S
NUT - 4
24M
WASHER - 4
13M
SILVER 1-1/4" BOLT - 4
48S
CAM COVER - 10
12P
BLACK 7/8" LARGE HEAD SCREW - 8
17S
PLATE - 4
41G
HEADBOARD BRACKET - 2
16G

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push twenty-nine HIDDEN CAMS (1F) into the ENDS (A and B), MOLDINGS (I and H) and PANELS (E, F and G). Then, insert the
metal end of a CAM DOWEL (2F) into each HIDDEN CAM, except the edges of the ENDS (A and B).
Page 4 www.sauder.com/services 414706
G
F
E
H
A
I
B
Do not tighten the HIDDEN CAMS in this step.
Arrow
1F
Arrow
(19 used)
(29 used) 1F
2F
Arrow
1F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do NOT insert CAM
DOWELS into these parts.

2
2
S
t
e
p
Page 5
www.sauder.com/services414706
Insert ten CAM SCREWS (8F) into LEFT FRONT MOLDING (I) and RIGHT FRONT MOLDING (H).
8F (10 used)
I
H

3
3
S
t
e
p
Page 6 www.sauder.com/services 414706
Fasten three MIDDLE PANEL MOLDINGS (K) to the MIDDLE PANEL (F). Use six BLACK 1-1/8" PAN HEAD SCREWS (9S).
Fasten six PANEL MOLDINGS (J) to the TOP PANEL (E) and the BOTTOM PANEL (G). Use twelve BLACK 1-1/8" PAN HEAD
SCREWS (9S).
BLACK 1-1/8" PAN HEAD SCREW
(18 used in this step)
9S
G
E
F
J
K
J
J
J
J
J
K
K
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS

4
4
S
t
e
p
Page 7
www.sauder.com/services414706
Fasten the ENDS (A and B) to the PANELS (E, F and G). Tighten twelve HIDDEN CAMS.
NOTE: You may want to start at the top and work towards the bottom.
F
G
E
B
A
Surface with
HIDDEN CAMS
Edge closer to holes
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Edge with CAM DOWELS
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Arrow
Arrow
Maximum
210 degrees
Minimum
190 degrees
Edge with
HIDDEN CAMS
These cams will be
closer to this edge.

5
5
S
t
e
p
Page 8 www.sauder.com/services 414706
Fasten the BOTTOM (D) to the BOTTOM PANEL (G). Use five BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Fasten four PLATES (41G) to the PANELS (E, F and G). Use sixteen BLACK 9/16" LARGE HEAD SCREWS (1S).
D
F
G
E
BLACK 9/16" LARGE HEAD SCREW
(16 used for the PLATES)
1S
BLACK 1-7/8" FLAT HEAD SCREW
(5 used in this step)
2S
(4 used)
41G
Finished surface
Unfinished edge

6
6
S
t
e
p
Page 9
www.sauder.com/services414706
NOTE:You may need someone's help to hold the unit in this step. Stand the unit up.
Fasten RIGHT FRONT MOLDING (H) to RIGHT END (A) and LEFT FRONT MOLDING (I) to LEFT END (B). Tighten ten
HIDDEN CAMS.
Put ten CAM COVERS (12P) over the HIDDEN CAMS.
A
B
H
I
These edges
should be even.
Surface with
HIDDEN CAM
(10 used)
12P
These edges
should be even. Edge with
CAM DOWELL

7
7
S
t
e
p
Page 10 www.sauder.com/services 414706
Fasten the TOP (C) to the TOP PANEL (E). Tighten seven HIDDEN CAMS.
Fasten two HEADBOARD BRACKETS (16G) to the ENDS (A and B). Use eight BLACK 7/8" LARGE HEAD SCREWS (17S).
Fasten the headboard to your bedframe. Use four SILVER 1-1/4" BOLTS (48S), four WASHERS (13M) and four NUTS (24M).
This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
A
B
C
16G
BLACK 7/8" LARGE HEAD SCREW
(8 used in this step)
17S
NUT (4 used in this step)
24M
WASHER (4 used in this step)
13M
SILVER 1-1/4" BOLT (4 used in this step)
48S
E
Maximum
210 degrees
Minimum
190 degrees
Arrow
Flat edge
