Sauder Beginnings 413037 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-17
Français pg18-20
Español pg 21-23
Lot # 390061 04/22/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Panel TV Stand
Beginnings Collection | Model 413037
Smart stand
for the idiot box.

Table of Contents Assembly Tools Required
3
4
5-17
18-20
21-23
24-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too large for the available space might be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly!
• This Sauder unit is designed for use with televisions weighing less than 70 pounds. Never use with a TV that weighs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diagram.
• Never place the front edge of the TV past the front edge of the TV support shelf (or stop molding – if equipped)
• Never allow the sides of the TV to extend past the side edges of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warning label as instructed in the last assembly step. The label provides important safety related information.
WARNING
!
70 lbs.
70 lbs.
15-1/2"
15-1/2"
39-1/4"
39-1/4"
Skip the power trip.
This time.
413037 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C RIGHT UPRIGHT (1)
D LEFT UPRIGHT (1)
D40 RIGHT DRAWER SIDE (1)
D41 LEFT DRAWER SIDE (1)
D69 DRAWER BACK (1)
D621 DRAWER BOTTOM (1)
E TOP (1)
F BOTTOM (1)
G SHELF (1)
H BACK (1)
I ADJUSTABLE SHELF (1)
J SMALL ADJUSTABLE SHELF (2)
K DRAWER FRONT (1)
Now you know
our ABCs.
413037www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
I
J
K
D69 D40
D41
J
D621

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
413037 www.sauder.com/servicesPage 4
SMALL DRAWER
FRONT BRACKET - 1
7G
3M ANTI-SKID PAD - 1
(Refer to the last step for proper
location and application)
WARNING LABEL - 1
2L
WARNING
Never use this furniture with a TV that is too
large or too heavy. Severe injury or death
can occur.The TV and furniture will be
unstable and may tip.
-The TV must less than 70 lbs.
-The base of the TV must be able to sit
completely on this shelf.
-Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not try
to remove. Surface will be damaged.
02/ 02 269224
35DA CABINET RIGHT - 1 35DB CABINET LEFT - 1 35DC DRAWER RIGHT - 1 35DD DRAWER LEFT - 1
BLACK 9/16" PAN HEAD SCREW - 4
51S
SHELF SNAP - 8
6R
BROWN 7/16" LARGE HEAD SCREW - 2
6S
BLACK 1-7/8" FLAT HEAD SCREW - 12
2S
CAM COVER - 8
12P
FOOT - 4
1E
SCREW COVER - 4
20P
3S GOLD 5/16" FLAT HEAD SCREW - 8
METAL PIN - 12
1R
NAIL - 22
1N
HIDDEN
CAM - 8
1F CAM DOWEL - 8 2F PULL - 1 45K
SILVER 3/4" MACHINE SCREW - 2
53S
RUBBER SLEEVE - 4
2R
30S BLACK 1-9/16" FLAT HEAD SCREW - 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push eight HIDDEN CAMS (1F) into the ENDS (A and B) and
UPRIGHTS (C and D). Then, insert a CAM DOWEL (2F) into
each HIDDEN CAM.
413037www.sauder.com/services Page 5
A
B
C
D
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
1F
2F
(8 used)

Step 2
å Fasten the CABINET RIGHT (35DA) and CABINET LEFT (35DB)
to the UPRIGHTS (C and D). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S).
413037 www.sauder.com/servicesPage 6
C
D
35DA
35DA
35DB
35DB
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Roller end
1
3
2
1
3
2
Finished edge
Roller end
Finished edge
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS

å Fasten the UPRIGHTS (C and D) to the SHELF (G). Use
four BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 3
413037www.sauder.com/services Page 7
C
D
G
If there is an unfinished surface,
it should be positioned here.
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Finished edge
Finished edge
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

Step 4
å Fasten the UPRIGHTS (C and D) to the TOP (E). Tighten
four HIDDEN CAMS.
413037 www.sauder.com/servicesPage 8
C
D
E
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with holes
Finished edge
Finished edge
Long finished edge

å Fasten the ENDS (A and B) to the TOP (E). Tighten four
HIDDEN CAMS.
Step 5
413037www.sauder.com/services Page 9
E
A
B
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Finished edge
Finished edge
Arrow
Minimum
190 degrees
Maximum
210 degrees

Step 6
å Fasten the BOTTOM (F) to the ENDS (A and B) and
UPRIGHTS (C and D). Use eight BLACK 1-7/8" FLAT
HEAD SCREWS (2S).
413037 www.sauder.com/servicesPage 10
A
B
C
D
F
BLACK 1-7/8" FLAT HEAD SCREW
(8 used in this step)
2S
Long finished edge
Surface with
more holes
