Sauder Harbor View 403794 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-36
Français p 37-40
Español p 41-44
Lot # 390206 04/13/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Corner Desk
Harbor View Collection | Model 403794
For all your
newfanled gadgetry.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
A DOOR RIGHT END (1)
B DOOR LEFT END (1)
C DRAWER RIGHT END (1)
D DRAWER LEFT END (1)
D24 SMALL RIGHT DRAWER SIDE (2)
D25 SMALL LEFT DRAWER SIDE (2)
D28 RIGHT DRAWER SIDE (1)
D29 LEFT DRAWER SIDE (1)
D78 DRAWER BACK (1)
D109 SMALL DRAWER BACK (2)
D707 DRAWER BOTTOM (1)
D716 SMALL DRAWER BOTTOM (2)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G3 TOP (1)
H2 SMALL TOP (1)
I MODESTY PANEL (2)
J BOTTOM (1)
K BACK (2)
L BRACE (2)
M DOOR (1)
N DRAWER FRONT (1)
S2 KEYBOARD UPRIGHT (2)
T KEYBOARD SHELF (1)
U SMALL DRAWER FRONT (2)
X BASE (2)
AA RIGHT MOLDING (1)
BB LEFT MOLDING (1)
2-3
4-5
6-36
37-40
41-44
45-46
47
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
403794 www.sauder.com/servicesPae 2
Electric drill with 1/8" bit
(ONLY in indicated step)

Part Identification
403794www.sauder.com/services Pae 3
A
B
C
D
E
F
G3
H2
I
J
K
L
M
S2
T
X
AA
BB
I
K
S2
X
L
D716 D707
D29
D28
D78
D109
D25
D24
UN
D716
D109
D25
D24
U

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
403794 www.sauder.com/servicesPae 4
FILE GLIDE - 2
RR
GG LONG RIGHT
CABINET RAIL - 1 HH LONG LEFT CABINET RAIL - 1 JJ LONG LEFT DRAWER SLIDE - 1
II LONG RIGHT
DRAWER SLIDE - 1
FILE ROD - 2
SS
35DA CABINET RIGHT - 2 35DD DRAWER LEFT - 2 35DC DRAWER RIGHT - 2 35DB CABINET LEFT - 2
PLATE - 2
TT KNOB - 4 WW
HIDDEN CAM - 18
PP2 CAM DOWEL - 18
QQ2
HIDDEN CONNECTOR - 4
OO
40AW CABINET RIGHT - 1 40AX CABINET LEFT - 1 40AY DRAWER RIGHT - 1 40AZ DRAWER LEFT - 1
UU HINGE - 2

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
403794www.sauder.com/services Pae 5
FELT DISC CARD - 1
FFF
ANGLE BRACKET - 10
BBB METAL PIN - 4
DDD EEE SLIDE CAM - 6
BLACK 1-1/8" PAN HEAD SCREW - 14
HHH
CONNECTOR SCREW - 4
NNN
BLACK 1-7/8" FLAT HEAD SCREW - 6
GGG
III BROWN 1" FLAT HEAD SCREW - 4
LLL GOLD 5/16" FLAT HEAD SCREW - 28 BLACK 1/2" FLAT HEAD SCREW - 4
MMM
NAIL - 30
OOO
CORD CLIP - 5
AAA
BLACK 9/16" LARGE HEAD SCREW - 36
JJJ
GROMMET CAP - 1
1P GROMMET - 1 10P
METAL BRACKET - 4
2G
30S BLACK 1-9/16" FLAT HEAD SCREW - 12

403794 www.sauder.com/servicesPae 6
å IMPORTANT: Follow the video to the riht for this option.
å IMPORTANT: Follow the video to the riht for this option.
DOOR ON RIGHT AND
DRAWERS ON LEFT
DOOR ON LEFT AND
DRAWERS ON RIGHT
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1476
to watch a video on how to assemble your unit.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1477
to watch a video on how to assemble your unit.

Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Use your hammer to tap four HIDDEN CONNECTORS (OO)
with SCREWS into the KEYBOARD UPRIGHTS (S2).
Step 2
å Insert a CONNECTOR SCREW (NNN) into each
HIDDEN CONNECTOR (OO).
NNN
OO
OO
STOP
If you purchased
the 403786
Hutch, assemble
that unit first.
403794www.sauder.com/services Pae 7
S2
S2

Step
å Push eihteen HIDDEN CAMS (PP2) into the ENDS (A, B, C,
and D), UPRIGHTS (E and F), BOTTOM (J), and BRACES (L).
Then, insert the metal end of a CAM DOWEL (QQ2) into each
HIDDEN CAM.
Step 3
403794 www.sauder.com/servicesPae 8
Arrow
PP2
QQ2
(18 used)
Arrow
PP2
QQ2
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tihten the HIDDEN CAMS in this step.
C
D
E
F
J
A
BL
L

StepStep 4
35DA
35DA
35DB
35DB
å Fasten the CABINET RIGHTS (35DA) and CABINET
LEFTS (35DB) to the DRAWER ENDS (C and D). Use
eiht GOLD 5/16" FLAT HEAD SCREWS (LLL) throuh
holes #1 and #3.
å Fasten the LONG CABINET RAILS (GG and HH) to the
DRAWER ENDS (C and D). Use four GOLD 5/16" FLAT
HEAD SCREWS (LLL) throuh holes #1 and #3.
å NOTE: The LONG CABINET RAILS (GG and HH) are
marked "CABINET RIGHT" and "CABINET LEFT" for
easy identification.
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
LLL
Roller end
1
3
2
1
3
2
C
D
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
1
3
2
1
3
2
4
Roller end
1
3
2
1
3
2
4
HH
GG
Remember:
Rihty tihty.
Lefty loosey.
403794www.sauder.com/services Pae 9

Step
403794 www.sauder.com/servicesPae 10
Step 5
GOLD 5/16" FLAT HEAD SCREW
(4 used for the CABINET RAILS)
LLL
S2
Surface with
HIDDEN CONNECTORS
Roller end
Roller end
40AW
40AW
40AX
40AX
å Fasten a CABINET RIGHT (40AW) and a CABINET LEFT (40AX) to the
KEYBOARD UPRIGHTS (S2). Use four GOLD 5/16" FLAT HEAD SCREWS (LLL).
å NOTE: Be sure to use the exact holes shown.
å Fasten the METAL BRACKETS (2G) to the KEYBOARD UPRIGHTS (S2). Use
four BLACK 9/16" LARGE HEAD SCREWS (JJJ).
å NOTE: Be sure the edes of the METAL BRACKETS are even with the edes of
the KEYBOARD UPRIGHTS.
S2
Surface with
HIDDEN CONNECTORS
BLACK 9/16" LARGE HEAD SCREW
(4 used for the METAL BRACKETS)
JJJ
2G
2G
2G
2G

å Fasten the LEFT UPRIGHT (F) to the RIGHT UPRIGHT (E).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (GGG).
Step 6
403794www.sauder.com/services Pae 11
E
F
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
GGG
Ede with CAM DOWEL
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step
å Insert four METAL PINS (DDD) into the ENDS (C and D).
å Fasten the ENDS (C and D) to the BRACES (L). Tihten
four HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the ENDS insert into
the holes in the BRACES.
Step 7
403794 www.sauder.com/servicesPae 12
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
C
DL
L
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface
with
HIDDEN
CAMS
DDD
(4 used)
These holes must be here.
Ede with CAM DOWELS

Step
403794www.sauder.com/services Pae 13
å Fasten four ANGLE BRACKETS (BBB) to the DRAWER
ENDS (C and D) and BRACE (L). Use four BLACK 9/16"
LARGE HEAD SCREWS (JJJ).
å NOTE: Be sure the edes of the ANGLE BRACKETS are
even with the edes of the ENDS and BRACE.
å Fasten the BASE (X) to the DRAWER ENDS (C and D)
and BRACE (L). Use four BLACK 9/16" LARGE
HEAD SCREWS (JJJ).
Step 8
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
JJJ
C
D
L
X
BBB
BBB
BBB
(4 used)

Step
å Fasten the DOOR ENDS (A and B) to the BOTTOM (J).
Tihten four HIDDEN CAMS.
Step 9
403794 www.sauder.com/servicesPae 14
Arrow
Minimum
190 derees
Maximum
210 derees
A
B
J
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with
HIDDEN CAMS
These holes must be here.
Ede with CAM DOWELS

Step
403794www.sauder.com/services Pae 15
å Fasten four ANGLE BRACKETS (BBB) to the DOOR
ENDS (A and B) and BOTTOM (J). Use four BLACK 9/16"
LARGE HEAD SCREWS (JJJ).
å NOTE: Be sure the edes of the ANGLE BRACKETS are
even with the edes of the ENDS and BOTTOM.
å Fasten the BASE (X) to the DOOR ENDS (A and B)
and BOTTOM (J). Use four BLACK 9/16" LARGE
HEAD SCREWS (JJJ).
Step 10
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
JJJ
BBB
BBB
BBB
(4 used)
A
B
J
X

Step
å Carefully turn your unit over onto its front edes. Lay the
BACKS (K) over your unit.
å Make equal marins alon all four edes of the
BACKS (K). Push on opposite corners of your unit if
needed to make it "square".
å Fasten the BACKS (K) to your unit usin the NAILS.
å NOTE: Perforations have been provided for access
throuh the BACK. Carefully cut out the rectanle in the
BACK for proper ventilation of your CPU.
Step 11
403794 www.sauder.com/servicesPae 16
Finished
surface
NAIL
(30 used in this step)
OOO
Finished
surface
K
K
A
B
C
D
Ede without holes
Ede without holes
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step
403794www.sauder.com/services Pae 17
Step 12
H2
H2
G3
G3
C
D
B
C
A
A
D
DOOR ON RIGHT AND
DRAWERS ON LEFT
DOOR ON LEFT AND
DRAWERS ON RIGHT
å IMPORTANT: You have the choice of assemblin the unit
two ways. If you want the drawers on the riht and the
DOOR on the left side of the desk, fasten the DRAWER
ENDS (C and D) to the SMALL TOP (H2) and the ENDS (A
and B) to the TOP (G3).
å If you want the drawers on the left and the DOOR on the
riht side of the desk, fasten the ENDS (A and B) to the
SMALL TOP (H2) and the ENDS (C and D) to the TOP (G3)
as shown in the lower diaram.
å NOTE: The followin steps in this book show the first option
with the DOOR on the left and drawers on the riht.
B

å Fasten the DOOR ENDS (A and B) to the TOP (G3).
Tihten four HIDDEN CAMS.
Step 13
403794 www.sauder.com/servicesPae 18
Arrow
Minimum
190 derees
Maximum
210 derees
A
B
G3
The lare hole
must be here.
Surface with more holes
Rounded ede
X

å Fasten the LEFT MOLDING (BB) to the TOP (G3). Use
three BLACK 1-1/8" PAN HEAD SCREWS (HHH).
å NOTE: Do not overtihten the SCREWS into the TOP.
å Fasten the UPRIGHTS (E and F) to the TOP (G3). Tihten
two HIDDEN CAMS.
Step 14
403794www.sauder.com/services Pae 19
Arrow
Minimum
190 derees
Maximum
210 derees
G3
EF
BB
Surface with
HIDDEN CAM
Surface with
HIDDEN CAM
BLACK 1-1/8" PAN HEAD SCREW
(3 used in this step)
HHH

å Use a drill and a 1/8" drill bit to complete the two holes in the
DOOR RIGHT END (A).
å Fasten the MODESTY PANEL (I) to the LEFT UPRIGHT (F). Use
two BLACK 1-1/8" PAN HEAD SCREWS (HHH).
å Fasten the MODESTY PANEL (I) to the DOOR RIGHT END (A).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (GGG).
Step 15
403794 www.sauder.com/servicesPae 20
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the MODESTY PANEL)
GGG
F
I
A
BLACK 1-1/8" PAN HEAD SCREW
(2 used for the LEFT UPRIGHT)
HHH
Use a 1/8" drill bit in the RIGHT END (A).
Cut-out
