Instruction leaflet
shieldLED 400 Recessed
52183, 52184, 52185, 61062
www.saxbylighting.com
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Recycling advice
Safety information
Saxby Lighting Ltd. BH23 3PE
• Werecommendcleaningwithasoftdrycloth.Do
not use solvents or abrasive cleaners as these could
damage the finish.
• Glassparts–Wipewithadampcloth.Donotuse
abrasive materials as these will damage the finish.
• TheLED'sinthisproductarenonreplaceable
Fitting/replacing bulbs
Iss.5 05082015
Check that...
• You have correctly identified the wires.
• Theconnectionsaretight.
• No loose strands have been left out of the connection
block.
• Thatthecoveroverthemainsterminalshasbeen
replaced.
• ConnectthefittingtotheLEDdriver.
• Theceilingsurfacemustbeflatandsmoothtoensure
a good fit.
• Ensure that the LED driver is sitting away from the
unit and has good ventilation.
• Pushthespringclipsupwardsandfitintotheceiling
hole, then push the unit up until firmly in position,
ensuring that no cables are trapped.
• Ensurethattheproductissittingproperlyinthehole.
• Ensureallrubbersealsarecorrectlyinplace.
• Replacefuseor circuitbreaker andswitch on.Your
light is now ready for use.
Commissioning

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactory operation of this product. Please retain these instructions for future reference.
Warning
Specification
Supply: 240V ~ 50Hz
Lamp: 4.5WLED
IP rating: 65
Layout
Thisproductissuitableforusein
Zone 1 and Zone 2 and outside Zones
in a bathroom. See diagram.
If this unit is being fitted in a room
containing a bath or shower, a 30mA
RCDmustbeused-inaccordance
with IEE regulations.
• Theseareonlysuitableforfittingtoaplasterboard
fire rated ceiling.
• Planthedesiredlayoutofthesefittingscarefully,
ensuring the cables will reach the distances between
the transformer and each light fitting.
• EnsurethatthereisadequateventilationfortheLED
driver.
• Avoidlocatinganycablesinpositionsthatwould
cause a hazard. Position cables and junction boxes
(not supplied) away from areas where they may be
at risk from being cut, trapped or damaged
• Themainssupplycablemusthaveaminimumcross
sectional area of 1.0mm²
• Thedistancebetweenunitsmustbe0.5mminimum.
• Theunitmustbelocated0.2mawayfromajoist.
• Thisproductmustbemountedoutofarmsreach.
• ThisproductisratedatIP65.
Ensure free movement of air around the fitting by removing any roof void insulation from at least
150mm around the hole. Under no circumstances must these fittings and drivers be covered with
insulating matting or similar material.
Ceiling Preparation
Existing fittings must be completely removed before
installation of a new product. Before removing the
existing fitting, carefully note the position of each set
of wires.
• PositiontheLEDdrivernexttothemainsoutletthat
thesystemwillconnectto.Donotconnectatthis
stage.
• Afterdecidingthelayoutofthelightfittingsensure
that the cables are long enough to connect to the
desired positions.
• Ensureaminimumceilingvoiddepthof90mmis
available.
• Cutamountinghole57mmdiameterintheceiling
taking care not to foul any pipes, mains cables or
joists beneath the surface.
• Itisalwaysrecommendedtocuttheholeslightly
smaller than the size specified, and then file the hole
until the recessed unit fits snugly.
This product is Double Insulated and does
not require connection to an Earth circuit.
Please read these instructions carefully before
commencing any work.
Thisunitmustbefittedbyacompetentandqualified
electrician.
Install in accordance with IEE Wiring regulations and
currentBuildingRegulations.
ThissystemoperatesatSafetyExtraLowVoltage,via
thesuppliedLEDdriver.Neverconnectthelightfittings
directlytothemainswithoutusingthesuppliedLED
driver.
Topreventelectrocutionswitchoffatmainssupply
before installing or maintaining this fitting. Ensure
other persons cannot restore the electrical supply
without your knowledge.
Thislightfittingmustbeconnectedtoafusedcircuit.
If replacing an existing fitting, make a careful note of
the connections.
Thesefittingsareonlysuitableforfittingtoa
plasterboardfireratedceiling.Thisfittingmustalways
befittedtoaplasterboardceiling.Thismustnotbe
fitted to a plaster and lath ceiling.
Thissystemcontainsnon-replaceablepartsand
cannot be serviced. If damage occurs the part should
be scrapped.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
ThisproductisNOTsuitablefor
direct mounting on normally
flammable surfaces (suitable only for mounting on
non-combustiblesurfaces).
Wiring
TheLEDDriverisdoubleinsulatedandmustnotbeearthed.Ifthereareanyincomingearthcables,theymustbe
joinedtogetherandwellinsulatedwithgoodqualityinsulationtape.Thisistoensureearthcontinuitythroughoutyour
property.
Removethecoverfromthemainsterminalsandhavingcorrectlyidentifiedthewiringfromyourexistinglightfitting,
pullthemainswiringthroughtheholeandconnecttotheconnectionblockinsidetheLEDdriver.
Either the outside or inside terminals can be used, including loop through connections.
MainsLive(L-Brown)
MainsNeutral(N-Blue)
L
N
