Saxby Lighting 76768 Manual

If after routine operation check, the lamp does not remain lit for the three hour period, a new battery pack may be required.
• Switchofftheelectricityatthemains.
•Allowbatteriestofullydischargethenreconnecttosupplyandallowtochargefor24hours.
• Testagainfor3hours,iflightdoesnotremainlitchangethebatterypackasfollows:
•Easetherecessedunitoutfromtheceiling,andgentlypullthecablestoaccessthebattery.
•Unplugthebatteryleadfromtheemergencypack.
• Writecurrentdateonthenewbatterypack.
•Pluginthenewbattery.
• Refitthebatteryandrecessedunitintheceiling.
•Restorepowerandallowtochargefor24hours.
•Performfulloperationcheckandupdatetestrecord.
Battery Replacement
NonMaintained:Lampisnormallyoffandbatteryisonautomaticcharge(LEDisgreen)whenthemainssupplyispresent
Fittingautomaticallyswitchesonthelampwhenthesupplyisinterrupted.
•Connecttheunittothemains(220-240Va.c.).VerifythatthegreenLEDisilluminated;thisconfirmsthatthebatteries
arecharging.
• Chargethebatteryforatleast24hoursbeforefirstuse.
•TheLEDwillbegreen,showingthatmainspowerispresentandthebatteryisbeingcharged.
• IftheLEDisnotilluminatedthentheremaybenoA.C.supply,thebatteryhasnotbeenconnectedproperlyorthe
internal circuit may have failed.
Instruction leaflet
Kyle LED EM Recessed
76768
www.saxbylighting.com SaxbyLighting.BH233PE
Iss125052018
Operating Instructions
Werecommendcleaningwithasoftdrycloth.
Donotusesolventsorabrasivecleanersasthesecoulddamagethefinish.
Care and Cleaning
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.
CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Foryoursafety,alwaysswitchoffthesupplybeforecleaning.
Safety information

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeandsatisfactory
operationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This is a Class 1 product and must be earthed.
Live Voltages may be present in this unit even when
turned off or when completely disconnected.
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupplybefore
installingormaintainingthisfitting.Ensureotherpersons
cannotrestoretheelectricalsupplyknowledge.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteofthe
connections.
Thissystemcontainsnon-replaceablepartsandcannotbe
serviced.Ifdamageoccursthepartshouldbescrapped.
Thisproductisnotsuitablefordimming.
Wasteelectricalproductsshouldnotbedisposedofwith
householdwaste.Pleaserecyclewherefacilitiesexist.
Checkwithyourlocalauthorityorretailerforrecycling
advice.
TheseproductsshouldnotbefittedtoPIRcircuitsorshort
duration timed switches
Specification
Layout
• Planthedesiredlayoutofthisfittingcarefully,ensuringthecableswillreachthedistancebetweenanyjunctionboxes
andthelightfitting.
• Avoidlocatinganycablesinpositionsthatwouldcauseahazard.Positioncablesandjunctionboxes(notsupplied)
awayfromareaswheretheymaybeatriskfrombeingcut,trappedordamaged.
• Themainssupplycablemusthaveaminimumcrosssectionalareaof1.0mm²
• Cablesinwallsmustbeprotectedusingsuitableconduitorplastictrunking.
Wiring
Voltage:AC220-240V~50Hz
Lamp:3WLEDHiPower
IPrating:20
Duration:3hours(180minutes)
OperatingTemperature:-10˚Cto50˚C
MaximumAmbientTemperature:50˚C
ChangeoverTime:<1s
BatterySpecification:3.6V3000mAhNi-Cd
BatteryChargeTime:24hours
ThisunitisonlycapableofbeingwiredinNonMaintainedconfigurations.
Identifythepermanentliveandconnecttotheconnectionblockinsidetheproductinthefollowingway:
Check that...
• You have correctly identified the wires.
• Theconnectionsaretight.
• No loose strands have been left out of the connection
block.
Commissioning
• Refitthecoverontheterminalblock.
•Clipthebatteryintotheconnectorasshownbelow.
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingtheexisting
fitting,carefully note the position of each set of wires.
• Ensureaminimumceilingvoiddepthof250mmis
available.
• Cuta55mmdiametermountingholeintheceiling
takingcarenottofoulanypipes,mainscablesorjoists
beneath the surface.
• Itisalwaysrecommendedtocuttheholeslightly
smallerthanthesizespecified,andthenfilethehole
untiltherecessedunitfitssnugly.
• Ensurefreemovementofairaroundthefittingby
removinganyroofvoidinsulationfromatleast150mm
aroundthehole.Undernocircumstancesmustthese
fittingsbecoveredwithinsulatingmattingorsimilar
material.
• Removetheplasticcoverfromtheterminalblockand
wire as detailed overleaf.
Installation
• Feedtheemergencypackintotheceiling.SeeFig.1.
•Feedthebatteryintotheceilingandpositionalongsidetheemergencypack.SeeFig.2.
• CliptherecessedLEDunitontothesmallconnector,andpushthespringclipsupwardsandfitthetwoarmsintothe
ceilinghole.SeeFig.3.
•Ensurethattheunitisseatedcorrectlyontheceilingandadjustthetilttosuit.SeeFig.4.
Fig. 1. Fig. 2.
Fig. 3. Fig. 4.
