1. SIGNED AND SEALED
With seca products, you are not only purchasing tech-
nology which has been perfected over 100 years, but
also quality with official legal certification confirmed by
institutions. seca products comply with European
directives, standards and national laws. When you buy
seca, you buy the future.
Products bearing this symbol meet the applicable regu-
latory requirements of the European Community, espe-
cially the following:
• Directive 93/42/EEC for medical devices
seca’s professionalism is also recognized by official
testing agencies. TÜV Süd Product Service, the
appointed office for medical devices, confirms with this
certificate that as a medical devices manufacturer,
seca consistently complies with the strict legal require-
ments. seca’s quality assurance system includes the
areas of design, development, production, sales and
service of medical scales and length measuring sys-
tems as well as software and measuring systems for
assessing state of health and nutrition.
seca helps the environment. Saving natural resources
is very important to us. We therefore make every effort
to save on packaging materials wherever it makes
sense and whatever is left over can be conveniently
disposed of on site via the recycling system.
0123

• 59
English
2. DEVICE DESCRIPTION
2.1 Congratulations!
With the seca 684 electronic multi-functional scale, you
have purchased a highly precise and simultaneously
robust device.
For over 170 years, seca has used its experience in the
service of healthcare and, as a market leader, it has
always set standards in many countries of the world
with innovative developments in weighing and measur-
ing.
2.2 Intended use
Electronic multi-functional scale seca 684 is mainly
used in hospitals, medical practices and in-patient care
facilities in accordance with national regulations.
The scale is for conventional determination of weight
and establishment of general state of nutrition; it assists
the physician supervising treatment in making a diag-
nosis or deciding on a course of treatment.
To make an accurate diagnosis, however, other spe-
cific examinations have to be ordered by the physician
and their results taken into account, in addition to
determining a weight value.
2.3 Description of function
On some variants of this scale, the weight display can
be switched between kilograms (kg), pounds (lbs) and
stones (sts). Weight is determined within a few
seconds.
In addition to conventional determination of weight, the
seca 684 provides a function for determining body
mass index. To this end, height is entered on the key-
pad and the body mass index associated with the
weight value is calculated automatically. Length meas-
uring devices from the seca 360° wireless system can
transmit height to the seca 684 wirelessly.

60 •
Via the seca 360° wireless wireless network, measur-
ing results can be transmitted wirelessly to a seca wire-
less printer or to a PC equipped with seca analytics
PC software and the seca USB wireless adapter.
The seca 684 can be moved on casters.
Use the scale only for the purpose named in the sec-
tion entitled "Intended use" on page 59.
2.4 User qualification
Assembly Devices that are shipped partially assembled may only
be mounted by sufficiently qualified persons such as
specialist dealers, hospital technicians or seca service
technicians.
Operation The device may only be operated by healthcare
professionals.

• 61
English
3. SAFETY INFORMATION
3.1 Safety information in these instructions for use
DANGER!
Used to identify an extremely hazardous situa-
tion. If you fail to take note of this information,
serious irreversible or fatal injuries will occur.
WARNING!
Used to identify an extremely hazardous situa-
tion. If you fail to take note of this information,
serious irreversible or fatal injuries may result.
CAUTION!
Used to identify a hazardous situation. If you fail
to take note of this information, minor to moder-
ate injuries may result.
ATTENTION!
Used to identify possible incorrect usage of the
device. If you fail to take note of this information,
you may damage the device, or the measured
results may be incorrect.
NOTE:
Includes additional information about use of the
device.
3.2 Basic safety instructions
Handling the instrument • Please take note of the information in these instruc-
tions for use.
• Keep the instructions for use in a safe place. The
instructions for use are a component of the device
and must be available at all times.
DANGER!
Risk of explosion
Do not use the device in an environment in
which one of the following gases has accumu-
lated:
–oxygen
– flammable anesthetics
– other flammable substances/air mixtures

62 •
CAUTION!
Patient hazard, damage to device
• Additional devices which are connected to
electrical medical devices must provide evi-
dence of compliance with the relevant IEC or
ISO standards (e.g. IEC 60950 for data-
processing devices). Furthermore, all configu-
rations must comply with the requirements of
standards for medical systems (see IEC
60601-1-1 or Section 16 of the 3rd edition of
IEC 60601-1 respectively). Anyone connect-
ing additional devices to electrical medical
devices is considered a system configurer
and is therefore responsible for ensuring that
the system complies with the requirements of
standards for systems. Your attention is
drawn to the fact that local laws take prece-
dence over the above-mentioned require-
ments of standards. In the event of any
queries, please contact your local specialist
dealer or Technical Service.
• Have servicing carried out regularly as
described in the relevant section of this docu-
ment.
• Technical modifications may not be made to
the device. The device does not contain any
parts for servicing by the user. Only have serv-
icing and repairs performed by an authorized
seca service partner. You can find service
partners in your area at www.seca.com or by
sending an e-mail to [email protected].
• Only use original seca accessories and spare
parts, otherwise seca will not grant any war-
ranty.
CAUTION!
Patient hazard, malfunction
• Keep other electrical medical devices, e.g.
high-frequency surgical devices, a minimum
distance of approx. 1 meter away to prevent
incorrect measurements or wireless transmis-
sion interference.
• Keep HF devices such as cell phones a mini-
mum distance of approx. 1 meter away to
prevent incorrect measurements or wireless
transmission interference.

• 63
English
• The actual transmission output of HF equip-
ment may require minimum distances of more
than 1 meter. Details can be found at
www.seca.com.
Preventing electric
shock WARNING!
Electric shock
• Set up the device so that the power supply
socket is easy to reach and the device can be
disconnected from the power supply quickly.
• Ensure that your local power supply matches
the information on the power supply unit.
• Do not touch the power supply unit with wet
hands.
• Do not use extension cables or power strips.
• Ensure that the power cable is not pinched or
damaged by a sharp edge.
• Do not operate the device above an altitude of
3000 m.
Avoiding infections
WARNING!
Risk of infection
• Hygienically reprocess the scales regularly as
described in the respective section in this
document.
• Make sure that the patient has no infectious
diseases.
• Make sure that the patient has no open
wounds or infectious skin alterations, which
may come into contact with the device.
Avoiding injuries
WARNING!
Risk of falling
• Ensure that the device is positioned firmly and
level.
• Route the mains cable so that there is no risk
of tripping for the patient or user.
• The device is not designed as a standing aid.
Assist people with limited motor skills when
they are getting up, e.g. from a wheelchair.

64 •
• Make sure that the patient does not step onto
the weighing platform directly at the edges.
• Make sure that the patient steps onto the
weighing platform slowly and securely.
WARNING!
Danger of slipping
• Ensure that the weighing platform is dry
before the patient steps onto it.
• Ensure that the patients feet are dry before he
or she steps onto the weighing platform.
• Make sure that the patient steps onto the
weighing platform slowly and securely.
Preventing device
damage ATTENTION!
Damage to device
• Ensure that no liquids enter the device. They
can damage the electronics.
• Switch off the device before disconnecting the
power supply unit from the mains socket.
• Disconnect the power supply unit from the
mains socket if you intend to not use the
device for a longer period of time. Only this
way it can be ensured that the device is cur-
rentless.
• Make sure not to drop the device.
• Do not expose the device to any impacts or
vibrations.
• Perform function controls regularly as
described in the relevant section in this docu-
ment. Do not operate the device if it is dam-
aged or not working properly.
• Ensure that there is no heat source in the
immediate vicinity. Do not expose to direct
sunlight. The excessive temperature could
damage the electronics.
• Avoid rapid temperature fluctuations. When
the device is transported so that a tempera-
ture difference of more than 20 °C occurs, it
must stay turned off for at least 2 hours before
it can be turned on again. Otherwise, conden-
sation water will form which can damage the
electronics.

• 65
English
• Caustic detergents may damage the surfaces.
Only use a soft cloth dampened with mild
soapsuds to clean the surfaces of the device.
Handling measuring
results WARNING!
Patient hazard
This device is no diagnostic device. It simply
assists the treating physician in establishing a
diagnosis.
– In order to make a precise diagnosis and
initiate therapeutic measures, besides
determination of the weight, further targeted
examinations must be set up by the
physician, and their results must be
considered.
– The responsibility for diagnosis and treatment
lies with the treating physician.
CAUTION!
Patient hazard
In order to avoid misinterpretations, test results
for medical use must be displayed and used in
SI units only. Some devices offer the ability to
display test results in other units. This is only an
additional function.
– Use the results exclusively in SI units.
– The use of measurement results in non-SI
units is the sole responsibility of the user.
ATTENTION!
Loss of data
• Before you save measurements aquired with
this device and process them for further use
(e.g. in the PC software seca analytics or in a
hospital information system), make sure the
measurement values are plausible.
• If measurement values are transmitted to the
seca analytics PC software or a hospital
information system, make sure prior to further
use that the measurement values are plausi-
ble and are assigned to the correct patient.

66 •
Handling packaging
material WARNING!
Danger of suffocation
Packaging material made of plastic foil (bags) is
a choking hazard.
– Keep packaging material out of reach of
children.
– In the event that the original packing material
may not be available anymore, only use
plastic bags with security holes in order to
reduce the risk of suffocation.
NOTE:
Keep the original packing material for future use
(e.g. returning for maintenance service).

• 67
English
4. OVERVIEW
4.1 Controls
6
2
3
5
4
7
8
910
11
12
1
No. Control Function
1Display housing Central control and display element, can be swiveled
180° to left and right
2Switch scale on and off
3
Arrow key
• During weighing:
- press briefly: activate hold function
- press and hold: activate tare function
• In the menu:
- select submenu, select menu item
- increase value
4
Arrow key
• During weighing:
- press briefly: activate BMI function
- press and hold: call up menu
• In the menu:
- select submenu, select menu item
- reduce value
tare

68 •
4.2 Symbols in the display
5
Enter key
During weighing (if wireless network is set up):
- press briefly: send measuring result to devices ready
to receive it (PC with USB wireless adapter)
- press and hold: print out measuring result (wireless
printer)
•Inthemenu:
- confirm selected menu item
- save set value
6Display Display element for measuring results and to configure
the device
7Folding seat For patients with restricted mobility who cannot stand for
the whole measuring process
8Latch Secures the folding seat in the upright position
9Transport cast-
ers The scale can be moved on these casters.
10 Spirit level Shows whether the device is horizontal
11 Power supply
connection Serves to connect the power pack supplied
12 Foot screw 4 pcs, for precise alignment
No. Control Function
2
A
B
C
Symbol Meaning
AOperation with power pack
BNon-calibratable function active
CMemory location currently in use
2
1
3

• 69
English
4.3 Marking on the device and on the rating plate
Text/symbol Meaning
Model Model number
Ser. no. Serial number
Follow instructions for use
Electrical medical device, type B
Insulated device, protection class II
dValue which gives the difference between two consecutive
display values
Device conforms to EC directives
•0123: appointed office for medical devices: TÜV Süd
Product Service
Symbol of the US Federal Communications Commission
(FCC)
FCC ID Device license number from the Federal Communications
Commission (FCC)
IC Device license number from Industry Canada
Rating plate on the power supply connection socket
•x-y V: required supply voltage
•max xxx mA: maximum current consumption
• : note polarity of device plug
• : operate device with direct current
Do not dispose of device with household waste
0123
use compatible
seca adapter only
x-y V
max. xxx mA

70 •
4.4 Marking on the packaging
Protect from moisture
Arrows indicate top of product.
Transport and store in an upright position.
Fragile
Do not throw or drop.
Permitted min. and max. temperature for transport and
storage
Permitted min. and max. moisture for transport and
storage
Packaging material can be disposed of through recycling
programs.

• 71
English
4.5 Menu structure
Other functions are available to you in the menu for the
device. This enables you to configure the device per-
fectly to suit your needs (details from Page 89).
Reg. Devices (Mo)
•Channel 1 (C1)
•Channel 2 (C2)
•Channel 3 (C3)
StoprF* Group (ID)Learn
Autosend
•on
•off
Autoprint
•HI
•MA
•HI_MA
•off
Time
•Year
•Month
•Day
•Hour
•Minute
Reset
Autohold
•on
•off
Fil
•0
•1
•2
Beep •on
•off
•on
•off
Press
Hold
Unit
•kg
•lbs
•sts
Erkannte Geräte (Mo):
-1: Personenwaage
-2: Längenmessstab
-3: Funkdrucker
-4: PC mit USB-Funkmodul
-7: Babywaage
Raum (ID):
Max. drei seca Funkräume: 0, 1, 2
Maximal-Konfiguration pro Funkraum:
-1 Babywaage
-1 Personenwaage
-1 Längenmessstab
-1 Funkdrucker
-1 PC mit USB-Funkmodul
Kanal (C1, C2, C3):
-Drei Kanäle pro Funkraum ( insg. 9 Kanäle)
-Kanalzahlen: 0-99
-Jede Kanalzahl für nur jeweils einen Kanal
-Empfohlener Abstand: 30
Beispiel-Konfiguration:
-Raum 0: C1__0, C2_30, C3_60
-Raum 1: C1_10, C2_40, C3_70
-Raum 2: C1_20, C2_50, C3_80
(Hinweis: Im Display keine Leerzeichen)
System •on
•off
PT Weight
PT Net Weight
*Funknetzwerk seca 360° Wireless:
•on
•off
Autoclear
Navigation:
Call up menu:
*seca 360° wireless network
Group (ID)
Max. three seca wireless groups: 0,
1, 2
Maximum configuration per
wireless group
- 1 baby scale
- 1 personal scale
- 1 length measuring rod
- 1 wireless printer
- 1 PC with USB wireless adapter
Channel (C1, C2, C3)
- Three channels per wireless
group (total 9 channels)
- Channel numbers: 0 - 99
- Only use each channel number
once
- Recommended spacing: 30
Example configuration
- Group 0: C1 0, C2 30, C3 60
- Group 1: C1 10, C2 40, C3 70
- Group 2: C1 20, C2 50, C3 80
(Note: no spaces in display)
Registered devices (Mo)
- 1: Personal scale
- 2: Length measuring rod
- 3: Wireless printer
- 4: PC with USB wireless adapter
- 7: Baby scale

72 •
5. BEFORE YOU REALLY GET STARTED ...
5.1 Scope of supply
Components
A
B
C
D
E
F
G
H
I
USA/Japan
Euro Australia
UK
J
No. Component Pcs.
AWeighing platform 1
BLeft-hand side part with casters 1
CLeft-hand cover with openings for casters 1
DFolding seat 1
EDisplay support with display housing 1
FRailing with top cross-piece 1
GBottom cross-piece 1
HRight-hand side part 1
IRight-hand cover with opening for power supply connection 1
JPower pack with adapters
(model-dependent: power pack with Euro-connector) 1

Before you really get started ... • 73
English
Fastenings
a
cd
e
f
g
h
i
j
k
b
l
No. Component Pcs.
a Countersunk screw M6 x 12 16
b Threaded plate 4
c
Cap to cover countersunk screws
- black, for side covers
- white, for railing
8
8
d Hexagon bolt M6 x 16 6
e Toothed ring J 6.4 6
f Hexagon nut M6 6
g Pan-head screw M6 x 20 4
h Washer 6.4 4
i Pan-head screw M8 x 20 4
j Washer 8.4 4
k Pan-head tapping screw B 3.5 x 9.5 4
l Cap for display support 2
Allen wrench, WAF 4 mm, not shown 1
Allen wrench, WAF 5 mm, not shown 1
Phillips screwdriver, size 1, not shown 1
Socket wrench WAF 8/10, not shown 1
Open-jawed wrench WAF 10, not shown 1
Instructions for use, not shown 1

74 •
5.2 Assembling the device
We recommend that two people perform the assembly,
as large individual parts have to be aligned with one
another and screwed together.
Fitting the side parts You need the following fastenings for this assembly
step (fitted to the weighing platform):
1. Remove the nuts and toothed rings on both sides
of the weighing platform.
2. Leave the screws in the bores.
3. Place the weighing platform on its front edge and
hold it in this position.
4. Put the right-hand side part on the screws on the
weighing platform.
5. Put one toothed ring and one nut on each of the
screws.
6. Tighten up the nuts.
7. Repeat steps 4. to 6. for the left-hand side part.
6 x M6 x 16 6 x J 6.4 6 x M6
