SECO-LARM Enforcer E-37EV User manual

Monitors up to three zones per
premises or vehicle, plus
manual paging.
One positive and two negative
instant trigger inputs.
Low-battery indicator.
Red LED transmission indicator.
Manual
E-37EV
Code-learning receiver learns
up to three transmitter codes.
Transmitter can page an
unlimited number of receivers.
Colored LEDs or vibrate
function indicate received page.
Unattended page indicator.
Alarm Pager System
NOTE: Antenna required. See page 3 for more details. Antenna not included.

ENFORCER E-37EV Alarm Pager System
2SECO-LARM U.S.A., Inc.
Introduction
The E-37EV is a sophisticated paging system consisting of two parts: a transmitter with trigger
and timing circuitry, and a matching E-37RV receiver with both vibrating and audible paging
functions.
The pager alerts users when a protected building or vehicle is being vandalized or broken into, or
when someone presses the manual paging button. The transmitter has a maximum output power
of 4 watts as allowed by the FCC.
Mount the E-37EV inside the secure area. The transmitter sends a page signal when triggered.
The page signal is received by the small, highly sensitive, lightweight receiver. The receiver
beeps or vibrates and colored LEDs indicate the type of trigger event.
The system is easy to install in any type of building or vehicle. The two 1.5V AAA-sized batteries
(batteries not included) in the receiver will last approximately one month (5 transmissions/day).
The receiver can be programmed to receive page signals from up to 3 separate transmitters and
the transmitter can page an unlimited number of receivers.
Parts List
1 x Transmitter
1 x Receiver (model E-37RV)
1 x Wire harness
3 x Mounting screws
1 x Radio antenna
adapter cord (18”)
Introduction .........................................................................................................................2
Parts List.............................................................................................................................2
Dimensions ........................................................................................................................2
Specifications......................................................................................................................3
Installation....................................................................................................................... 3-4
Wiring..................................................................................................................................4
Connection Diagram ...........................................................................................................5
Programming ......................................................................................................................5
Audible and Visual Signals Chart........................................................................................6
Operation ........................................................................................................................ 6-7
Warning...............................................................................................................................7
Troubleshooting ..................................................................................................................8
Also available from SECO-LARM .......................................................................................8
Table of Contents
Dimensions
15/16”
(33mm)
41/8”
(105mm)
31/8”
(79mm)
21/8”
(54mm)
3”
(76mm)
5/8”
(16mm)

ENFORCER E-37EV Alarm Pager System
SECO-LARM U.S.A., Inc. 3 SECO-LARM U.S.A., Inc. 33 3
Transmitter Installation
1. Mark locations for drilling the mounting bracket holes. Be careful that the area to be drilled
is free from wiring, trim, and/or any other obstructions.
2. Drill holes at the location marks. Position the transmitter where it will be mounted, but do
not secure immediately.
3. The transmitter should be permanently mounted only after all connections and tests
are made.
NOTES:
Do not mount the E-37EV transmitter in the engine compartment as this automatically voids
the warranty.
Do not power up the transmitter before the antenna connections are made as this may
damage the transmitter.
In a building, mount as close to a window as possible.
In a vehicle, mount under the dashboard or in the glove compartment.
Antenna Installation (see Connection Diagram on pg. 5)
The E-37EV can be connected to one of four types of antennas:
TYPE 1: Strip antenna (A Position)
1. E-37ANT (optional) can be used in either a building or vehicle.
2. Connect the male antenna plug into the transmitter jack marked “ANT.”
3. Place the antenna selection switch in the “A” position.
4. Do not secure the strip antenna to metal, window defrosters, or existing antennas.
Installation
Transmitter
Number of codes
Over 2 million (factory pre-set)
Power
12VDC
RF output power
4W max.
Current drain
Standby
10mA
Active
1A
Frequency
27MHz
Antenna impedance
50 Ω
Range
Up to 1/2mile in open air1
Dimensions
41/8”x31/8”x15/16” (105x79x33 mm)
Weight
5.1-oz (145g)
1 Actual range may vary depending on the environment, installation, and/or antenna.
Receiver
Number of codes
Learns up to 3 transmitter codes
Power
3VDC (2 AAA batteries)2
Battery life
Approx. 1 month3
Current drain
Standby
1mA
Active (Beep)
20mA
Active (Vibrate)
50mA
Dimensions
3”x21/8”x5/8” (76x54x16 mm)
Weight
1.6-oz (45g) (without battery)
2 Batteries not included
3 Based on 5 transmissions/day
Specifications

ENFORCER E-37EV Alarm Pager System
4SECO-LARM U.S.A., Inc.
Wiring
Red Wire –Positive 12VDC power
Connect the red wire to a constant +12VDC power source.
Black Wire –Ground
Connect the black wire to the negative terminal of a 12VDC power source.
Optionally, connect to the frame of the vehicle.
Purple Wire –Positive trigger input
Connect the purple wire to a burglar or car alarm output that outputs +12V when the alarm is
triggered (the trigger signals must be at least 1 second long in order to trigger pager.)
Green Wire –Negative trigger input #1
Connect the green wire to a burglar or car alarm output that outputs ground when the alarm
is triggered (the trigger signals must be at least 1 second long in order to trigger pager.)
Blue Wire –Negative trigger input #2
Connect the blue wire to a burglar or car alarm output that outputs ground when the alarm is
triggered (the trigger signals must be at least 1 second long in order to trigger pager.)
White Wire –Fully automatic radio antenna
Connect the long white wire (female spade plug) to the power antenna wire coming from the
power antenna sensor wire.
Connect the short white wire (male spade plug) to the power antenna wire coming from the
radio switched power lead.
Warning: Do not reverse the white wire connections.
TYPE 2: CB antenna (A Position)
1. Connect the male antenna plug of an optional CB antenna into the transmitter jack marked
“ANT.”
2. Place the antenna selection switch in the “A” position.
TYPE 3: Standard radio antenna (B Position)
1. Disconnect the radio antenna lead going into the radio and connect it to the transmitter jack
marked “ANT.”
2. Connect the provided male-to-male 18” radio antenna adapter cord between the transmitter
jack marked “RADIO” and the radio antenna jack.
3. Place the antenna selection switch in the “B” position.
TYPE 4: Fully automatic radio antenna (B Position)
1. Disconnect the radio antenna lead going to the radio and connect to the transmitter jack
marked “ANT.”
2. Connect the provided male-to-male 18” radio antenna adapter cord between the transmitter
jack marked “RADIO” and the radio antenna jack.
3. Cut the power antenna lead running from the radio to the fully automatic radio antenna.
4. Connect the lead coming from the power antenna to the long white wire (marked “To power
antenna sensor wire”).
5. Connect the lead coming from the radio to the short white wire (marked “To radio switched
power lead”).
6. Place the antenna selection switch in the “B” position.

ENFORCER E-37EV Alarm Pager System
SECO-LARM U.S.A., Inc. 5 SECO-LARM U.S.A., Inc. 33 5
Connection Diagram
Programming
The receiver must learn the transmitter’s code before it can receive signals from the transmitter.
The receiver can learn the page codes of up to 3 transmitters.
1. Turn the receiver OFF. Then press and hold the ON//OFF switch and slide it to the ON
position. Continue holding for 3 seconds until the receiver beeps once.
2. The PAGE LED will flash GREEN at a steady rate. The ZONE LED will be solid ORANGE.
This means the receiver is ready to learn the page code of the first transmitter.
3. Press the manual page button on the transmitter. This will send the page signal to the
receiver. The receiver will beep twice and the LEDs will turn off to indicate the code has been
learned. The receiver will beep five times in four minutes if no code is learned.
4. To learn a second (or third) transmitter, repeat step 1 then press down on the ON//OFF
switch once. The PAGE LED will begin flashing RED for the second transmitter and
ORANGE for the third transmitter.
5. Press the manual page button on the second (or third) transmitter. The receiver will beep
twice and the LEDs will turn off to indicate the page code has been learned. The receiver will
beep five times in four minutes if no code is learned.
6. If no additional transmitters need to be learned then move the ON/ /OFF switch back to
the OFF position.
Notes:
The receiver remembers the transmitter codes in EEPROM memory even without
power for over one year. The receiver does not need to re-learn the transmitter codes
after battery replacement.
Only one of each transmitter ID may be learned at a time. For example, if a green
transmitter is already programmed and a new green transmitter is learned, the previous
green transmitter will no longer work.
E-37ANT
(Optional)
Green: First Negative (-) Trigger
Blue: Second Negative (-) Trigger
Purple: Positive (+) Trigger
Black: Ground
Red: Constant +12V to Fuse
Box
White (Long): Power Antenna
White (Short): Radio Switched Power
Lead
Radio (“RADIO”)
Antenna (“ANT”)
Radio
+12 VDC
Ground
Fuse (2A)
Antenna
LED
Manual Page
Antenna Selection
Switch
Cut
Diode
IN4004

ENFORCER E-37EV Alarm Pager System
6SECO-LARM U.S.A., Inc.
1
2
0
V
A
C
Transmitter
ID
Input
Receiver Display
Page LED
Zone LED
Audible / Vibrator
Indicator
Green
Positive Trigger
Green
Green
Groups of 9
Negative Trigger #1
Green
Red
Groups of 9
Negative Trigger #2
Green
Orange
Groups of 9
Manual Page
Green
Green
3 groups of 3
Power ON
Green
None
3 groups of 3
Red
Positive Trigger
Red
Green
Groups of 9
Negative Trigger #1
Red
Red
Groups of 9
Negative Trigger #2
Red
Orange
Groups of 9
Manual Page
Red
Green
3 groups of 3
Power ON
Red
None
3 groups of 3
Orange
Positive Trigger
Orange
Green
Groups of 9
Negative Trigger #1
Orange
Red
Groups of 9
Negative Trigger #2
Orange
Orange
Groups of 9
Manual Page
Orange
Green
3 groups of 3
Power ON
Orange
None
3 groups of 3
Audible and Visual Signals Chart
Operation
Receiver Switch Settings
: Beeping only ON: Vibration only OFF: Receiver off
Trigger Duration
The transmitter will transmit the page signal for a cycle of about 30 seconds, whether or not
the triggered zone is reset. If the same zone remains triggered, the transmitter will not start
a new transmission cycle. However, a new cycle will begin once another un-triggered zone
is triggered.
Manual Paging
When triggered by the manual page button the receiver will beep (or vibrate) continuously
for 1 minute in 3 groups of 3.
The Page LED will indicate which transmitter is sending the signal (Green, Red, or Orange).
The Zone LED will flash green.
Press the ON//OFF button after 30 seconds to stop the indicator.
Power-On Paging
When the transmitter is connected to power the receiver will beep (or vibrate) continuously
for 1 minute in 3 groups of 3.
The Page LED will indicate which transmitter is sending the signal (Green, Red, or Orange).
The Zone LED will remain blank.
Press the ON//OFF button after 30 seconds to stop the indicator.

ENFORCER E-37EV Alarm Pager System
SECO-LARM U.S.A., Inc. 7 SECO-LARM U.S.A., Inc. 33 7
Warning
Ensure that an antenna is connected before connecting power to the unit. Failure to do so may
damage the transmitter.
Do not open the receiver or transmitter cases. All adjustments have been made at the factory.
There are no user serviceable parts inside.
Holes marked 1, 2, and 3 on the transmitter case are factory set. Do not make any
adjustments in these holes.
Use only AAA size 1.5V alkaline batteries for the receiver.
Alarm Paging
When triggered by either the purple (+), green (-), or blue (-) triggers, the receiver will beep
(or vibrate) continuously for 1 minute in groups of 9.
The Page LED will indicate which transmitter is sending the signal (Green, Red, or Orange).
The Zone LED will indicate which trigger was triggered.
-Positive trigger (purple wire) will flash green.
-Negative trigger #1 (green wire) will flash red.
-Negative trigger #2 (blue wire) will flash orange.
Press the ON//OFF button after 30 seconds to stop the indicator.
Receiver Power-On
The receiver will beep (or vibrate) once each time the receiver is turned on.
Unattended Indicator
The receiver will beep (or vibrate) once every 30 seconds to remind the user that it received
a page signal from the transmitter.
Press the ON//OFF button to stop the indicator.
Low-Battery Indicator
The receiver will beep (or vibrate) twice following power-on if the batteries are low.
The receiver will also beep (or vibrate) twice every 60 seconds when the batteries are low.
Viewing the Page Memory
Scroll back the page signal memory by pressing the ON//OFF button repeatedly.
The receiver remembers the last 6 page signals received.
Page signals will be shown one by one, beginning with the most recent.
The receiver will beep once for an alarm page, but will not beep for a manual page.
The receiver will beep three times to indicate that all signals have been viewed, or that no
signals are stored.
Two consecutive page signals carrying the same information are treated as one.
Turning off the receiver will erase all stored signals.

ENFORCER E-37EV Alarm Pager System
8SECO-LARM U.S.A., Inc.
MiE-37EV_1209.docx
PIHKK2
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original customer. SECO-LARM’s obligation is limited to the
repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair
or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such
equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM and the purchaser’s exclusive remedy shall be limited to replacement or repair only, at
SECO-LARM’s option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal
or property damages of any kind to the purchaser or anyone else.
NOTICE
The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM
policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right to change
specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2012 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or
in part, without the written permission of SECO-LARM.
SECO-LARM U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: [phone]
Website: www.seco-larm.com
E-mail: [e-mail]
Also Available from SECO-LARM
E-37RV Vibrating Transmitter
E-37ANT Strip Antenna
FCC COMPLIANCE STATEMENT
Information to the user: This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his or her own expense.
Troubleshooting
No page signal
Check that all connections are securely made
Check that the antenna is securely fastened
Check the receiver batteries
Possibly out of range –Move antenna to better position
Make sure the antenna selection switch is in the correct
position
Check that the transmitter has been properly learned
Receiver only outputting vibrate/beep
Check that the receiver is in the correct alert mode
