SECO-LARM Enforcer Voice Dialer E-920A User manual

Voice Dialer
Model: E-920A
Automatically dials up to four telephone
numbers and delivers up to two different
messages when triggered by an alarm system.
FEATURES
®920A — VOICE DIALERENFORCER
SPECIFICATIONS:
M
I
H
G
F
JK
L
N
C
B
E
A
D
A. Siren jack (piezo siren output)
B. Sensor input modular connector
C. Telephone line modular connector
D. DC adapter jack
E. 9VDC battery compartment
F. Speaker
G. Microphone
H. Dial keys
I. Power switch
J. LCD display
K. MODE button
L. MEMORY button
M. VOICE memory button
N. DIP Switches for programming
CONTROLS:
ENFORCER
Voice Dialer
!Easily connects to an alarm panel and
automatically dials out when activated.
!Two independent voice messages. Stores up to
four telephone numbers, cellular numbers or pager
numbers.
!Delivers a message of up to 16 seconds to
each number stored.
!Instant trigger or exit and entry delay settings.
!Repeats message two times to ensure full message
is delivered.
!Waits 8 to 10 rings; calls back unanswered
numbers up to 8 times.
!EEPROM retains memory if power is lost for up to
one year.
!Optional 9-Volt internal battery provides stand-by
power for approximately two to three days.
!Can be used worldwide due to Universal Dial Tone.
!Can be used with PBX and regular telephone
systems.
Power
Current Draw
Trigger Inputs
Temperature Range
Number of Tel. #
Max. Digits per Tel. #
Case Material
Weight
Dimensions
E-920A
12VDC
20mA (standby)
60mA (operate)
2 N.C. Inputs
-200C to +500C
-40F to +1220F
Up to 4
32
ABS plastic
10.6 oz. (300gm)
53/4” x 4” x 11/2”
146 x 102 x 38mm
Tel: [phone] (Domestic U.S. & Canada) Tel: [phone] (California &international)
Fax: [phone] Email: [email protected] Website: www.seco-larm.com
SECO-LARM
®
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
E920A.pmd
La póliza de SECO-LARM esta en continuo mejoramiento. Por esa razón, SECO-LARM se reserva el derecho de cambiar precios y especificaciones sin previo aviso. SECO-LARM no se hace responsable de errores de imprenta.
