Shini Budget SG-24EB Series User manual

SG-24EB Series
"Budget" Screenless Granulators
Date:Nov, 2018
Version:Ver.A(English)

3(60)
Contents
1. General Description..................................................................................... 7
1.1 CodingPrinciple...................................................................................... 8
1.2 Feature.................................................................................................... 8
1.3 TechnicalSpecifications........................................................................ 10
1.4 SafetyRegulations................................................................................ 11
1.4.1 SafetySignsand Labels............................................................. 11
1.4.2 Transportation andStorageoftheMachine................................ 13
1.5 ExemptionClause................................................................................. 15
2. Structural Features and Working Principle.............................................. 16
2.1 GeneralDescription.............................................................................. 16
2.1.1 WorkingPrinciple........................................................................ 16
2.2 SafetySystem....................................................................................... 17
2.2.1 SafetySwitch.............................................................................. 17
2.2.2 Lock............................................................................................ 17
2.3 AssemblyDrawing ................................................................................ 19
2.3.1 AssemblyDrawing(SG-2417EB)................................................ 19
2.3.2 PartsList (SG-2417EB).............................................................. 20
2.3.3 AssemblyDrawing(SG-2427EB)................................................ 22
2.3.4 PartsList (SG-2427EB).............................................................. 23
2.3.5 AssemblyDrawing(SG-2436EB)................................................ 25
2.3.6 PartsList (SG-2436EB).............................................................. 26
2.3.7 CuttingChamber......................................................................... 28
2.3.8 CuttingChamberPartsList......................................................... 28
2.3.9 Blade Rest.................................................................................. 29
2.3.10 Blade Rest PartsList.................................................................. 29
2.3.11 TransmissionParts..................................................................... 30
2.3.12 TransmissionPartsList.............................................................. 30
2.3.13 Feed Box, Sound Insulation BoxandCheck Plate..................... 31
2.3.14 Feed Box, Sound Insulation BoxandCheck PlatePartsList..... 31
2.3.15 StorageBox................................................................................ 31

4(60)
2.3.16 StorageBoxPartsList................................................................ 31
2.3.17 MainBody................................................................................... 32
2.3.18 MainBodyPartsList................................................................... 32
2.4 ElectricalDiagram................................................................................. 33
2.5 OptionalAccessories............................................................................ 41
2.5.1 ManualCollection Bins............................................................... 41
2.5.2 30-SecInstant RecyclingSystem............................................... 41
2.5.3 OtherOptions............................................................................. 41
3. Installation and Debugging........................................................................ 42
3.1 Installation Notice.................................................................................. 43
3.2 Installation Place................................................................................... 44
3.3 Installation of Bearingand BladeRest.................................................. 44
3.4 Installation of Motor............................................................................... 45
3.5 Installation of RotatingBlade andFixed Blade...................................... 46
3.6 Installation of Feed Box, Feed Throat and StorageBox........................ 48
4. Operation Guide......................................................................................... 49
4.1 StartupPretest...................................................................................... 49
4.1.1 BeforetheFirst Startup............................................................... 49
4.1.2 AfterFirst Startupfor2Hours..................................................... 49
4.1.3 AfterFirst Startupfor20~30 Hours............................................. 49
4.2 Circuit Connection................................................................................. 49
4.2.1 Check theRunningDirection ofthe Motor.................................. 50
4.3 Openingthe FeedBoxandtheStorageBox......................................... 50
4.3.1 Openingthe FeedBox................................................................ 50
4.3.2 Openingthe StorageBox........................................................... 51
4.4 Closingthe Feed Boxand theStorageBox.......................................... 51
4.4.1 Closingthe Feed Box................................................................. 51
4.4.2 Closingthe StorageBox............................................................. 51
4.5 Start and StoptheGranulator............................................................... 52
5. TroubleShooting........................................................................................ 53
5.1 Granulatordoesn'trun........................................................................... 53
5.2 OtherReasonsforShutdown................................................................ 53
6. Maintenance and Repair............................................................................ 54

5(60)
6.1 Preservation.......................................................................................... 54
6.1.1 Replacethe Blades..................................................................... 54
6.2 Transmission......................................................................................... 56
6.2.1 RoutinePreservation ofReducer................................................ 56
6.3 Preservation.......................................................................................... 57
6.3.1 DailyCheck................................................................................ 57
6.3.2 WeeklyCheck............................................................................. 57
6.3.3 MonthlyCheck............................................................................ 57
6.4 Cleaning................................................................................................ 58
6.5 MaintenanceSchedule.......................................................................... 59
6.5.1 About theMachine...................................................................... 59
6.5.2 Check AfterInstallation............................................................... 59
6.5.3 DailyCheck................................................................................ 59
6.5.4 WeeklyCheck............................................................................. 59
6.5.5 MonthlyCheck............................................................................ 59
6.5.6 Check Half-yearlyorEvery1000 RunningHours....................... 59
6.5.7 3yearChecking.......................................................................... 60
Tableindex
Table1-1 TechnicalSpecifications................................................................. 10
Table2-1 PartsList (SG-2417EB).................................................................. 20
Table2-2 Partslist (SG-2427EB)................................................................... 23
Table2-3 PartsList (SG-2436EB).................................................................. 26
Table2-4 CuttingChamberPartsList............................................................ 28
Table2-5 BladeRestPartsList ..................................................................... 29
Table2-6 Transmission PartsList.................................................................. 30
Table2-7 FeedBox,SoundInsulation Boxand Check PlatePartsList......... 31
Table2-8 StorageBoxPartsList................................................................... 31
Table2-9 MainBodyPartsList...................................................................... 32
Pictureindex

6(60)
Picture1-1 Dimensions.................................................................................. 10
Picture2-1 WorkingPrinciple......................................................................... 16
Picture2-2 SafetySwitch............................................................................... 17
Picture2-3 AssemblyDrawing(SG-2417EB)................................................. 19
Picture2-4 AssemblyDrawing(SG-2427EB)................................................. 22
Picture2-5 AssemblyDrawing(SG-2436EB)................................................. 25
Picture2-6 CuttingChamber.......................................................................... 28
Picture2-7 BladeRest................................................................................... 29
Picture2-8 Transmission Parts...................................................................... 30
Picture2-9 FeedBox, Sound InsulationBoxandCheck Plate...................... 31
Picture2-10 StorageBox............................................................................... 31
Picture2-11 MainBody.................................................................................. 32
Picture3-1 InstallationSpace........................................................................ 43
Picture3-2 InstallationPlace.......................................................................... 44
Picture3-3 InstallationofBearingand BladeRest 1...................................... 44
Picture3-4 InstallationofBearingand BladeRest 2...................................... 45
Picture3-5 InstallationofMotor1................................................................... 45
Picture3-6 InstallationofMotor2................................................................... 46
Picture3-7 InstallationofRotatingBladeandFixed Blade1......................... 46
Picture3-8 InstallationofRotatingBladeandFixed Blade2......................... 47
Picture3-9 InstallationofRotatingBladeandFixed Blade3......................... 47
Picture3-10 Installation of FeedBox, Feed ThroatandStorageBox1......... 48
Picture3-11 Installation of FeedBox, Feed ThroatandStorageBox2......... 48
Picture4-1 Openingthe Feed Box................................................................. 50
Picture4-2 Openingthe storagebox.............................................................. 51
Picture4-3 MotorCircuit................................................................................ 52
Picture6-1 Replacethe Blades...................................................................... 55
Picture6-2 Removethe Fixed Blades............................................................ 55
Picture6-3 Removethe RotatingBlades....................................................... 56

7(60)
1.General Description
Pleaseread thismanualcarefullybeforeusingthismachineinorderto
operatecorrectlyagainst anydamagecaused duetoimproperoperation.
Note!
Alwaystakegreatcarewhen the knivesarewithinreach,theyarevery
sharpand can causepersonalinjury.
Forbiddentoprocess flammableortoxicmaterial!
SG-24EBseries"Budget"screenlessgranulatorsaresuitableforinstantrecycling
orgranulatinghardandthick materials.WithEuropean-type styleand compact
size,theyfeaturelowrotatingspeed,lowabrasion andsupersoundproof.Unique
cuttingbladesdesignensureswell-proportioned granulesandminimalamountof
dusts. It seasytocleanand safetooperate.Theunique transmission designcuts
the cost greatly.
Model: SG-2417EB

8(60)
1.1CodingPrinciple
1.2Feature
Standardconfiguration
lExcellent gearmotorfeaturesreliableperformance, longservicelifeand
hightorque.
lIntegraldesignofteethcuttersandstaggered bladesmakesroughly
grindingand finegrindingsimultaneouslytomixwithnewmaterials.
lEven granulewithlittledust.
lUnique screwgearingtransmissiondesignmakesit runningstablywith
lownoiselevel.
lEuropean type appearance,compact insizeand easytoaccess for
cleanigandmaintenance.
lFeedinghopperadoptsvisiblewindowinweldingwaytomakesolid
structure.
lEasymotorinstallationandmaintenance.
Accessoryoption
lStainless steelfeedinghopperand storagebinareoptional.

9(60)
All serviceworkshouldbe carried out byaperson withtechnicaltrainingor
correspondingprofessionalexperience.The manualcontainsinstructionsforboth
handlingand servicing.Chapter6, whichcontainsserviceinstructionsintendedfor
serviceengineers. Otherchapterscontaininstructionsforthedailyoperator.
Anymodificationsofthemachinemustbe approved bySHINI inordertoavoid
personalinjuryand damagetomachine.Weshall not beliableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellent after-salesservice. Shouldyou haveanyproblem
duringusingthemachine,pleasecontactthecompanyorthelocalvendor.
HeadquarterandTaipeifactory
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc
Tel:[phone]
ShiniPlastics TechnologiesIndiaPvt.Ltd.
Tel:[phone]

10(60)
1.3Technical Specifications
Picture1-1 Dimensions
Table1-1 TechnicalSpecifications
Model SG-2417EB SG-2427EB SG-2436EB
Motor Power (kW, 50/60Hz) 0.75 / 0.86 0.75 / 0.861.5/ 1.75
RotatingSpeed (r.p.m,50/60Hz) 27/32.5 27/32.5 27/32.5
Capacityof optional manual
collection bins(L)
30 40 48
Material of TeethCutters SKD-11 SKD-11 SKD-11
Numberof Staggered Blade1 2 3
Number TeethCutters 2 3 4
CuttingChamber (mm) 240×175 240×270 240×365
Max. Throughput Capacity(kg/hr) 3.5 6 8.5
NoiseLevel dB(A) 80~85 80~85 80~85
Dimensions
H (mm) 1360 1360 1400
W(mm) 566 713 899
W1 (mm) 268 338 428
D (mm) 530 530 530
D1(mm) 297 297 297
Weight (kg) 180 220 260
Note: 1) The skewteethcutteris standardequipped; and thenarrowand
widenedskewteethcutter areoptional.
2) Max. Capacityof themachineissubject tothesizeand composition

11(60)
ofthe material.
3) Noiselevelvariesaccording todifferent granules.
4) Toavoidplastic fromsticking totheblades, all materialsshould be
crushed at normaltemperature.
5) Power supply: 3Φ,230 / 400 / 460 / 575VAC, 50 /60Hz.
1.4 SafetyRegulations
Followthe instructionsinthismanualtoavoidpersonalinjuryand damageto
machine components.
Thefollowingsafetymeasuresshall befollowed when operatingthe granulator.
1.4.1SafetySignsand Labels
Electricalinstallation mustonlybe donebyacompetent electrician!
Beforethegranulatorisopened forservicing andmaintenance,always
disconnect the powerwithboththe mainswitchandthe controlswitchon
the granulator.
Neverput anypartofyourbodythroughthe granulatoropenings, unless
boththemainswitchand the controlswitchonthegranulatorarein
"OFF"position.
Highvoltage! Danger!
Thissignisattachedonthecontrolboxand the wiringbox.
Be carefulwiththe rotatingknives, theyareverysharpandcancause
personalinjury!
If therotormust beturned manually-do thiswithgreat care!
Thegranulatorshouldnotbe abletostart beforethehopperandscreen
bracketareproperlyclosed.
Attention please!
Earprotectionisusedduringgranulatingofplasticmaterials.

12(60)
Makesurethepowerhasbeencutoff beforeopeningthefeed box.
Attention！
Noneed forregularinspectionbecauseall theelectricalpartsinthe
controlunit arefixed tightly！
When operatethe granulator,pleasenoticethefollowingsigns
Hazard
Highvoltage!
Maylead tocasualtyorotherseriousdanger.
Pleasecutoffthe powerbeforerepairing.
Circuit diagramshouldonlybe changed by
professionals.
Groundingisnecessary.
Warning
Thereisapinchrisk forthisprotectivecover
keep somedistanceawayfromthat.
Warning
Thecutterareverysharp, cancauseinjury
takeoutoropen protectivecoverisnot
allowed when it isrunning.
Keepsomedistanceawayfromthecutters.
Notice
Read the instructionmanualcarefullybefore
operating.
Beforestart, do thesafetydevicetest
accordingtotheinstruction. It isnot allowed
tochangethedesignofthe machine unless it
isapproved fromthemanufacturer.

13(60)
1.4.2Transportation andStorageoftheMachine
Transportation
1)SG-24EB seriesofgranulatorsarepackedinplywood caseswithwooden
palletat the bottom, suitableforquick positioningbyforklift.
2)Afterunpacked, castorsequipped onthemachine canbeused foreaseof
movement.
3)Donotrotatethe machine and avoidcollision withotherobjectsduring
transportationtoprevent improperfunctioning.
4)Thestructureof themachineiswell-balanced, althoughitshouldalsobe
handled withcarewhenliftingthemachineforfearoffallingdown.
5)Themachineand itsattachedpartscanbekept atatemperaturefrom
-25 to+55 forlongdistancetransportation and forashort distance,
it can be transported withtemperatureunder+70 .
Storage
1)SG-24E seriesshouldbe stored indoorswithtemperaturekeptfrom5 to
40 and humiditybelow80%.
2)Disconnectall powersupplyand turnoffmainswitchand exigencystop
switch.
3)Keepthewholemachine,especiallythe electricalcomponentsawayfrom
watertoavoidpotentialtroublescaused bythe water.
4)Useplasticfilmtocoverthe machine tightlytoprevent themachine from
dustandrains.
Workingenvironment
Themachineshouldbeoperated:
1)Indoorsinadryenvironment withmax. temperature+45 andhumidity
no morethan80%.
Donotusethemachine:
1)Ifit iswithadamaged cord.
2)Onawet floororwhen it isexposed toraintoavoidelectricshock.

14(60)
3)Ifithasbeendropped ordamaged untilitischecked orfixedbya
qualifiedserviceman.
4)Thisequipmentworks normallyintheenvironmentwithaltitudeover
3000m.
5)At least1msurroundingspaceisrequested when thisequipmentis
running.Keepthisequipmentawayfromflammablesourcesatleasttwo
meters.
6)Inthe workarea ofvibration andstrongmagneticforce.
Rejectedpartsdisposal
When the equipmenthasrun out itslifetimeand can notbe usedanymore,
unplugthepowersupplyand disposeof it properlyaccordingtolocalcode.
Firehazard!
Incaseoffire, CO2drypowderfireextinguishershouldbeapplied.
Flammablematerialsormaterialswhicharecontaminatedbyflammable
substances/liquidmaynotbeprocessed inthegranulator.Seriousrisk of
fireorexplosion maycausepersonnelinjury.
It isveryimportant totighten the screwasrequired torque.
Whenprocess itemislongerthanfeedport, pleasecut longitemsinto
halfuntil thelengthisshorterbeforeprocessing.
Pleasedon tputmaterialsintothe granulatoriftheyarethinnerthan 2
mmandaresoftandflexible, likerubber.

15(60)
1.5 Exemption Clause
Thefollowingstatementsclarifytheresponsibilitiesand regulationsbornbyany
buyeroruserwho purchasesproductsand accessoriesfromShini(including
employeesandagents).
Shiniisexemptedfromliabilityforanycosts,fees,claimsandlossescausedby
reasonsbelow:
1.Anycareless orman-madeinstallations, operation and maintenances
uponmachineswithoutreferringtotheManualpriortomachine using.
2.Anyincidentsbeyondhuman reasonablecontrols, whichinclude
man-made viciousordeliberatedamagesorabnormalpower, and
machine faultscaused byirresistiblenaturaldisastersincludingfire,
flood,stormand earthquake.
3.Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories,dismantling, deliveringor
repairing.
4.Employingconsumablesoroil mediathatarenotappointed byShini.

16(60)
2.Structural Features and Working Principle
2.1GeneralDescription
SG-24EB machine-sidegranulatorsaremainlyoperatedbeside the moulding
machine forsmall quantityof granulation, sodon'tputexcessivematerialintoit
when granulating.Thegranulatoriscontrolledbythe mainpowerswitch, start
button, stopbutton, safetyswitchesandemergencystop button.
2.1.1WorkingPrinciple
Partsname:
A. FeedboxB. Staggered blade C. Fixed blade D. Teethcutter
E. Storagebox
Picture2-1 WorkingPrinciple
Thematerialisfedinviafeed box(A)andfallsdownintothe cuttingchamber,the
block materialiscuttedbythe staggered blades(B)andfixed blades(C),then the
materialisgrindedintoeven granulebyteethblade(D) andfixed blades(C).The
granuledirectlyfall intothe collectingbox(E),itdoesnotneed thescreen.The
cuttinghouseiseasytoopen forcleaningandmaintenance.Thegranulecan be
reused directlyafterprocessedorput intootherplaceforstorage.

17(60)
2.2SafetySystem
Toavoidaccidentalbodilyinjuryduringgranulatorrunning,asetofsafetysystem
hasbeendesigned.High-speed rotatingcutterislocatedinthegranulatorand
subjecttoaccident. So safetysystemhasbeen setuptoprotectbodilysafety.In
anycases, the safetysystemcannotbe changed at random.
Otherwisethe machinewillbe underdangerouscondition and subjecttoaccident
happening.The maintenanceandpreservation ofsafetysystemshall be doneby
professionalstaff.
Incasethesafetysystemofgranulatorischanged,ourcompanywill notperform
ourcommitment. Thereplacementofall sparepartswill be done bySHINI
Company.
2.2.1SafetySwitch
Thecircuitsafetyswitchisequipped on the granulator.Ifthe position ofstorage
boxorfeedboxischanged orthebreakerisloosened,thesafetyswitchwill cutoff
the powersupply.There retwosafetyswitchesonthegranulator:one islocated
between thefeed boxand the cuttingchamberwhilethe otheroneison the inner
wall ofthecuttingchamber, linkedwiththestoragebox.
Picture2-2 SafetySwitch
2.2.2Lock
Thelock ofthismachine isalonghexagonalscrew,whichcan extend thetimeof
dooropeningtoavoidanyinjury.Whenopeningthedoor,thishexagonalscrew
shall beloosened. The looseningwill lastaquitelongperiod oftimetoenablethe
granulatorfullystops,avoidingpersonalinjury.

18(60)
Thefollowingshall be paidattention tobeforeswitchon:
1)Check ifthe feedboxhasbeen tightened.
2)Check ifthe safetyswitchpinofstorageboxand the hexagonalscrew
havebeentightened.

19(60)
2.3AssemblyDrawing
2.3.1AssemblyDrawing(SG-2417EB)
Note: Pleasereferto2.3.2material list aboutthepartscode.
Picture2-3 AssemblyDrawing(SG-2417EB)

20(60)
2.3.2PartsList (SG-2417EB)
Table2-1 PartsList (SG-2417EB)
No. Name Part No.
1 Suction pipe -
2 Storage box -
3 American platefixed blackcastor 3 /SG-23YW03000300500
4 Standardspringwasher GB/T93 8-longzine YW65008000100
5 Flat gasket A GB/T97.18(8x19x2.0) -longzine YW66081900000
6 Hexagon screwbolt GB/T5781 M8x16-4.8-longzine YW60081600100
7 American sidebrakeblackcastor 3 YW03000300900
8 Base -
9 Left bearing holderatbottom BH10241100110
10 ScrewlocknutBH11241000010
11 Flat gasket A GB/T97.112(13.5x24x2.5) -longzine YW66122400000
12 Star assemblyBH56240200010
13 Right bearing holder atbottom BH10002405210
14 Cuttingchamber rotatingblock 2 BH10240900210
15 Front lower caseblockBH10241705320
16 Back lower caseblockBH10241705220
17 Feed boxrotating block 2 BH10241200110
18 Inner hexagon countersunkhead
screwGB/T70.3M8x20-12.9-longzine YW61082000100
19 Interlayer 2 BH10002400910
20 Interlayer 1 BH10002400710
21 Bearing6213DDU/VV YW11621300000
22 Elastic ring for hole useGB/T893.1127YW69012700000
23 Washer BL51802100020
24 Inner hexagon cylindrical
screwGB/T70.1M12x20-12.9-longzine YW61122000000
25 Bearingcover -
26 Inner hexagon cylindrical
screwGB/T70.1M12x25-12.9-longzine YW61122500000
27 Left bearing block BW30024001010
28 Left shaftsleeve BW30024000210
29
Teethcutter R * YW40024000400
Narrowteeth-cutter R *YW40241400000
Broadened teethcutter R *YW40241000000
30 Cuttingchamber rotatingblock 1 BH10240900110
31 Staggered blade* BW40240500010
