Shini Standard Series User manual

SG-23E/30E
"Standard" Series Central Granulators
Date:Oct. 2018
Version:Ver.C(English)

3(41)
Contents
1. General Description..................................................................................... 7
1.1 CodingPrinciple......................................................................................8
1.2 Feature....................................................................................................8
1.3 TechnicalSpecifications........................................................................ 10
1.4 SafetyRegulations................................................................................ 11
1.4.1 Safetysignsandlabels............................................................... 11
1.4.2 Transportation andStorageoftheMachine................................ 12
1.5 ExemptionClause................................................................................. 14
2. Structural Features and Working Principle.............................................. 15
2.1 GeneralDescription.............................................................................. 15
2.1.1 WorkingPrinciple........................................................................ 15
2.2 SafetySystem....................................................................................... 16
2.2.1 EmergencyStop ......................................................................... 16
2.2.2 SafetySwitch.............................................................................. 16
2.2.3 StarKnob.................................................................................... 17
2.3 ElectricalComponentsInstruction......................................................... 18
2.3.1 ACContactor.............................................................................. 18
2.3.2 Overheat Relay........................................................................... 18
2.4 Options.................................................................................................. 19
2.4.1 Full-receiverAlarmDevice.......................................................... 19
2.4.2 SpecialScreen........................................................................... 19
2.4.3 Flywheel..................................................................................... 20
2.4.4 Feed HopperwithMagnet.......................................................... 20
3. Installation and Debugging........................................................................ 21
3.1 Installation Notice.................................................................................. 22
3.2 Installation Place................................................................................... 23
3.3 Installation of Blade Rest and Bearing.................................................. 23
3.3.1 Installation of Blade Rest Shaft................................................... 23
3.3.2 Installation of the Flap................................................................. 24
3.3.3 Installation of BearingBlock andBearing................................... 24

4(41)
3.3.4 Installation of bearingcover........................................................ 25
3.4 Installation of the Bearing, Belt Pulleyand Belt..................................... 25
3.5 Installation of Screen,Screen FrameandStorageBin......................... 26
3.6 Installation of the FeedBox, FeedPortandMaterialStopper............... 26
3.7 Installation of the Blade......................................................................... 27
3.8 BladesInstallationAdjusting(SG-30E)................................................. 28
4. Operation Guide......................................................................................... 30
4.1 Prestart Check...................................................................................... 30
4.1.1 TwoHoursSfterFirstStart......................................................... 30
4.2 PowerConnection................................................................................. 30
4.3 Start / Stopof theMachine.................................................................... 31
4.4 OpentheFeedBox............................................................................... 32
5. TroubleShooting........................................................................................ 33
5.1 GranulatorCan NotWork...................................................................... 33
6. Maintenance and Repair............................................................................ 34
6.1 Repair ................................................................................................... 34
6.1.1 Changingthe Blade.................................................................... 35
6.2 Transmission......................................................................................... 35
6.2.1 DailyMaintenanceofV-belt........................................................ 35
6.2.2 Adjust the V-belt......................................................................... 36
6.3 Lubrication ............................................................................................ 37
6.3.1 LubricatingOils........................................................................... 37
6.3.2 LubricatingMethod..................................................................... 37
6.4 Maintenance......................................................................................... 38
6.4.1 DailyMaintenance...................................................................... 38
6.4.2 WeeklyChecking........................................................................ 38
6.4.3 MonthlyChecking....................................................................... 38
6.5 Cleaning................................................................................................ 39
6.6 MaintenanceSchedule.......................................................................... 40
6.6.1 About theMachine...................................................................... 40
6.6.2 Check AfterInstallation............................................................... 40
6.6.3 DailyCheck................................................................................ 40
6.6.4 WeeklyCheck............................................................................. 40

5(41)
6.6.5 MonthlyCheck............................................................................ 40
6.6.6 Check Half-yearlyorEvery1000 RunningHours....................... 41
6.6.7 3yearChecking.......................................................................... 41
Form index
Chart 1-1:TechnicalSpecifications.................................................................. 10
Chart 3-1:AttachedForm, CuttersandOtherFixingScrewTorque ................. 22
Pictureindex
Picture1-1: Dimensions.................................................................................... 10
Picture2-1:WorkingPrinciple.......................................................................... 15
Picture2-2: Emergency Stop............................................................................ 16
Picture2-3: SafetySwitch................................................................................. 16
Picture2-4: StarKnob...................................................................................... 17
Picture2-5: ACContactor................................................................................. 18
Picture2-6: Overheat Relay............................................................................. 18
Picture3-1: Installation Space.......................................................................... 22
Picture3-2: Installation Place........................................................................... 23
Picture3-3: Installation ofBlade Rest Shaft..................................................... 23
Picture3-4: Installation ofthe Flap ................................................................... 24
Picture3-5: Installation ofBearingBlock andBearing...................................... 24
Picture3-6: Installation ofBearingCover......................................................... 25
Picture3-7: Installation ofthe Bearing, Belt Pulleyand Belt............................. 26
Picture3-8: Installation ofScreen,ScreenFrameandStorageBin.................. 26
Picture3-9: Installation ofthe Feed Box, Feed Port and MaterialStopper....... 27
Picture3-10: InstallationoftheBlade ............................................................... 28
Picture3-11:BladesInstallationAdjusting(SG-30E)........................................ 29
Picture4-1: Start / StopoftheMachine ............................................................ 31
Picture6-1: Changingthe Blade....................................................................... 35
Picture6-2: DailyMaintenanceofV-belt........................................................... 36
Picture6-3: Adjust the V-belt 1......................................................................... 36

6(41)
Picture6-4: Adjust the V-belt 2......................................................................... 37
Picture6-5: Lubricating Method........................................................................ 37
Picture6-6: StarScrew..................................................................................... 38

7(41)
1.General Description
Pleasereadthismanualcarefullybeforeusingthismachineinorderto
operatecorrectlyagainst anydamagecaused duetoimproperoperation.
Note!
Alwaystakegreatcarewhen the knivesarewithinreach,theyareverysharpand
can causepersonalinjury.
Forbiddentoprocess flammableortoxicmaterial!
SG-23E/30Eseriesof"Standard"centralgranulatorsarebuilttoconformto
sound-proofmodelsbothinsafetyconfiguration andoperationsecurity.Theyare
suitableforcentralizedrecyclingofwastesand rejectedproductsfrominjection,
blowmouldingandextrusion lines.The granulatorsfeatureoptimalstructure,easy
operation and quick bladeschanging.Staggered rotatingbladescan easilygrab
and cut throughthe materialsand ensureslowenergyconsumption.
Model: SG-2336E

8(41)
1.1CodingPrinciple
1.2Feature
lSG-23E seriesadoptsstaggered bladesdesign, SG-30Eseriesadopts
paddlebladesdesign.
lTheblade materialisimported steeltoensurehighqualityand high
durability.
lStaggered bladesdesigncan decentralizeworkingload when granulating
toincreasecuttingefficiency.
lStaggered bladesretainerisdesignedforquick bladeschangingwithout
re-adjustment.
lPaddlebladeswithincreased bladeinclinationdesigntoensurebetter
cuttingeffectandlowernoise.
lEquippedwithmotoroverload relayand multiplesafetydevices.
lEasyaccess forconvenientmaintenanceandcleaning.
lCompact insizeforsavingfloorspaceand castorsforeasymovement.
lStandardstructuredesigncan reducethe cost ofreplacement parts.
lSG-30E standardwithpresettingknifejig, rotatingbladescanbeadjusted
inthefixtureoutside themachineinsteadofmachine inside.It makes
bladesadjustmentmust easier.

9(41)
All serviceworkshouldbe carried outbyaperson withtechnicaltrainingor
correspondingprofessionalexperience. Themanualcontainsinstructionsforboth
handlingandservicing.Chapter7,whichcontainsserviceinstructionsintendedfor
serviceengineers. Otherchapterscontaininstructionsforthedailyoperator.
Anymodificationsofthe machine mustbeapproved bySHINIinordertoavoid
personalinjuryand damagetomachine.Weshall notbe liableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellentafter-salesservice.Shouldyou haveany
problemduringusingthe machine,pleasecontactthecompanyorthe local
vendor.
HeadquarterandTaipeifactory
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc
Tel:[phone]
ShiniPlastics TechnologiesIndiaPvt.Ltd.
Tel:[phone]

10(41)
1.3Technical Specifications
Picture1-1: Dimensions
Chart 1-1:TechnicalSpecifications
Model SG-2324E SG-2336E SG-2348E SG-3048E SG-3060E
Ver. C C C C C
Motor Power (kW, 50/60Hz) 5.5/6.3 7.5/8.6 11/12.6 11 15
RotatingSpeed (rpm,50/60Hz) 415 415 415 415 415
Material of Blades SKD11 SKD11 SKD11 SKD11 SKD11
QuantityofFixed Blades 2 2 2 2 2
Quantityof Rotating Blades 3 2 3 3 3 4 3 3
CuttingChamber (mm) 230 240 230 360 230 480 300 480 300 600
Max. Output (kg/hr) 90 120 150 185 220
NoiseLevel dB(A) 105~110 105~110 105~110 105~110 105~110
Screen(mm) (Ф8) (Ф8) (Ф8) (Ф8) (Ф8)
Dimension
H (mm) 1390 1390 1390 1430 1430
H1(mm) 1320 1320 1320 1330 1330
W(mm) 590 710 830 830 950
W1 (mm) 240 360 480 480 600
D (mm) 1130 1130 1130 1200 1200
D1(mm) 890 890 890 1000 1000
Weight (kg) 320 380 450 500 530
Notes:1) " √"standsforstandard.
2) SKD11 issteelgrade ofJapaneseJIS standard.
3) Max. capacityof themachine is subject todiameter ofscreenmeshand composition of the
material.
4) Noiselevelvarieswithdifferentmaterials and motor types.
5)Toavoidplasticfromstickingtotheblades,allmaterialsshouldbecrushedatnormaltemperature.
6) Power supply: 3Φ,400VAC, 50Hz.

11(41)
1.4SafetyRegulations
Followthe instructionsinthismanualtoavoidpersonalinjuryand damageto
machine components.
Thefollowingsafetymeasuresshall befollowed when operatingthe granulator.
1.4.1Safetysignsandlabels
Electricalinstallation mustonlybe donebyacompetent electrician!
Beforethe granulatorisopened forservicingand maintenance,always
disconnectthe powerwithboththemainswitchand the controlswitchon
the granulator.
Neverputanypartofyourbodythroughthegranulatoropenings,unless
boththemainswitchand the controlswitchonthegranulatorarein"Off"
position.
Highvoltage! Danger!
Thissignisattachedonthecontrolboxand the wiringbox.
Be carefulwiththe rotatingknives,theyareverysharpandcancause
personalinjury!
If therotormust beturned manually-do thiswithgreat care!
Thegranulatorshouldnotbeabletostartbeforethehopperand screen
bracketareproperlyclosed.
Attention please!
Earprotectionisusedduringgranulatingofplasticmaterials.

12(41)
Neverremoveprotectivespongeorquick couplingclipsadjacenttothe
outletofstoragebin.
Makesurethepowerhasbeencutoff beforeopeningthefeed box.
Air inlet dust clean.
Attention!
Noneedforregularinspectionbecauseall theelectricalpartsinthecontrol
unit arefixed tightly!
1.4.2Transportation andStorageoftheMachine
Transportation
1)SG-23E/30E seriesofgranulatorsarepackedinplywood caseswith
wooden pallet at thebottom, suitableforquickpositioningbyforklift.
2)Afterunpacked, castorsequipped onthemachine canbeused foreaseof
movement.
3)Donotrotatethe machine and avoidcollision withotherobjectsduring
transportationtoprevent improperfunctioning.
4)Thestructureof themachineiswell-balanced, althoughitshouldalsobe
handled withcarewhenliftingthemachineforfearoffallingdown.
5)Themachineand itsattachedpartscanbekept atatemperaturefrom
-25℃to+55 forlongdistancetransportation and forashort distance,
it can be transported withtemperatureunder+70 .
Storage
1)SG-23E/30E seriesshouldbe stored indoorswithtemperaturekept from
5to40 and humiditybelow80%.
2)Disconnectall powersupplyand turnoffmainswitchand exigencystop
switch
3)Keepthewholemachine,especiallythe electricalcomponentsawayfrom
watertoavoidpotentialtroublescaused bythe water.

13(41)
4)Useplasticfilmtocoverthe machine tightlytoprevent themachine from
dustandrains.
Workingenvironment
Themachineshouldbeoperated:
1)Indoorsinadryenvironment withmax. temperature+45℃andhumidity
no morethan80%.
Donotusethemachine:
1)Ifit iswithadamaged cord.
2)Onawet floororwhen it isexposed toraintoavoidelectricshock.
3)Ifithasbeendropped ordamaged untilitischecked orfixedbya
qualifiedserviceman.
4)Thisequipmentworks normallyintheenvironmentwithaltitudeover
3000m.
5)At least1msurroundingspaceisrequested when thisequipmentis
running.Keepthisequipmentawayfromflammablesourcesatleast two
meters.
6)Inthe workarea ofvibration andstrongmagneticforce
Rejectedpartsdisposal
When the equipmenthasrunoutitslifetimeandcannotbe used anymore,
unplugthepowersupplyand disposeof it properlyaccordingtolocalcode.
Firehazard!
Incaseoffire, CO2drypowderfireextinguishershouldbeapplied.
Flammablematerialsormaterialswhicharecontaminatedbyflammable
substances/liquidmaynotbeprocessed inthe granulator.Seriousrisk of
fireorexplosion maycausepersonnelinjury.
It isveryimportant totighten the screwasrequired torque.

14(41)
Whenprocess itemislongerthanfeedport, pleasecutlongitemsintohalf
until thelengthisshorterbeforeprocessing.
Pleasedon`tput materialsintothegranulatoriftheyarethinnerthan 2mm
and aresoft and flexible, likerubber.
1.5 Exemption Clause
Thefollowingstatementsclarifythe responsibilitiesand regulationsbornbyany
buyeroruserwho purchasesproductsandaccessoriesfromShini(including
employeesandagents).
Shiniisexemptedfromliabilityforanycosts,fees,claimsandlossescausedby
reasonsbelow:
1. Anycarelessorman-madeinstallations,operation andmaintenancesupon
machineswithoutreferringtothe Manualpriortomachineusing.
2. Anyincidentsbeyondhumanreasonablecontrols, whichincludeman-made
viciousordeliberatedamagesorabnormalpower,and machine faultscaused
byirresistiblenaturaldisastersincludingfire,flood,stormand earthquake.
3. Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories, dismantling,deliveringorrepairing.
4. Employingconsumablesoroil mediathatarenotappointed byShini.

15(41)
2.Structural Features and Working Principle
2.1GeneralDescription
SG-23E/30Egranulatorisdesignedforgrindingplasticwastetogranulatefor
recycling.Theplasticwasteshouldbefree frommetalpartsand contamination
beforegranulating.Mountmagnetatthefeedporttopreventmetalscrapsfrom
gettingintocuttingchamberandbringsdamagetotheblades.The granulatoris
controlledbystart/stop andemergencystop buttononcontrolpanel.
2.1.1WorkingPrinciple
Partsname:
A. FeedportB. RotarybladesC. Fixed bladesD. Screen E. Storagebin
Picture2-1:WorkingPrinciple
Theplasticwasteiffeedviafeedport(A)andfallsdownintothecuttingchamber,
whererotaryblades(B)cut theplasticwasteagainstfixedblades(C)togranulate.
Aperforated screen(D) determinesthe sizeofthegranulate.The screen is
locatedinthelowersection ofthe cuttingchamberand can easilybe changed to
givethedesiredgranulatesize.Thegrnulatepassedthescreenandfallsdownin

16(41)
the storagebin(E).Afterthis,the granulateisreadyforre-useinthe production
machine,ortobe transportedtoacontainerforlateruse.
2.2SafetySystem
Thegranulatorhaskniveswhichrotateathighspeed,thereforeequip-ped witha
safetysystemtoavoidpersonalinjury. The safetysystemmustnotbechanged or
modifiedinanycircumstances.Ifthesafetysy-stemofgranulatorischanged or
modified,the machine can be danger-oustouse,presentingaseriousrick of
personalinjury.
Allmaintenancetothe safetysystemofthe granulatormustbe carried outby
personnelwiththenecessaryknowledge.
2.2.1EmergencyStop
Thegranulatorhasanemergencystopbuttononthecontrolpanelandthe
emergencystopisactivated bypressingthebutton.Resettingiseffected by
turningthebuttoninthedirectionof arrow(anti-clockwise).
Picture2-2: Emergency Stop
2.2.2SafetySwitch
Thegranulatorhassafetyposition switchwithcircuitbreaker,ifasecured
position ischanged orwhen acircuitbreakerisundone,itwillcutthe currentand
the granulatorstops.
Picture2-3: SafetySwitch

17(41)
2.2.3StarKnob
Thestarknobswhichonthe hopperandscreenframeareveryimportant
componentsinthesafetysystemofthegranulator.When itisunscrewed,the
bladeshavebeenstoped toavoidpersonalinjuries.
Picture2-4: StarKnob
NOTE:Thelengthofthescrew mustneverbechanged. The
screwcannotbemoved.
Beforestartingthe starknobsonthe hopperand screenframemustbefully
tightenedtostop.Thestoragebinshouldbeinstalledanddoorshutand locked.

18(41)
2.3Electrical ComponentsInstruction
2.3.1ACContactor
Mainlyused forremoteturnonand breakthecircuit
A1.A2 Windingofthecontactor
13.14 Frequentlyon contact point
21.22 Frequentlyoffcontact point
Picture2-5: ACContactor
2.3.2Overheat Relay
Picture2-6: Overheat Relay
1)Terminalforcontactcoil A2.
2)Settingcurrent adjustingscale.
3)Reset (blue).
H: manualreset
A: automaticreset
4)Stop.
5)ON/ OFF idication and TESTfunction.

19(41)
6)Auxiliarycontactterminalsshownin95.96.97.98.NC and NOcontactsare
showninposition95.96. and 97.98. respectively.
7)Maincircuitconnection No.mustbecorrespondingwithterminalNumberof
contactor.
At delivery,the overload relayissetformannualreset. (the resetbuttonpointing
toH).Manuallyresetthe relayatthe trippingofthe switch.Whenmotoroverload
occurs,stop the machine,then check andsolvethe problem.Afterthatopen the
doorofcontrolbox,press downtheresetbuttonofoverloadrelay(ifyou cannot
press downthereset button, waitforone minute.)
2.4Options
2.4.1Full-receiverAlarmDevice
2.4.2SpecialScreen
Full-receivealarmdevicecan helptorealize
unmannedoperation andnomaterialswillbe
wasted.Whenevertheregrind levelreachesthe
motorposition, the machine will be forcedtostop
and becutoffviaitissensor,thusstop the
granulatorandwarnthe userbysoundingan
alarm.Add “FAD”atthe modelbehind.
Optionalscreenmeshsizesincludes Ф4,
Ф6,Ф10, Ф12 (mm)whichareapplicableto
SG-23E/30Eseriesand Ф8,Ф12, Ф17, Ф25 (mm)
whichapplicabletoSG-36E series.All canbe
selectedaspercustomer's requirement. Add
“SS”at themodelbehind.

20(41)
2.4.3Flywheel
2.4.4Feed HopperwithMagnet
Increaseinertia,therebyincreasingthe cutting
ability.At the sametimecanresultinamore
balanced forceand longerservicelife.It isan
optionforSG-36E series.Add “FW”atthe model
behind.
Feed hopperwithmagnetisused totakeout
metalcrapsandimpuritiesinthematerial.Add
“R”at the modelbehind.
