Shini SAL-910G User manual

SAL-910G/920G
"Standard" Separate-vacuum
Hopper Loader
Date: May, 2022
Version: Ver.A

3(32)
Content
1. General Description .....................................................................................5
1.1 Coding Principle......................................................................................6
1.2 Features..................................................................................................6
1.3 Technical Specifications .........................................................................8
1.3.1 External Dimension.......................................................................8
1.3.2 Specification................................................................................10
1.3.3 Loading Capacity.........................................................................11
1.4 Safety Regulations................................................................................11
1.4.1 Safety Signs and Labels..............................................................11
2. Structure Characteristics and Working Principle.................................... 13
2.1 Working Principle..................................................................................13
2.2 Options .................................................................................................14
2.3 Options .................................................................................................14
3. Installation Layout......................................................................................15
3.1 Installation and Positioning...................................................................15
3.2 Power Connection.................................................................................15
3.3 Compressed Air Connection.................................................................16
3.4 Installation diagram...............................................................................17
3.5 Installation Steps...................................................................................18
3.6 Shut-off Suction Box.............................................................................19
3.7 Installation with the Cyclone Dust Collector ACF-1...............................19
4. Operation ....................................................................................................21
4.1 Panel Description..................................................................................21
4.2 Operation Description...........................................................................22
4.3 Parameter Description..........................................................................22
4.3.1 Individual Parameters (hopper)...................................................22
4.3.2 Comm. Parameters Overall Unit）...........................................23
4.3.3 Communication Parameter Setting..............................................25
4.4 Code Description ..................................................................................25
4.5 Action Description.................................................................................25
4.6 Communication Parameter Table (Protocol modbus RTU).................27

4(32)
5. Troubleshooting.........................................................................................30
6. Maintenance................................................................................................31
6.1 Hopper Cleaning(Take SVH as an example)........................................31
6.2 Main Body Cleaning..............................................................................32
Table Index
Table 1-1: SMH Specification..............................................................................8
Table 1-2: SVH-L Specification ...........................................................................9
Table 1-3: Specification.....................................................................................10
Table 2-1: ACF Specification.............................................................................14
Picture Index
Picture 1-1: SMH External Dimension.................................................................8
Picture 1-2: SVH External Dimension..................................................................8
Picture 1-3: SHR External Dimension..................................................................9
Picture 1-4: SAL-910G External Dimension ........................................................9
Picture 1-5: Loading Capacity ...........................................................................11
Picture 2-1: Working Principle ...........................................................................13
Picture 2-2: ACF External Dimension................................................................14
Picture 3-1: Air Suction Inlet..............................................................................17
Picture 3-2: Installation Layout 1 .......................................................................17
Picture 3-3: Installation Layout 2 .......................................................................18
Picture 3-4: Installation Layout 3 .......................................................................18
Picture 3-5: Suction Box Wiring Points..............................................................19
Picture 3-6: ACF Installation Diagram...............................................................20
Picture 6-1: Hopper Cleaning............................................................................31
Picture 6-2: Filter Barrel Cleaning Diagram.......................................................32

5(32)
1. General Description
Please read through this operation manual before using and installation to
avoid damage of the machine and personal injuries.
Model:SAL-900G

6(32)
1.1 Coding Principle
Model No.
Shini Hopper Loader
G: Separated Vaccum Unit
Options
1.2 Features
Motor overheat protector that can increase the service life.
Shortage alarm informs the customer to troubleshoot.
The filter barrel adopts PC (polycarbonate) that is easy to check the dust
in the barrel for cleaning.
The loader equips with RS485 interface for information exchange, which is
controlled by central integrator.
SAL-910G/920G has two-stage conveying function.

7(32)
All maintenance work should be carried out by a person with technical training or
corresponding professional experience. The manual contains instructions for both
operating and maintenance. Chapter 6 contains maintenance instructions for
service engineers. Other chapters contain instructions for the daily operator.
Any modifications of the machine must be approved by SHINI in order to avoid
personal injury and damage to machine. We shall not be liable for any damage
caused by unauthorized change of the machine.
Our company provides after-sales service. Should you have any problem during
using the machine, please contact the company or the local vendor.
Shini Hotline Service:
Headquarter and Taipei factory：
Tel: + 886 (0)2 2680 9119
Shini Plastics Technologies (Dongguan), Inc.：
Tel: [phone]
Shini Plastics Technologies (Pinghu), Inc.：
Tel: [phone]
Shinden Precision Machinery (Chongqing), Inc.:
[phone]

8(32)
1.3 Technical Specifications
1.3.1 External Dimension
SMH
Picture 1-1: SMH External Dimension
Table 1-1: SMH Specification
Model L(mm) L1(mm) L2(mm)
SMH-6L 210 180 148
SMH-12L
SVH
Picture 1-2: SVH External Dimension

9(32)
Table 1-2: SVH-L Specification
Models L(mm) L1(mm) D(mm) R(mm)
SVH-6L 150 70 55 6.5
SVH-12L 180 80 55 6.5
SHR
W
D
H
4×Ф9EQS
4×Ф9EQS
Ф231.5
Ф197
Ф254.5
Ф275
Picture 1-3: SHR External Dimension
SAL-910G (Main controller)
H
DW
Picture 1-4: SAL-910G External Dimension

10(32)
1.3.2 Specification Table 1-3: Specification
Main Unit Hopper Receiver(s)
RS-485
communication
function
Conveying
HoseDia.
(Inch)
Air
Suction
Pipe
Dia.
(Inch)
Conveying
Capacity
( 50/60Hz)
(kg / hr)
Model Ver.
Motor
Type
Motor
Power
(kW)
(50/60Hz)
Dimensions
(mm)H WD
Weight
(kg)
Recommended
Model
Hopper
Capacity
(L)
Dimensions
(mm)
HWD
Weight
(kg)
SAL
-910G
A Induction 0.75(3Φ) 500×395×800 44
1×SMH-6L
6
460×260×315 6
●1.5 1.5 500/
760
1×SVH-6L 600×285×305 7
2×SMH-6L 460×260×315 11
2×SVH-6L 600×285×305 7
SAL
-920G
A Induction 1.5(3Φ) 500×395×800 44
1×SMH-12L
12
515×300×350 7
●1.5 1.5 680/
960
1×SVH-12L 695×300×360 11
2×SMH-12L 515×300×350 7
2×SVH-12L 695×300×360 11
Notes: 1) "SVH" stands for photosensor hopper receiver; " SMH " stands for vacuum hopper receiver. " SHR-U " stands for
Euro-Hopper receiver.
2) Test condition of conveying capacity：Plastic material of bulk density 0.65kg/L, dia. 3~5 mm, vertical conveying height:
4m, horizontal conveying distance: 5m.
3) "●" stands for standard, "○" stands for options, "-" stands for none.
4) Adopt the 4P heavy-duty connector.
5) Power supply: 3Φ, 400VAC, 50Hz.

11(32)
1.3.3 Loading Capacity
Co
n
veying capacity
(
k
g/hr
)
Horizontal di
s
ta
n
ce
(
m
)
0155 25 35 45 55 65 75 85 95
200
400
600
800
1,000
SAL-920G2
SAL-830G
SAL-910G
SAL-700G
SAL-810G
SAL-820G
Co
n
veying capacity
(
k
g/hr
)
0
200
400
600
800
1000
1200
5 15 25 35 45 55 65 75 85 95
49' 82 ' 115' 148' 180' 213' 264 ' 279' 312'
441 lb/hr
1323 lb/hr
2646 lb/hr
1764 lb/hr
16'
882 lb/hr
2205 lb/hr
Horizontal di
s
ta
n
ce (m)
Picture 1-5: Loading Capacity
1.4 Safety Regulations
Please abide by the safety guide when you operate the machine so as to
prevent damage of the machine and personal injuries.
1.4.1 Safety Signs and Labels
All electrical components should be installed by qualified electricians.
Turn off main switch and control switch during repair and maintenance.
Warning！High voltage！
This mark is attached on the cover of the control box.

12(32)
Warning！Be careful！
Be more careful when this mark appears.
Attention！
No need for regular inspection because all the electrical parts in
the control unit are fixed tightly！

13(32)
2. Structure Characteristics and Working Principle
2.1 Working Principle
SAL-910G series are suitable for conveying plastic granules over long distance.
Utilizing high efficiency vacuum blower to produce vacuum in material hopper,
plastic materials will then be fed into material hopper by air pressure.
15
8
14
12
13
14
15
9
10
6 7
5
4
321
Picture 2-1: Working Principle
1. Control box 2. Buzzer
3. Power switch 4. High-pressure blower
5. Three way valve 6. Air suction inlet 1
7. Air suction inlet 2 8. Hopper 1
9. Hopper 2 10. Discharging plate1
11. Photosensor 12. Discharging plate2
13. Microswitch 14. Hopper suction pipe
15. Material inlet pipe
Turn on the power switch (3), and set the suction time of hopper 1 (8) and
hopper 2 (9) on the touch panel. Press the start button, the high pressure blower
(4) works, the three-way valve (5)’s control suction inlet 1 (6) opens, the suction
inlet 2 (7) and discharge plate 1 (10) close, and the hopper 2 (9) begins to suck
the materials. After suction, the high pressure blower (4) stops running, and the

14(32)
materials in hopper 2(9) drop because of the gravity. When the micro switch (13)
detected no material in hopper 1 (8), the high pressure blower (4) works. At this
time, the solenoid valve switches, the three-way valve’s control suction inlet 2 (7)
opens, the discharge plate 2 (12) closes and the hopper 1 (8) starts to suck the
materials. After suction, if the photosensor swtich (11) detected no materials in
hopper 2 (9), the high pressure blower (4) will start to suck materials again by
switching the solenoid valve, and so on. When no materials can be sucked or in
shortage, the buzzer (2) on the control box (1) will alarm.
2.2 Options
Cyclone dust collector
Picture 2-2: ACF External Dimension
For SHR,SCH-6U/12U/24U and SICH-6U/12U/24U are optional
(Temperature redution is below 30℃within 30min).
SMH can be matched with SCH-12U/24U to facilitate the temporary storage
of materials.
2.3 Options
For folished hopper inside ones,add “P”at the end of model code.
It is suggested to opt cyclone dust collector to reduce
cleaning times of filter when regrind material occupies
over 30% of total raw material.
Table 2-1: ACF Specification
Model H WD Pipe diameter (inch)
ACF-1 550×220×235 1.5

15(32)
3. Installation Layout
3.1 Installation and Positioning
1)
Machine just can be mounted in vertical position. Make sure there’s no
pipe, fixed structure or other objects above the installing location and around
the machine which may block machine’s installation, hit objects or injure
human person.
2) For easy maintenance, it’ssuggested to leave 1m space around themachine.
3) Machine should be placed on water-level surface. If it needs to be mounted
on a higher surface (e.g. the scaffold or the interlayer), should ensure its
structure and size could bear the weight and size of the machine.
3.2 Power Connection
1) Make sure the voltage and frequency of the power source comply with
those indicated on the manufacturer nameplate that attached to the
machine.
2) Power cable and earth connection should conform to your local
regulations.
3) Use independent electrical wires and power switch. Diameter of electrical
wire should not be less than those used in the control box.
4) The power cable connection terminals should be tightened securely.
5) The machine requires 3-phase 3-wire power source, connect the power
lead (L1, L2，L3) to the live wires, and the earth (PE) to the ground.
6) Power supply requirements:
Main power voltage: +/- 5%
Main power frequency: +/- 2%
7) Please refer to electrical drawing of each model to get the detailed
power supply specifications

16(32)
3.3 Compressed Air Connection
Table 3-1: Compressed Air Specification
Items Range Remarks
Quality Grade 335
According to GB/T 13277-1991, the concentration of solid
particles is not more than 5mg/m3, the temperature of dew
point is about - 20 ℃, and the oil content is not more than
25mg/m3.
Air Source
Pressure (bar) 3~5 --
Air Flow (L/hr) ~10 --
Pipe Size PM20 Quick connector

17(32)
3.4 Installation diagram
Picture 3-1: Air Suction Inlet
Air suction
inlet
SMH
Air suction pipe A Hopper dryer
IMM
Air suction pipe B
SVM
Storage tank
Material suction
pipe B
Material suction
pipe A
Picture 3-2: Installation Layout 1

18(32)
Air suction
inlet
SMH
Air suction pipe A Hopper dryer
IMM
IMM
SMH
Air suction
pipe B
Picture 3-3: Installation Layout 2
Picture 3-4: Installation Layout 3
3.5 Installation Steps

19(32)
1) Place the SAL-910G/920G2 in proper place
2) Install the photosensor hopper receiver and vacuum hopper receiver, and
connect the signal wire to the loader SAL-910G/920G2. (The hopper with
high use rate shall be connected to position No. 1 first).
3) Connect the photosensor hopper suction inlet and vacuum hopper suction
inlet to corresponding suction inlet of loader SAL-900G/900G2 with the steel
wire hose, and connect the vacuum hopper suction inlet and photosensor
hopper suction inlet to the suction box (usually under the dryer or storage
hopper).
3.6 Shut-off Suction Box
The shut-off valve is linked with the photosensor hopper receiver. When the
photosensor hopper receiver sucks materials, the shut-off valve will open for a
period of time (adjustable) and close immediately. Then, the loader will continue
to suck materials till all materials in the suction pipe are getting into the
photosensor hopper receiver.
1) Connect the signal line of the connection point on the suction box to the
signal connection point of the host shut-off valve.
2) Connect the suction box’s suction inlet and hopper’s feed port with the steel
wire hose.
Picture 3-5: Suction Box Wiring Points
3.7 Installation with the Cyclone Dust Collector ACF-1
Shut-off valve signal
connection point
Connection point

20(32)
1) Find the installation hole as shown in below Picture 3-6.
2) Remove the bolts.
3) Install the ACF-1 on the cover plate of SAL-G and locked with screws.
4) Connect the suction inlet of SAL-G’s host unit and ACF-1’s exhaust outlet
with the steel wire hose.
5) Connect the ACF-1’s air inlet and hopper’s suction inlet with the steel wire
hose.
SAL-910G/920G
ACF-1
Hose 1
Hose 2
Hose 1 connect the cyclone dust collector ACF-1 and hopper loader
SAL-910G/920G
Hose 2 connects to the hopper’s air suction pipe
Picture 3-6: ACF Installation Diagram
