Shini SG-50 Series User manual

SG-50/50B
"Regular" Central Granulators
Date:Feb,2019
Version:Ver.B(English)

3(59)
Contents
1. General Description..................................................................................... 9
1.1 CodingPrinciple.................................................................................... 10
1.2 Feature.................................................................................................. 10
1.3 TechnicalSpecifications........................................................................ 12
1.3.1 Outline Dimension(SG-50B)....................................................... 12
1.3.2 TechnicalSpecification(SG-50B)................................................ 12
1.3.3 Outline Dimension(SG-50).......................................................... 14
1.3.4 TechnicalSpecification(SG-50).................................................. 15
1.4 SafetyRegulations................................................................................ 16
1.4.1 SafetySignsand Labels............................................................. 16
1.4.2 Transportation andStorageoftheMachine................................ 18
1.4.3 Rejectedpartsdisposal.............................................................. 19
1.5 ExemptionClause................................................................................. 20
2. Structural Features and Working Principle.............................................. 21
2.1 GeneralDescription.............................................................................. 21
2.1.1 WorkingPrinciple........................................................................ 21
2.2 SafetySystem....................................................................................... 22
2.2.1 EmergencyStopButton.............................................................. 22
2.2.2 Breakerinterlock......................................................................... 22
2.2.3 SafetySwitch.............................................................................. 23
2.3 OptionalAccessories............................................................................ 24
2.3.1 Dust SeparatingSystem............................................................. 24
2.3.2 Screen........................................................................................ 24
2.3.3 Cutter.......................................................................................... 25
2.3.4 AutomaticConveyingDevice...................................................... 26
2.3.5 Belt Conveyor............................................................................. 26
2.3.6 MaterialSideFeedPipe............................................................. 27
2.3.7 Flywheel..................................................................................... 27
2.3.8 Sound-proof Box......................................................................... 28
2.3.9 Height-increasingStorageBin.................................................... 28
3. Installation and Debugging........................................................................ 29
3.1 Installation Notice.................................................................................. 29

4(59)
3.2 Installation Place................................................................................... 29
3.3 Feed BoxInstallation............................................................................. 31
3.4 CoolingWaterConnection.................................................................... 32
3.5 PowerConnection................................................................................. 32
3.5.1 Check theRunningDirection ofthe Motor.................................. 33
3.5.2 Check theRunningDirection ofthe Blower................................ 34
3.6 OptionsInstallation................................................................................ 34
3.6.1 Installation of Dust-seperatingSystem....................................... 34
3.6.2 Installtionof Separating ConveyingDevice................................ 35
3.6.3 ConveyingBelt Installation......................................................... 35
4. Operation Guide......................................................................................... 36
4.1 StartupPretest...................................................................................... 36
4.1.1 BeforetheFirst Startup............................................................... 36
4.1.2 AfterFirst Startupfor2Hours..................................................... 37
4.1.3 AfterFirst Startupfor20~30 Hours............................................. 37
4.2 Start / Stopof theMachine.................................................................... 37
4.3 OpentheFeedBox, Screen BracketandtheStorageBox................... 38
4.3.1 OpentheFeedBox..................................................................... 39
4.3.2 OpentheStorageBoxand Screen............................................. 40
4.4 Timer(Optionalwithfeedingblower)..................................................... 41
5. Trouble-shooting ........................................................................................ 42
5.1 GranulatorCan NotWork...................................................................... 42
5.2 Stop Due toOtherReasons.................................................................. 42
6. Maintenance and Repair............................................................................ 43
6.1 Repair ................................................................................................... 43
6.1.1 Operationand MaintenanceofDust-separating System............ 43
6.1.2 Dust-separatingSystemCleaning.............................................. 44
6.1.3 Blade Replacement.................................................................... 44
6.2 Installation of Bearingand BladeRest.................................................. 49
6.3 Installation of Belt Pulleyand Motor...................................................... 49
6.4 Installation of Screen,Screen BracketandStorageBox....................... 51
6.5 Transmission......................................................................................... 53
6.5.1 DailyMaintenanceofV Belts...................................................... 53

5(59)
6.5.2 Adjustmentsof V Belts................................................................ 54
6.6 Lubrication ............................................................................................ 54
6.6.1 LubricatingOils(Followingbrandsaresuggested.).................... 54
6.6.2 PleaseGreasetheBearingwithLubricatingOilsPeriodically.... 55
6.7 Maintenance......................................................................................... 55
6.7.1 DailyCheck................................................................................ 55
6.7.2 WeeklyCheck............................................................................. 55
6.7.3 MonthlyCheck............................................................................ 56
6.8 Cleaning................................................................................................ 56
6.9 MaintenanceSchedule.......................................................................... 58
6.9.1 About theMachine...................................................................... 58
6.9.2 Check AfterInstallation............................................................... 58
6.9.3 DailyCheck................................................................................ 58
6.9.4 WeeklyCheck............................................................................. 58
6.9.5 MonthlyCheck............................................................................ 59
6.9.6 Check Half-yearlyorEvery1000 RunningHours....................... 59
6.9.7 3yearChecking.......................................................................... 59
Tableindex
Table1-1:TechnicalSpecification(SG-50B).................................................... 12
Table1-2:TechnicalSpecification(SG-50)....................................................... 15
Table6-1: Attached Form, CuttersandOtherFixingScrewTorque................. 48
Table6-2: DailyMaintenanceof V Belts........................................................... 54
Pictureindex
Picture1-1: Outline Dimension (SG-50B)......................................................... 12
Picture2-1:WorkingPrinciple.......................................................................... 21
Picture2-2: Emergency Stop Button................................................................. 22
Picture2-3: BreakerInterlock ........................................................................... 23
Picture2-4: SafetySwitch................................................................................. 23

6(59)
Picture2-5: LockingBolt ofFeedBox............................................................... 24
Picture2-6: DustSeparatorSystem................................................................. 24
Picture2-7: Screen........................................................................................... 24
Picture2-8: OptionalCutter(HighCuttingPoint).............................................. 25
Picture2-9: AutomaticConveyingDevice......................................................... 26
Picture2-10:Belt Conveyor.............................................................................. 26
Picture2-11: MaterialSide Feed Pipe.............................................................. 27
Picture2-12: Flywheel...................................................................................... 27
Picture2-13:Sound-proofBox......................................................................... 28
Picture2-14: Height-increasingStorageBin..................................................... 28
Picture3-1: Installation Diagram1.................................................................... 30
Picture3-2: Installation Diagram2.................................................................... 30
Picture3-3: Installation Diagram3.................................................................... 30
Picture3-4: Feed BoxInstallation1.................................................................. 31
Picture3-5: Feed BoxInstallation2.................................................................. 31
Picture4-1: Position-adjustingScrews............................................................. 37
Picture4-2: ElectricHandspikeButton............................................................. 39
Picture4-3: LoosentheFastPipe Clamp......................................................... 40
Picture4-4: DrawOut the StorageBox............................................................. 40
Picture4-5: SpringBolt..................................................................................... 40
Picture6-1: RemovetheRotatingBlade........................................................... 45
Picture6-2: BladesInstallationAdjusting.......................................................... 46
Picture6-3: Installation ofRotatingand Fixed Blade........................................ 47
Picture6-4: Installation ofBearingandBlade Rest.......................................... 49
Picture6-5: Installation ofBelt Pulleyand Motor1........................................... 49
Picture6-6: Installation ofBelt Pulleyand Motor2........................................... 50
Picture6-7: Installation ofBelt Pulleyand Motor3........................................... 50
Picture6-8: Installation ofBelt Pulleyand Motor4........................................... 51
Picture6-9: Installation ofStorageBox, ScreenandScreen Bracket1............ 51
Picture6-10: InstallationofStorageBox, Screen and ScreenBracket2.......... 51
Picture6-11: InstallationofStorageBox, Screen and ScreenBracket3.......... 52
Picture6-12: InstallationofStorageBox, Screen and ScreenBracket4.......... 52
Picture6-13: InstallationofStorageBox, Screen and ScreenBracket5.......... 52
Picture6-14: InstallationofStorageBox, Screen and ScreenBracket6.......... 53

7(59)
Picture6-15: DailyMaintenanceof V Belts....................................................... 53
Picture6-16:Belt Adjustment........................................................................... 54
Picture6-17: Oil Throat..................................................................................... 55

8(59)

9(59)
1.General Description
Pleaseread thismanualcarefullybeforeusingthismachineinorderto
operatecorrectlyagainst anydamagecaused duetoimproperoperation.
Note!
Alwaystakegreatcarewhenthebladesarewithinreach,theyarevery
sharpand can causepersonalinjury.
Forbiddentoprocess flammableortoxicmaterial!
SG-50(B)seriesgranulatorsareapplicabletogranulatevariouskindsofplastic
materialsfrominjectionmolding,blowmoldingorextrusion molding.Thisseries
featurescompactdesign,easyoperationandquick bladereplacement.Gradually
inclined cuttingandintegrated powerdesign offersabettercuttingeffectanda
lowernoiselevel.
Model SG-50110Model SG-5080B

10(59)
1.1CodingPrinciple
1.2Feature
lRotatingcuttersadoptnewlydeveloped V-typecuttingtechnologywhich
can send thefeedingmaterialintothecenterofrotatingcutterssoto
prevent thematerialfromadheringontotheinnersideof thecutting
chamberwhileenhancingitswearability.
lThecuttersaremadeofimportedhighqualitysteelfeaturingwearability,
highrigidity, longservicelifeand reusableafterre-sharpening.
lEquippedwithpresettingknifejig, rotatingbladescan be adjusted inthe
fixtureoutsidethemachine insideofmachineinsteadof machineinside. It
madebladesadjustmentmucheasier.
lCuttingchambermadeofhighrigiditymaterial, afterprocessingbyCNC
machine,hasthefeatureslikehighintensity, superwearability, no
contamination, longservicelifeandeasyformaintenanceandrepairing.
lSound-prooffeedingboxreducesthe noiselevelinoperation,alsoequips
asafetymaterialcheckingcurtainwhichensuresnomaterialsprinkling
duringgranulating.
lV-type transmission beltshelpmaintainabalanced operationmode,close
contact, and alsoeasytodisassembleandrepair.
lBoth feedinghopperand screencradlecanbeopenedand closedbythe
hydraulicsystemwhichensuressafeoperation.
lCoolingwaterdeviceat therearplateofcutting chambercaneffectively
cooldownthe cuttingchamberand prevent theinsidematerialfrom
meltingup.

11(59)
All serviceworkshouldbecarriedoutbyatechnicalperson.Themanualcontains
instructionsforbothhandlingand servicing.Chapter6,whichcontainsservice
instructionsintended forserviceengineers.Otherchapterscontaininstructionsfor
the dailyoperator.
Anymodificationsofthe machinemustbeapprovedbySHINIinordertoavoid
personalinjuryanddamagetomachine.Weshall notbe liableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellentafter-salesservice.Shouldyou haveany
problemduringusingthemachine,pleasecontactthecompanyorthe local
vendor.
Headquarterand Taipeifactory
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc
Tel:[phone]

12(59)
1.3Technical Specifications
1.3.1Outline Dimension(SG-50B)
MainunitControlbox
Conveyorbelt isoptionalOptionalheight-increasingstoragebin
Picture1-1: Outline Dimension (SG-50B)
1.3.2TechnicalSpecification(SG-50B)
Table1-1:TechnicalSpecification(SG-50B)
Model SG-5080B SG-50110B
Ver. A B
Motor Power (kW) (50/60Hz) 37 45
Rotor Speed (rpm) (50/60Hz) 525 525
Conveying blower (kW)(50/60Hz) 7.5 7.5
HandspikeMotor Power (kW, 50/60Hz) 0.32 0.32
Material of Blades SKD11 SKD11
QuantityofFixed Blades(Optional) 2 2(5 2) 2 2(3 2)
Quantityof Rotating Blades(Optional) 3 2(5 2) 3 2(5 2)

13(59)
CuttingChamber (mm) 500 800 500 1100
Max. Output(kg/hr) 1100 1500
NoiseLevel dB(A) 110~115 110~115
CoolingWater Device ●●
Screen(mm) Ф12 Ф12
Height-increasing storage bin ○○
Dimension
H (mm) 2980 2980
H1(mm) 2170 2170
H2(mm) 620 620
H6(mm) 690 690
H7(mm) 1260 1260
H8(mm) 1630 1630
H9(mm) 3500 3500
H10 (mm) 1190 1190
D (mm) 2000 2000
D1(mm) 1740 1740
D2(mm) 5470 5470
D3(mm) 690 690
W1 (mm) 1760 2060
W3 (mm) 800 1100
W4(mm) 700 700
Weight(kg) 3800 4260
Note: 1)"●"standsforstandard, "○"standsforoptions,Wereservethe righttochange
"-"standsfornone.specificationswithout priornotice.
2) SKD11 is steel grade of JapaneseJIS standard.
3) Maximumoutputis subject tothe diameter andmaterial ofscreen mesh. Forgranulatingframeand
shellmaterial,maximumoutput will be reduced about50%.
4) Noiselevelwill varieswithdifferent materialsandmotor types.
5) Noiselevelistestedunderconditionsof 1maroundthe machine and 1.6mfromtheground.
6) Toavoid plasticsfromsticking tothe blades,allmaterialsshould becrushed at normaltemperature.
7) Power supply: 3Φ，400VAC，50Hz.

14(59)
1.3.3Outline Dimension(SG-50)
Mainunit
OptionalDS+300kgmaterialstoragetankControlbox
Side feed pipe isoptionalConveyor belt isoptional
OptionalDSOptionalmaterialstorage tank

15(59)
Optionalheight-increasing storage bin
Picture1-2: Outline Dimension (SG-50)
1.3.4TechnicalSpecification(SG-50)
Table1-2:TechnicalSpecification(SG-50)
Model 5080 50110
Ver. B A
Motor Power (kW) (50/60Hz) 37 45
Rotor Speed (rpm) (50/60Hz) 525 525
Conveying blower (kW)(50/60Hz) 7.5 7.5
HandspikeMotor Power (kW, 50/60Hz) 0.25 0.25
Material of Blades SKD11 SKD11
QuantityofFixed Blades(Optional) 2 2(3 2) 2 2(3 2)
Quantityof Rotating Blades(Optional) 3 2(5 2) 3 2(5 2)
CuttingChamber (mm) 500 800 500 1100
Max. Output(kg/hr) 1100 1500
NoiseLevel dB(A) 105~110 105~110
Screen(mm) Ф12 Ф12
Dimension
H (mm) 2980 2980
H1(mm) 2170 2170
H2(mm) 620 620
H3(mm) 3100 3100
H4(mm) 1625 1625
H5(mm) 700 700
H6(mm) 1260 1260
H7(mm) 1630 1630
H8(mm) 394 394
H9(mm) 1077 1077
H10 (mm) 1120 1120
H11 (mm) 3480 3480

16(59)
D (mm) 2000 2000
D1(mm) 1740 1740
D2(mm) 5470 5470
D3(mm) 690 690
W1 (mm) 1740 2040
W2 (mm) 2730 2730
W3 (mm) 800 1100
W4(mm) 700 700
W5(mm) 215 215 215 215
Weight(kg) 3280 3820
Note:1) SKD11ismaterial codenumberof JapaneseJISstandard.Wereservethe right tochange
2) Maximumoutputis subject tothe diameter andmaterial of specificationswithout prior notice.
screen mesh. Forgranulatingframeandshellmaterial,
maximumoutput will be reducedabout 50%.
3) Noiselevelwill varywithdifferentmaterialsand motortypes.
4) Noiselevelistestedunderconditionsof 1maroundthe machine and 1.6mfromtheground.
5) Toavoid plasticsfromsticking tothe blades,allmaterialsshould becrushed at normaltemperature.
6) Power supply: 3Φ，400VAC，50Hz.
1.4SafetyRegulations
Followthe instructionsinthismanualtoavoidpersonalinjuryand damageto
machine components.
1.4.1SafetySignsand Labels
Electricalinstallation mustonlybe donebyacompetent electrician!
Beforethegranulatorisopenedforservicingandmaintenance,always
disconnectthe powerwithboththe mainswitchand the controlswitchon
the granulator.
Neverputanypartofyourbodythrough thegranulatoropenings,unless
boththemainswitchand thecontrolswitchonthegranulatorarein"Off"
position.
Highvoltage! Danger!
Thissignisattachedonthecontrolboxand the wiringbox.

17(59)
Be carefulwiththe rotatingknives,theyareverysharpandcancause
personalinjury!
If therotormust beturned manually-do thiswithgreat care!
Thegranulatorshouldnotbe abletostartbeforethehopperandscreen
bracketareproperlyclosed.
Attention please!
Earprotectionisusedduringgranulatingofplasticmaterials.
Makesurethepowerhasbeencutoffbeforeopeningthefeed box!
Neverremoveprotectivespongeorquick couplingclipsadjacenttothe
outletofstoragebin!
Thefeedingblowerisused toconveygranulesandpowderwhichrequires
the temperatureisnothigherthan80 .
Loadingblowerhasgreatsuction poweranditiseasytohaveobjectsand
clothessuctionedintoand leadtopersonalinjuries.Sotheblowershould
notbe usedwithout anyprotectivecover.
Whenitisworkingwithtransmission belt,pleasecarefullycheckifthe
operator's clothes,arm orleghasbeenstuck bythe transmissionbelt.
Clean the duston theair inlet regularly.
SG-50(B)seriescuttingchambershouldbeheat-processedandthe
bladesmustbechanged beforethegranulatorsdealwithfiberadded
materials.

18(59)
When operatethe granulator, pleasenoticethefollowingsigns.
Pleasedo maintenanceregularly.
Wateroutlet: coolingwater.
Waterinlet: inletforreplenishing
waterand coolingwater.
1.4.2Transportation andStorageoftheMachine
Transportation
1)SG-50(B)seriesofgranulatorsarepackedincrateorplywood caseswith
wooden pallet at thebottom, suitableforquickpositioningbyforklift.
2)Donotrotatethe machine and avoidcollision withotherobjectsduring
transportationtoprevent improperfunctioning.
3)Thestructureof themachineiswell-balanced, althoughitshouldalsobe
handled withcarewhenliftingthemachineforfearoffallingdown.
4)Themachineand itsattachedpartscanbekept atatemperaturefrom
-25 to+55 forlongdistancetransportationandforashort distance, it
can betransported withtemperatureunder+70 .

19(59)
Storage
1)SG-50(B)seriesshouldbestoredindoorswithtemperaturekeptfrom
5to40 andhumiditybelow80%.
2)Disconnectall powersupplyand turnoffmainswitchand controlswitch.
3)Keepthewholemachine,especiallythe electricalcomponentsawayfrom
watertoavoidpotentialtroublescaused bythe water.
4)Useplasticfilmtocoverthe machine tightlytoprevent themachine from
dustandrains.
Workingenvironment
Indoorsinadryenvironmentwithmax.temperature+45 and humidityno more
than80%.
Donotusethemachine:
1)If it iswithadamaged cord.
2)Onawetfloororwhenit isexposedtoraintoavoidelectricshock.
3)If ithasbeendroppedordamageduntil it ischeckedorfixed byaqualified
serviceman.
4)Thisequipment works normallyinthe environment withaltitudeover
3000m.
5)At least1msurrounding spaceisrequested when thisequipment is
running. Keep thisequipmentawayfromflammablesourcesatleast2
meters.
6)Intheworkarea of vibration andstrongmagneticforce.
1.4.3Rejectedpartsdisposal
When theequipmenthasrunoutitslifetimeandcannotbeused anymore,
unplugthepowersupplyand disposeof it properlyaccordingtolocalcode.
Firehazard!
Incaseoffire, CO2drypowderfireextinguishershouldbeapplied.

20(59)
Flammablematerialsormaterialswhicharecontaminatedbyflammable
substances/liquidmaynotbeprocessed inthe granulator.Seriousrisk of
fireorexplosion maycausepersonnelinjury.
Whenblockingoccurs!Especiallyinmanualfeeding(suchasfilm,fiber,
fragmentorothers),pleasemakefurtherconfirmationwithSHINIorlocal
agent.
It isveryimportanttotighten the screwasrequired torque.
Whenmaterialislongerthanfeedport,pleasecutthematerialahalfuntil
the lengthisshorterthan the feedport.
Pleasedon’tputmaterialsintothegranulatoriftheyarethinnerthan2mm
and aresoftandflexible, likerubber.
1.5ExemptionClause
Thefollowingstatementsclarifythe responsibilitiesand regulationsbornbyany
buyeroruserwho purchasesproductsandaccessoriesfromShini(including
employeesandagents).
Shiniisexempted fromliabilityforanycosts,fees,claimsandlossescausedby
reasonsbelow:
1)Anycareless orman-madeinstallations, operation and maintenances
uponmachineswithoutreferringtotheManualpriortomachine using.
2)Anyincidentsbeyondhuman reasonablecontrols, whichinclude
man-made viciousordeliberatedamagesorabnormalpower, and
machine faultscaused byirresistiblenaturaldisastersincludingfire,flood,
stormandearthquake.
3)Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories,dismantling, deliveringor
repairing.
4)Employingconsumablesoroil mediathatarenotappointed byShini.
