Shini SAL-UG User manual

SAL-UG
Separate-vacuumHopperLoader
Date:Sep.,2020
Version:Ver.C(English)

3(33)
Contents
1. General Description.....................................................................................6
1.1 CodingPrinciple......................................................................................7
1.2 Feature...................................................................................................7
1.3 TechnicalSpecifications.........................................................................9
1.3.1 Dimensions....................................................................................9
1.3.2 Specifications..............................................................................10
1.3.3 Loadingcapacity.........................................................................11
1.4 SafetyRegulations................................................................................11
1.4.1 SafetySignsand Labels..............................................................11
1.4.2 Signsand Labels.........................................................................12
1.5 ExemptionClause.................................................................................12
2. StructureCharacteristics and WorkingPrinciple....................................13
2.1 MainFunctions......................................................................................13
2.1.1 WorkingPrinciple........................................................................13
3. Installation and Debugging .......................................................................15
3.1 Install the Machine on the Dryer...........................................................15
3.1.1 Installation Elements...................................................................15
3.1.2 Installation Steps.........................................................................15
3.1.3 PowerSupply..............................................................................16
4. Application and Operation.........................................................................17
4.1 Controlpaneldescription........................................................................17
4.2 ParameterSetting ..................................................................................19
4.2.1 ParameterSetting.......................................................................19
4.2.2 Communication ParameterSetting..............................................22
4.3 AlarmProcedure...................................................................................22
4.4 Operaton ProcedureDescription...........................................................22
4.4.1 OperationProcedure...................................................................23
4.4.2 DataResetting.............................................................................24
4.5 Communication Address protocolmodbus-RTU）.............................25
5. Trouble-shooting........................................................................................29

4(33)
6. Maintenance and Repair............................................................................30
6.1 MaterialHopper....................................................................................30
6.2 MainBody.............................................................................................31
6.3 Glass Tube ...........................................................................................31
6.4 Reed Switch, PhotoelectricSwitch........................................................32
6.5 WeeklyChecking..................................................................................32
6.6 MonthlyChecking.................................................................................32
6.7 MaintenanceSchedule.........................................................................33
6.7.1 About theMachine......................................................................33
6.7.2 Installation &Inspection..............................................................33
6.7.3 DailyChecking ............................................................................33
6.7.4 WeeklyChecking.........................................................................33
6.7.5 MonthlyChecking........................................................................33
Form Index
Table1-1: HopperBaseSize............................................................................10
Chart 1-2:Specifications...................................................................................10
PictureIndex
Picture1-1: SAL-UG Dimensions........................................................................9
Picture1-2: DimensionsofMaterialHopper........................................................9
Picture1-3: LoadingCapacity...........................................................................11
Picture2-1:WorkingPrinciple...........................................................................13
Picture3-1: Installation Elements......................................................................15

5(33)

6(33)
1. General Description
Read thismanualcarefullybeforeoperationtopreventdamageofthe
machine orpersonalinjuries.
SAL-UG seriesseparate-vacuumhopperloaderarebasedontheestablished
designandnowfeaturemoreattractiveappearance,betterperformance,and
improved easeofoperation.The wholerangecomprisesof seven models
equippedwithvacuumblowerfrom1to15 HP. Economymodelscanbe offered
on request.
Model: SAL-5HP-UG&SHR-24U

7(33)
1.1CodingPrinciple
1.2Feature
TheseriesofSAL-UG/UGPmodesadoptLCD displayer+microcomputer
controllerwhichfeaturesdirectdisplayandeasyoperation;
Thecontrollerhasindependent mixingand shut-offoutput function,whichcan
controlthe proportionalvalveSPV-U and shut-off boxSBUdirectly;
EquippedwithRS485 communicationinterface;
Equippedwithaudibleand visualalarm
SAL-5HP-UG/UGP(-D) adoptsintegrated cyclone filterthatcan effectively
reducethefilterloader;
SAL-10HP-UG/UGP(-D) hasautocleaningfunction withoutshutdownthatcan
prolongitsworkingtime.
TheseriesofSAL-UG/UGPmodelsareequipped withvacuumbreakingvalve
toprotectthe protector;
SAL-UGseriesisequipped withEurostainless steelhoppertoensureno
materialscontamination.

8(33)
All serviceworkshouldbe carried out byaperson withtechnicaltrainingor
correspondingprofessionalexperience.Themanualcontainsinstructionsforboth
handlingand servicing.Chapter6,whichcontainsserviceinstructionsintended for
serviceengineers. Otherchapterscontaininstructionsforthedailyoperator.
Anymodificationsofthemachinemustbe approved bySHINI inordertoavoid
personalinjuryand damagetomachine.Weshall not beliableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellent after-salesservice. Shouldyou haveany
problemduringusingthe machine,pleasecontact thecompanyorthe local
vendor.
Headquarterand Taipeifactory：
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc：
Tel:[phone]
ShiniPlastics TechnologiesIndiaPvt.Ltd.：
Tel:[phone]

9(33)
1.3Technical Specifications
1.3.1Dimensions
5HP(MainUnit) 10HP(MainUnit)20HP(MainUnit)
Picture1-1: SAL-UG Dimensions
3U6U-24U36U-96U
Picture1-2: DimensionsofMaterialHopper

10(33)
Table1-1: HopperBaseSize
Model L(mm) L1(mm) d(mm) R(mm)
SVH-24L 180 85 80 R6.5
1.3.2Specifications
Chart 1-2:Specifications
Main Unit Hopper Receiver Loading
Pipe Dia.
(Inch)
Air
Suction
Pipe Dia.
(Inch)
Loading
Capacity
(kg/hr)
Model Ver.
Motor
Power (kW)
(50 / 60Hz)
Dimensions
(mm)
HWD
Weight
(kg)
Recommended
Model
Hopper
Capacity
(L)
Dimensions
(mm)
HWD
Weight
(kg)
SAL
-5HP-UG
C
3.75/8.5
(3Φ) 1380×470×600
74 SHR-24U×1
24
690×315×400 9
2 2
1000
SAL-5HP
-UG-D C
3.4/8.2
(3Φ) 1380×670×600
76 SVH-24U-E×1 1120×360×375 13 1125
SAL
-10HP-UG
C
7.5 / 8.6
(3Φ)
2015×620×795 160
SHR-36U×1 36 822×348×457 11 2 2.5 1600
SAL-10HP
-UG-D C
2015×620×795 162
SAL-20HP
-UG-D C
13 / 18.7
(3Φ) 2200×745×1000
236 SHR-48U×1 48 976×348×455 15 2.5 3 2000
Note: 1)"SVH-L" standsforphotosensorhopperreceiver,Wereservetherighttochangespecifications
"SHR-E " referstovacuumhopperreceiver.withoutprior notice.
2) Test conditionof conveyingcapacity: Plasticmaterrialofbulkdensity0.65kg/L,
dia.3~5mm, ventical conveying height:4m,horizontal conveyingdistance: 5m.
3) Power supply: 3Ф,230/400/460/575VAC, 50/60Hz.

11(33)
1.3.3Loadingcapacity
Picture1-3: LoadingCapacity
1.4SafetyRegulations
Strictlyabide bythe followingsafetyregulationstoprevent damageofthe
machine orpersonalinjuries.
1.4.1SafetySignsand Labels
All the electricalcomponentsshouldbeinstalled byprofessional
technicians.
Turnoffthe mainswitchandcontrolswitchduringmaintenanceorrepair.
Warning! Highvoltage!
Thissignisattachedonthecoverofcontrolbox!
Warning! Becareful!
Be morecarefulat the placewherethissignappears!
Attention！
Noneed forregularinspectionbecauseall theelectricalpartsinthecontrol
unit arefixed tightly！

12(33)
1.4.2Signsand Labels
1. Pleaseclean thesuction filterregularlytoavoid
cloggingand ensureproperloadingcapacityand long
lifespan.
2.Theoneyearwarrantydoesnot coverthe suction
filter,pleaseclean the filtercarefully.
1.5ExemptionClause
Thefollowingstatementsclarifythe responsibilitiesandregulationsbornbyany
buyeroruserwho purchasesproductsandaccessoriesfromShini(including
employeesandagents).
Shiniisexemptedfromliabilityforanycosts,fees, claimsand lossescausedby
reasonsbelow:
1.Anycareless orman-madeinstallations,operation and maintenancesupon
machineswithoutreferringtothe Manualpriortomachineusing.
2.Anyincidentsbeyond human reasonablecontrols, whichinclude man-made
viciousordeliberatedamagesorabnormalpower, and machinefaultscaused
byirresistiblenaturaldisastersincludingfire,flood,stormand earthquake.
3.Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories,dismantling, deliveringorrepairing.
4.Employingconsumablesoroil mediathatarenotappointed byShini.

13(33)
2. Structure Characteristics andWorkingPrinciple
2.1MainFunctions
SAL-UG series"Euro" Separate-vacuumhopperLoadersaresuitablefor
conveyingplasticgranulesoverlongdistance. Utilizinghighefficiency vacuum
blowertoproducevacuuminmaterialhopper, plasticmaterialswill then be fed
intomaterialhopperbyoutside pressure.
2.1.1WorkingPrinciple
Names ofParts：
1. Blower suction pipe2. Blower3.Vacuumbreakingdiaphragm valve
4. Steelwirehose 5. Dust collectingbarrel6. Airsuctionpipe
7. Air filter8. Dust separatingbarrel9.Alarmlight
10. Electriccabinet11. Mainswitch12. Materialinlet
13. Materialhopper 14. Material15. Dischargingplate
16. Reed switch Picture2-1:WorkingPrinciple
Afterstartup,when thereed switch(16)detected there’snomaterials,theblower
(2)startsworkingtogeneratenegative-pressurevacuuminsidethehopper(13).
Meanwhile,thedischargingplate(15)isclosed,andmaterials(14)inthestorage

14(33)
hopperaredischarged intothehopper(12)viathematerialinputpipe(12)dueto
air pressuredifference.Afterthesuctioniscompleted,the materialswill drop due
tothe gravity.If there’sno materialsuckedorshortagehappensthree times,the
alarmlight (9)onthecontrolbox(10)will light uptoalarm. Duringtheblower’s(2)
suction process,the air inthe pipeentersthe filter(7)throughtherecyclerto
removethedustadhereded on the filter.When the blowerfinishesthe suction
process,thevacuumbreakingvalve(3)between the blowerandthe filterwill
producethe anti-impactair flowtoblowawaythe dustadhereded on thefilterto
the dust collectionbin(5).

15(33)
3.Installation and Debugging
Thisseriesof modelsonlycouldbeappliedinworkingenvironmentwithgood
ventilation.
Read thischaptercarefullybeforeinstallationofthemachine. Install the
machine byfollowingsteps.
Powersupplyshouldbefixed byqualifiedtechnicians!
3.1InstalltheMachineonthe Dryer
3.1.1Installation Elements
Picture3-1: Installation Elements
3.1.2Installation Steps
1)Put the mainbodyofthe machine at aproperplaceand connect it withpower
supply.
2)Install materialhopperontothedryerand connect it withsignalwiresfromthe
mainbody.
3)Usesteelwireconveyinghosetoconnect air suction pipe (A)on material
hopperwithair suctionpipe (D) onmainbody. Materialsuction (B)shouldbe
connectedwithmaterialsuctionprobe (B)inmaterialstoragebin.
4)Connect highpressureair pipe (C) withair supply(pressureat3~6kg/cm2).

16(33)
3.1.3PowerSupply
Makesurethat thepowersupplyconformstorequired specificationsbefore
installation.SAL-UG (E)Seriesshouldbe connected with3Φ400V 50HzPower
supplyorotherspecificationsif required.
Note:Make suremainswitchisturnedoff beforeyou connect
thepower.

17(33)
4. Application andOperation
4.1Controlpanel description
Pic.4-1：Descriptionof operation panelkeys

18(33)
NO. Graphical Interpretation
1 ON/OFF
2 MENU
3 SET
4 DOWN
5 UP
6 FULL MAT.LIGHT
7 BLENDING
8 MAT.SHUT-OFF
9 SHORTAGE ALARM
10 COMMUNICATION
11 FILTERMESHCLEAN

19(33)
4.2Parameter Setting
InOFF mode，Press , andenterparametersetting.
Press or toselectparameter，press entersetting.
Press or modifyparameters，press Confirmrevision.
E.g：set “Suctiontimesetting”15S
InOFF mode，Press and enterparametersetting.
Press or keytoselect the functioncode F.01, and press keyto
enter.
Press or keytochangeit toparameter15, andpress keytoconfirm
aftermodification.
4.2.1ParameterSetting
Code Status Parameters
Preset
value Range
F.01
Suction action time
Motorsuctiontimewhen there’sashortage ofmaterials,
whichis alsothevacuumbreakingvalve’sworking time.
Corresponding action: D
15 secs. 5-127
secs.
F.02 Shut-off actiontime
Start withthe suctionaction at the sametime,and setthe
shut-off time.Set0asnotstart.0 0-100
secs.

20(33)
F.03
Mixing proportion
Start atthe sametimewiththesuctionaction, andset the
mixing proportion.
Timecalculation method:suction time*[F.03]%
Set 0asnot start.
0%
Not start
0-100%
F.04
Mixing mode
The number oflayersofmixing action when it startsmixing.
For example:thesuctiontimeis20sec,themixing proportion
is 10%, the number oflayersis2,and then the mixing action
is 9s—1s----9s---
1s
Set singlelayer’sworking, andthe suctiontimerange is 5-99
secs.
Set doublelayers’working, andthe suctiontimerangeis
17-99 secs.
Setthree layers’working,andthe suctiontimerange is32-99
secs.
Set fourlayers’working, andthe suction timerange is46-99
secs.
If the suctiontimechanges, themin. actiontimeis lessthan
1sec. aftercalculation, and theprogramwill forcetochange
the actiontimeto1sec.
1 1-4times
F.05
Mixing actioncountcycle start setting
Count fromthe firststart-up,and start oncemixing action
afterseveral timesof repeatedsuctionstartings.
Set 1asmixing materials everytime.
Set [F.03] to0withoutmixing.
once1-9times
F.06 Settingtimeof cleaning beforesuction Set 0asthenoscreencleaningbeforesuction.
Corresponding action: R01 0secs. 0-99 secs.
F.07 Settingtimeof screencleaningaftersuction Set 0asnoscreencleaning after suction.
Corresponding action: R11 5secs. 0-99 secs.
F.08
Screen cleaningcycle
It startsonce[F.06] or[F.07]cleaningactiononlyafter
several timesof repeated suction actions.
Set 1ascleaningthescreencleaningateverysuction.
10 times1-99 times
F.09
Circulatingsuction waiting time
Waiting timebeforeanewsuction action startsafter each
suctionaction.
Set 0asnot waiting.
Waiting timebeforeanewsuction action starts
Corresponding action: N03
0
(Unit 10
secs.) 0-9990
