Shini SG-23 Series User manual

SG-23/30
Sound-proofCentral Granulator
Date Sep,2017
Version Ver.C (English)

3(47)
Contents
1. General Description.....................................................................................7
1.1 CodingPrinciple......................................................................................8
1.2 Feature....................................................................................................8
1.3 Machine Specifications.........................................................................10
1.4 SafetyRegulations................................................................................11
1.4.1 Safetysignsandlabels...............................................................11
1.4.2 Transportation andStorageoftheMachine................................13
1.4.3 Rejectedpartsdisposal..............................................................14
1.5 ExemptionClause.................................................................................14
2. Structural Features and Working Principle..............................................16
2.1 GeneralDescription..............................................................................16
2.1.1 WorkingPrinciple........................................................................16
2.2 SafetySystem.......................................................................................17
2.2.1 EmergencyStop.........................................................................17
2.2.2 SafetySwitch..............................................................................17
2.2.3 StarScrew..................................................................................18
2.3 ElectricalComponentsInstruction.........................................................19
2.3.1 MicroprocessorBoard(PCB)......................................................19
2.3.2 ElectricalComponentsinElectricalComponentsbox.................20
2.4 OptionalAccessories............................................................................21
2.4.1 Full-receiverAlarmDevice..........................................................21
2.4.2 Feed HopperwithMagnet..........................................................21
2.4.3 SpecialScreens..........................................................................21
2.4.4 FeedingHopperforConveyor....................................................22
2.4.5 Dust separatingSystem..............................................................22
3. Installation and Debugging........................................................................23
3.1 Machine Location..................................................................................24
3.2 PowerConnectors.................................................................................25
Mainpowervoltage: 10%................................................................................25
3.3 OptionsInstallation................................................................................25
3.3.1 Installation of DustSeparatingSystem.......................................25

4(47)
4. Operation Guide.........................................................................................27
4.1 StartupPretest......................................................................................27
4.1.1 After2Hoursof First Startup......................................................27
4.2 Startupand Shutdown...........................................................................28
4.3 OpentheFeedBox, Screen and theStoragebox.................................28
4.3.1 OpenFeedBox...........................................................................29
4.3.2 OpentheScreen Bracket...........................................................29
4.4 CloseFeedBox, Mount ScreenBracket and StorageBox....................30
4.4.1 MountScreenBracketand StorageBox.....................................30
4.4.2 ClosetheFeedBox....................................................................30
5. Trouble-shooting........................................................................................31
5.1 TheGranulatordoesn tWork................................................................31
6. Maintenance and Repair............................................................................32
6.1 Repair...................................................................................................33
6.1.1 Operationand maintenance.......................................................33
6.1.2 CleaningofDust SeparatingSystem..........................................33
6.1.3 Replacement of Blade................................................................34
6.1.4 Conveying...................................................................................35
6.1.5 Lubrication..................................................................................37
6.2 Maintenance.........................................................................................37
6.2.1 Dailymaintenance......................................................................37
6.2.2 WeeklyCheck.............................................................................37
6.2.3 MonthlyCheck............................................................................38
6.3 Cleaning................................................................................................38
6.4 Installation of Blade Rest and Bearing..................................................39
6.4.1 Installation of Blade Rest Shaft(Thislnstallation illustrationis
onlysuitableforSG-23).........................................................................39
6.4.2 Installation of Blade Rest Shaft(Thislnstallation illustrationis
onlysuitableforSG-30).........................................................................40
6.4.3 Installation ofmaterialfender(Thislnstallation illustration isonly
suitableforSG-23)................................................................................41
6.4.4 Installation of BearingBlock andBearing...................................42
6.4.5 Installation of BearingCoverPlate.............................................42
6.5 Installation of Bearing,Motor, BeltPlleyand Belt..................................42

5(47)
6.6 Installation of Screen,Screen BracketandStoragebox.......................43
6.7 Installation of Feed Boxand FeedPort.................................................44
6.8 Installation of Blades.............................................................................44
6.9 MaintenanceSchedule..........................................................................46
6.9.1 About theMachine......................................................................46
6.9.2 Check afterInstallation...............................................................46
6.9.3 DailyCheck................................................................................46
6.9.4 WeeklyCheck.............................................................................46
6.9.5 MonthlyCheck............................................................................46
6.9.6 Check Half-yearlyorEvery1000 RunningHours.......................47
6.9.7 Check Every3Years..................................................................47
Contents
Chart 1-1:Machinespecifications.....................................................................10
Pictureindex
Picture1-1: DimensionsofSG-23/30...............................................................10
Picture2-1:Workingprinciple...........................................................................16
Picture2-2: Emergency stop switch..................................................................17
Picture2-3: Safetyswitch.................................................................................18
Picture2-4: Starscrew.....................................................................................18
Picture2-5: PCB Circuit board..........................................................................19
Picture2-6: Mainelectricalcomponents...........................................................20
Picture3-1: Installation space...........................................................................24
Picture3-2: Installation 1..................................................................................24
Picture3-3: Installation 2..................................................................................25
Picture4-1: Startupandshutdown...................................................................28
Picture4-2: Open feed box...............................................................................29
Picture4-3: Open thescreen bracket...............................................................29
Picture6-1: Disassembletherotaryblades......................................................35
Picture6-2: Maintenanceofconveyorbelt........................................................36
Picture6-3: Adjustment ofV-belt......................................................................36
Picture6-4: Lubricating method........................................................................37

6(47)
Picture6-5: CleaningofMachine......................................................................38
Picture6-6: Installation ofbladerest.................................................................39
Picture6-7: Installation ofBearingandBlade Rest 2........................................40
Picture6-8: Installation ofBearingandBlade Rest 3........................................40
Picture6-9: Installation ofBearingandBlade Rest 4........................................40
Picture6-10 Installation of BearingandBladeRest.......................................41
Picture6-11: Installationofmaterialfender......................................................41
Picture6-12: Installationofbearingblock and bearing.....................................42
Picture6-13: Installationofbearingcoverplate................................................42
Picture6-14: Installationofbearing, motor, belt Plleyand belt.........................43
Picture6-15: Installationofscreen,screenbracket and storagebox................43
Picture6-16: Installationofrotarybladeandfixed plate(3)..............................44
Picture6-17: Installationofrotarybladeandfixed plate(4)..............................45

7(47)
1.General Description
Pleasereadthismanualcarefullybeforeusingthismachineinorderto
operatecorrectlyagainst anydamagecaused duetoimproperoperation.
Note!
Alwaystakegreatcarewhen the knivesarewithinreach,theyarevery
sharpand can causepersonalinjury.
Forbiddentoprocessflammableortoxicmaterial!
SG-23/30 seriessound-proofcentralgranulatoraresuitableforgranulatingall
kindsofplasticmaterials,includingrejectedpartsfrominjectionmolding,blow
moldingorrecyclingofwastes.Themachinesfeatureoptimized structure,easy
operation,andquick blade replacement.Staggered rotatingbladescan easily
grab andcutmaterials.Thisdesigncan reduceenergyconsumptiontothe
minimum.Thisgranulatorhasvariousmodelswithwide application tomeet
different customers demand.
Model SG-3060

8(47)
1.1CodingPrinciple
1.2Feature
●SG-23 seriesadoptsstaggered blades, itcan decentralizeworkingload when
granulatingtoincreasecuttingefficiency, Bladeretainerisdesignedforquick
bladereplacement withoutreadjustment.
●SG-30 seriesadoptspaddleblades. It allowsincreasedefficiencyand
reducedenergyconsumption.
●Bladesadopt imported steeltoensurehighqualityand highdurability.
●Full-closed designand sound-proofingensurelownoiselevel.
●Equipped withelectricalcurrent relay, motoroverload protectorandmultiple
safetydevices.
●Cyclone dust separatorcan effectivelyremovethe air fromregrind and
facilitatesthematerialcollecting.
●Dust collectingbagbringseasiness fordustcleaningand reduce
contamination.
●Regrind conveyingsystemasstandard.
●ForSG-30, c
oolingwaterdeviceat therearplateofthe cuttingchambercan
effectivelycooldownthe cuttingchamberandpreventmaterialsfrom
melting-up.
●SG-30 seriesequipped withpresettingknifejig, rotatingbladescanbe
adjusted inthefixtureoutsidethemachine inside of machineinsteadof
machine inside.It madebladesadjustmentmucheasier.

9(47)
All serviceworkshouldbe carried out byaperson withtechnicaltrainingor
correspondingprofessionalexperience.The manualcontainsinstructionsforboth
handlingand servicing.Chapter6containsserviceinstructionsintended forservice
engineers. Otherchapterscontaininstructionsforthedailyoperator.
Anymodificationsofthemachinemustbe approved bySHINI inordertoavoid
personalinjuryand damagetomachine.Weshall not beliableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellent after-salesservice. Shouldyou haveanyproblem
duringusingthemachine,pleasecontactthecompanyorthelocalvendor.
HeadquarterandTaipeifactory
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc
Tel:[phone]
ShiniPlastics TechnologiesIndiaPvt.Ltd.
Tel:[phone]

10(47)
1.3MachineSpecifications
Picture1-1: DimensionsofSG-23/30
Chart 1-1:Machinespecifications
Model SG-2324 SG-2336 SG-2348 SG-3048 SG-3060
Ver. C C C C C
Motor Power (kW, 50/60Hz) 5.5/6.3 7.5/8.6 11/12.6 11/12.6 15/17.3
RotatingSpeed (rpm,50/60Hz) 415/500 415/500 415/500 415/500 415/500
Conveying Blower (kW,50/60Hz) 0.55/0.66 0.55/0.66 0.55/0.66 0.55/0.66 0.55/0.66
Material of Blades SKD11 SKD11 SKD11 SKD11 SKD11
Blade Type Staggered Staggered Staggered Paddle Paddle
QuantityofFixed Blade 2 2 2 2 2
Quantityof Rotating Blade 3 ×2 3 ×3 3 ×4 3 3
CuttingChamber (mm) 230 ×240 230 ×360 230 ×480 230 ×480 300 ×600
Max. Output (kg/kr) 90 120 150 185 220
NoiseLevel dB(A) 90~95 90~95 90~95 90~95 90~95
ScreenΦ8mm
Dimensions
H (mm) 2210 2210 2210 2210 2210
H (mm) 2310 2310 2310 2310 2310
H1(mm) 1180 1180 1180 1220 1220
H2(mm) 250 250 250 340 340
H3(mm) 1510 1510 1510 1640 1640
H4(mm) 960 960 960 960 960
W(mm) 1530 1650 1770 1780 1900
W1 (mm) 1110 1230 1350 1350 1470
W3 (mm) 240 360 480 480 600
D (mm) 1250 1250 1250 1390 1390
D1(mm) 920 920 920 1010 1010
Weight(kg) 470 520 600 700 780
Notes:1) SKD11 is steeel grade ofJapaneseJIS standard.
2) Max. capacityof themachineis subject todiameter ofscreen meshand composition ofmaterial.
3) Noiselevelvarieswithdifferent materialsandmotor types.
4) Toavoid plasticfromstickingtotheblades,all materials shouldbe crushedatnormal
temperature.
5) Power supply: 3Φ,230/400/460/575VAC, 50/60Hz.

11(47)
1.4SafetyRegulations
Followthe instructionsinthismanualtoavoidpersonalinjuryanddamageto
machine components.
1.4.1Safetysignsandlabels
Electricalinstallation mustonlybe donebyacompetent electrician!
Beforethegranulatorisopened forservicing andmaintenance,turnoff
boththemainswitchand the controlswitchonthegranulator.
Neverput anypartofyourbodythroughthe granulatoropenings, unless
boththemainswitchand the controlswitchonthegranulatorarein"Off"
position.
Highvoltage! Danger!
Thissignisattachedonthecontrolboxand the wiringbox.
Be carefulwiththe rotatingknives, theyareverysharpandcancause
personalinjury!
If therotormust beturned manually-do thiswithgreat care!
Thegranulatorshouldnotbestarted beforethe feedboxand storagebox
areproperlyclosed.
Earprotectionshouldbe used duringgranulatingofplasticmaterials.
Makesurethepowerhasbeencutoff beforeopeningthefeed box.
Feeding blowerwhichrequiresthat the temperatureof regrind and dust
shouldnotbehigherthan 80℃isapplicabletoconveyregrind and dust.
Thefeedingblowerhasgreatsuction powerand itiseasytogetgoodsor
clothessuckedinto, whichwill causepersonalinjury!

12(47)
ForSG-30,thecutting chambershouldbe heat-processed andthe
bladesmust bechanged beforethegranulatordealwithfibreadded
material.
Attention！
Noneed of regularinspectionbecauseall theelectricalpartsinthe
electriccomponentsboxarefixed tight！
Warning！
When thislight ison, itmeansoverload workingand growingflow.
Pleasestopfeedinguntil the light isoff.
Attention！
1. Afterthefirst1-2daysofoperating, it snecessarytoloosethefour
screwson motorfixingbaseandthen tighten thisscrewup for
tighteningbelt.
2.Wheneverbelt slipoccurs, pleasetightenupthisscrew.
Air inlet
Clean dust.
Pleaseaddbutterlubricant regularly.
When operatethe granulator,pleasenoticethefollowingsigns:
Wateroutlet (notforSG-23)
Waterinlet (notforSG-23)
Motorrotation directio

13(47)
1.4.2Transportation andStorageoftheMachine
Transportation
1) SG-23/30 seriesofgranulatorarepacked incratesorplywood caseswith
wooden palletatthebottom,whichissuitableforquick positioningbyforklift.
2)Equippedwithcastorsforeaseof movement afterbeingunpacked.
3)Donot rotatethemachineandavoidcollision withotherobjectsduring
transportationtoprevent improperfunctioning.
4)The structureofthe machine iswell-balanced and possessgood handling
devices, however，it alsoshouldbehandled withcarewhen liftingthe
machine toprevent fallingdown.
5)The machine anditsattachedpartscanbekept withatemperaturefrom-25
℃to+55℃forlongdistancetransporotationwhileforashortdistance, it
can betransported withtemperatureunder+70℃.
Storage
1) SG-23/30 seriesshouldbe stored indoorswithtemperaturekept from5℃to
40℃and humiditylowerthan80%.
2)Cut off all powersupplyand turnoff mainpowerswitch.
3)Keepthe wholemachine,especiallythe electricalcomponentsawayfrom
watertoavoidpotentialtroublescaused bythe water.
4)Useplasticfilmtocoverthemachinetightlytopreventthemachine fromdust
and rainwater.
Workingenvironment
Indoorswithadryenvironmentofmaximumtemperature+45℃andhumidity
no morethan80%
Donotusethemachine:
1)Ifit iswithadamaged cord.
2)Onawet floororwhen it isexposed toraintoavoidelectricshock.
3)Ifithasbeendropped ordamaged until it ischeckedorfixed bya
qualifiedserviceman.

14(47)
1.4.3Rejectedpartsdisposal
When the equipmenthasrunoutitslifetimeand can notbeusedanymore,
unplugthepowersupplyand disposeof it properlyaccordingtolocalcode.
Firealarm!
Incaseoffire, CO2drypowderfireextinguishershouldbeprovided.
Flammablematerialsormaterialswhicharecontaminatedbyflammable
materials/liquidshouldnotbeprocessedinthegranulator.Seriousrisk of
fireorexplosion mayoccur.
It isveryimportant totighten the screwup asrequired.
If materialislongerthan feedport,pleasecut it off until it isshorterthan
the feedport beforeprocessing.
Pleasedon`t put soft and flexiblematerialsthinnerthan2mm, like
rubber, intothegranulator.
1.5 Exemption Clause
Thefollowingstatementsclarifythe responsibilitiesand regulationsbornbyany
buyeroruserwho purchasesproductsand accessoriesfromShini(including
employeesand agents).Shiniisexempted fromliabilityforanycosts,fees,
claimsand lossescaused byreasonsbelow:
1. Anycarelessorwronginstallations, operation and maintenancesupon
machine withoutreferringtotheManualpriortomachineusing.
2. Anyincidentsbeyondhumanreasonablecontrols, whichincludeman-made
viciousordeliberatedamagesorabnormalpower, and machine faults
causedbyirresistiblenaturaldisastersincludingfire,flood, stormand
earthquake.

15(47)
3. Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories,dismantling, deliveringor
repairing.
4. Employconsumablesoroil mediathat arenotappointedbyShini.

16(47)
2.Structural Features and Working Principle
2.1GeneralDescription
SG-23/30 seriesaresuitableforgranulatingwasteplastics fordirectlyrecycling
use. Beforegranulating, it snecessarytoclean metalscrapsanddirts. Mount
magnetatthematerialinlet topreventmetalscrapsfromgettingintocutting
chamberand bringingdamagetotheblades. Thegranulatoriscontrolled
through"Start/Stop"button and"Emergencystop"button.
2.1.1WorkingPrinciple
Partsname:
A. MaterialinletB. Rotaryblade C. Fixedblade D. Screen E. Storage bin
F. Discharging pipe G. Feeding blowerH. Cyclonedust collectorI. Motor
J. Feed box
Picture2-1:Workingprinciple
Thewastematerialsenterthecuttingchamberviamaterialinlet(A).Therotary
blade (B)andfixed blade (C) granulatethematerials.The particlesizeis
controlledbythesizeofscreen(D).Thescreen(D) islocatedatthe bottomof
cuttingchamber.Thusitisconvenient toreplacescreen tootherdifferentsizes.

17(47)
Thegranulatedmaterialsaredroppedintothe storagebox(E)viathescreen
and be conveyed viadischargingpipe (F).Usefeedingblowertoabsorbthe
granulatedmaterialsintocyclone dustcollectortoseparatethe air and dust.
Theparticlescan be reused directlyorsenttosomewhereforstorageafter
beinggranulated.
Thefeed boxisfoldable, thusit isveryconvenientforcleaning.
2.2SafetySystem
Thefast-rotatingbladeinthe granulatorisprone toresultinanaccident.
Therefore,the granulatorisequippedwithahighly-securesafetysystemto
avoidaccident duringthe operation.
2.2.1EmergencyStop
Emergencystopisared buttononthecontrolpanel.Oncepress it,thepower
will be cut offandthenthe machinewill stop working.It can be resetbyturning
the button asthe arrowdirection (clockwise).
Picture2-2: Emergency stop switch
2.2.2SafetySwitch
Therearesafepositionswitchesinthe granulator.Ifit son orloose,itwill cut
offthe powerand stop the machine.Twosafetyswitchesmaybe involved.One
islocatedbetweenthefeedboxandthecutting chamberandtheotherisonthe
storagebox.

18(47)
Picture2-3: Safetyswitch
2.2.3StarScrew
Starscrewson feedboxand screenbracketareveryimportantpartsofsafety
operationsystemof thegranulator.When unscrewingthosestarscrews, blades
will stop runningtoavoidpersonalinjury.
Picture2-4: Starscrew
Caution！
Thestarscrewscan tbe loosened unless themachineisnot working.
Beforestartingthe machine,thestarscrewson feed boxand screen
bracketshouldbetightenedup andastorageboxshouldbe assembled.
Then closethe frontdoorofgranulatorand lock it tightly.

19(47)
2.3Electrical ComponentsInstruction
2.3.1MicroprocessorBoard(PCB)
Function 1)Star-deltastarting.
2)Granulatingmotoroverload detectionandalarm.
3)Materialconveyingblowerpostponesmachine stop.
4)phasesequencedection, warningandmachine halt.
Picture2-5: PCB Circuit board
Scaleof Variable Resistor
1 2 3 4 5 6 7 8 9
Fine Adjustment I(A):VR1 -4 -3 -2 -1 0 +1 +2 +3 +4
RateCurrent setting（I）
VR3
5A 10A 20A 30A 40A 50A 60A 70A 80A
Scaleof Variable Resistor
1 2 3 4 5 6 7 8 9
Y/ Start Switching 3S 6S 9S 12S 15S 19S 22S 24S 30S

20(47)
2.3.2ElectricalComponentsinElectricalComponentsbox
Picture2-6: Mainelectricalcomponents
1.Transformer, whichsuppliespropervoltageforcontrolcircuit.
2. PCB whichcontrolsthe start and stop ofthemachine.
3.Gatecircuitbreaker，whichcan perform the functionofcircuitisolationand
protection.
4.Fuse,whichperformsthe functionofoverloadingprotectionandshortcircuit
protectionincontrolcircuit.
5.Intermediaterelay,whichperformsthefunctionofswitchandconnectionof
contact point incontrolcircuit.
6.Contactor,whichcan switchonandswitchoff themaincircuitfromalong
distance.
7.Thermooverload relay,whichcan protectthemotorwhenoverloadingor
openphase.
