Siemens PCA2005-A1 User manual

Cerberus PACE, Novigo,
Cerberus PACE Compact, Novigo Core
Loop isolator (100V) PCA2005-A1
Technical Manual
A6V11571319_en--_b Smart Infrastructure
2020-12-30

Imprint
2 | 34 A6V11571319_en--_b
Imprint
Technical specifications and availability subject to change without notice.
Transmittal, reproduction, dissemination and/or editing of this document as well as
utilization of its contents and communication thereof to others without express
authorization are prohibited. Offenders will be held liable for payment of damages.
All rights created by patent grant or registration of a utility model or design patent
are reserved.
Issued by:
Siemens Switzerland Ltd.
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
Tel. [phone]
www.siemens.com/buildingtechnologies
Edition: 2020-12-30
Document ID: A6V11571319_en--_b
© Siemens Switzerland Ltd, 2020

A6V11571319_en--_b 3 | 34
Table of contents
1About this document................................................................................ 5
1.1 Applicable documents................................................................................. 8
1.2 Revision history.........................................................................................10
2Safety.......................................................................................................11
2.1 Safety notes..............................................................................................11
2.2 Safety regulations for the method of operation...........................................12
2.3 Standards and directives complied with......................................................14
2.4 Release notes............................................................................................14
2.5 Cyber security disclaimer...........................................................................15
3Structure and function ............................................................................16
3.1 Description ................................................................................................16
4Planning...................................................................................................17
4.1 Loop audio matrices ..................................................................................17
4.2 Topologies.................................................................................................17
4.3 Notes.........................................................................................................19
4.4 Details for ordering ....................................................................................19
5Product data ............................................................................................20
5.1 Views ........................................................................................................20
5.2 Pin assignments........................................................................................21
5.2.1 Pin assignment, line and loudspeakers........................................21
5.2.2 Connection diagram, external LED indicator................................22
5.3 Operation modes.......................................................................................22
5.4 Indicators...................................................................................................23
5.5 Technical data...........................................................................................24
6Mounting, installation..............................................................................27
6.1 Mounting in the housing.............................................................................28
6.2 Wiring........................................................................................................29
7Configuration...........................................................................................31
7.1 Adjustment elements.................................................................................31
8Commissioning and maintenance..........................................................32
8.1 Function test..............................................................................................33

4 | 34 A6V11571319_en--_b
Index of Figures
Fig. 1: Isolation of a short circuit...........................................................................16
Fig. 2: Loop with loop isolators at every loudspeaker ...........................................17
Fig. 3: Loop with loudspeakers at loop isolators and loudspeakers between the
loop isolators.......................................................................................................18
Fig. 4: Loop without loudspeakers at loop isolators and with loudspeakers between
the loop isolators.................................................................................................18
Fig. 5: Equipment view, loop isolator (100 V) PCA2005-A1..................................20
Fig. 6: Pin assignments for loop and loudspeakers...............................................21
Fig. 7: Loop audio matrix, loop circuitry................................................................21
Fig. 8: Connection diagram, external LED............................................................22
Fig. 9: Loop isolator (100V) connector view..........................................................29
Fig. 10: View of SIL switch SW1, all switches in 'OFF' position.............................31

About this document
Applicable documents 1
A6V11571319_en--_b 5 | 34
1 About this document
Retention and availability
NOTICE
Missing information
Damage due to misuse
●This document must be available in a usable format throughout the entire life
cycle of the product. Keep the document for reference and ensure that it can
be accessed by target groups.
Should you require another copy of this document, please contact the Customer
Support Center, phone [phone].
Goal and purpose
This document explains the technical description and installation of a module from
the Cerberus PACE and Novigo network-based voice alarm and announcement
system for isolating short-circuits on the loudspeaker loop.
Scope
The information contained in this document is valid for Cerberus PACE and
Novigo.

About this document
Applicable documents
1
6 | 34 A6V11571319_en--_b
Target groups
The information in this document is intended for the following target groups:
Target group Activity Qualification
System owner ●According to EN 50110-1,
'nominated person with the overall
responsibility to ensure the safe
operation of the electrical
installation by setting rules and
organisation or framework.'
●'This person can be the owner,
employer, proprietor or a delegated
person.'
●'Some of these duties can be
delegated to others as required. For
large or complex electrical
installations or networks, the duties
can be delegated for parts of the
installations or the network.'
IT security officers ●Support companies when it comes
to assessing the security of
products, solutions, and services,
and defining and implementing
improvements.
●Are technical experts in all aspects
of IT security.
Project engineer ●Sets parameters for product
depending on specific national
and/or customer requirements.
●Checks operability and approves
the product for commissioning at the
place of installation.
●Is responsible for troubleshooting.
●Has obtained suitable specialist
training for the function and for the
products.
●Has attended the training courses
for Product Engineer.
Installation personnel ●Assembles and installs the product
components at the place of
installation.
●Carries out a function check
following installation.
●Has received specialist training in
the area of building installation
technology or electrical installations.
Commissioning personnel ●Configures the product at the place
of installation according to
customer-specific requirements.
●Checks the product operability and
releases the product for use by the
operator.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for the
products.
●Has attended the training courses
for commissioning personnel.
Maintenance personnel ●Carries out all maintenance work.
●Checks that the products are in
perfect working order.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for the
products.
Source language and reference document
●The source/original language of this document is German (de).
●The reference version of this document is the international version in English.
The international version is not localized.

About this document
Applicable documents 1
A6V11571319_en--_b 7 | 34
Document identification
The document ID is structured as follows:
ID code Examples
ID_languageCOUNTRY_ modification index
-- = multilingual or international A6V10215123_deDE_a A6V10215123_en--_a
A6V10315123_----_a
Date format
The date format in the document corresponds to the recommendation of
international standard ISO 8601 (format YYYY-MM-DD).
Presentation conventions
Text markups
Special text markups are used as follows in this document:
⊳
Prerequisite for an instruction telling you what to do
1.
2.
Instruction with at least two steps
◈Instruction with one step
– Variant, option, or detailed information on an instruction
⇒
Interim result of an instruction
⇒
Final result of an instruction
●Lists
[➙X] Reference to a page number
'Text' Quote, exact match
<Button> Identification of buttons
>Indicates a link and identifies steps in a sequence, e.g., 'Menu bar' >
'Help' > 'Help topics'
↑Text Identifies a glossary entry
Additional information and tips
The 'i' symbol identifies additional information and tips to simplify the procedure.

About this document
Applicable documents
1
8 | 34 A6V11571319_en--_b
1.1 Applicable documents
You will find more information on the Cerberus PACE system or the Novigo system
and its components in the following documents:
Title Document ID
Cerberus PACE Novigo
IT security policies
IT security policies A6V11439692 A6V11773711
System documentation
Planning A6V11244536 A6V11467812
Configuration A6V10429097 A6V11474760
Mounting / Installation A6V10430579 A6V11467817
Operation A6V10430571 A6V11467803
Data sheets
System data sheet A6V11243351 A6V11467196
19" cabinets A6V10429243 A6V11467209
Digital audio matrix A6V10430497 A6V11467202
Power amplifier A6V10430515 A6V11467204
Operating terminals A6V10430526 A6V11467198
Call stations A6V10430544 A6V11467200
Power supply and batteries A6V10430553 A6V11467207
Accessories and options A6V10430563 A6V11467211
Environmental declaration
Environmental declaration A6V11948779 A6V11948779
EU declaration of conformity (CE)
For PCA2005-A1 A6V12101771 A6V12101771

About this document
Applicable documents 1
A6V11571319_en--_b 9 | 34
You will find more information on the Cerberus PACE Compact system or the
Novigo Core system and its components in the following documents:
Title Document ID
Cerberus PACE
Compact Novigo Core
IT security policies
IT security policies A6V11439692 A6V11773711
System documentation
Planning A6V11899877 A6V11940318
Configuration A6V10429097 A6V11474760
Mounting / installation A6V11899867 A6V11940317
Operation A6V11899865 A6V11940315
Data sheets
System data sheet A6V11868429 A6V11940333
Voice alarm panel Compact/Core 400 A6V11940263 A6V11940334
Voice alarm panel Compact/Core 1000 A6V11940268 A6V11940335
Network components A6V11940273 A6V11940338
Operating and call stations A6V11940274 A6V11940337
Power supply and batteries A6V11940272 A6V11940336
Accessories and options A6V11940275 A6V11940339
Loop isolator (100V)
Loop isolator (100V) - technical manual A6V11571319 A6V11571319
Environmental declaration
Cerberus PACE/Novigo – environmental
declaration A6V11948779 A6V11948779
Cerberus PACE Compact/Novigo Core –
environmental declaration A6V12161830 A6V12161830
Download center
Related documents such as environmental declarations, CE declarations, etc., can
be downloaded at the following Internet address:
http://siemens.com/bt/download

About this document
Revision history
1
10 | 34 A6V11571319_en--_b
1.2 Revision history
The reference document's version applies to all languages into which the reference
document is translated.
The first edition of a language version or a country variant may, for example, be
version 'd' instead of 'a' if the reference document is already this version.
The table below shows this document's revision history:
Version Edition date Brief description
b2020-12-30 New:
Loop audio matrices [➙17]
Revised:
Applicable documents [➙8];Topologies [➙17];Notes [➙19];Pin
assignment, line and loudspeakers [➙21];Technical data [➙24]
a2019-05-19 First edition

Safety
Safety notes 2
A6V11571319_en--_b 11 | 34
2 Safety
2.1 Safety notes
Comply with the following safety notes to protect life, limb, and property.
The safety notes in the document include the following elements:
●Symbol for hazard
●Signal word
●Type and source of hazard
●Consequences in the event the hazard occurs
●Measures or prohibitions to prevent the hazard
Symbol for hazard
This is the symbol for hazard. It warns you of Risks of injury.
Comply with all measures designated by this symbol to prevent injury or
death.
Additional hazard symbols
These symbols indicate general hazards, type of hazard, possible consequences,
measures and prohibitions, a sample of which is displayed in the following table:
General hazard Potentially explosive
atmospheres
Voltage/electrical shock Laser light
Battery Heat
Signal word
The signal word classifies the hazard as defined in the following table:
Signal word Danger level
DANGER 'DANGER' identifies a dangerous situation, that results directly in death or
serious injuries, if you do not avoid this situation.
WARNING 'WARNING' identifies a dangerous situation, that can result in death or serious
injuries, if you do not avoid this situation.
CAUTION 'CAUTION' identifies a dangerous situation, that can result in minor or
moderate injuries, if you do not avoid this situation.
Note 'NOTE' identifies a possible situation that may cause damage if not observed.
'NOTE' does not reference possible injury.
Depiction of risk of injury
Notes on risk of injury is depicted as follows:

Safety
Safety regulations for the method of operation
2
12 | 34 A6V11571319_en--_b
WARNING
Type and source of
hazard
Consequences in the event the hazard occurs
●Measures/prohibitions to prevent the hazard
DEPICTION for possible damage to property
Notes on possible damage to property is depicted as follows:
NOTICE
Type and source of hazard
Consequences in the event the hazard occurs
●Measures/prohibitions to prevent the hazard
2.2 Safety regulations for the method of operation
National standards, regulations and legislation
Siemens products are developed and produced in compliance with the relevant
European and international safety standards. Should additional national or local
safety standards or legislation concerning the planning, mounting, installation,
operation or disposal of the product apply at the place of operation, then these
must also be taken into account together with the safety regulations in the product
documentation.
Electrical installations
WARNING
Electrical voltage
Electric shock
●Work on electrical installations may only be carried out by qualified
electricians or by instructed persons working under the guidance and
supervision of a qualified electrician, in accordance with the electrotechnical
regulations.
●Wherever possible disconnect products from the power supply when carrying
out commissioning, maintenance or repair work on them.
●Lock volt-free areas to prevent them being switched back on again by mistake.
●Label the connection terminals with external voltage using a
'DANGER External voltage' sign.
●Route mains connections to products separately and fuse them with their own,
clearly marked fuse.
●Fit an easily accessible disconnecting device in accordance with EN 62368-1
outside the installation.
●Produce earthing as stated in local safety regulations.

Safet
y
Safety regulations for the method of operation 2
A6V11571319_en--_b 13 | 34
CAUTION
Noncompliance with the following safety regulations
Risk of injury to persons and damage to property
●Compliance with the following regulations is required.
●Specialist electrical engineering knowledge is required for installation.
●Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.
Mounting, installation, commissioning and maintenance
●If you require tools such as a ladder, these must be safe and intended for the
work in question.
●When starting the voice alarm system, make sure that no unstable states can
occur.
●Make sure that all points described in the 'Testing and checking the
functionality of the products' section below are observed.
●You may only put controls into normal operation once work to test and check
the functionality of the products has been completed and the site has been
handed over to the customer.
Testing and checking the functionality of the products
●Prevent incorrect triggering of the remote transmission.
●When you test building equipment or activate devices from third-party
companies, you must liaise with the people responsible for these.
●No one must be injured and no damage to the building equipment must occur
when voice alarm controls are activated for test purposes. The following
instructions must be observed:
– Use the correct potential for the activation; as a rule, this will be the
potential of the building equipment.
– Only check controls up to the interface (relay with blocking option).
– Make sure that only the controls to be tested are activated.
●Inform people before testing alarm devices and determine any potential panic
reactions.
●Inform people of any noise or smoke emission which may occur.
●Inform the corresponding alarm and fault receiving centers before performing a
test remote transmission.
Modifications to the system design and the products
Modifications to the system and to individual products may lead to faults,
malfunctioning and safety risks. Written confirmation must be obtained from
Siemens and the corresponding safety bodies for modifications or additions.
Modules and spare parts
●Components and spare parts must comply with the technical specifications
defined by Siemens. Only use products specified or recommended by
Siemens.
●Only use fuses with the specified fuse characteristics.
●Wrong battery types and improper battery changing lead to a risk of explosion.
Only use the same battery type or an equivalent battery type recommended by
Siemens.
●Batteries must be disposed of in an environmentally friendly manner. Observe
national guidelines and regulations.

Safety
Standards and directives complied with
2
14 | 34 A6V11571319_en--_b
Disregard of the safety regulations
Before they are delivered, Siemens products are tested to ensure they function
correctly when used properly. Siemens disclaims all liability for damage or injuries
caused by the incorrect application of the instructions or the disregard of danger
warnings contained in the documentation. This applies in particular to the following
damage:
●Personal injuries or damage to property caused by improper use and incorrect
application
●Personal injuries or damage to property caused by disregarding safety
instructions in the documentation or on the product
●Personal injury or damage to property caused by poor maintenance or lack of
maintenance
2.3 Standards and directives complied with
A list of the standards and directives complied with is available from your Siemens
contact.
2.4 Release notes
Limitations to the configuration or use of devices in a voice alarm system with a
particular firmware version are possible.
WARNING
Limited or non
-
existent fire detection
Personal injury and damage to property in the event of a fire.
A limited or missing voice alarm in the intended application - also due to improper
use, project planning or configuration of the loop isolators - can lead to personal
injury.
●Read the 'Release Notes' before you plan and/or configure a voice alarm
system.
●Read the 'Release Notes' before you carry out a firmware update to a voice
alarm system.
NOTICE
Incorrect planning and/or configuration
Important standards and specifications are not satisfied.
Additional expense resulting from necessary new planning and/or configuration.
●Read the 'Release Notes' before you plan and/or configure a voice alarm
system.
●Read the 'Release Notes' before you carry out a firmware update to a voice
alarm system.

Safety
Cyber security disclaimer 2
A6V11571319_en--_b 15 | 34
2.5 Cyber security disclaimer
Siemens provides a portfolio of products, solutions, systems and services that
includes security functions that support the secure operation of plants, systems,
machines and networks. In the field of Building Technologies, this includes building
automation and control, fire safety, security management as well as physical
security systems. In order to protect plants, systems, machines and networks
against cyber threats, it is necessary to implement – and continuously maintain – a
holistic, state-of-the-art security concept. Siemens’ portfolio only forms one element
of such a concept.
You are responsible for preventing unauthorized access to your plants, systems,
machines and networks which should only be connected to an enterprise network
or the internet if and to the extent such a connection is necessary and only when
appropriate security measures (e.g. firewalls and/or network segmentation) are in
place. Additionally, Siemens’ guidance on appropriate security measures should be
taken into account. For additional information, please contact your Siemens sales
representative or visit https://www.siemens.com/global/en/home/company/topic-
areas/future-of-manufacturing/industrial-security.html.
Siemens’ portfolio undergoes continuous development to make it more secure.
Siemens strongly recommends that updates are applied as soon as they are
available and that the latest versions are used. Use of versions that are no longer
supported, and failure to apply the latest updates may increase your exposure to
cyber threats. Siemens strongly recommends to comply with security advisories on
the latest security threats, patches and other related measures, published, among
others, under https://www.siemens.com/cert/en/cert-security-advisories.htm.

Structure and function
Description
3
16 | 34 A6V11571319_en--_b
3 Structure and function
3.1 Description
The Loop isolator (100V) PCA2005-A1 is used in voice-alarm evacuation systems
with a loop topology. The Loop isolator (100V) monitors the speaker line from its
loudspeaker connection to the speaker for short-circuit and open lines. The matrix
monitors the loop for short-circuit, open lines and ground fault.
If a short-circuit occurs on the loudspeaker line, the loop isolators identify the
defective cable segment and disconnect it. The loop concerned is then supplied
with power from two sides. This does not impair the function of the remaining
loudspeakers.
Fig. 1: Isolation of a short circuit
Each Loop isolator (100V) has a built-in cutoff relay. If a short circuit occurs, the
relevant cable segment is disconnected from the rest of the loop. The short-circuit
can either arise between two Loop isolator (100V) or at the loudspeaker connection
of a Loop isolator (100V). The cable segment between two Loop isolator (100V)
and the loudspeaker connection at the Loop isolator (100V) concerned with the
OUT output are always isolated simultaneously (as per Fig. Loop isolator (100V) X)
Properties
●Short circuit isolator according to EN 54-17
●Isolates one or more short circuits in a 100 V loudspeaker loop
●Isolation time of under 4 seconds an alarm condition, under 30 seconds in
normal operation
●If a short circuit occurs, only the cable segment concerned is isolated
●The Loop isolator (100V) monitors the speaker line from its loudspeaker
connection to the speaker for short-circuit and open lines.
●Suitable for 100 V loudspeaker systems
●No noise emissions at the loudspeaker by the Loop isolator (100V)
●Status display on the Loop isolator (100V) via LED
●Optional external Loop isolator LED can be connected for status display
●Loop returned to initial condition automatically after troubleshooting
●Maintenance mode for fast error search
●Spelsberg i 16-L Li Box PCA2013-A1 housing available for Loop isolator
(100V)

Planning
Loop audio matrices 4
A6V11571319_en--_b 17 | 34
4 Planning
4.1 Loop audio matrices
The 'Loop isolator (100V)' can be connected to the following audio matrices:
●PC2003-A1, Cerberus PACE, Novigo, 'Digital audio matrix (4/4/16)'
●PC1001-A2, Novigo, 'Voice alarm panel Core 400'
●PC1002-A2, Novigo, 'Voice alarm panel Core 1000'
●PC1001-A3, Cerberus PACE, 'Voice alarm panel Compact 400'
●PC1002-A3, Cerberus PACE, 'Voice alarm panel Compact 1000'
4.2 Topologies
The following topologies are possible with the Loop isolator (100V).
Loop with loop isolators at every loudspeaker
This topology is the most reliable. If a short-circuit occurs on the loop, just one
single loop segment fails. The only loudspeakers to fail are those at the OUT
connection of the loop isolator concerned.
Fig. 2: Loop with loop isolators at every loudspeaker
Loop with loudspeakers at loop isolators and loudspeakers
between the loop isolators
This topology is the most cost-effective. Some loudspeakers are connected
between loop isolators. If a short-circuit occurs on the loop, all the loudspeakers in
the segment concerned fail.

Planning
Topologies
4
18 | 34 A6V11571319_en--_b
Fig. 3: Loop with loudspeakers at loop isolators and loudspeakers between the loop isolators
Loop without loudspeakers at loop isolators and with
loudspeakers between the loop isolators
It is also possible to use the loop isolators without loudspeakers at the Loop
isolator (100V) itself. In this case, we recommend terminating the loudspeaker
output at the loop isolator with a 12 kΩ/ 1 W EOL resistor; this guarantees an
isolation time of < 4 seconds if a short-circuit occurs in alarm operation. A 12 kΩ
EOL resistor consumes 0.85 W of power, which must be taken into account when
calculating the amplifier power.
Fig. 4: Loop without loudspeakers at loop isolators and with loudspeakers between the loop isolators
If the loudspeaker output is not to be terminated at the loop isolator, this must be
configured using the SIL switch. If a short-circuit occurs in alarm operation in this
configuration, the isolation time increases to approximately 15 seconds.
●To deactivate loudspeaker monitoring: set SIL switch 8 [4] to ON.
See also
Adjustment elements [➙31]

Planning
Notes 4
A6V11571319_en--_b 19 | 34
4.3 Notes
●It is allowed to mix speaker loops and stub lines on one loop audio matrix (See
Loop audio matrices [➙17]). The supervision of stub lines is limited to
impedance supervision. The usage of 'EOL3 (active)' PCA2004-A1 is
prohibited.
●It is allowed to connect max. two speaker loops to one amplifier. Both loops
must be in the same speaker zone.
●It could occur on background music with high level that a fault display will be
delayed and the loop isolator LED doesn’t show the correct status. This
malfunction disappears as soon as the sound level drops.
In order to further increase the reliability and the availability of the loudspeaker
systems, the following planning is recommended:
●Set up two loop segments in one room separated by loop isolators and install
at least one speaker in each segment
●Set up two separated loops in one room/building, connecting to one power
amplifier respectively
●Set up two separated loops in one room/building, connecting to one audio
matrix respectively
●Set up two separated loops in one room/building, connecting to one cabinet
respectively
4.4 Details for ordering
Type Designation Order number
PCA2005-A1 Loop isolator (100V) Cerberus PACE: S54451-B53-A1
Novigo: OFB:NOVIGO_2160
PCA2013-A1 Spelsberg i 16-L Li Box Cerberus PACE: S54451-B54-A1
Novigo: OFB:NOVIGO_2161

Product data
Views
5
20 | 34 A6V11571319_en--_b
5 Product data
5.1 Views
Fig. 5: Equipment view, loop isolator (100 V) PCA2005-A1
1Fastening tabs for relieving strain on loudspeaker lines
2 Fastening tab for relieving strain on the LED connection cable
X4 Connection terminals for '+OUT-' loudspeaker line output
X5 Connection terminals for '+SP-' loudspeaker
X6 Connection terminals for '+IN-' loudspeaker line input
LED1 LED status display
LED +
-Connection terminal for external loop isolator LED
SW1 SIL switch for configuration (single-in-line switch)
