Parallon
CAFÉ AND OCCASIONAL X-BASE TABLE
ASSEMBLY INSTRUCTIONS
C6554 Rev D |www.sitonit.net |1
Everything to the table.
When you want cohesion in spaces large,
small, shared or separate, there’s Parallon.
It’s a single collection with a singular look,
oering an array of choices for a variety of
environments—and all the features to t.
Ensure design is never a distraction in the
places where everyone needs to focus. Our
Parallon line of café and occasional tables
provides a unied and streamlined look from
room to room.

2 |www.sitonit.net |C6554 Rev D
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Failure to follow instructions could result in product failure or
potential injury.
Do not apply sudden weight to table.
Do not exceed 200 lb static load weight capacity.
CAUTION
Read the entire instruction manual before you start installation and
assembly. If you have any questions regarding any of the instructions or
warnings, please contact your local distributor for assistance.
To report any issues with this product, contact our customer experience
team at: [phone] or [email protected].

C6554 Rev D |www.sitonit.net |3
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
•Cordless Drill/Driver
•#3 Phillips Bit
•5⁄32" Hex Bit
•1⁄2" Combination Wrench
•1⁄2" Deep Well Hex Socket, ¼" Drive
•Hex Shank to ¼" Square Drive
Adapter
•Universal Joint, ¼" Drive
Recommended Tools
1⁄2" Combination Wrench
Universal Joint
¼" Drive
1⁄2" Deep Well
Hex Socket, ¼" Drive
Cordless
Drill/Driver
Hex Shank to
1⁄4" Square Drive Adapter
#3 Phillips Bit
5⁄32" Hex Bit

4 |www.sitonit.net |C6554 Rev D
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
#12 x 1"
Screws
1⁄4"x 1"
Screws
•Tabletop (1, round or square)
•Top Plate
•Column (1)
•Foot (4)
•Pack A:
•#12 × 1" Screw (8)
•Pack B:
•5⁄16" × 1½" Bolt (4)
•5⁄16" Nut (4)
•Foot Attachment Plate (4)
•Pack C:
•¼" × 1" Screw (4)
PACK C
PACK A
Parts
Feet Column
Top Plate
Top Plate
PACK B
Foot Attachment Plates
5⁄16 x 1½"
Bolts
5⁄16" Nuts
OR
Round
Tabletop
Square
Tabletop

C6554 Rev D |www.sitonit.net |5
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
1:1 HARDWARE TOOLS
Step 1: Attach the top plates to the columns.
5⁄32 Hex Drill Bit 1⁄4"x 1" Screw (Pack C)

6 |www.sitonit.net |C6554 Rev D
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 2: Attach the column assemby to the tabletop.
#12 x 1" Screw (Pack A) #3 Phillips Bit
1:1 HARDWARE TOOLS
Pilot Hole

C6554 Rev D |www.sitonit.net |7
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
1:1 HARDWARE
Step 3: Slide the bolt through the foot attachment plate and column.
1:1 HARDWARE
5⁄16 x 11⁄2" Bolt (Pack B)
Foot Attachment Plate
5⁄16 x 11⁄2" Bolt
Column
Hole
Repeat this step with each foot.

8 |www.sitonit.net |C6554 Rev D
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 4: Slide the foot over the bolt.
5⁄16 x 11⁄2" Bolt
Foot
Repeat this step with each foot.

C6554 Rev D |www.sitonit.net |9
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 5: Hold the bolt in place and tighten the nut.
Repeat this step with each foot.
1:1 HARDWARE TOOLS
5⁄16 Nut (Pack B)
Universal Joint
1⁄2" Deep Well Hex Socket,
¼" Drive
Hex Shank to Square Drive Adapter
Adapter
Universal Joint
Socket

10 |www.sitonit.net |C6554 Rev D
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Glide
Step 6: Unscrew the glides to level as needed and turn the table upright
with the help of another person.

C6554 Rev D |www.sitonit.net |11
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 7: Turn the table upright with the help of another person.

Parallon
POWER READY
CAFÉ AND OCCASIONAL X-BASE TABLE
C6619 Rev A |www.sitonit.net |1
ASSEMBLY INSTRUCTIONS
Everything to the table.
When you want cohesion in spaces large,
small, shared or separate, there’s Parallon.
It’s a single collection with a singular look,
oering an array of choices for a variety of
environments—and all the features to t.
Ensure design is never a distraction in the
places where everyone needs to focus. Our
Parallon line of cafe and occasional tables
provides a unied and streamlined look from
room to room.

2 |www.sitonit.net |C6619 Rev A
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Failure to follow instructions could result in product failure or
potential injury.
Do not apply sudden weight to table.
Do not exceed 200 lb static load weight capacity.
CAUTION
Read the entire instruction manual before you start installation and
assembly. If you have any questions regarding any of the instructions or
warnings, please contact your local distributor for assistance.
To report any issues with this product, contact our customer experience
team at: [phone] or [email protected].

C6619 Rev A |www.sitonit.net |3
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
•Cordless Drill/Driver
•#3 Phillips Bit
•5⁄32" Hex Bit
•1⁄2" Combination Wrench
•1⁄2" Deep Well Hex Socket, ¼" Drive
•3⁄8" Hex Socket, 1⁄4" Drive
•Hex Shank to ¼" Square Drive
Adapter
•Universal Joint, ¼" Drive
Recommended Tools
1⁄2" Combination Wrench
Universal Joint
¼" Drive
1⁄2" Deep Well
Hex Socket, ¼" Drive
Cordless
Drill/Driver
Hex Shank to
1⁄4" Square Drive Adapter
#3 Phillips Bit
5⁄32" Hex Bit
3⁄8" Hex Socket,
1⁄4" Drive

4 |www.sitonit.net |C6619 Rev A
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
1⁄4"x 1⁄2"
Bolt
Parts
PACK P
#12 x 1"
Screws
PACK A PACK B
Foot Attachment Plates
5⁄16 x 1½"
Bolts
5⁄16" Nuts
•Tabletop (1, round or square)
•Grommet (1)
•Column (1)
•Foot (4)
•Pack A:
•#12 × 1" Screw (8)
•Pack B:
•5⁄16" × 1½" Bolt (4)
•5⁄16" Nut (4)
•Foot Attachment Plate (4)
•Pack C:
•¼" × 1" Screw (4, unused)
•Pack P:
•1⁄4"x 1⁄2" Bolt (4)
Power Cone
Column
Power
Module
Feet
OR
Round
Tabletop
Square
Tabletop
Grommet

C6619 Rev A |www.sitonit.net |5
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 1: Remove the plastic nut from the power module.
Plastic Nut
Note: If power module was not purchased, go to Step 4 on page 8.

6 |www.sitonit.net |C6619 Rev A
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 2: Insert the power module in through the top-side of the tabletop.

C6619 Rev A |www.sitonit.net |7
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 3: Flip the tabletop over and tighten the plastic back onto the
power module.
Note: Place the tabletop on top of packaging to prevent damage to the
power module.

8 |www.sitonit.net |C6619 Rev A
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 4: Slide the power cone onto the column.

C6619 Rev A |www.sitonit.net |9
Parallon CAFÉ/OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Step 5: Attach the power cone to the column.
1:1 HARDWARE TOOLS
1⁄4"x 1⁄2" Bolt (Pack P)
3⁄8" Hex Socket, 1⁄4" Drive
Hex Shank to Square Drive Adapter
