SKYDANCE C1 User manual

Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Dimming data
Dimming range
RF 2.4GHz + Push Dim
30m
4096 levels
0 -100%
Technical Parameters
Output power 1.05W-16.1W (350mA)
Output voltage 3-46VDC
Output current 1CH,350mA/700mA
Input and Output
Input voltage 12-48VDC
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
Output type Constant current
Warranty and Protection
5 years
Protection Reverse Polarity
Short circuit
Warranty
Input signal
Control distance
Dimming level
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
RED
Model No.: C1(350mA) / C1(700mA)
Single Color LED Controller
1 Channel/Step-less dimming/Wireless remote control/Auto-transmitting/Synchronize/Push Dim
Features
● Match with Skydance’s 2.4G dimming remote control,
one RF controller accept up to 10 remote control.
● Auto-transmitting function: Controller automaticly transmit
signal to another controller with 30m control distance.
● Synchronize on multiple number of controllers.
● Connect with external push switch to achieve on/off and
dimming function.
Dimming curve Logarithmic
2.1W-32.2W (700mA)
User Manual Ver 1.0.2 Page 1
www.iskydance.com

Push Switch
LED Controller
AC100-240V
Power Supply
12-48VDC
Constant Voltage
C1
Match Remote Control (two match ways)
Use the controller’s Match key
Match:
Short press match key, immediately press on/off
key (single zone remote) or zone key (multiple zone
remote) of the remote.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/off key (single zone remote)
or zone key (multiple zone remote) 3 times on the remote.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power, then switch on power again,
immediately short press on/off key (single zone remote)
or zone key (multiple zone remote) 5 times on the remote.
The light blinks 5 times means all matched remotes were
deleted.
Delete:
Press and hold match key for 5s to delete all match,
The light blinks 5 times means all matched remotes
were deleted.
Mechanical Structures and Installations
LED output -
LED output +
Power input -
Power input +
LED indicator
Match key
Push switch com
Push switch in
Installation rack
Installation rack
End user can choose the suitable match/delete ways. Two options are offered for selection:
1.The controller could auto check and output a proper voltage according to its LED quantities.
2.The controller works on buck mode, the voltage of power supply should be greater than the total voltage of the seried LEDs.
Drives 1-13pcs 1W LED
97mm
33mm
18mm
C1 Single Color LED Controller
User Manual Ver 1.0.2 Page 2
www.iskydance.com

Push Dim Function
● Short press:
Turn on or off light.
● Long press (1-6s):
Press and hold to step-less dimming,
With every other long press, the light level goes to the opposite direction.
● Dimming memory:
Light returns to the previous dimming level when switched off and on again, even at power failure.
● Synchronization:
If more than one controller are connected to the same push switch, do a long press for more than 10s,
then the system is synchronized and all lights in the group dim up to 100%.
This means there is no need for any additional synchrony wire in larger installations.
We recommend the number of controllers connected to a push switch does not exceed 25 pieces,
The maximum length of the wires from push to controller should be no more than 20 meters.
The provided Push-Dim interface allows for a simple dimming method using commercially available non-latching
(momentary) wall switchs.
Application notes
1. All the receivers in the same zone.
2. Each receiver(one or more) in a different zone, like zone 1, 2, 3 or 4.
Zone 1 Zone 2 Zone 3
RF remote
30m 30m
Zone 4
RF remote
Auto-transmitting: One receiver can transmit the signals from the remote to another receiver within 30m,
as long as there is a receiver within 30m, the remote control distance can be limitless.
Auto-synchronization: Multiple receivers within 30m distance can work synchronously when they are controlled
by the same remote.
Receiver placement may offer up to 30m communication distance. Metals and other metal materials will reduce the range.
Strong signal sources such as WiFi routers and microwave ovens will affect the range.
We recommend for indoor applications that receiver placements should be no further apart than15m.
30m
30m30m
C1 Single Color LED Controller
User Manual Ver 1.0.2 Page 3
www.iskydance.com

C1 Single Color LED Controller
Malfunctions Analysis & Troubleshooting
Malfunctions
Causes Troubleshooting
No response
from the remote
1. The battery has no power.
2. Beyond controllable distance.
3. The controller did not match the remote.
1. Replace battery.
2. Reduce remote distance.
3. Re-match the remote.
1. No power.
2. Wrong connection or insecure.
1. Check the power.
2. Check the connection.
No light
100
90
80
70
60
50
40
30
20
10
PWM duty(%)
50 60 70 80 90 100
Brightness(%)
10 20 30 40
Gamma=1.6
Dimming Curve
User Manual Ver 1.0.2 Page 4
