SMC Networks VQC1000 User manual

5-Port Solenoid Valve
Series VQC
CAT.ES11-80 A

Features 1
Series VQC1000/2000/4000
(Based on IEC529)
Connector
Type
(Series)
VQC1000
VQC2000
VQC4000
Manifold
pitch (mm)
10.5
16
25
Flow characteristics Note)
Metal seal
Applicable
cylinder
size (mm)
to ø50
to ø80
to ø140
Compact and high flow
Connector entry direction
can be changed with a
single push
The connector entry direction can be changed from the
top to the side by simply pressing the manual release
button.
It is not necessary to use the manual release button when
switching from the side to the top.
Top entry
Side entry
Conforming to IP67 for
protection from dust
and moisture
M12/M8
connector selection available
For I/O SI unit
(DeviceNet compatible)
Input blocks
Serial transmission
EX250
Note) Values for 2-position single from the cylinder port to the exhaust. (From 2 to 3 and from 4 to 5)
Series
EX500
Connector Type Manifold
(For kits S and T)
Outstanding response times
and long life
(Metal seal: Single type with light and surge suppressor)
VQC1100: 10ms ±2ms; 200 million cycles
VQC2100: 20ms ±2ms; 200 million cycles
VQC4100: 17ms ±3ms; 100 million cycles
Accommodates gateway
type serial wiring
• Gateway unit types are DeviceNet, PROFIBUS-DP and
Remote I/O.
• Because just one gateway unit controls up to 4 branch
lines, it offers much more freedom in choosing valve
mounting locations than do conventional serial units.
• Manifolds and input blocks can be mounted in close
proximity of actuators, thus effectively shortening air
piping and electrical wiring lengths.
• Since wiring is “prepackaged” into one multi-connector
type cable, wiring work is not only made easier, but
much more accurate.
• A single cable from the gateway provides both signal
and power to each branch, thus eliminating the need for
separate power connections for each manifold valve and
input block.
• The use of a multi-connector for input blocks makes
manifold station expansion or reduction a breeze.
NEW CONCEPT
Rubber seal
C[dm3/(s•bar)]
0.72
2.6
6.9
b
0.25
0.15
0.17
Cv
0.18
0.60
1.7
C[dm3/(s•bar)]
1.0
3.2
7.3
b
0.30
0.30
0.38
Cv
0.25
0.80
2.0

Features 2
Dual 3-port valves, 4 positions
VQC1000/2000 (Rubber seal type only)
A wide variety of prepackaged wiring configurations
R1 A P B R2
VQC1A01
VQC2A01
VQC1B01
VQC2B01
VQC1C01
VQC2C01
N.C.
valve N.C.
valve
N.O.
valve N.O.
valve
N.C.
valve N.O. valve
Model A side B side JIS symbol
1
(P)
5
(R1) 3
(R2)
4
(A) 2
(B)
1
(P)
5
(R1) 3
(R2)
4
(A) 2
(B)
1
(P)
5
(R1) 3
(R2)
4
(A) 2
(B)
SKit
(Serial transmission) FKit
(D-sub connector)
Protective enclosure
conforms to IP 67
TKit
(Terminal block box)
PKit
(Flat ribbon cable)
•Our four standard wiring packages bring a world of ease to wiring and maintenance work, while the protective enclosures of two of
them conform to IP67 standards.
•The S Kit is compatible with a combined I/O unit.
(If used with gataway unit, SI must be output only.)
Replaceable
One-touch fittings
Single mounting screw,
clamp construction
NEW CONCEPT
(Refer to the connector wiring diagram)
Printed circuit board patterns between connectors are shifted at every station.
This allows for viable connections to take place without necessarily specifying
whether the manifold station is double, single, or mixed wiring.
Series
EX500
25-pin 26-pin, 20-pin
Connector wiring diagram (mixed wiring)
1
2
3
4
5
6
7
8
9
10
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
19
20
19
20
6
A
4
A
3
A
1
A5
B
2
B
Output
COM
Station 1
Double wiring Station 2 Single wiring Station 3 Double wiring Station 4 Single wiring
1
2
3
4
Protective enclosure
conforms to IP 67
Connector type manifold
•The use of multi-pin connectors to replace wiring inside manifold
blocks provides flexibility when adding stations or changing
manifold configuration.
•Connector clusters give a new dimension to the notion of
interchangeability. For example, changing from F Kit (D-sub
connector) to S Kit (serial transmission) is achieved by simply
changing the kit piece.
•Two 3-port valves built into one body.
•The 3-port valves on the A and B sides can operate
independently.
•When used as 3-port valves, only half the number of
stations is required.
•Can also be used as a 4-position, 5-port type valve.
Exhaust center : VQC1A01
VQC2A01
Pressure center: VQC1B01
VQC2B01
Serial transmission
EX500 D-sub connector Flat ribbon cable Terminal block box
Wiring
1
2
3
4
5
6
7
8
9
10
19
20
1
2
3
4
5
6
7
8
9
10
19
20
1
2
3
4
5
6
7
8
9
10
19
20
1
2
3
4
5
6
7
8
9
10
19
20
1
2
3
4
5
6
7
8
9
10
19
20
1
2
3
4
5
6
7
8
9
10
19
20

Features 3
Base-Mounted type: Variations
Series
VQC1000
Series
VQC2000
Series
VQC4000
Metal sealRubber seal
VQC100
VQC101
Metal sealRubber seal
VQC200
VQC201
Metal sealRubber seal
VQC400
VQC401
Sonic
Conductance
C[dm3/(s•bar)]
S Kit
Serial transmission
Single/Double
Applicable bore size
0.72 0.72
1.0 0.65
2.6 2.0
3.2 2.2
6.9 6.3
7.3 6.4
to ø50
to ø80
to ø140
Gateway application
Compatible network
• Remote I/O
• DeviceNet
• PROFIBUS-DP
Gateway application requires a
gateway unit and
communication cable
separately.
Contact SMC for
more details.
Conforms to IP67
Conforms to IP67
Decentralized Serial Wiring
Compatible network
• DeviceNet
• PROFIBUS-DP
I/O
Serial unit: EX500 Serial unit: EX250


—


—
Series
Ex500
Values of
CYL to EXH
(From 4 to 5
and
from 2 to 3)
3-position (Closed center)

Series
Ex500
Features 4
Port size
F Kit
D-sub connector P Kit
Flat ribbon cable T Kit
Terminal block box
D-sub connector
Compatible with
D-sub connector that
(
complies with MIL standard.
)
Flat ribbon cable
Compatible with
flat ribbon cable connector
that complies
with MIL standard.
Terminal block box
(Terminal blocks)
Conforms to IP67 Conforms to IP67
Compatible network
•DeviceNet
•PROFIBUS-DP
I/O
Serial unit: EX240
Terminals are concentrated
in compact clusters within
the terminal block box. SUP
port
EHX
1, 3
(P, R)
Cylinder
port
C3 (for ø3.2)
C4 (for ø4)
C6 (for ø6)
M5 (M5 thread)
N1 (ø1/8")
N3 (ø5/32")
N7 (ø1/4")
C4 (for ø4)
C6 (for ø6)
C8 (for ø8)
N3 (ø5/32")
N7 (ø1/4")
N9 (ø5/16")
C8 (for ø8)
C10 (for ø10)
C12 (for ø12)
N7 (ø1/4")
N9 (ø5/16")
N11 (ø3/8")
Rc 1/4
Rc 3/8
Rc 1/4
(bottom ported)
(NPT, NPTF, G)
2, 4
(A, B)
C8 (for ø8)
N9 (ø5/16")
C10 (for ø10)
N11 (ø3/8")
<SUP port>
Rc 1/2
(NPT, NPTF, G)
<EXH port>
Rc 3/4
(NPT, NPTF, G)
—
—



—


—



25-pin 26-pin
20-pin
( )

Conforms to IP67
TD0 Terminal block box kit 1 to 10 stations
(20 stations)
1
Plug-in Unit
Series VQC1000/2000
Base-Mounted Type
How to Order Manifolds
VV5QC 1 108 C6
1
2VQC1000
VQC2000
Series
FD1
1Plug-in unit
Manifold type
Stations
VV5QC 1 108 C6
B
SDQ
Options
Input block COM
(Indicate for I/O unit only)
SI unit COM
Kit designation/Electrical entry/Cable length
Number of input blocks
(Indicate for I/O unit only)
Input block type
(Indicate for I/O unit only)
Cylinder port size
Refer to manifold specification sheet on pages 23 to 26
for detailed information on models.
S
F P T
T
Kit
(Decentralized wiring type serial transmission kit)
Kit
(Terminal block box kit)
SD0
SDA1
SDA2
Serial kit without SI unit
Serial kit for Remote I/O
Serial kit for DeviceNet/PROFIBUS-DP
1 to 8 stations
(16 stations)
Serial unit: EX500
SKit
(I/O serial transmission kit)
SD0
SDQ
SDN
Serial kit without SI unit
Serial kit for DeviceNet
Serial kit for PROFIBUS-DP
1 to 12 stations
(24 stations)
Serial unit: EX250
Kit
//
SKit
PD0
PD1
PD2
PD3
PDC
PKit
(Flat ribbon cable kit)
FD0
FD1
FD2
FD3
1 to 12 stations
(24 stations)
FKit
(D-sub connector kit)
D-sub connector kit (25P) without cable
D-sub connector kit (25P) with 1.5m cable
D-sub connector kit (25P) with 3.0m cable
D-sub connector kit (25P) with 5.0m cable
1 to 12 stations
(24 stations)
1 to 9 stations
(18 stations)
Flat ribbon cable kit (26P) without cable
Flat ribbon cable kit (26P) with 1.5m cable
Flat ribbon cable kit (26P) with 3.0m cable
Flat ribbon cable kit (26P) with 5.0m cable
Flat ribbon cable kit (20P) without cable
B
Note) A separate gateway unit and communication cable are required.
25-pin 26-pin
20-pin Conforms to IP40
Conforms to IP67
Conforms to IP67
Conforms to IP40
⋅⋅⋅⋅⋅⋅
⋅⋅⋅⋅⋅⋅

2
How to Order Valves
Manifold Options
1
2VQC1000
VQC2000
Series
Type of actuation
VQC 1 1 0 5
Coil voltage
Manual override
Seal type
Function
Light/Surge voltage suppressor
Note 1) For metal seal type only.
Note 2) When specifying more than
one option, enter symbols in
alphabetical order.
2-position single
2-position double (metal)
2-position double (rubber)
3-position closed center
3-position exhaust center
3-position pressure center
14-position dual 3-port valve
(A)
4-position dual 3-port valve
(B)
4-position dual 3-port valve
(C)
A
B
C
2
3
4
5
Metal seal
Rubber seal
Note) Not applicable to S Kit.
0
1
With
Without Note)
Nil
E
Standard type (1W)
High voltage type (1.0MPa)
Negative COM
External pilot
Low-wattage type (0.5W)
Nil
K
N
R
Y
24VDC
12VDC
5
6
Nil: Non-locking
push type
(Slotted)
B: Locking type
(Slotted)
C: Locking type
(Manual)
SUP block plate
VVQ1000-16A
VVQ2000-16A
Blanking plug
KQ2P-
VVQC1000-19A- -
D
SC3
C4
C6
M5
EXH block plate assembly
Back pressure check valve
Assembly [-B]
VVQ1000-18A, VVQ2000-18A
Name plate [-N]
VVQ1000-N-Stations (1 to max. no. of stations)
VVQ2000-N-Stations (1 to max. no. of stations)
Direct EXH outlet with
built-in silencer [-S]
AB
PEBEA
AB
EAPEB
AB
P
EA EB
AB
EBPEA
1
53
42
N.C. N.C.
1
53
42
N.O. N.O.
1
53
42
N.C. N.O.
AB
PEA EB
AB
PEA EB
Blanking plate assembly
VVQ1000-10A-1
VVQ2000-10A-1
Perfect block
VVQ1000-FPG-
VVQ2000-FPG-
Dual flow fitting assembly
VVQ1000-52A-C8
VVQ2000-52A-C10
Blanking plate with connector
VVQ1000-1C-
(VQC1000 only)
Electrical wiring
specifications [-K]
Individual SUP spacer
VVQ1000-P-1-C6
VVQ2000-P-1-C8
Elbow fitting assembly
VVQ1000-F-L
VVQ2000-F-L
Port plug
VVQ0000-58A (For VQC1000)
VVQ1000-58A (For VQC2000)
Individual EXH spacer
VVQ1000-R-1-C6
VVQ2000-R-1-C8 EXH block plate
VVQ2000-19A
DIN rail mounting bracket [-D]
VVQ1000-57A
VVQ2000-57A
Silencer (EXH port)
AN200-KM8 (For VQC1000)
AN200-KM10 (For VQC2000)
D-sub connector
Connector terminal no.
Terminal no.
Station 1
Station 2
Station 3
Station 4
Station 5
Station 6
Station 7
Station 8
SOL. A
SOL. A
SOL. A
SOL. A
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
COM
1
14
2
15
3
16
4
17
5
18
6
19
13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Standard manifolds are for double
wiring, but mixed wiring (single
and double wiring) can be speci-
fied as options.
0
Note)
Note)
Note)
Note 1)
Note) For rubber seal type only.
CYL
to
port
C6 (SUP port)
ø6 One-touch fitting
C6 (EXH port)
ø6 One-touch fitting
123459
8
7
6
Exhaust port
(-S)
(-T)
(-S)
(-T)
Conforms to IP40
Conforms to IP40
VQC1000/2000 Base-Mounted Type Plug-in Unit
Conforms to IP40

TD0 Terminal block box kit 1 to 10 stations (16 stations)
3
Plug-in Unit
Series VQC4000
Base-Mounted Type
How to Order Manifolds
VV5QC 4 108 02
4VQC4000
Series
TD0
1Plug-in unit
Manifold type
Stations
VV5QC 4 116 03 SDQW
Options
Input block COM
(Indicate for I/O unit only)
SI unit COM
Kit designation/Electrical entry
Number of input blocks
(Indicate for I/O unit only)
Cylinder port size Refer to manifold specification sheet on pages 27
and 28 for detailed information on models.
S
T
T
Kit
(I/O serial transmission kit)
Kit
(Terminal block box kit)
SD0
SDQW
SDNW
Serial kit without SI unit
Serial kit for DeviceNet
Serial kit for PROFIBUS-DP 1 to 16 stations
Serial unit: EX240
Kit
SKit
Conforms to IP67
Conforms to IP67
⋅⋅⋅⋅⋅⋅
⋅⋅⋅⋅⋅⋅

VQC4000
Base-Mounted Type Plug-in Unit
4
How to Order Valves
Manifold Options
4VQC4000
Series
Type of actuation
VQC 4 1 0 5
Coil voltage
Manual override
Seal type
Function
Light/Surge voltage suppressor
Note) When specifying more than
one option, enter symbols in
alphabetical order.
2-position single
2-position double (metal)
2-position double (rubber)
3-position closed center
3-position exhaust center
3-position pressure center
3-position perfect
1
2
3
4
Metal seal
Rubber seal
5
6
0
1
With
Without light, with surge voltage supressor
Nil
E
Standard type (1W)
External pilot
Low wattage type (0.5W)
Nil
R
Y
5 24VDC
Nil: Non-locking
push type
(Slotted)
B: Locking type
(Slotted)
02
03
AB
PEBEA
AB
EAPEB
AB
P
EA EB
AB
EBPEA
AB
PEA EB
AB
PEA EB
Blanking plate assembly
VVQ4000-10A-1 Individual SUP spacer
VVQ4000-P-1- 02
03
Individual EXH spacer
VVQ4000-R-1- SUP/EXH block plate
VVQ4000-16A
Throttle valve spacer
VVQ4000-20A-1
Residual pressure release valve
perfect spacer
VVQ4000-25A-1 Note 1) SUP stop valve spacer
VVQ4000-37A-1 Interface regulator
ARBQ4000-00- -1
AB
EBPEA
A
B
P
Note1) Perfect spacers with residual pressure release valve cannot be combined with external pilot specifications.
<EXH block plate>
<SUP block plate>
LOCK
PUSH
0

5
Series
No. of
solenoids
VQC1000
Model Response time ms
Note 2)
Weight
g
Standard:
1W
Low
wattage
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Single
VQC1100
VQC1101
VQC1200
VQC1201
VQC1300
VQC1301
VQC1400
VQC1401
VQC1500
VQC1501
Double
Closed
center
Exhaust
center
Pressure
center
Dual
3-port valve
0.70
0.85
0.70
0.85
0.68
0.70
0.68
0.70
0.70
0.85
0.70
2.0
2.2
2.0
2.2
2.0
2.0
2.0
2.0
2.4
3.2
1.8
6.2
7.2
6.2
7.2
5.9
7.0
6.2
7.0
6.2
7.0
2.7
2.8
0.72
1.0
0.72
1.0
0.72
0.65
0.72
1.0
0.72
0.65
0.70
2.6
3.2
2.6
3.2
2.0
2.2
2.6
3.2
2.0
2.2
1.8
6.9
7.3
6.9
7.3
6.3
6.4
6.9
7.3
6.4
7.1
3.7
3.9
12 or less
15 or less
10 or less
15 or less
20 or less
25 or less
20 or less
25 or less
20 or less
25 or less
15 or less
20 or less
13 or less
20 or less
26 or less
33 or less
26 or less
33 or less
26 or less
33 or less
64
78
90
110
VQC2000
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Rubber seal
Single
VQC2100
VQC2101
VQC2200
VQC2201
VQC2300
VQC2301
VQC2400
VQC2401
VQC2500
VQC2501
VQC1 01
Double
Closed
center
Exhaust
center
Pressure
center
2-position3-position
22 or less
24 or less
15 or less
20 or less
29 or less
34 or less
29 or less
34 or less
29 or less
34 or less
25 or less 33 or less
29 or less
31 or less
20 or less
26 or less
38 or less
44 or less
38 or less
44 or less
38 or less
44 or less
VQC4000
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Metal seal
Rubber seal
Single
Perfect
VQC4100
VQC4101
VQC4200
VQC4201
VQC4300
VQC4301
VQC4400
VQC4401
VQC4500
VQC4501
VQC4600
VQC4601
Double
Closed
center
Exhaust
center
Pressure
center
2-position3-position
20 or less
25 or less
12 or less
15 or less
45 or less
50 or less
45 or less
50 or less
45 or less
50 or less
55 or less
62 or less
22 or less
27 or less
12 or less
15 or less
47 or less
52 or less
47 or less
52 or less
47 or less
52 or less
57 or less
64 or less
230
260
280
500
4-position dual 3-port valve (A)
4-position dual 3-port valve (B)
4-position dual 3-port valve (C)
1
53
42
N.C. N.C.
1
53
42
N.O. N.O.
1
53
42
N.C. N.O.
3-position perfect
(A)
4(B) 2
3
(R2)
1
(P)
5
(R1)
A
B
C
Dual
3-port valve
Rubber seal VQC2 01 34 or less 44 or less
A
B
C
Note 1) Values represented in this column are in the following conditions:
VQC1000: Cylinder port size C6 without a back pressure check valve
VQC2000: Cylinder port size C8 without a back pressure check valve
VQC4000: Cylinder port size Rc 3/8
Note 2) Values represented in this column are based on JISB8375-1981 (operating with clean air and a supply pressure
of 0.5MPa. Equipped with light and surge voltage suppressor. Values vary depending on the pressure as well as
the air quality.) Values for double types are when the switch is ON.
Symbols
2-position single
2-position double (metal)
2-position double (rubber)
3-position closed center
3-position exhaust center
3-position pressure center
(A)(
4 B) 2
1
(P)(R2)
5
(R1) 3
(A)
4(B) 2
1
(P)
5
(R1) 3 (R2)
(A)
4(B) 2
1
(P)
5
(R1) 3 (R2)
(A)
4(B) 2
1
(P)
5
(R1) 3 (R2)
(A)
4(B) 2
1
(P)
5
(R1) 3 (R2)
(A)
4 (B) 2
1
(P)
5
(R1) 3 (R2)
Models
4, 2→5, 3 (A, B→R1, R2)
1→4, 2 (P→A, B)
2-position
3-position
4-position
4-position
Series VQC
Base-Mounted Type
Plug-in Unit
Flow characteristics
0.15
0.20
0.15
0.20
0.15
0.20
0.15
0.20
0.15
0.20
0.20
0.15
0.28
0.15
0.28
0.15
0.28
0.15
0.28
0.17
0.28
0.28
0.19
0.43
0.19
0.43
0.23
0.34
0.18
0.38
0.18
0.38
––
––
0.16
0.21
0.16
0.21
0.16
0.16
0.16
0.16
0.16
0.21
0.16
0.46
0.55
0.46
0.55
0.46
0.49
0.46
0.49
0.57
0.80
0.46
1.5
2.1
1.5
2.1
1.5
1.9
1.5
1.9
1.9
1.9
––
––
0.25
0.30
0.25
0.30
0.25
0.42
0.25
0.30
0.25
0.42
0.20
0.15
0.30
0.15
0.30
0.18
0.31
0.15
0.30
0.18
0.31
0.28
0.17
0.38
0.17
0.38
0.18
0.42
0.17
0.38
0.18
0.38
––
––
0.18
0.25
0.18
0.25
0.18
0.18
0.18
0.25
0.18
0.18
0.16
0.60
0.80
0.60
0.80
0.46
0.60
0.60
0.80
0.46
0.60
0.46
1.7
2.0
1.7
2.0
1.6
1.9
1.7
2.0
1.6
2.0
––
––
C[dm3/(s•bar)]
bCv
C[dm3/(s•bar)]
bCv

( )
( )
( )
( )
S Kit
1 to 8 stations:
EX500
1 to 12 stations:
EX250
T Kit
1 to 10 stations
F and P Kits
1 to 12 stations
6
Standard Specifications
Manifold Specifications
Valve specifications
Electrical
specifications VQC1000/2000VQC4000
Single
Double
3-position
4-position
Single
Double
3-position
Valve Configuration
Fluid
Max. operating pressure
Max. operating pressure Note 3)
Min. operating
pressure
Proof pressure
Ambient and fluid temperature
Lubrication
Manual override
Impact resistance/Vibration resistance
Enclosure
Rated coil voltage
Allowable voltage fluctuation
Coil insulation type
Power consumption (Current) 24VDC
Metal seal
0.1MPa
0.1MPa
—
0.15MPa
0.15MPa
Air/Inert gas
0.7MPa (High pressure type: 1.0MPa) Note 4)
0.1MPa
1.0MPa (0.7MPa)
0.15MPa
1.5MPa
–10°to 50°C Note 1)
Not required
Push type/Locking type (tool required) optional
150/30 m/s²Note 2)
Dust proof (conforms to IP67)
24VDC
±10% of rated voltage
Equivalent to B type
1W DC (42mA), 0.5W DC (21mA)
Rubber seal
0.15MPa
0.2MPa
0.15MPa
0.2MPa
0.2MPa
Note 1) Use dry air to prevent condensation at low temperatures.
Note 2) Impact resistance: No malfunction resulted from the impact test using a drop impact tester. The test was
performed one time each in the axial and right angle directions of the main valve and armature, for both
energized and de-energized states.
Vibration resistance: No malfunction occurred in a one-sweep test between 8.3 and 2000Hz. Test was
performed in the axial and right angle directions of the main valve and armature for both energized and
de-energized states.
Note 3) Values in ( ) are for the low wattage (0.5W) specification.
Note 4) Metal seal type only.
Series
 F Kit: D-sub connector
 P Kit: Flat ribbon cable
 T Kit: Terminal block box
 S Kit: Serial transmission
 F Kit: D-sub connector
 P Kit: Flat ribbon cable
 T Kit: Terminal block box
 S Kit: Serial transmission
Base model
VQC1000 VV5QC11-
VQC2000 VV5QC21-
 T Kit: Terminal block box
 S Kit: Serial transmission
VQC4000 VV5QC41-
Connection type
Piping specifications Applicable
stations
Applicable
solenoid
valves
5-station
weight
(g)
Port
direction
Side
Port size Note 1)
1, 3 (P, R)
C8 (for ø8)
Options
Direct outlet
with built-in
silencer
2, 4 (A, B)
C3 (for ø3.2)
C4 (for ø4)
C6 (for ø6)
M5 (M5 threads)
C8 (for ø8)
C10 (for ø10)
C12 (for ø12)
Rc 1/4
Rc 3/8
P: Rc 1/2
R: Rc 3/4
Rc 1/4
628
(Single)
759
(Double, 3P)
VQC100-5
VQC101-5
Note 2)
Side
Side
Bottom
C10 (for ø10)
Options
Direct outlet
with built-in
silencer
C4 (for ø4)
C6 (for ø6)
C8 (for ø8)
1051
(Single)
1144
(Double, 3P)
4150
•S Kit
(without unit)
•Solenoid
weight is not
included.
VQC200-5
VQC201-5
VQC400-5
VQC401-5
Note 1) One-touch fittings in inch sizes are also available.
Note 2) An optional specification for special wiring is available to increase the maximum number of stations.
T Kit
1 to 10 stations
( )
S Kit
1 to 16 stations
Min. operating
pressure
VQC
Base-Mounted Type Plug-in Unit

EX500-GAB1-X1
Rockwell⋅Automation PLC
57.6Kbit/sec, 115.2Kbit/sec
230.4Kbit/sec
Gateway (GW) Unit
Input Block
Cables
Gateway type serial transmission system
•Since wiring is "prepackaged" into one multi-connector type cable, wiring work is not only made
easier, but much more accurate.
S Kit can be used by connecting to gateway unit.
S
7
Specifications
How to Order
Model
Applicable PLC
Communication protocol
Communication speed
Rated voltage
Current consumption
Number of inputs/outputs
Number of input/output
branches
Branch cable
Branch cable length
Communication connector
Power connector
Ambient operating
temperature and humidity
Enclosure
Applicable standard
Power supply voltage range
24VDC
200mA or less
Maximum 64 inputs/64 outputs
4 branches (16 inputs/16 outputs per branch)
8-core heavy-duty cable
5m or less (total extension 10m or less)
M12 connector (8-pin, socket)
M12 connector (5-pin, plug)
+5°to +45°C at 35% to 85% RH (no condensation)
IP65
UL, CSA, CE
EX500-GDN1
DeviceNet Release 2.0
125Kbit/sec, 250Kbit/sec
500Kbit/sec
EX500-GPR1
PROFIBUS-DP
9.6, 19.2, 93.75, 187.5, 500Kbit/sec
1.5, 3, 6, 12Mbit/sec
Input and control unit power supply:24VDC ±10%
Solenoid valve power supply: 24VDC +10%/–5% (with power drop warning at approx.20V)
∗ Communication cables and communication connectors are sold separately.
EX500 G DN
DN
PR
AB
Communication protocol
DeviceNet
PROFIBUS-DP
Remote I/O (RIO)
Nil
-X1
Applicable GW unit
DeviceNet
PROFIBUS-DP
Remote I/O (RIO)
1
How to Order Input Block
EX500 IE
Nil
-X1
Applicable GW unit
DeviceNet
PROFIBUS-DP
Remote I/O (RIO)
1
1
2
3
4
5
6
Block type
M8 connector, PNP specifications
M8 connector, NPN specifications
M12 connector, PNP specifications
M12 connector, NPN specifications
8-point integrated type, M8 connector, PNP specifications
8-point integrated type, M8 connector, NPN specifications
How to Order Input Manifold
EEX500 IB1
1
8
Stations
1 station
8 stations
Nil
-X1
Applicable GW unit
DeviceNet
PROFIBUS-DP
Remote I/O (RIO)
E8
⋅⋅⋅
⋅⋅⋅
E
T
M
Connector type
M8 connector
M12 connector
M8 and M12 mixed
Input unit specifications
Input block specifications
Applicable sensor
Sensor connector
Number of inputs
Rated voltage
Indication
Insulation
Sensor supply current
Current source type (PNP output)
or
Current sink type (NPN output)
M8 connector (3-pin) or M12 connector (4-pin)
2 inputs/8 inputs (M8 only)
24VDC
Green LED
None
Maximum 30mA/Sensor
How to Order Power Cable with Connector
EX500 AP S050
010
050
Cable length
1m
5m S
A
Connector specifications
Straight
Angle
How to Order Cable with M12 Connector
EX500 AC SSPS030
003
005
010
030
050
Cable length
0.3m
0.5m
1m
3m
5m
Connector specifications
SSPS
SAPA
Socket side: Straight
Plug side: Straight
Socket side: Angle
Plug side: Angle
Input block specifications
Connection block
Communication connector
Number of connection blocks
Block supply voltage
Block supply current
Current consumption
Short circuit protection
Current source type input block (PNP input block)
or
Current sink type input block (NPN input block)
Operates at 1A Typ. (power supply cut)
GW unit reset by turning power OFF and back ON.
M12 connector (8-pin, plug)
Maximum 8 blocks
24VDC
0.65A maximum
100mA or less (at rated voltage)
∗ With waterproof cap
23
4
5
6
71
817
6
5
4
32
8
Socket connector
pin arrangement Plug connector
pin arrangement
Terminal no. Cable
core wire colors
1 White
2 Brown
3 Green
4 Yellow
5 Gray
6 Pink
7 Blue
1
3
5
78 Shield
2
4
6
8
Connections
2
43
5
Socket connector
pin arrangement
11
23
45
White: 24VDC +10%/-5% (solenoid valve power supply)
Black: 24VDC ±10% (input and control power supply)
Brown: 0V (solenoid valve power supply)
Blue: 0V (input and control power supply)
Gray: PE
Terminal no. Cable
core wire colors
Connections
EX500
Note) When ordering an input block manifold, enter the
Input manifold part no. + Input block part no.
together. The input block, end block and DIN rail
are included in the input manifold.
VQC1000/2000
Kit (Serial Transmission Kit) Decentralized Serial wiring Conforms to IP67

8
VV5QC11
S Kit (Serial Transmission Kit: EX500)
VV5QC21
S Kit
(Serial Transmission Kit: EX500)
n
LL1
L2
L3
L4
1
55.5
104
125
135.5
2
66
114.5
137.5
148
3
76.5
125
150
160.5
4
87
135.5
162.5
173
5
97.5
146
175
185.5
6
108
156.5
187.5
198
7
118.5
167
187.5
198
8
129
177.5
200
210.5
9
139.5
188
212.5
223
10
150
198.5
225
235.5
11
160.5
209
237.5
248
12
171
219.5
250
260.5
13
181.5
230
250
260.5
14
192
240.5
262.5
273
15
202.5
251
275
285.5
16
213
261.5
287.5
298
n
LL1
L2
L3
L4
1
73
118
137.5
148
2
89
134
150
160.5
3
105
150
175
185.5
4
121
166
187.5
198
5
137
182
200
210.5
6
153
198
212.5
223
7
169
214
237.5
248
8
185
230
250
260.5
9
201
246
262.5
273
10
217
262
287.5
298
11
233
278
300
310.5
12
249
294
312.5
323
13
265
310
337.5
348
14
281
326
350
360.5
15
297
342
362.5
373
16
313
358
375
385.5
Formulas: L1 = 10.5n + 45, L2 = 10.5n + 93.5 n: Stations (maximum 16 stations)
Formulas: L1 = 16n + 57, L2 = 16n + 102 n: Stations (maximum 16 stations)
M12
Female thread
(12) 13 65
2n-C3, C4, C6, M5
C3: ø3.2 One-touch fitting
C4: ø4 One-touch fitting
C6: ø6 One-touch fitting
M5: M5 thread
DIN rail clamp screw
2-C8
1(P) port
2-C8
3(R) port
M12
Male thread
0
1
9.5
25
40.5
20.5
34
P = 10.5
62.5
60
(12)
(7.5)
7.5
18.5
n1234567
Stations
D-side 8U-side
n1234567
Stations
D-side 8U-side
DIN rail clamp screw
2n-C4, C6, C8
C6: ø6 One-touch fitting
C8: ø8 One-touch fitting
C4: ø4 One-touch fitting
C10
3(R) port 2-C12
3(R) port
2-C12
1(P) port
C10
1(P) port
0
1
13.5 30
49.5
25
45
P = 16
(7.5) 10
(12) 25 60
76.5
13
76.5
(12)
Indicator light Manual override
Mounting hole for 4-M4
1.5
P = 10.5
1.5 L1 28
(5.5)
(35)
66
75
93.5
37.5
21
SI UNIT
Series
EX 500
42.5 L2
(L3)
(L4)
7
Approx. 9
Approx. 2
Indicator light
Manual override
Mounting hole for 4-M5
11 38.5
P = 16
34.5 L1
(L3)
(L4)
(5.5)
(35)
80
Approx. 5.5
105.5
Approx. 10.5
(46.5) 127
Approx. 3.5
38.5
SI UNIT
Series
EX500
L2
VQC1000/2000
Base-Mounted Type Plug-in Unit

Compatible network DeviceNet/PROFIBUS-DP
DeviceNet/PROFIBUS compatible SI unit
As a DeviceNet/PROFIBUS slave unit, this kit is capable of solenoid valve
ON and OFF control up to 32 points.
Furthermore, by connecting an input block, a maximum 32 sensor signal
inputs are possible.
Input block
This expansion block connects to the SI unit and allows for sensor input to
the auto switches.
Each input block can receive input from up to two or four sensors, and the
common can be matched to the sensor by an NPN/PNP selector switch.
Input connectors are available in both M8 and M12 types.
VQC1000/2000
Kit (Serial Transmission Kit) for I/O
SConforms to IP67
9
2
1
3
4
5
BUS
PWR
0
1
R
P
12
X
3
1
0
1
0
1
2
3
0
1
2
3
1
4
2
3
5
2
1
3
4
5
2
1
3
4
5
4
31
 Power connector: M12, 5 pins
(Boss configuration differs from plug and communication connector.)
Example of corresponding cable assemblies with connector:
Hans Turck FmbH & Co. KG SAKW4.5T-2.
 Input connector: M8, 3 pins (receptacle)
Cable side connector example: Franz Binder GesmbH
718,768 series
4-input block (EX250-IE3) No.
1
2
3
4
5
Description
SV24V
SV0V
SW24V
SW0V
E
Function
For solenoid valve +24V
For solenoid valve 0V
For sensor unit +24V
For sensor unit 0V
Ground
Description
PWR(V)
PWR
MOD/NET
ON when solenoid valve power supply is turned ON.
ON when DeviceNet circuit power supply input is turned ON.
OFF: Power supply off, off line, or when checking duplication of MAC_ID.
GREEN BLINKING: Waiting for connection (on line).
GREEN ON: Connection established (on line).
RED BLINKING: Connection time out (minor communication abnormality).
RED ON: MAC_ID duplication error, or BUSOFF error
(major communication abnormality).
Description
Function
ON when sensor power is turned ON.
ON when each sensor input goes ON.
 Input connector: M12, 5 pins (receptacle)
Cable side connector example: OMRON Corporation XS2G
2-input block (EX250-IE1)
4-input block (EX250-IE2)
No.
1
2∗
3
4
5
Description
SW+
N.C. (SIGNAL)
SW–
SIGNAL
E
Function
(+) Sensor power supply
Open
(–) Sensor power supply
Sensor input signal
Sensor ground
No.
1
3
4
Description
Function
(+) Sensor power supply
(–) Sensor power supply
Sensor input signal
 Communication connector DeviceNet: M12, 5 pins (for plug and DeviceNet only)
Example of corresponding cable assemblies with connector:
OMRON
Corporation DCA1-5CN05F1, Karl Lumberg GmbH & Co. KG RKT5-56
 Communication connector (PROFIBUS-DP): M12, 5 pins (plug)
No.
1
2
3
4
5
Description
Drain
V+
V–
CAN_H
CAN_L
Function
Drain/Shield
(+) Circuit power supply
(–) Circuit power supply
Signal H
Signal L
 SI unit (DeviceNet)
 SI unit (PROFIBUS-DP)
 Input block
Indicator Unit (LED) Description and Function
Connector Details
∗In the case of 4-input block unit (EX250-IE2), this is
the sensor input signal.
∗ Contact your SMC
representative for specifications
and handling precautions.
No.
1
2
3
4
5
Description Function
Description
PWR(V)
RUN
DIA
BF
ON when solenoid valve power supply is turned ON.
OFF when the power supply voltage is less than 19V.
ON when operating (SI unit power supply is ON).
ON when the self diagnosis device detects abnormality.
ON for BUS abnormality.
PWR
0
1
2
3
EX250
SETTINGS
1
PWR(V) PWR MOD/NET
0
EX250
2-input type
(EX250-IE1)
1
0
PWR
EX250
4-input type
(EX250-IE2/3)
24V
0V
IN
VP
R x D/T x D(N)
DGND
R x D/T x D(P)
SHIELD
Terminal +5V
Signal –N
GND terminal
Signal –P
Shield ground
PWR
0 to 1(3)
Function
Function
•The serial transmission system greatly reduces connection work, minimizes wiring, and saves space.

n1234567
Stations
D-side 8U-side
n1234567
Stations
D-side 8U-side
10
VV5QC11
S Kit
(Serial Transmission Kit: EX250)
VV5QC21
S Kit
(Serial Transmission Kit: EX250)
n
LL1
L2
L3
L4
1
55.5
178
200
210.5
2
66
188.5
212.5
223
3
76.5
199
225
235.5
4
87
209.5
237.5
248
5
97.5
220
250
260.5
6
108
230.5
250
260.5
7
118.5
241
262.5
273
8
129
251.5
275
285.5
9
139.5
262
287.5
298
10
150
272.5
300
310.2
11
160.5
283
312.5
323
12
171
293.5
325
335.5
13
181.5
304
325
335.5
14
192
314.5
337.5
348
15
202.5
325
350
360.5
16
213
335.5
362.5
373
17
223.5
346
375
385.5
18
234
356.5
387.5
398
19
244.5
367
387.5
398
20
255
377.5
400
410.5
21
265.5
388
412.5
423
22
276
398.5
425
435.5
23
286.5
409
437.5
448
24
297
419.5
450
448
Formulas: L1 = 10.5n + 45, L2 = 10.5n + 167.5 (for 1 input block. For each additional input block, add 21mm.) n: Stations (maximum 24 stations)
n
LL1
L2
L3
L4
1
73
192
212.5
223
2
89
208
237.5
248
3
105
224
250
260.5
4
121
240
262.5
273
5
137
256
275
285.5
6
153
272
287.5
298
7
169
288
312.5
323
8
185
304
325
335.5
9
201
320
337.5
348
10
217
336
362.5
373
11
233
352
375
385.5
12
249
368
387.5
398
13
265
384
400
410.5
14
281
400
425
435.5
15
297
416
437.5
448
16
313
432
450
460.5
17
329
448
462.5
473
18
345
464
487.5
498
19
361
480
500
510.5
20
377
496
512.5
523
21
393
512
537.5
548
22
409
528
550
560.5
23
425
544
562.5
573
24
441
560
587.5
598
Formulas: L1 = 16n + 57, L2 = 16n + 176 (for 1 input block. For each additional input block, add 21mm.) n: Stations (maximum 24 stations)
Manual override
Indicator light
Mounting hole
for 4-M5
11 38.5
P = 16
34.5 L1
(5.5)
(35)
80
105.5
Approx. 5.5
Approx. 10.5
127
Approx. 3.5
63
21 1075.5 L2
(46.5)
(L3)
(L4)
DIN rail clamp screw
2-C8
3(R) port
4-M8
2-M12 M3
0BUS
PWR
1
2
3
9.5
25
40.5
20.5
34
P = 10.5
62.5
60
(12)
(7.5)
7.5
18.5
Indicator light
Manual override
Mounting hole for 6-M4
SI unit
Input block
1.5
P = 10.5
1.5
L1 28
(5.5)
(35)
66
75
21 63
111 L2
5.5
93.5
37.5
(L3)
(L4)
Approx. 2
Approx. 4
(12) 13
65
2n-C3, C4, C6, M5
C3: ø3.2 One-touch fitting
C4: ø4 One-touch fitting
C6: ø6 One-touch fitting
M5: M5 thread
2n-C4, C6, C8
C4: ø4 One-touch fitting
C6: ø6 One-touch fitting
C8: ø8 One-touch fitting
2-C8
1(P) port
(12) 13 76.5
2-C12
3(R) port
2-C12
1(P) port
DIN rail clamp screw
C10
3(R) port
C10
1(P) port
13.5 30
49.5
25
45
P = 16
10
25
76.5
60
(12)
(7.5)
BUS
PWR
VQC1000/2000
Base-Mounted Type Plug-in Unit

Compatible network DeviceNet/PROFIBUS-DP
DeviceNet/PROFIBUS compatible SI unit
As a DeviceNet/PROFIBUS slave unit, this kit is capable of solenoid valve
ON and OFF control up to 32 points.
Furthermore, by connecting a maximum of 4 input blocks, up to 32 sensor
signal inputs are possible.
Input block
This expansion block connects to the SI unit and allows for sensor input to
the auto switches.
Each input block can receive input from up to 8 sensors, and the common
can be matched to the sensor by an NPN/PNP selector switch.
 SI unit (DeviceNet)  SI unit (PROFIBUS-DP)  Input block
Indicator Unit (LED) Descriptions and Functions
Connector Details
VQC4000
Kit (SerialTransmission Kit) for I/O Conforms to IP67
S
11
PWR
SI UNIT
PWR(V) MOD/NET
1
SETTINGS
0
1
2
4
3
5
5
4
3
1
2
1
2
3
4
5
•Input connector: M12, 5 pins (OMRON Corporation XS2F compatible) x 8 pcs.
Cable side connector example: OMRON Corporation XS2G
SW +
SIGNAL -n + 1
SW–
SIGNAL -n
PE
No.
1
2
3
4
5
Description
SW +
N.C.
SW –
SIGNAL
PE
Function
(+) Sensor power supply
Open∗
(–) Sensor power supply
Sensor input signal
Protective sensor ground
∗ The second pin of the connector with input no. 0, 2, 4, 6 (the connector
at the right side of the input block) is connected internally to the fourth
pin (sensor input no.) of the connector with input no. 1, 3, 5, 7. This
makes it possible to directly input two inputs that are combined together
by the common connector.
•Power connector: Franz Binder GesmbH Series723, 5 pins (72309-0115-80-05)
Cable side connector example: Franz Binder GesmbH 72309-0114-70-15, etc.
∗ DIN type 5 pins
•Communication connector (DeviceNet): M12, 5 pins (for DeviceNet only)
Example of corresponding cable assemblies with connector:
OMRON Corporation DCA1-5CN05F1, Karl Lumberg GmbH & Co. KG RKT5-56.
No.
1
2
3
4
5
Description
SV24V
SV0V
PE
SW24V
SW0V
Function
For solenoid valve +24V
For solenoid valve 0V
Protective ground
For solenoid valve +24V
For solenoid valve 0V
No.
1
2
3
4
5
Description
Drain
V +
V –
CAN_H
CAN_L
Function
Drain/Shield
(+) Circuit power supply
(–) Circuit power supply
Signal H
Signal L
Compatible with DeviceNet specification Micro
Style connector.
•Communication connector (PROFIBUS-DP):
CONINVERS®RC-2RS1N12, 12 pins
Cable side connector example: Siemens AG 6ES5 760-2CB11
No.
1
2
4
6
9
12
Description
M5V
A
B
+5V
SHIELD
RTS
Function
GND Terminal
Signal –N
Signal –P
Terminal +5V
Shield ground
Optical fiber (reserve)
Input block SI unit (DeviceNet) SI unit (PROFIBUS-DP)
Input connector
Communication
connector
Power connector
1
2
3
4
5
1
2
3
4
5
Connector: Input no.0, 2, 4, 6 Input no. 1, 3, 5, 7
When IP65 or equivalent enclosures are required, install a waterproof
cover on the input connector that is not being used. Order waterproof
covers separately.
Example: OMRON Corporation XS2Z-12
Caution
Description
PWR(V)
PWR
MOD/NET
Function
ON when solenoid valve power supply is turned ON.
ON when DeviceNet circuit power supply input is turned ON.
OFF: Power supply off, off line, or when checking duplication of MAC_ID.
GREEN BLINKING:Waiting for connection (on line).
GREEN ON: Connection established (on line).
RED BLINKING: Connection time out (minor communication abnormality).
RED ON: MAC_ID duplication error, or BUSOFF error
(major communication abnormality).
Description Function
PWR(V)
RUN
DIA
BF
ON when solenoid valve power supply is turned ON.
OFF when the power supply voltage is less than 19V.
ON when operating (SI unit power supply is ON).
ON when self diagnosis device detects abnormality.
ON for BUS abnormality.
Description
PWR
0 to 7
Function
ON when sensor power is turned ON.
OFF when short circuit protection is working.
ON when each sensor input goes ON.
12
9
1
2
46
PWR(V) MOD/NETPWR
1
0
TMTM
FB
PS
SETTINGS
ADDRESS
H
DIA BF
L
PWR(V) RUN
FB
PS
0
2
4
6
1
3
5
7
PWR
•The serial transmission system greatly reduces connection work, minimizes wiring, and saves space.
•Pin no. 3, 5, 7, 8, 10 and 11 marked with "" are open.
∗ The connector configuration and the pin arrangement are
compatible with Siemens AG ET200C.

12
VV5QC41
S Kit (Serial Transmission Kit: EX240)
n
LL1
L2
1
131
266
2
156
291
3
181
316
4
206
341
5
231
366
6
256
391
7
281
416
8
306
441
9
331
466
10
356
491
11
381
516
12
406
541
13
431
566
14
456
591
15
481
616
16
506
641
Formulas: L1 = 25n + 106, L2 = 25n + 241 (for 1 input block. For each additional input block, add 54mm.) n: Stations (maximum 16 stations)
101
10 143
32 98.8
143 9
9163
14.5 (128.5)
54 P = 25
AB AB AB AB A A AB
65.5
L1
86.5
L2 (1 input block: 8 inputs)
Min.0 to Max. 4
unit
(0 to 216mm)
Indicator light
Manual override
Mounting hole for 2-M5, with input block only
Input block
SI unit
75.5
61.5
1.5
12 20.5
43.5
11.5
21.5
(6.5)
27
31
38.5
77.5
95.5
823
2-Rc 1/8
(External pilot port)
2-Rc 1/4, 3/8, C8, C10, C12
(2(B), 4(A) port)
2-Rc 1/8
(Pilot EXH port)
2-Rc 3/4
3(R) port
2-Rc 1/2
1(P) port
n1234567
Stations
D-side
8
U-side
VQC4000
Base-Mounted Type Plug-in Unit

F
13
Note) When using the negative COM specification, use valves for negative COM.
Cable assembly
Electrical wiring specifications
1(–) (+) Black None
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
COM
14 (–) (+) Yellow Black
Station 1
Station 2
Station 3
Station 4
Station 5
Station 6
Station 7
Station 8
Station 9
Station 10
Station 11
Station 12
2(–) (+) Brown None
15 (–) (+) Pink Black
3(–) (+) Red None
16 (–) (+) Blue White
4(–) (+) Orange None
17 (–) (+) Purple None
5(–) (+) Yellow None
18 (–) (+) Gray None
6(–) (+) Pink None
19 (–) (+) Orange Black
7(–) (+) Blue None
20 (–) (+) Red White
8(–) (+) Purple White
21 (–) (+) Brown White
9(–) (+) Gray Black
22 (–) (+) Pink Red
10 (–) (+) White Black
23 (–) (+) Gray Red
11 (–) (+) White Red
24 (–) (+) Black White
12 (–) (+) Yellow Red
25 (–) (+) White None
13 (+) (–) Orange Red
Polarity
Terminal
no. Lead wire
color Dot
marking
Positive
COM
spec.
Negative
COM
spec.
D-sub connector
Lead wire colors for
D-sub connector assemblies
(AXT100-DS25- )
As the standard electrical wiring specification
used is for 12 stations or less, double wiring
(connected to SOL. A and SOL. B) is used for
the internal wiring of each station regardless
of valve and option types.
Mixed single and double wiring are available
as options.
Refer to special wiring specifications (options)
below.
Mixed single and double wiring are available as
options. The maximum number of manifold stations
is determined by the number of solenoids. Count one
point for a single solenoid type and two points for a
double solenoid type. The total number of solenoids
(points) must not exceed 24.
015
030
050
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Connector terminal no.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
COM
(For 25P)
D-side
1 2 3⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅stations
AXT100-DS25- 015
030
050
Lead wire colors for
D-sub connector
cable assembly
terminal numbers
Terminal
no.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Lead
wire
color
Black
Brown
Red
Orange
Yellow
Pink
Blue
Purple
Gray
White
White
Yellow
Orange
Yellow
Pink
Blue
Purple
Gray
Orange
Red
Brown
Pink
Gray
Black
White
Dot
marking
None
None
None
None
None
None
None
White
Black
Black
Red
Red
Red
Black
Black
White
None
None
Black
White
White
Red
Red
White
None
D-sub connector cable assemblies (optional)
Electrical characteristics
Cable
length (L) Part no. Note
1.5m
3m
5m
AXT100-DS25-015
AXT100-DS25-030
AXT100-DS25-050
Cable
0.3mm²x 25 cores
Item
Characteristic
Conductor resistance
Ω/km, 20°C
Withstand pressure
V, 1 minute, AC
Insulation resistance
MΩ/km, 20°C
65 or less
1000
5 or more
Some connector manufacturers:
•Fujitsu, Ltd.
•Japan Aviation Electronics Industry, Ltd.
•J.S.T. Mfg. Co., Ltd.
•HIROSE ELECTRIC CO., LTD.
Cable
0.3mm²x 25 cores
O.D. ø1.4
Seal (length indication)
Connector DB-25SF-N
manufactured by
Japan Aviation
Electronics Industry, Ltd.
Socket side
Terminal no.
Approx. ø10
47.04
55
16 44
8(2.4)
L
1⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅13
14⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅25
Molded cover
2-M2.6 x 0.45
SMC
015
Special wiring specifications (options)
•Using our D-sub connector for electrical connections greatly reduces labor,
while it also minimizes wiring and saves space.
•We use a D-sub connector (25P) that conforms to MIL standards and is
therefore widely compatible with many standard commercial models.
•Top or side entry for the connector can be changed freely, allowing for
changes even after mounting, to meet any changing needs for space.
D-sub connector cable assemblies can be ordered with manifolds.
Refer to manifold ordering.
∗When using a standard commercial
connector, use a type 25P female connector
conforming to MIL-C-24308.
∗Cannot be used for transfer wiring.
Note) The minimum bending
radius for D-sub connector
cables is 20mm.
U-side
Note)
VQC1000/2000
Kit (D-sub Connector Kit) Conforms to IP40

14
VV5QC11
n
LL1
L2
L3
L4
1
55.5
112.5
137.5
148
2
66
123
150
160.5
3
76.5
133.5
162.5
173
4
87
144
175
185.5
5
97.5
154.5
175
185.5
6
108
165
187.5
198
7
118.5
175.5
200
210.5
8
129
186
212.5
223
9
139.5
196.5
225
235.5
10
150
207
237.5
248
11
160.5
217.5
237.5
248
12
171
228
250
260.5
13
181.5
238.5
262.5
273
14
192
249
275
285.5
15
202.5
259.5
287.5
298
16
213
270
300
310.5
17
223.5
280.5
300
310.5
18
234
291
312.5
323
19
244.5
301.5
325
335.5
20
255
312
337.5
348
21
265.5
322.5
350
360.5
22
276
333
362.5
373
23
286.5
343.5
375
385.5
24
297
354
375
385.5
Formulas: L1 = 10.5n + 45, L2 = 10.5n + 102 n: Stations (maximum 24 stations)
2n-C3, C4, C6, M5
C3: ø3.2 One-touch fitting
C4: ø4 One-touch fitting
C6: ø6 One-touch fitting
M5: M5 thread
2-C8
3(R) port
2-C8
1(P) port
DIN rail clamp screw
(7.5)
7.5
18.5
9.5 25
40.5
(12)
20.5
34
P = 10.5
3560
62.5
Manual override
Indicator light
Manual release for
switching connector direction
Mounting hole for 4-M4
1.5
P = 10.5
1.5
L1
L2
51
(L3)
(L4)
28
(5.5)
(35)
37.5 93.5
Approx. 2
66
75
n1234567
Stations
D-side 8U-side
n1234567
Stations
D-side 8U-side
VV5QC21
Manual override
Indicator light
Mounting hole for 4-M5
Release for switching connector direction
1
138.5
P = 16
34.5 L147 L2
(L3)
(L4)
(5.5)
(35)
80
105.5
Approx. 5.5 Approx. 10.5
(46.5)
127
Approx. 3.5
50.5
1
73
126.5
150
160.5
2
89
142.5
162.5
173
3
105
158.5
187.5
198
4
121
174.5
200
210.5
5
137
190.5
212.5
223
6
153
206.5
237.5
248
7
169
222.5
250
260.5
8
185
238.5
262.5
273
9
201
254.5
275
285.5
10
217
270.5
300
310.5
11
233
286.5
312.5
323
12
249
302.5
325
335.5
13
265
318.5
350
360.5
14
281
334.5
362.5
373
15
297
350.5
375
385.5
16
313
366.5
387.5
398
17
329
382.5
412.5
423
22
409
462.5
487.5
498
18
345
398.5
425
435.5
21
393
446.5
475
485.5
23
425
478.5
500
510.5
24
441
494.5
525
535.5
19
361
414.5
437.5
448
20
377
430.5
450
460.5
n
LL1
L2
L3
L4
Formulas: L1 = 16n + 57, L2 = 16n + 110.5 n: Stations (maximum 24 stations)
Applicable connector: D-sub connector (25P)
(Conforms to MIL-C-24308)
(12) 13
65
Applicable connector: D-sub connector (25P)
(Conforms to MIL-C-24308)
13
76.5
(12)
2n-C4, C6, C8
C4: ø4 One-touch fitting
C6: ø6 One-touch fitting
C8: ø8 One-touch fitting
2-C12
3(R) port
2-C12
1(P) port
DIN rail clamp screw
C10
3(R) port
C10
1(P) port
13.5 30
49.5
25
45
P = 16
(7.5)
10
(12)
25
3560
76.5
VQC1000/2000
Base-Mounted Type Plug-in Unit

VQC1000/2000
Kit (Flat Ribbon Cable Kit) Conforms to IP40
P
15
Cable assembly
Electrical wiring specifications
Mixed single and double wir-
ing are available as options.
The maximum number of
manifold stations is deter-
mined by the number of sol-
enoids. Count one point for a
single solenoid type and two
points for a double solenoid
type. The total number of
solenoids (points) must not
exceed 24.
D-side
1 2 3⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅stations
AXT100-FC - 1
2
3
20
26
Flat ribbon cable connector assemblies (optional)
Cable
length (L) Part no.
1.5m
3m
5m
26P
AXT100-FC26-1
AXT100-FC26-2
AXT100-FC26-3
20P
AXT100-FC20-1
AXT100-FC20-2
AXT100-FC20-3
Some connector manufacturers:
•HIROSE ELECTRIC CO., LTD.
•Sumitomo/3-M Limited
•Fujitsu, Ltd.
•Japan Aviation Electronics Industry, Ltd.
•J.S.T. Mfg. Co., Ltd.
•Oki Electric Cable Co., Ltd.
6
(15.6)
L
Terminal no.
Red
28AWG
30 (20P)
37.5 (26P)
26 2 25 1
Note) When using the negative COM specification, use valves for negative COM.
Flat ribbon cable connector
<26P> <20P>
Connector terminal number
26
24
22
20
18
16
14
12
10
8
6
4
2
25
23
21
19
17
15
13
11
9
7
5
3
1Triangle mark indicator position
Double wiring (connected to SOL. A
and SOL. B) is used for the internal
wiring of each station regardless of
valve and option types.
Mixed single and double wiring are
available as options.
Refer to special wiring specifica-
tions (options) below.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
COM
COM
Station 1
Station 2
Station 3
Station 4
Station 5
Station 6
Station 7
Station 8
Station 9
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
SOL. A
SOL. B
COM
COM
Station 1
Station 2
Station 3
Station 4
Station 5
Station 6
Station 7
Station 8
Station 9
Station 10
Station 11
Station 12
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(–)
(–)
Terminal
no.
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(–)
(+)
(+)
Polarity
Positive
COM
spec.
Negative
COM
spec.
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(+)
(–)
(–)
Positive
COM
spec.
Negative
COM
spec.
26
24
22
20
18
16
14
12
10
8
6
4
2
25
23
21
19
17
15
13
11
9
7
5
3
1
COM COM
(For 26P)
20
18
16
14
12
10
8
6
4
2
19
17
15
13
11
9
7
5
3
1
COM COM
(For 20P)
Special wiring specifications (options)
U-side
•Using our flat ribbon cable for electrical connections greatly reduces
labor, while it also minimizes wiring and saves space.
•We use flat ribbon cables whose connectors (26P and 20P) conform
to MIL standards, and are therefore widely compatible with many
standard commercial models.
•Top or side entry for the connector can be changed freely, allowing
for changes even after mounting, to meet any changing needs for
space.
Terminal
no.
Polarity
Type 26P flat ribbon cable connector assemblies can be ordered
with manifolds. Refer to manifold ordering.
∗When using a standard commercial connector, use a type 26P
connector conforming to MIL-C-83503 or a type 20P with strain relief.
∗Cannot be used for transfer wiring.
