SRC H-CRF250L-09-01-AL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-CRF250L-09-01-AL
Part Description: Engine Guard–HONDA CRF250 L
Applicable to Finished colour versions of Silver
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
Remove the Cover already installed in
the Motorbike. This will allow access to
the Mounting Holes for fitment of SRC
Engine Guard
Step 2:
Mounting of Rear End Bracket (3) Orient the
Rear End Bracket, as shown, and slip-in the
Long Bolt (Original Equipment –already
available in the Motorbike) through the
holes as shown, and secure the threads,
using the Hexagonal Nut (again Original
Equipment –already available in the
Motorbike) from the other side.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 3:
Mounting the Engine Guard
Orient the Engine Guard for
mounting it to the Rear End
Bracket, as shown.
Slip-in the Taper Ring –2 off and
M6 x 20 Screw (9) –2 off and
secure the threads using Nut M6
(8) –2 off, from the other side of
the Rear End Bracket, as shown.
Rear End Bracket in “As is mounted
condition”

Copyright By SRC
Design and Specification are subjected to change
Page 5
Step 4:
Mounting the Engine Guard from the
frontal end
Slip-in the Spacer (5) –2 off between
the mounting surface of the holes (as
shown in “Red”) and from the frontal
side of the Engine Guard, slip-in the
Taper Ring (4) –2 off and Screw M6 x
45 (6) –2 off and secure the threads
Step 5:
Ensure Orientation, Mounting
Symmetry of the Engine Guard
from the frontal side and
tighten the fasteners to torque
as specified in the BOM table
The Engine Guard “As is final
Mounted Condition”

Copyright By SRC
Design and Specification are subjected to change
Page 6
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
