Sunricher SR-2411-ZG-DIM-A User manual

+A1 DA
DALI OUTPUT
DA
ZigBee to DALI Controller
Prog.
A1-A2: 8-230V
-A2
IMP
ZigBee to DALI DT6 Controller
09.2411ZGDIM.04791
Function introduction
Important: Read All Instructions Prior to Installation
Input signal
Output
Power Supply
Current Consumption
Operating temperature
Relative humidity
Dimensions(LxWxH)
Radio frequency
Product Data
Rotary Switch to select
Group or Address
control to DALI circuit
DALI signal output8-230V PUSH switch input
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Safety & Warnings
Program key for factory
reset the controller LED indicator
ZigBee/Push
DALI signal
Powered by DALI Bus
70mA
0-40°C
8% to 80%
45.5x45x20.3mm
2.4GHz
• ZigBee to DALI DT6 Controller based on ZigBee 3.0
• Receives ZigBee signal and outputs DALI signal to DALI line, DALI Bus Powered
• Comply to DALI standard protocol IEC 62386-102, IEC 62386-207 and in compliance with DALI products from other
international incorporations
• ZigBee end device that supports Touchlink commissioning
• Supports zigbee green power and can learn to max. 20 zigbee green power remotes
• Can directly pair to a compatible ZigBee remote through Touchlink
• Compatible with universal ZigBee gateway products
• Supports self-forming zigbee network without coordinator
• Enables to add devices to the self-formed zigbee network
• Compatible with universal ZigBee dim remotes
• Can be controlled by universal 8V-230V input single wire PUSH switch
• Enable to select Group control or Address control to DALI line by a rotary switch
• Enable to control 1 DALI Group of devices or 1 DALI Address on DALI line
• Enable to control all devices on DALI line via broadcast
• Enable to select any DALI Group (0-15) or DALI Address (00-63) to control by rotary switches
• Each DALI line can install multiple controllers for multi control points
• Waterproof grade: IP20
Add.Group
1*(0~9) for setting
units position
10*(0~9) for setting
tens position
Rotary switches for setting DALI Group number (0-15) or
Address number (0-63) to be controlled, the number equals to
tens position plus units position
1. Select DALI Address/Group Control Mode:
1) A rotary switch is used to select Address/Group control mode.
2) When the rotary switch arrow is at Add. position, address control mode is selected.
3) When the rotary switch arrow is at Group position, group control mode is selected.
2. Select DALI Address to be Controlled:
1) When Address control mode is selected, use the two rotary switches for setting address number (00-64) to
select the DALI address (00-63) you would like to control, the number equals to tens position plus units
position.
2) Set the address number as 0, all DALI devices on the circuit will be controlled through broadcast.
3) Set the address number as X except 0 (01-64), control gear with DALI address X-1 will be controlled.
Note: if X is set as 64, control gears with DALI address 63 will be controlled by the controller.
3. Select DALI Group to be Controlled:
1) When Group control mode is selected, use the two rotary switches for setting group number to select the
DALI group (0-15 selectable) you would like to control, the number equals to tens position plus units position.
2) This DALI controller enables on/off and dimming commands to be sent to 1 Group of devices on the DALI
circuit.
3) When group number is set as 0, all DALI devices on the circuit will be controlled through broadcast.
4) When group number is set as X except 0 (1-15), the controller will control DALI Group X-1.
Note: Please first group all DALI control gears on the circuit by a master controller.
Please refer to the detailed Group setting table as follows:
4. This ZigBee device is a wireless receiver that communicates with a variety of ZigBee compatible
systems. This receiver receives and is controlled by wireless radio signals from the compatible ZigBee
system.
Group Number
Setting
DALI Group
Selected
0
Broadcast
1
0
2
1
3
2
4
3
5
4
6
5
7
6
8
7
9
8
10
9
11
10
12
11
13
12
14
13
15
14
Operation
Input Clusters
• 0x0000: Basic • 0x0003: Identify • 0x0004: Groups • 0x0005: Scenes
• 0x0006: On/off • 0x0008: Level Control • 0x0b05: Diagnostics
Output Clusters
• 0x0019: OTA
ZigBee Clusters the device supports are as follows:
x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8

Step 1: Remove the device from previous zigbee network if it has already been added to, otherwise pairing will
fail. Please refer to the part "Factory Reset Manually".
Step 2: From your ZigBee Controller or hub interface, choose to add lighting device and enter Pairing mode as
instructed by the controller.
Step 4: LED indicator will blink 5 times and then
stay solid on, then the device will appear in your
controller's menu and can be controlled through
controller or hub interface.
8. Factory Reset Manually
Step 2: LED indicator will blink 3 times to indicate successful reset.
Step 1: Short press “Prog.” key for 5 times continuously or re-power
on the DALI bus power supply 5 times continuously if the “Prog.” key
is not accessible.
Note: 1) If the device is already at factory default setting, there is no indication when factory reset again .
2) All configuration parameters will be reset after the device is reset or removed from the network.
DALI bus
AC Power
50/60Hz
Zigbee
Remote < 10cm
6. TouchLink to a Zigbee Remote
Step 2: Bring the remote or touch
panel within 10cm of the lighting
device.
Step 3: Set the remote or touch
panel into Touchlink
commissioning,
please refer to corresponding
remote or touch panel manual to
learn how.
Step 4: There shall be indication on the remote for successful link and
LED indicator will flash twice.
Note: 1) Directly TouchLink (both not added to a ZigBee network), each device can link with 1 remote.
2) TouchLink after both added to a ZigBee network, each device can link with max. 30 remotes.
3) For Hue Bridge & Amazon Echo Plus, add remote and device to network first then TouchLink.
4) After TouchLink, the device can be controlled by the linked remotes.
7. Removed from a Zigbee Network through Coordinator or Hub Interface
From your ZigBee controller or hub
interface, choose to delete or reset the
lighting device as instructed. The
connected light blinks 3 times to indicate
successful reset.
DALI bus
L N
DALI BUS PS
DA DA
DALI bus
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
5. Zigbee Network Pairing through Coordinator or Hub (Added to a Zigbee Network)
Step 3: power on the DALI bus power
supply, the device will be set into
network pairing mode (LED indicator
flashes twice slowly), the network
pairing mode will last until the device
is added to a zigbee network.
Step 1: Method 1: Short press “Prog” button (or re-power on the DALI bus power supply) 4 times to start
Touchlink commissioning immediately, 180S timeout, repeat the operation.
Method 2: If the device is already added to a network, it will be set into Touchlink commissioning immediately,
180S timeout. Once timeout, re-power on the DALI bus power supply to set it into touchlink commissioning
again.

10. Find and Bind Mode
Step 1: Short press “Prog.” button 3 times (Or re-power on DALI bus PS 3 times) to set
the device (initiator node) to start Find and Bind mode (LED indicator flashes slowly) to
find and bind target node, 180 seconds timeout, repeat the operation.
Zigbee
Remote
Step 2: Set the remote or touch
panel (target node) into find and
bind mode, and enable it
to find and bind initiator, please
refer to corresponding remote or
touch panel manual.
Step 3: There shall be indication
on the remote or touch panel that
it bind the device successfully
and can control it then.
Note: Make sure the device and remote already added to the same zigbee network.
DALI bus
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
11. Learning to a Zigbee Green Power Remote
Step 1: Short press “Prog.” button 4 times (Or re-power on DALI bus PS 4 times) to start
Learning mode (LED indicator flashes twice), 180 seconds timeout, repeat the operation.
Zigbee
Green Power
Remote
Step 2: Set the green power
remote into Learning mode,
please refer to its manual.
Step 3: LED indicator will flash twice to indicate successful
learning. Then the remote can control the device.
Note: Each device can learn to max. 20 zigbee green power remote.
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
12. Delete Learning to a Zigbee Green Power Remote
Step 1: Short press “Prog.” button 3 times (Or re-power on DALI bus PS 3 times) to start delete
Learning mode (LED indicator flashes slowly), 180 seconds timeout, repeat the operation.
Zigbee
Green Power
Remote
Step 2: Set the paired green
power remote into Learning
mode, please refer to its manual.
Step 3: LED indicator will flash 4 times to indicate successful deleting.
DALI bus
9. Factory Reset through a Zigbee Remote (Touch Reset)
Note: Make sure the device already added to a network, the remote added to the same one or not added to any
network.
Step 1: Re-power on DALI
bus power supply to start
TouchLink Commissioning
of the device, 180 seconds
timeout, repeat the
operation.
Step 4: There shall be indication on the remote and
LED indicator flashes 3 times for successful reset.
Step 2: Bring the remote or touch
panel within 10cm of the lighting
device.
Step 3: Set the remote or touch
panel into Touch Reset procedure
to reset the device, please refer to
corresponding remote or touch
panel manual to learn how.
Zigbee
Remote < 10cm
DALI bus
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
DALI bus
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8

(3)With Push LV
AC Input
L N
DALI bus
DALI Cont roller
123
4
GND
0-6 0 -9
DA DA
PUSH LV
Power Supply
Wiring Diagram
DALI bus
DALI Cont roller
123
4
0-6 0 -9
DA DA
DA
DA
DA
DA
DAL I DALI
V+
V-
V+
V-
12- 36VD C
INP UT
DA
DA
DA
DA
DAL I DALI
AC Input
PUSH
L N
DALI bus
DALI Cont roller
123
4
0-6 0 -9
DA DA
(2)With Push
DA
DA
DA
DA
DAL I DALI
V+
V-
V+
V-
12- 36VD C
INP UT
ZigBee
remote
(1)With ZigBee remote
45.00 mm
45.50 mm
20.3 mm
Product Dimension
+A1 DA
DALI OU TPUT
DA
ZigBee to DALI Controller
Prog.
A1-A2: 8-23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigBee to DALI Controller
Prog.
A1-A2: 8-23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
+A1 DA
DALI OU TPUT
DA
ZigBee to DALI Controller
Prog.
A1-A2: 8-23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
14. OTA
The device supports firmware updating through OTA, and will acquire new firmware from zigbee controller or
hub every 10 minutes automatically.
15. Push Dim
While connected with a push switch, click the button to switch on/off, press and hold down the button to
increase/decrease light intensity between 1% and 100%.
Note: 1) Each added device can link and be controlled by max. 30 added remotes.
2) Each added remote can link and control max. 30 added devices.
13. Setup a Zigbee Network & Add Other Devices to the Network (No Coordinator Required)
Step 1: Short press “Prog.” button 4 times (Or re-power on DALI bus PS 4 times) to enable the
device to setup a zigbee network (LED indicator flashes twice) to discover and add other
devices, 180 seconds timeout, repeat the operation.
Zigbee
Remote
Step 2: Set another device or remote or touch panel into network pairing mode and pair to the network, refer to
their manuals.
Step 3: Pair more devices and remotes to the network as you would like, refer to their manuals.
Step 4: Bind the added devices and remotes through Touchlink so that the devices can be controlled by the
remotes, refer to their manuals.
< 10cm
TouchLink
Zigbee Lighting Device
DALI bus
AC Power
50/60Hz
L N
DALI BUS PS
DA DA
+A1 DA
DALI OU TPUT
DA
ZigB ee to DALI Contro ller
Prog.
A1-A2: 8- 23 0V
-A2
IMP
Add.Group x1
x10
5
0
1
6
2
7
4
9
3
8
5
0
1
6
2
7
4
9
3
8
