Target 6-Cube User manual

>> assembly instructions
6-Cube
style dpci nish
1114 002-11-0837 Gray
58018 002-11-0615 White
58021 002-11-0587 Espresso
58036 002-11-1202 Mint
58046 002-11-1203 Teal

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your room
in no time. Good luck—though we’re condent you won’t need it.
tools needed
before you begin
1. Check for damaged or missing parts. Call 1-800-874-0008 to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.

3QUESTIONS? Just call 1-800-874-0008 for parts and service. For faster service, have the style number and DPCI number ready when calling.
introduction 2
hardware 4
parts list 5
safety precautions 6
helpful hints 7
installing L-bracket 8
assembly 9-18
table of contents

4
hardware
(H5) x 6
short dowel
(H1) x 18
assembly screw
#10 x 1-1/2 in. athead
(H2) x 18
screw cover
(H9) x 1
L-bracket
(H7) x 1
L-bracket screw
#10 x 1/2 in. athead
(H8) x 1
wall screw
#10 x 1-1/2 in.
(H3) x 2
hole plug
(H6) x 36
nail
(H4) x 4
long dowel

5
A
A
B
B
D
C
C
D
D
E
E
E
ITEM DESCRIPTION QUANTITY
A side panel 2
Btop/bottom panel 2
Chorizontal divider 2
D vertical divider 3
Eback panel 3

6
• This unit contains small parts which could be a choking hazard for small children. Children should be under adult supervision at all times or
serious injury could occur.
• Always unload unit prior to moving the unit. The weight of personal belongings can cause the unit to become unstable and either tip or collapse.
Serious bodily injury and/or damage to personal belongings may occur.
• Do not overload unit. If any shelf, top, or bottom of unit bows or bends greater than 1/2 in., it is overloaded. The shelf, top, or bottom could
collapse and cause serious bodily injury and/or damage to personal belongings.
• Do not climb or step on the unit. This is not a bench. The unit may become unstable and either tip or collapse. Serious bodily injury and/or
damage to personal belongings may occur.
• Do not use this unit as a television stand. Serious bodily injury and/or damage to personal belongings may occur.
• Do not mount or attach anything to the sides, rear or front of the unit as this can create a force which can cause the unit to tip. Serious bodily
injury and/or damage to personal belongings may occur.
• Do not hang this unit on the wall. The product structure is not designed for wall hanging. Serious bodily injury, damage to personal belongings,
and/or damage to the wall may occur.
• All units must be secured individually to wall stud using L-Bracket and Wall Screw (#10 x 1-1/2 in.) provided. If wall stud is not accessible,
consult your local hardware store for appropriate mounting hardware. Failure to do so may create an unsafe tipping hazard that could lead to
serious bodily injury and/or damage to personal belongings.
• We recommend you protect your work surface during assembly to prevent scratching or damage to table tops, wood oors, etc.
safety precautions
warning

7
We recommend you protect your work surface during assembly to prevent scratching or damage to table tops, wood oors, etc.
helpful hints
Unfinished edges are shaded in gray. It is important to understand how finished edges go together. Take a moment to lay out all
the wood pieces and note the finished and unfinished (raw wood) edges. Arrange pieces so all finished edges are facing the same
way. While assembling, take care to note in each diagram which way finished edges are facing. In general, all finished edges will
face forward and all finished sides (large area of piece) will face up when product is fully assembled and upright.
hand tighten screws
We recommend you hand-tighten screws. Use care not to overtighten if using power tools.
unfinished edgefinished edge

8
There are several "key points" to
L-bracket installation. Please review the
drawings and comments at right as well
as the assembly steps provided.
All units must be fastened to the wall.
Always mount L-bracket to a wall-stud.
installing L-bracket
short
end
long
end
wall
stud
Install short end against wall/wall
stud; long end against unit.
Do not install this unit ush against the
wall! This unit requires a gap of between
1/2 inch and 1 inch to install properly.
For more hidden hardware, secure L-bracket
under top panel. See step 10 for detailed
installation instructions.
Max.
1 in.
Min.
1/2 in.
wall
stud
top panel
wall
stud
Serious or fatal crushing injuries can occur
from furniture tip-over.
To help prevent tip-over:
- Install tip-over restraint provided.
- Unless specically designed to
accommodate, do not set TVs or other
heavy objects on top of this product.
- Never allow children to climb or hang on
drawers, doors, or shelves.
- Place heavy items on lower shelves and as
far back as possible.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove.
WARNING

9
1. Push two short dowels into holes of one xed shelf.
2. Install dowels only into one top/bottom panel (both top/bottom panels are the same.)
3. Top/bottom panels have three holes on one side with the middle holes going through to the other side.
4. Unnished edges are shaded in light gray.
B
step 1.
(H5) x 2
short dowel

10
1. Attach top panel to one side panel.
2. Make sure nished edges of unit are up.
A
B
finished edges up
step 2.
(H1) x 2
assembly screw
#10 x 1-1/2 in. athead

11
1. Attach vertical divider.
2. Push vertical divider onto dowels in xed shelf.
3. Make sure nished edges of unit are up.
4. From opposite side of xed shelf, secure vertical divider with a screw.
finished edges up
A
B
D
A
B
D
step 3.
(H1) x 1
assembly screw
#10 x 1-1/2 in. athead

12
1. Insert long dowels into vertical divider.
2. Attach horizontal divider down over dowels. Be sure to assemble with all nished edges to front.
3. Push horizontal divider down over dowels. (Holes in horizontal dividers go all the way through.)
4. Secure horizontal divider with two screws through side panel.
finished edge
A
D
A
D
C
step 4.
(H1) x 2
assembly screw
#10 x 1-1/2 in. athead
(H4) x 2
long dowel

13
1. Push vertical divider onto dowels of horizontal divider.
2. Insert long dowels into vertical divider.
3. Attach horizontal divider down over dowels. Be sure to assemble with all nished edges to the front.
4. Secure horiztonal divider with two screws through the side panel.
5. Push top vertical divider onto dowels of horizontal divider.
D
C
D
finished edge
step 5.
(H1) x 2
assembly screw
#10 x 1-1/2 in. athead
(H4) x 2
long dowel

14
1. Insert SHORT dowels into top vertical divider. Be sure to assemble with all nished edges to front.
2. Align holes in underside of top panel and place top panel into position.
3. Secure top panel with two screws through side panel.
4. Secure top vertical divider with one screw through top panel.
D
C
A
B
D
B
finished edge
step 6.
(H1) x 3
assembly screw
#10 x 1-1/2 in. athead
(H5) x 2
short dowel

15
1. Attach other side panel with provided screws.
2. Be sure to assemble with all nished edges to front.
finished edge
step 7.
(H1) x 8
assembly screw
#10 x 1-1/2 in. athead

16
1. Lay unit so nished (front) edges face down and unnished edges face up. (Unnished surfaces are shaded in gray.)
2. Push screw covers onto all screw heads.
3. Position the back panels in a staggered pattern as shown.
4. Nail the back panels into place through the holes provided, being careful not to angle the nail.
E
step 8.
(H2) x 18
screw cover
(H6) x 36
nail

17
1. Install dowels or hole plugs.
2. For single unit: Insert hole plugs into top holes.
3. For stacking units: Insert dowels into top holes.
step 9.
(H5) x2
short dowel
(H3) x 2
hole plug
when
stacking units
single unit

18
1. Align center of unit with wall stud. (All units MUST be fastened to the wall. When stacking units, the unit on the
bottom must be attached to the wall rst before setting another unit on top. Do not stack units more than 72 in. high.)
2. Place short end of L-bracket against wall/wall stud. Use 1-1/2 in. screw to secure L-bracket to wall.
3. Use 1/2 in. screw to secure L-bracket to top panel. For hidden hardware mount L-bracket through an open cube
which does not have a back panel.
step 10.
(H9) x 1
L-bracket
(H7) x 1
L-bracket screw
#10 x 1/2 in. athead
(H8) x 1
wall screw
#10 x 1-1/2 in.
wall
stud
top panel
top panel
wall
stud

19
weight capacity/care instructions
This unit has been designed for the weight
shown. Exceeding this recommended weight
could result in excessive "sagging" of the top
or shelves. Extreme overloading can cause
failure of the unit and possible injury.
Care Instructions:
Dust with a clean, lint-free dry cloth.
warning
15 lbs.
15 lbs.
35 lbs.
15 lbs.
15 lbs.
15 lbs.
15 lbs.
50 lbs.
15 lbs. 15 lbs.
15 lbs.
15 lbs.
15 lbs. 15 lbs.

© 2018 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
