Target Paulo TGELSDTBWH User manual

paulo
side table
assembly instructions
style # TGELSDTBWH (weathered white)
dpci # 249-16-9754
tcin # 53281502
style # TGELSDTBGY (weathered smoke)
dpci # 249-16-9755
tcin # 53281503
style # TGELSDTBBR (midtone)
dpci # 249-16-9756
tcin # 53281504
>>
© 2018 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Read through and review assembly steps.
4. Gather all tools prior to assembly.
tools needed

3
table of contents
introduction 2
hardware 4
parts list 5
how to use the cam lock system 6
assembly 7-13
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.

4
hardware
(H1) x 6
wooden dowel
(H2) x 10
cam bolt
(H3) x 10
cam
(H4) x 10
at head screw
(H5) x 4
short round head bolt
(H6) x 1
allen wrench
(H7) x 4
at head bolt
(H8) x 2
long round head bolt
(H9) x 1
handle
(H10) x 4
washer
(H11) x 2
long round head screw
(H12) x 2
short round head screw

5
exploded diagram
ITEM DESCRIPTION QUANTITY
A top panel 1
B left side frame 1
C right side frame 1
D shelf 1
E left side panel 1
F right side panel 1
G back panel 1
H bottom panel 1
I drawer face 1
J drawer front 1
K drawer left side 1
L drawer right side 1
M drawer back 1
N drawer bottom 1

how to use the cam lock system
1.
Screw cam bolt into panel
2.
Align cam bolt(s) with cross-bored
hole(s) and insert all the way until
panels are ush
3.
Push cam into panel - arrow feature
on cam top points to panel edge
4.
Rotate cam(s) clockwise 180° to
lock panels together
5.
Panels should be tight against each
other and connection should be rigid
6
6
4. 5.
1. 2. 3.

7
step 1: attach cam bolts to left side panel, right side panel, and shelf
(H2) x 10
cam bolt
1.1. Screw-In cam bolts must be screwed down ush in left side panel, right side panel, and shelf.
1.2. Refer to page 6 for instructions on how to use the cam lock system.
1.3. Do not over tighten bolts.

step 2: attach back panel to shelf and bottom panel
(H1) x 2
wooden dowel
(H3) x 2
cam bolt
(H4) x 2
at head
screw
2.1. Carefully tap small wooden dowels into place in back panel. Leave 1/2” of the dowels sticking out.
2.2. Align at head screws with pre-drilled holes to attach bottom panel to shelf. Do not over tighten screws.
2.3. Refer to page 6 for instructions on how to use the cam lock system.
2.4. Do not over tighten bolts.
8

step 3: attach left side panel and right side panel
(H1) x 4
wooden dowel
(H3) x 8
cam
3.1. Carefully tap small wooden dowels into place in left side panel and right side panel. Leave 1/2” of the dowels sticking out.
3.2. Refer to page 6 for instructions on how to use the cam lock system.
3.3. Do not over tighten bolts.
9

step 4: attach top panel, left side frame, and right side frame
(H5) x 4
short round
head bolt
(H6) x 1
allen wrench
(H7) x 4
at head bolt
(H10) x 4
washer
(H12) x 2
short round
head screw
4.1. Align at head bolts with pre-drilled holes to attach left side frame and right side frame to bottom panel. Do not over tighten bolts.
4.2. Align short round head screw with pre-drilled holes to attach left side frame and right side frame to back panel. Do not over tighten screws.
4.3. Align short round head bolts with pre-drilled holes to attach left side frame and right side frame to top panel. Do not over tighten bolts.
10
(H12)
(H7)

step 5: attach drawer left side to drawer front and drawer back
(H4) x 4
at head
screw
(H11) x 2
long round
head screw
5.1. Align long round head screws with pre-drilled holes to attach drawer face to drawer front. Do not over tighten screws.
5.2. Align at head screws with pre-drilled holes to attach left drawer side to drawer front and drawer back. Do not over tighten screws.
11
(H11)

12
step 6: attach drawer bottom and drawer right side
(H4) x 4
at head
screw
6.1. Slide drawer bottom into drawer back, drawer front, and drawer left side.
6.2. Align long round head screws with pre-drilled holes to attach drawer right side to drawer front. Do not over tighten screws.

step 7: attach drawer handle and install drawer
(H8) x 2
long round
head bolt
(H9) x 1
handle
7.1. Align long round head bolts with pre-drilled holes to attach handle to door. Do not over tighten bolts.
7.2. Align tracks on drawer box with tracks on left side panel and right side panel.
13
adjustable leg leveler

1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in
excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury.
2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed.
