UNIS Ducky Splash User manual

CEC version
Operation Manual
Distributed by: Amusements Worldwide
www.amusementsworldwide.com
Tel: [phone]
Serial Number: Date of installation:

Ducky Splash CEC Rev. 1.02
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual.
Failing to comply can cause severe accidents such as electric shock or
other serious injuries. All repairs must be performed to original
manufacturer specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
IMPORTANT SAFETY INSTRUCTIONS…………………………………………………………… 2
1. SPECIFICATIONS………………………………………………………………………………………4
2. PACKAGE CONTENTS..............................................................................................5
3. SET UP & INSTALLATION ........................................................................................6
4. HOW TO PLAY…………………………………………………………………………………………10
5. PARAMETER SETTINGS .............................................................................……….11
6. MAINTENANCE&INSPECTION…………………………………………………………………..17
7. OVERALL CONSTRUCTION………………………………………………………………………..21
8. GAME DECALS ………………………………………………………………………………………..37
9. DUCKY SPLASH IO CHART….................................................................................41
10.WIRING DIAGRAM………………………………………………………………………………….42
WARNING

Ducky Splash CEC Rev. 1.02
2
Thank you for purchasing Ducky splash. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and personnel in charge of product
operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and troubleshooting
guide. If the product fails to function properly, non-technical personnel should under no
circumstance attempt to service the machine. Contact your distributor or manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and understand these instructions
before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may cause fire,
electric shock or personal injury. Unplug the game from the outlet when not in use, when
moving from one location to another, and before cleaning and servicing.
Explanations which require special attention are indicated by signs of warning. Depending on
the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock. Do not touch.
Use the following safety guidelines to help ensure your own personal safety
and to help protect your equipment and surrounding environment from
potential damage.

Ducky Splash CEC Rev. 1.02
3
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury and/or machine
malfunctioning:
•Places subject to rain/moisture, or places subject to high humidity.
•Places subject to direct sunlight, or places subject to extremely hot or cold temperatures
to ensure that it is used within the specified operating range.
•Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
•On unstable or sloped surfaces. The machine may topple or cause unforeseen accidents.
•Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL RISKS.
Note: The contents of this manual may be updated without notice

Ducky Splash CEC Rev. 1.02
4
1. SPECIFICATIONS
Rated power supply：110V 50/60Hz
Min. Power consumption: 120W
Max. Power consumption：630W
Dimension：W760×D394×H823 (inches)
Weight：approximately474 (lb)
Note: After turning off the game, please wait at least 1 minute before restarting again.
Note: Game parameters are subject to change without notice.

Ducky Splash CEC Rev. 1.02
5
2. PACKAGE CONTENT
2.1 Open the package and make sure all the items are included:
1 x Body Assembly
Following accessories
No. Part No. Name Qty
1 D114-142-000
AC Power cord
1
2 D114-143-000
Fuse 1
3 D114-144-000
Manual 1
4 D114-145-000
Key 1
6 D114-146-000
Bucket 1
7 D114-147-000
Ducky 10
(Put four ducks to each side when playing the game.)
If any items are found to be missing, please contact your sales representative for
help immediately.
Warranty: Universal Space provides 90 days warranty for all electrical and
mechanical components, when used under normal operating conditions. Any
modification or abuse of these items immediately voids the warranty. Graphic and
consumable items are exempt from any warranty.
NOTE: Part models are subject to change without notice.
Note: Part models are subject to change without notice.

Ducky Splash CEC Rev. 1.02
6
3. SET UP & INSTALLATION
3.1 Play Zone
3.2 Installation Area
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 11.81 inches
Play area: 39.37 inches
安全遮板
3.3 Do not be placed in these places
This product is an indoor game machine. Do not install outdoors.
△
!Warning
zPlaces subject to rain/moisture, or places subject to high humidity.
zPlaces subject to extremely hot temperatures.
zPlease subject to dangerous.
zPlease subject to slippery and unstable surface.
zThe place where shake seriously
△
!Warning
39.37 inches 11.81 inches
11.81inches

Ducky Splash CEC Rev. 1.02
7
3.4 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause a malfunction.
To fix the game, adjust the Leveler down until it touches the floor, lifting the casters off the
ground by 5mm. Repeat the same for all levelers.
3.5 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position so the casters touch
the ground.
Make sure the machine is level with the ground and all the adjustable legs
should stick to the floor closely.
NOTICE
Leveler Caster
Move
Leveler Caster
About 5mm
Move Fix

Ducky Splash CEC Rev. 1.02
8
3.6 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to an electrical
outlet to ensure that the required voltage and frequency match the available power source.
Please refer the label of the machine.
Do not plug the equipment power cables into an electrical outlet if the power cable is
damaged.
Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
Connect the grounding conductor to the earth terminal (GND):
Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
zTurn off the power switch and unplug the connector wire before moving；
zReplace a new caster if it broke；
zFor longer distance transport, package the game properly to prevent damages;
zRandom movement ，overturn、transportation might damage the machine；
zMovement ，overturn ，transportation should according to manufacturer’s
requirements.
△
!NOTICE
Power Plug
Power socket
Power
Cable
Power Plug
Inlet box

Ducky Splash CEC Rev. 1.02
9
△
!WARNING
¾Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet does
not sit on the power cord as this could damage the cord and become hazardous
¾To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the cord.
¾To prevent electric shock, do not touch the power plug when hand is wet.
¾Ensure that nothing rests on the power cord and that it is not located where it can be
stepped on or tripped over.
¾To use the correct voltage and fuse.
3.7 FIRST TIME SET-UP
Step 1:
After properly setting up the machine on a flat surface, slowly add water into the playfield
directly until the water reaches the indicated waterline (See section 7.5 “Adding and Draining
Water”)
Step 2:
Take out 12 rubber ducks from the package included and place 6 ducks on each side of the
playfield.
Step 3:
Switch on the game and test run both sides to make sure everything works perfectly.
Always take out the rubber ducks prior to servicing/maintaining the playfield in
order to facilitate service work and to prevent unnecessary damages to the ducks.
△
!Notice

Ducky Splash CEC Rev. 1.02
10
4. HOW TO PLAY
Ducky Splash is a 1- 2 player water shooting game for
children and the whole family!
The object of the game is to use the Dino water guns to shoot
rubber ducks into the 2 tunnel entrances.
Players must shoot as many ducks as possible into their own
entrance before the time runs out!
Single Player Mode：
•Pick a side (left side OR right side),
and insert coin(s) to start.
•Water gun is activated
and the timer starts counting down.
•Aim and shoot ducks into the entrance ON YOUR SIDE
to earn points
(Ducks entering the wrong entrance will not give points)
•Once time is up, tickets
will be awarded based on the final score.
2- Player Match Mode
•Insert coin(s) at the same time to begin together.
•Both water guns are activated and the timer starts counting down.
•Shoot ducks into entrance of each corresponding side to earn points
(Shooting ducks into the opponent’s entrance will give them extra points!)
•Once time is up, winner receives all the tickets. (Loser will be awarded mercy tickets.)
Note: Maximum memory score for each water gun is 999 when there is no ticket payout.

Ducky Splash CEC Rev. 1.02
11
5. Parameter Settings
5.1 Please refer to the I/O chart and schematics included with the game.
5.2 To adjust DIP settings, please refer to the I/O chart. The initial settings are in CAPITAL
LETTERS.
5.3 Main Board:
Test mode:
Press “test” button get into the test menu.
LED Display
Left score LED<1>3-1/Left time LED<1>6-5
Right score LED<2>3-1/Right time LED<2>6-5
(Flashing): Left credit LED<1>6-5 Right credit LED<2>6-5

Ducky Splash CEC Rev. 1.02
12
Testing - Options
LED displays segment scan, digit scan and shows <1, 2, 3, 4, 5, 6, 7, 8> and <87654321> - To
check LED display.
Press TEST button again and LED displays 1 - shows the LED 1and LED2 of 1# in DIP SW.
Press TEST button again and LED displays 2 - shows the number of on-off SW
Press TEST button again and LED displays 3. Press IN1-40 to test sound/music.
Press TEST button and LED displays 4 - Corresponding lighting output.
Press TEST button again and LED displays 5, - Lighting moves slowly.
Error Codes
The following error codes will display if there is an error in the input signal:
E.01 Ticket.Reseterror
E.83/E.84 Coin Mech signal error
E.04 Left entrance sensor error
E.07 Right entrance sensor error
5.4 DIP adjust（Default Setting）
The above technical instructions would change without notice. The parameter
setting of the IO chart subject to the game only.
Notice

Ducky Splash CEC Rev. 1.02
13
5.5 Parameter Settings
DIP Adjust 1 (SW1)
(1) Coin(s) per game
Item Content DIP (SW1) Note
1 2
Coin(s) per
game
1 on on
2 off on
3 on off
4 off off
(2) Play time (s)
Item Content DIP (SW1) Note
3 4 5
Play time (s)
30 on on on
35 off on on
40 on off on
45 off off on
50 on on off
60 off off on
75 on off off
90 off off off
(3) Mercy Tickets
Item Content DIP (SW1) Note
6 7
Mercy Tickets
0 on on
1 off on
2 on off
3 off off
(4) Score memory
Item Content DIP (SW1) Note
8
Score memory YES on
NO off

Ducky Splash CEC Rev. 1.02
14
DIP 2 (SW2)
(5) Payout (Score per ticket)
Item Content
DIP (SW2)
Score 1-150 151-300 301-999
1 2 3 4
Payout
(Score
per
ticket)
1# on on on on 1# 0 tickets 0 tickets 0 tickets
2# Off ON ON ON 2# 1 tickets 2 tickets 3 tickets
3# on off on on 3# 2 tickets 4 tickets 6 tickets
4# off off on on 4# 5 tickets 8 tickets 12 tickets
5# on on off on 5# 3 tickets 3 tickets 3 tickets
6# off on off on 6# 4 tickets 4 tickets 4 tickets
7# on off off on 7# 5 tickets 5 tickets 5 tickets
8# off off off on 8# 8 tickets 12 tickets 18 tickets
9# on on on off 9# 10 tickets
10 tickets 10 tickets
10# off on on off 10# 15 tickets
15 tickets 15 tickets
11# on off on off 11# 20 tickets
20 tickets 20 tickets
(6) Hole Score
Item Content DIP (SW2) Note
4 5 6
Hole Score
1 on on on
2 off on on
5 off
off on
10 off off on
20 on on off
25 off on off
30 on off off
(7) Demo music
Item Content DIP (SW2) Note
8
Demo music YES on
NO off

Ducky Splash CEC Rev. 1.02
15
5.6 Input & Output Parts：
Inputpart: Outputpart:
INPUT CONTENT
J9-1 Ticket reset
J9-2
J9-3
J9-4 Left sensor
J9-5
J9-6
J9-7 Right sensor
J9-8 Left service
button
J9-9 Right service
button
Volume pot
interface Coin device interface Ticket machine
interface Speaker interface
J20-1 POT_L 1 J19-1
L_ Coin lock J21-1 L_ Ticket drive
J27-1 Speaker _L+
J20-2 POT_L ○
2 J19-2
L_ Coin signal J21-2 L_ Ticket
signal J27-2 Speaker _L -
J20
-
3 POT_R ○
1 J19
-
3
GND
J
21
-
3
12V
J28
-
1 Speaker _R +
J20-4 POT_R ○
2 J19-4
R_ Coin lock J21-4 GND J28-2 Speaker _R -
J20-5 POT_L ○
3 J19-5
R_ Coin signal
J21-5 R_ Ticket drive
Counter
J20-6 POT_R ○
3 J19-6
12V J21-6
R_ Ticket
signal J8-1 +12V
J21-712V
J8-2 +12V
J21-8GND
J8-3 Coin counter
J8-4 Ticket counter
OUTPUT CONTENT OUTPUT
CONTENT OUTPUT
CONTENT
J23-9 L_ entrance J24-17 Left gun J4-1
J23-10 R_ entrance
J24-18 Left gun J4-2
J23-11 L_TIK. light J24-19 Right gun J4-3 LAT
J23-12 R_TIK. light J24-20 Right gun J4-4 CLOCK
J23-13 J24-21
Back
-
water
valve J4-5 DATA
J23-14 J24-22
Back
-
water
valve J4-6
J23-15 J24-23 Water pump J4-7
J23-16 J24-24 J4-8

Ducky Splash CEC Rev. 1.02
16
6. MAINTENANCE & INSPECTION
6.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for
safe machine operation:
1. Try to run the game before operation each day.
2. Conduct monthly routine checks of game components ensure good working
condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to be kept running
smoothly
★Installation and Test
¾Firstly check the assembling instructions and assemble the game.
¾Secondly, adjust the leveler of the game on even ground.
¾After installation, plug in. check the game operation. If there is a problem, stop
the game and please check the trouble shooting section of this manual.
★Game maintenance
¾Try to run the game before operation each day.
¾Use soft cotton to clean the machine when it accumulated dust.
¾Conduct monthly routine checks of game components ensure good working
condition
¾Check the machine regularly for dust and clean when necessary.。
★Clean up
¾Cabinet
Use soft brush clean up the dust on the surface, and use a soft cloth wipe it off.
¾Cooling fans and air-vents
Cooling fan is influence in machine operation, because the clean environment and
smooth air circulation is very important. Please ensure that enough thermal
dissipation space for cooling fan, clean and replace fans regularly.
6.2 Regular Cleaning:
It is recommended that the water filter be cleaned once a month and changed every 6
months. If the game is placed in an area exposed to high level of dust, increase cleaning
frequency.
6.3 Pump Assembly Setting:
•Pressure valve should be kept in a half open state. Adjusts the gun pressure.
•Pressure meter default setting is 0.1.
•Drain Valve should be closed during normal times and only opened for draining or to
change water.
•Drainage button

Ducky Splash CEC Rev. 1.02
17
6.4 Adding and Draining Water:
Draining Water
NOTE: Always empty water in the tank and in the pump before transporting
Adding Water
Loosen the two side-screws, which will automatically open up the front protection net. Slowly
pour water down into the playfield directly until the water reaches the indicated water line. (See
pictures below)
IMPORTANT: When adding water to the game, the amount of water needs to be exactly at the
Waterline (as indicated in the playfield). Keep adding water until the water surface reaches the
water line. Be careful not to go over because too much water affects floatation of the ducks and
can affect the overall game play.
Ste
p
1:
Close the Pressure Valve
Step 2: Turn on
the Drain Valve
Open the door and adding
water until waterline.
waterline
Unscrew the Nut under the pump to
em
p
t
y
the water inside the
p
um
p
.
Step 3: Press and hold
the Drain Button until
water is fully emptied

Ducky Splash CEC Rev. 1.02
18
6.5 Left & Right Gun Assembly Maintenance：
Step 1: Fasten the Lock
Pin from the inside to
secure the front panel
d
Step 2: To open the control panel, grip the two Dino
water guns at the base then pull them towards you. The
control panel should open up.
Control Switch Frame

Ducky Splash CEC Rev. 1.02
19
6.5 Other Parts Maintenance：
1Waterpipemaintenances 2Filtermaintenances
3Filter maintenances
1 2 3
Unscrewed and take out water pipe. Unscrewed and clean up filter
filter
Unscrewed
and
maintenance sen
sor
