Universal Space FROST ISLAND User manual

Operation Manual
www.universal-space.com

Frost Island Manual Rev.1.02
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual. Failing
to comply can cause severe accidents such as electric shock or other
serious injuries. All repairs must be performed to original manufacturer
specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
IMPORTANT SAFETY INSTRUCTIONS........................................................................ 2
1. SPECIFICATIONS ..................................................................................................... 4
2. PACKAGE CONTENTS.............................................................................................. 5
3. PART NAME.............................................................................................................. 6
4. SET UP & INSTALLATION........................................................................................ 7
5. HOW TO PLAY ........................................................................................................10
6. GAME OPTION .......................................................................................................12
7. ERROR MESSAGE AND RECOVERY ....................................................................13
8. MAINTENANCE & INSPECTION ...........................................................................16
9. OVERALL CONSTRUCTION ...................................................................................21
10. DECALS ................................................................................................................28

Frost Island Manual Rev.1.02
2
Thank you for purchasing Frost Island. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Frost Island Manual Rev.1.02
3
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install
outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
•Places subject to rain/moisture, or places subject to high humidity.
•Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
•Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
•On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
•Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Frost Island Manual Rev.1.02
4
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz
Min. Power consumption: 350W
Max. Power consumption：1100W
Dimensions：W1109×D1930×H2264 (mm)
Weight：Approximately 300kg
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game parameters are subject to change without notice.
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.

Frost Island Manual Rev.1.02
5
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
1. 1 x Body Assembly
2. Following accessories
NOTE: Part models are subject to change without notice.
No. Part No. Code Name Spec. Qty Picture
1 F132-482-000
23301000039
Power cord 15A/250V 1.8M 1
1 F132-491-000
21901000014
Fuse
Φ6×30mm
T10A
250VAC (220V) 1
2 F132-483-000
21901000011
Φ6×30 T15A
250VAC (110V)
3 F132-701-000
41441218002
Manual ENGLISH 1
4 F132-484-000
25300171002
Key
171A 3
5 F132-485-000
25302222002
2222 2
6 F132-486-000 41300000004
Memory
stick 4G 1

Frost Island Manual Rev.1.02
6
3. PART NAME
Gun Assy.
42’ Monitor
Control panel
Control Panel Assy.
Coin Assy.
Marquee Assy.
Side decal
Service Door Assy.

Frost Island Manual Rev.1.02
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install
outdoors.
zRefer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid
zPlace the unit on a dry level surface
zVentilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 How to Install the Marquee
Step 1 After unpack the game, remove screws on top in order to stand up the marquee.
Step 2 Fix the marquee to the machine with two provided metal plate.

Frost Island Manual Rev.1.02
8
4.2 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 500mm
Play area: 500mm
4.3 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 5mm. Repeat the same for all levelers.
Leveler Caster
About 5 mm
Move Fix
Make sure the machine is level with the ground and all the
adjustable legs should stick to the floor closely.
NOTICE
Play area
Service areaService area

Frost Island Manual Rev.1.02
9
4.4 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position so the casters
touch the ground.
NOTICE
•Be careful not to damage the machine during transport.
•The machine should be handled with care when bringing it down from a higher level.
•Always unplug the game before moving.
•Keep the machine in upright position during transport.
•For longer distance transport, package the game properly to prevent damages.
4.5 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to
an electrical outlet to ensure that the required voltage and frequency match
the available power source. Please refer the label of the machine.
•Do not plug the equipment power cables into an electrical outlet if the power cable
is damaged.
•Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
•Connect the grounding conductor to the earth terminal (GND):









Leveler Caster
Move
F
Power socket
Power outlet
Power plug
Power cord
Power plug

Frost Island Manual Rev.1.02
10
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet
does not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the
cord.
To prevent electric shock, do not touch the power plug when hand is wet.
Ensure that nothing rests on the power cord and that it is not located where it can be
stepped on or tripped over.
5. HOW TO PLAY
1 Insert coin(s). Shooting water to select the map. There are 4 stages: Waterfall, Basin,
Cave and Canyon.

Frost Island Manual Rev.1.02
11
2 Aim at targets and shoot off them in order to pass the stage.
3 During the game play, some part needs player to press button to fill up the bar in the
limited time in order to escape from the monsters. Or press the button to stop the moving
triangle at the specified point to escape successfully.
4 Stage clear can win score. And have an option to open a treasure box to get more
tickets.

Frost Island Manual Rev.1.02
12
6. GAME OPTION
6.1 Adjustment button instruction
Open the coin door there is a meter panel. Press service button to get into the setting
menu.
6.2 Setting menu
6.2.1 Main Menu
6.2.2 Game Mode
T
est Service Reset
Game Mode
Input Test
Output Test
Game Reset
Lanuage 语言
Date/Time Setting
Bookkeeping
Daily Record
GameRecord
Alignment
Exit & Without Save
Exit & Save
Free Play OFF
Tickets Out ON
Attract Mode ON
SaveCoins ON
Volume 10
CoinsPerGame 1
TicketPayout 10
GameDifficulty Normal
Color of blood red
ShowAward OFF
MercyTickets 2
TicketsOfOneStar 5
TicketsOfTwoStars 10
TicketsOfThreeStars 15
TicketsOfFourStars 20
Tickets Of Five Stars 30
Ticket Mode Store Tickets in Memory

Frost Island Manual Rev.1.02
13
Note:
No. Item Options Explanation
1 Free Play ON/OFF
2 Tickets Out ON/OFF
3 Attract Mode ON/OFF
4 Save Tickets ON/OFF Whether save tickets when power is
off.
5 Volume 0~10 0 is mute. 10 is max.
6 Coins per
Game
1~10 Coins to play one game.
7 Ticket Payout 1~15 Average ticket payout for one game
8 Game Difficult Easy/Normal/Hard
9 Color of UI Normal/Special Normal is red blood, Special is brown
blood.
10 Show Award ON/OFF Whether have treasure box selected
after one stage is passed.
11 Mercy Ticket 0~10
12 Tickets Of One
Star
1~100 Get one star after one stage is passed
can win specified tickets.
13 Tickets Of Two
Stars
1~100 Get two stars after one stage is
passed can win specified tickets.
14 Tickets Of
Three Stars
1~100 Get three stars after one stage is
passed can win specified tickets.
15 Tickets Of
Four Stars
1~100 Get four stars after one stage is
passed can win specified tickets.
16 Tickets Of Five
Stars
1~100 Get five stars after one stage is
passed can win specified tickets.
17 Ticket Mode Store tickets in memory/
call attendant
Whether continue to play the game
when ticket is owed.
6.2.3 Input Test
Water High Level OFF
Water Low Level OFF
Back high door OFF
Back low door OFF
Player1 Pos X 0
Player1PosY 0
Player2 Pos X 0
Player2PosY 0
Service Coin OFF
Reset OFF
Coin0 OFF
Coin1 OFF
KeyLeft OFF
KeyRight OFF
KeyMiddle OFF
Note:
Key Left: P1 start button
Key Right: P2 start button
Ke
y
Middle: Middle button

Frost Island Manual Rev.1.02
14
6.2.4OutputTest 6.2.5GameReset
6.2.6Language 6.2.7Date/TimeSetting
6.2.8Bookkeeping 6.2.9DailyRecord
6.2.10 Alignment
Left light
Right light
Control Light
Trumpet Light
Player 1 Lamp
Player 2 Lamp
Middle Light
Player 1 Gun
Player 2 Gun
Player 1 Shake
Player 2 Shake
Reset Game Setting
Delete All Record
Clear Ticket
Note:
Reset Game setting: Reset all settings to default.
Delete All Record: Clear all bookkeeping data
Clear Ticket: Clear owed tickets.
English
简体中文(Chinese)
Year 2013
Month 8
Day 13
Hour(24) 8
Minute 26
Second 1
Player Coin Tickets Payout
1 0 0 0
2 0 0 0
Sum 0 0 0
Reset
Back
Save?
No
Yes
Date Weekday RunTime Coins Tickets Payout
2013 SAT 00:10 0 0 0.00
Reset
Back
Save?
No
Yes
1P_X:0_Y:0 Control the activated water gun to
shoot water at the highlighted spot
on by one. Press button confirm each
time. There are going to be 9 spots in
total.

Frost Island Manual Rev.1.02
15
7. ERROR MESSAGE AND RECOVERY
7.1 Trouble Shootings
zPlease confirm whether every connector connected tightly.
Troubles Cause Methods
Cannot start Frame assembly connector fall off
Please plug in connector tightly
Frame assembly fault Please contact with dealer
Power cutting Circuit protector make power SW
in cutting state
Please turn on power SW again. If
appeared again and again, machine
has anomaly. Please contact with
dealer
Coin mech. no
reaction
Coin mech. fault Change coin mech.
Coin mech. signal cable loosen Check coin mech. signal line loosen or
not
IO control board fault Change IO board
Speaker no
sound
Volume set too low Please raise the volume
Connector falls off Please plug in connector tightly
PCB fault Please change PCB
Speaker fault Please change speaker
Monitor black
screen
Connector falls off Please plug in connector tightly
Monitor fault Please change monitor
Monitor blue
screen
PC power cord is loose Check PC power cord whether is loose.
VGA signal cable is loose. Check VGA signal whether is loose.
PC video card is loose. Plug video card again.
PC into protection
Open front cover, if power on light flash
all the time. Press power button 30s,
then restart. If no work, please call
Lenovo: 8008108888
Playing normal,
but appear
system halted
Video card is loose or poor contact Plug video card again
PC crash Restart or system recovery
Gun no reaction
POT no initialize Please initialize it
Connector falls off Please plug in connector tightly
POT install error Please install POT correctly
POT fault Please change POT
Trigger no
reaction
Connector falls off Please plug in connector tightly
Micro SW fault Please change micro SW
Start button no
reaction
Connector falls off Please plug in connector tightly
Button breakdown Please change star button
Gun doesn’t
shock
PCB fault Please change PCB
Shock assembly fault Please change shock assembly
Gun thumb
error
Thumb position error Please calibrate gun assembly
Thumb reverse Gun calibrate reverse

Frost Island Manual Rev.1.02
16
7.2 System Recovery Operation
1. Turn off the game. Insert the memory
stick into the USB port at the back of
the computer.
2. Restart PC to enter the system
recovery screen as shown.
3. The game will automatically start
recovery which will last about 5
minutes.
Please wait until process is complete.
Please wait until process is complete.
WARNING: the USB flash drive should only be used to fix software errors. Using it for
other purposes may cause unexpected results and damages.
4. Once system recovery is finished (as shown on
the left), remove the USB flash drive from the
computer and turn off the PC. Wait at least 30
seconds before restarting the PC.

Frost Island Manual Rev.1.02
17
8. MAINTENANCE & INSPECTION
8.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Try to run the game before operation each day.
2. Conduct monthly routine checks of game components ensure good working condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to be kept running
smoothly
8.2 Handling Precautions
When installing or inspecting the machine, be very careful of the following points and
pay attention to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to
the cautionary matters herein stated can cause personal injury or damage to the machine
• Before servicing the machine, be sure to turn power off. Servicing without turning the
power off can cause electric shock or short circuit.
• To avoid electric shock or short circuit, do not plug then unplug the power quickly
• Do not expose power cords and earth wires, these are susceptible to damage.
• Damaged cords and wires can cause electric shock or short circuit and should be
replaced immediately.
• When or after installing the product, avoid pulling the power cord to prevent
unnecessary wear and tear. Use the power button to disconnect power.
• In case the power cord is damaged, ask for replacement through where the product was
purchased from or replace locally. Continued usage of damaged cord can cause fire,
electric shock or leakage.
• Perform grounding appropriately. Inappropriate grounding can cause electric shock.
• Use fuses that meet specified rating. Fuses exceeding can cause an electric shock.
• Should a problem occur, turn off the power immediately and stop operating the
machine. Unplug the power cord of the service outlet. Operating the machine without
correcting the problem may cause a fire or injuries.
• Insert the power plug securely into the outlet. Poor contact may cause overheating,
resulting in fire or burns.
• To ensure the warning labels attached on the machine are visible and legible, install the
machine in a well-lit location, and keep the labels clean at all times. Make sure the
labels are not hidden behind other game machines.
WARNING

Frost Island Manual Rev.1.02
18
8.3 How to Add Water
1When adding water, please turn off the drain valve and lock tightly water pump drain
screw, Release drain button.
2Make sure no crack on water tank and no loose on water pipe connectors. Keep the
water tank in the correct position. The waterproof cloth should in the funnel.
3When first time to fill water into the water tank, we can fill up70L water slowly from the
front. This is the max capacity for the water tank.
4If “Low water” warning information is appear in the game, please fill up 50L.
Highest water level fill line
Clean the water tank every
month
Change the water every
month
Lowest water level
Notice:
1. Clean the water tank every month.
2. Clean the foam every month; change the foam every 3 months.
3. Change distilled water every month. Please refer to 8.6

Frost Island Manual Rev.1.02
19
8.4 Initialize water pump and Attention
First use the machine, Please inject water for water pump;;
(1)Use the tool turned on injection screw
(2)Injection from the hole until it filled;
(3)After filled, tighten the screw, Ensure no leakage;
Note: This step is only performed before first use. As shown in figure：
8.5 Water Pressure Adjustment
Adjust the water pressure by adjusting the valve：
Start the game, please adjust the water pressure to 0.25MPa
Water pressure will be higher
when the valve is closed.
Water pressure will be lower
when the valve is open.
