Universal Space Pong User manual

1.1 version
www.universal-space.com
Operation Manual
IMPORTANT

PONG Manual
05/16/2019
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
When contacting Service, you will need the following information
and the name of your authorized distributor.

PONG Manual
05/16/2019
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................4
2. CONTENTS OF THE ACCESSORY KIT................................................................... 6
3. PART NAME............................................................................................................7
4. SET UP & INSTALLATION...................................................................................... 8
5. HOW TO PLAY........................................................................................................ 9
6. GAME OPTION..................................................................................................... 12
7. TROUBLESHOOTING............................................................................................18
8. MAINTENANCE & INSPECTION..........................................................................19
9. OVERALL CONSTRUCTION................................................................................. 26
10. WIRING DIAGRAM............................................................................................ 39

PONG Manual
05/16/2019
3
Thank you for purchasing PONG. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

PONG Manual
05/16/2019
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

PONG Manual
05/16/2019
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz
Min. Power consumption: 80W
Max. Power consumption: 200W
Dimension: W47.64×D29.07×H18.90 in
W1210×D738.4×H480 mm
Weight：Approximately 176.36 lb
80KG
Part No: P156
Model: A-416
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.
Note: Game specifications are subject to change without notice.
47.64 in (1210mm)
18.90 in (480mm)
29.07 in (738.4mm)

PONG Manual
05/16/2019
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
1. Following accessories
No.
Part No.
Code
Name
Qty
1
P156-801-000
23301010020
Power cord
1
2
P156-432-000
21901000010
Fuse
1
3
P156-803-000
40607000013
L wrench
1
4
P156-804-000
41440000247
Manual
1
5
P156-459-000
25100080015
Suction cup
1
6
P156-160-000
20211707045A
Adjust plate A
1
7
P156-161-000
20211707046A
Adjust plate B
1
8
P156-324-000
20101020034
Cross recessed pan head
screw set
2
9
P156-303-000
20113000003
Standard spring washer
/
2
10
P156-101-000
20211707H040
Block
1
NOTE: Part models are subject to change without notice.

PONG Manual
05/16/2019
7
3. PART NAME
Key Components
Display
Control Panel
Power Switch
Control Panel
Paddle
Ball Assembly
Jog

PONG Manual
05/16/2019
8
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings must not be obstructed by objects or by wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Play area: 20 in
Play area
Your unit must be leveled to operate properly.
NOTICE
We do not recommend using power tools as they may cause damage.
NOTICE

PONG Manual
05/16/2019
9
4.2 Voltage Conversion(110V to 220V)
Step 1 Power off the game and use the suction cup as shown in the picture to remove the
glass.
Step 2 Open end panel of player position shown in the pictures. Remove the screw covers
and loosen the screws.
Step 3 Open the control panel as shown. Unplug the connector as indicated by the red
circle.

PONG Manual
05/16/2019
10
Step 4 Locate the Power supply. Toggle the switches to 230V.

PONG Manual
05/16/2019
11
5. HOW TO PLAY
5.1 Press 1P Start button or 2P Start button to start the game. Move the jog to control the
paddle, press the orange button to shoot. (Same function as the two orange buttons)
Press the orange
button to start the
game and shoot
the ball!
Turn the jog to
control the paddle
moving left and
right in order to
catch the ball.
Orange button
Jog
1P Start
Orange button

PONG Manual
05/16/2019
12
6. GAME OPTION
Enter into the setting menu
Locate the player 1 side, press two orange buttons and 1P Start button to make the Ball be
in the middle. Then you’ll see “CONF” on the display. (It doesn’t work during game over
time)
Roll the jog or press 1P and 2P to choose, press the right orange button to enter and set,
press the left orange button to exit.
Note: It is the same steps when game playing.
Exit
Next/Prev
Next
Enter /Set
Prev

PONG Manual
05/16/2019
13
6.1 Setting Menu
When SERVICE MODE is active, you
will see CONF in the scoreboard by
default. Spinning the JOG will switch
spelling between configuration (CONF)
and checks (CHEC)
PREV exits SERVICE MODE and SET
selects the active option.
Functions audio related
Default settings reset
(Press SET to “0” to set)

PONG Manual
05/16/2019
14
VALUES: CL
FU
Ny
Re
DEFULT: CL
VALUES: CL
FU
Ny
Re
DEFULT: CL
MERCY TICKET
TICKET FOR
WINNER
VALUES: #
RANGE: 0..99
DEFULT: 0
VALUES: #
RANGE: 0..99
DEFULT: 0
LOCK COIN
This option only applies to units
fitted with a coin mechanism.
Choose FREE PLAY or COIN
OPERATED.
This menu is navigated with
NEXT/PREV
JOG changes the parameter.
SET for select.
VALUE:#
RANGE:0-99
(NOT OPEN)
VALUE:#
RANGE:0-99
(NOT OPEN)
VALUE: #
RANGE: 1-20
VALUE:#
RANGE:0-02
(NOT OPEN)

PONG Manual
05/16/2019
15
VALUES: #
RANGE: 3..39
DEFAULT: 05
VALUES: #
RANGE: 0..5
DEFAULT: 03
VALUE: #
RANGE: 0-04
Game Speed:
0-----0.3175m/s
1-----0.4978m/s
2-----0.6782m/s
3-----0.8585m/s
4-----1.0389m/s
5-----1.2192m/s
6-----1.5875m/s
VALUE: #
RANGE: 0..99
DEFAULT: 01

PONG Manual
05/16/2019
16
AUTO
LEDS, Motors and
Inputs auto tests.
( Press SET and
BACK to exit.)
Motors tests.
( Press SET and
BACK to exit.)
Inputs tests.
( Press SET and
BACK to exit.)
VALUES: #
RANGE: 0..99
VALUES: #
RANGE: 0..15

PONG Manual
05/16/2019
17
After powering on the machine, the display will show the Program Version(the left two
characters) and the Music File Version(the right two characters).
Music File
Version
Program
Version

PONG Manual
05/16/2019
18
7. TROUBLESHOOTING
7.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom
Possible Cause
Recommended action
Game will not
start
Frame assembly connector is
loose.
Check connector.
Frame assembly is faulty.
Contact UNIS Service.
Power off
Circuit protector changes power
SW to “off”.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact UNIS Service.
No sound
Low volume
Raise the volume.
Connector loose.
Check connector.
Speaker is faulty.
Check speaker.
Audio cable problem.
Reconnect the audio cable or change
it.
Driver problem
Restart the audio driver.
Ball shaking
The bottom of the Ball or the
playfield has dirt.
Utilize non-woven fabric with distilled
water to clean the bottom of the Ball.
Clean the playfield. (Refer to 8.4)
Error code
Possible Cause
Recommended action
Motors of Ball X axle doesn’t
work.
Check the connection of motors of Ball
X axle.
Check the motors of Ball X axle.
Sensor of Ball X axle doesn’t
work.
Check the sensor of Ball X axle.
Motor of Ball Y axle doesn’t
work.
Check the connection of motor of Ball Y
axle.
Check the motor of Ball Y axle.
Sensor of Ball Y axle doesn’t
work.
Check the sensor of Ball Y axle.
Motor of P1 Paddle doesn’t
work.
Check the connection of motor of P1
Paddle.
Check the motor of P1 Paddle.
Sensor of P1 Paddle doesn’t
work.
Check the sensor of P1 Paddle.
Motor of P2 Paddle doesn’t
work.
Check the connection of motor of P2
Paddle.
Check the motor of P2 Paddle.
Sensor of P2 Paddle doesn’t
work.
Check the sensor of P2 Paddle.
Out of ticket
Fill the ticket dispenser with tickets.
(Refer to next page for detailed locations.)

PONG Manual
05/16/2019
19
8. MAINTENANCE & INSPECTION
8.1 Safety Check
These checks are necessary for safe machine operation:
1. Test game before operation each day.
2. Conduct monthly routine checks of game components to ensure good working
condition
3. Check the machine regularly for dust and clean as necessary.
Note: Parts and components require preventative maintenance to maintain proper
operation.
8.2 Handling Precautions
When inspecting the machine, be very careful of the following points and pay attention
to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the
cautionary matters herein stated can cause personal injury or damage to the machine
We do not recommend using power tools as they may cause damage.
NOTICE
Motor of Ball Y axle
Motor of P2
Paddle
Motor of Ball
X axle
Motor of Ball
X axle
Motor of P1
Paddle
Sensor of Ball Y axle
Sensor of
Ball X axle
Sensor of P1
Paddle
Sensor of P2
Paddle
