Universal Space D-DAY User manual

www.universal-space.com
Operation Manual
IMPORTANT

D-Day Manual
12/02/2017
1
CONTENT
IMPORTANT SAFETY INSTRUCTIONS........................................................................ 2
1. SPECIFICATIONS ..................................................................................................... 4
2. CONTENTS OF THE ACCESSORY KIT .................................................................... 6
3. PART NAME.............................................................................................................. 7
4. SET UP & INSTALLATION........................................................................................ 8
5. HOW TO PLAY ........................................................................................................ 17
8. TROUBLE SHOOTINGS ..........................................................................................18
9. MAINTENANCE & INSPECTION ...........................................................................23
8. OVERALL CONSTRUCTION ...................................................................................24
9. WIRING DIAGRAM ................................................................................................40

D-Day Manual
12/02/2017
2
Thank you for purchasing D-Day. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

D-Day Manual
12/02/2017
3
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

D-Day Manual
12/02/2017
4
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V-240V 50/60Hz
Min. Power consumption: 200W
Max. Power consumption: 1200W
Dimension: W51.1×D95.3×H100.6 in
Weight：Approximately 771.6 lb
Part No: D139
Model No: V-006
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

D-Day Manual
12/02/2017
5
This machine will be divided into two parts during transportation.
Display part: W44.3×D38.5×H73.4 in
Seat part: W39×D59.8×H55.4 in
Note: Game specifications are subject to change without notice.

D-Day Manual
12/02/2017
6
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
1. Following accessories
No. Part No. Code Name Picture Qty
1 D139-805-000 41440000234A Manual 1
2 D139-801-000 25300171002 Key 2
3 D139-802-000 25300172002 Key 2
4 D139-541-000 23301000001 Power cord
1
5 D139-578-000 23302000012 Network cable 1
NOTE: Part models are subject to change without notice.

D-Day Manual
12/02/2017
7
3. PART NAME
Key Components
Coin ass
y
.
HTC headset
Mar
q
uee
Ass
y
.
Display
Gun assy.
Base Station

D-Day Manual
12/02/2017
8
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 0.2 in. Repeat the same for all levelers.
Leveler Caster
Move F
i
Caster
Leveler
About 0.2 in
Move Fix
NOTICE
Make sure the machine is level.
We do not recommend using power tools as they may cause damage.
NOTICE

D-Day Manual
12/02/2017
9
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 20 in
Service area
Play area

D-Day Manual
12/02/2017
10
4.4 Machine Installation
Before processing with assembly assure you have the following tools.
Step 1 Install base station and set the channel.
1-1 Install the base station
No. Name Picture
Use for
1 Phillips screwdriver Step 2 & Step 3
2 Allen hexagon wrenches Step 2 & Step 3

D-Day Manual
12/02/2017
11

D-Day Manual
12/02/2017
12
1-2 Set the channel
Step 2 Marquee installation
2-1 Install marquee fix plates on the Marquee decal 1 with Hexagon flange nuts.
No. Part No. Code No. Name Picture Qty
1 D139-702-000 20541706A002
Marquee decal 1
1
2 D139-310-000 20241706045 Marquee fix plate 1 1
3 D139-309-000 20241706046 Marquee fix plate 2 1
4 D139-171-000 20102040011 Hexagon flange nut
8
Signal light Channel button
1
2
3

D-Day Manual
12/02/2017
13
2-2 Install marquee fix plates (with marquee decal) on the cabinet.
No. Part No. Code No. Name Picture Qty
1 D139-124-000 20101020039 Cross recessed pan
head screw set
8
2-3 Install Marquee decal 2 on the Marquee fix plate 3 in red square area.
No. Part No. Code No. Name Picture Qty
1 D139-717-000 20541706003 Marquee decal 2
1
2 D139-311-000 20241706047 Marquee fix plate 3
1
3 D139-169-000 20101010140 Cross recessed pan
head screw
8

D-Day Manual
12/02/2017
14
2-4 Install Marquee fix plate 3 (with marquee decal) on the cabinet.
No. Part No. Code No. Name Picture Qty
1 D139-124-000 20101020039 Cross recessed pan
head screw set
8
2-5 Install Marquee POP decal on the cabinet.
No. Part No. Code No. Name Picture Qty
1 D139-720-000 20541706006 Marquee POP decal
1
2 D139-169-000 20101010140 Cross recessed pan
head screw
8

D-Day Manual
12/02/2017
15
Step 3 Cabinet Installation
3-1 Place two parts as picture shown and connect all the plugs in red circle area.
3-2 Connect the display part and seat part with Cross recessed hexagon screw kits in red
circle area.
No. Part No. Code No. Name Picture Qty
1 D139-170-000 20104003006 Cross recessed
hexagon screw kit
2

D-Day Manual
12/02/2017
16
3-3 Install the Wiring cover with Cross recessed pan head screws in red rectangle area.
No. Part No. Code No. Name Picture Qty
1 D139-308-000 20241706001 Wiring cover
1
2 D139-169-000 20101010140 Cross recessed pan
head screw
6

D-Day Manual
12/02/2017
17
5. HOW TO PLAY
5.1 Insert coin(s) to start the game.
5.2 Put on the headset and fasten the seat belt.
5.2 Press the trigger to shoot.

D-Day Manual
12/02/2017
18
6. TROUBLESHOOTING
6.1 Common Problem
Please confirm that all connectors fit tightly.
Symptom Possible Cause Recommended action
Game will not
start
Frame assembly connector is
loose. Check connector.
Frame assembly fault Contact with UNIS Service.
Power off Circuit protector make power SW
in off state.
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
No sound
Low volume Raise the volume.
Connector loose. Check connector.
Speaker fault. Check speaker.
POT installation error. Install POT correctly.
POT fault. Change POT.
Audio cable problem. Reconnect the audio cable or change
it.
PC crash. Restart or system recovery.
Driver problem Restart the audio driver.
Display black
screen
Check connectors. Plug in connector tightly
Display fault. Utilize another source such as a PC to
verity if the display is operational.
RAM is loose. Remove and reinsert RAM.
Display blue
screen
PC power cord is loose Check PC power cord whether is loose.
VGA signal cable is loose. Check VGA cable
PC video card is loose. Reseat video card.
“0X000000A” code appears.
Conflict between computer drive
and software.
Contact service
No motion and
gun is
immovable.
Stop button is activated. Press the stop button again to
deactivate the stop button.
Seat belt unfasten. Fasten the seat belt.
No motion or
weak motion,
but gun is
movable.
Not enough air pressure for air
compressor. Waiting for air supply.
Air compressor is off.. Turn on the air compressor.
Blow-down valve is on. Turn off the blow-down valve.
Air compressor error Change the air compressor.
Gun is
immovable. Gun rotary motor malfunction. Change the gun rotary motor
Note: After replacing component from pc (except for RAM), and replacing monitor, the
game should be recovered again with the memory stick attached to the machine.
