Universal Space Super Big Rig User manual

Operation Manual
www.universal-space.com

Super big rig Manual Rev.1.0
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual. Failing
to comply can cause severe accidents such as electric shock or other
serious injuries. All repairs must be performed to original manufacturer
specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.........................................................2
1. SPECIFICATIONS ......................................................................................4
2. PACKAGE CONTENTS...............................................................................5
3. PART NAME...............................................................................................6
4. SET UP & INSTALLATION.........................................................................7
5. HOW TO PLAY ........................................................................................ 10
6. GAME OPTION ....................................................................................... 15
7. ERROR MESSAGE AND RECOVERY .................................................... 19
8. MAINTENANCE & INSPECTION ........................................................... 21
9. OVERALL CONSTRUCTION ................................................................... 22
Wiring Diagram ......................................................................................... 39

Super big rig Manual Rev.1.0
2
Thank you for purchasing Super big rig. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Super big rig Manual Rev.1.0
3
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install
outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Super big rig Manual Rev.1.0
4
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz
Min. Power consumption: 170W
Max. Power consumption：260W
Dimensions：W1240×D1330×H1920 (mm)
Weight：Approximately280kg
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game parameters are subject to change without notice.
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.

Super big rig Manual Rev.1.0
5
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
1. 1 x Body Assembly
2. Following accessories
NOTE: Part models are subject to change without notice.
No. Part No. Code Name Spec. Qty Picture
1 S127-443-000 23301000001 Power cord 10A/250V 1.8M 1
2 S127-417-000 21901000012 Fuse Φ5×20mm T10A
250VAC 1
3 S127-801-000 41440000077 Manual ENGLISH 1
4 S127-452-000 25300171002 Key 171A 2
5 S127-454-000 25300172002 Key 171B 1
6 S127-465-001 40607000001 L-type hex wrench
CR-4mm 1

Super big rig Manual Rev.1.0
6
Top Marquee
Chimney Assy.
St
eer
i
ng w
h
ee
l
Spare tire Assy.
Taillight Assy.
Rear Marquee
3. PART NAME
Microphone
Pull
-
cord Switch
32” Display
Coin mech.

Super big rig Manual Rev.1.0
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install
outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 500mm
Service area
The machine play area

Super big rig Manual Rev.1.0
8
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 5mm. Repeat the same for all levelers.
4.3 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position so the casters
touch the ground.
NOTICE
Be careful not to damage the machine during transport.
The machine should be handled with care when bringing it down from a higher level.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.4 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to
Leveler Caster
About 5 mm
Move Fix
Make sure the machine is level with the ground and all the
adjustable legs should stick to the floor closely.
NOTICE
Leveler Caster
Move
F

Super big rig Manual Rev.1.0
9
an electrical outlet to ensure that the required voltage and frequency match
the available power source. Please refer the label of the machine.
Do not plug the equipment power cables into an electrical outlet if the power cable
is damaged.
Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
Connect the grounding conductor to the earth terminal (GND):
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet
does not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the
cord.
To prevent electric shock, do not touch the power plug when hand is wet.
Ensure that nothing rests on the power cord and that it is not located where it can be
stepped on or tripped over.
Power socket
Power outlet
Power plug
Power cord
Power plug

Super big rig Manual Rev.1.0
10
5. HOW TO PLAY
5.1 Game interface
A：Items to Deliver and game time.
B：Game start.
B
A
A

Super big rig Manual Rev.1.0
11
A：There will be different tasks in the game.
A：There will be different tasks in the game.
A
A

Super big rig Manual Rev.1.0
12
5.2 Game Introduction:
Announcement of the results

Super big rig Manual Rev.1.0
13
5.2 Task Setting.
Set three tasks in the game.

Super big rig Manual Rev.1.0
14
5.3. Scene setting
There are two scenes in the game.
Scenes 1
Scenes 2

Super big rig Manual Rev.1.0
15
6. GAME OPTION
6.1 Adjustment button instruction
Open the coin door there is a meter panel. Press service button to get into the setting
menu.
6.2 Setting menu
6.2.1 Main Menu
6.2.2 Basic Setting
Main Menu
Basic Setting
Customized Setting
Input Test
Output Test
Game Reset
Date/Time Setting
Language/语言/言語選択
Bookkeeping
Daily Record
About This Game
Back to Game
Super BigRig1.0
Free Play OFF
Tickets Out ON
DemoMusic OFF
Memory Save ON
Volume 10
Game Time 60
CoinsPerGame 1
OutofTickets Storeinmemory
Back&Save
Back
Super BigRig1.0
Test Service Reset

Super big rig Manual Rev.1.0
16
6.2.3 Customized Setting
6.2.4InputTestandOutputTest
6.2.5 Game Reset
Customized Setting
Fixed Ticket 0
Two Tickets Equal One OFF
The Best Truck Driver 5
An Excellent Truck Driver 4
A Great Driver 3
AGoodDriver 2
Back&Save
Back
Super BigRig1.0
Input Test
Coin OFF
Horn Button OFF
Wippers Button OFF
Headlights Button OFF
Microphone OFF
Start Button OFF
Steering Wheel OFF
Back
Super BigRig1.0
Game Reset
Factory Restore
Reset Game Mode Settings
Clear all records
Clear unused coin
lear Owed Ticket
Clear Unused Coin
Back
Super BigRig1.0
Output Test
Voice Control Button
Start Button
Ticket Driver
Motor1
Motor2
Motor3
Meter D
Meter R
Super BigRig1.0

Super big rig Manual Rev.1.0
17
6.2.6 Date/Time Setting
6.2.7 Bookkeeping
6.2.9 Daily Record
Date/Time Setting
Year 2014
Month 9
Day 24
Hour(24) 22
Minute 26
Second 0
Back&Save
Back
Su
p
er Bi
g
Ri
g
1.0
Bookkeeping
Player Coins Tickets Payout
1 0 0 0
2 0 0 0
Sum 0 0 0
NON RESETTABLL POINTS
NON RESETTABLE TICKETS
Back
Super BigRig1.0
Daily Record
Date Weekday RunTime Coins Tickets Payout
Clear
Back
Su
p
er Bi
g
Ri
g
1.0

Super big rig Manual Rev.1.0
18
6.2.10 About this game
About This Game Press Setting Button to Back
CPU Intel(R)Core(TM)i5-3450CPU@3.10GHz
MainBoard MSI
HDD ST500DM002-1BD142 ATA Device 465GB
RAM 3553MB
Monitor LT32BM20(L)
Screen 1360X768
Version Super BigRig1.0
Super BigRig1.0

Super big rig Manual Rev.1.0
19
7. ERROR MESSAGE AND RECOVERY
7.1 Trouble Shootings
Please confirm whether every connector connected tightly.
Troubles Cause Methods
Cannot start Frame assembly connector fall off
Please plug in connector tightly
Frame assembly fault Please contact with dealer
Power cutting Circuit protector make power SW
in cutting state
Please turn on power SW again. If
appeared again and again, machine
has anomaly. Please contact with
dealer
Coin mech. no
reaction
Coin mech. fault Change coin mech.
Coin mech. signal cable loosen Check coin mech. signal line loosen or
not
IO control board fault Change IO board
Speaker no
sound
Volume set too low Please raise the volume
Connector falls off Please plug in connector tightly
PCB fault Please change PCB
Speaker fault Please change speaker
Monitor black
screen
Connector falls off Please plug in connector tightly
Monitor fault Please change monitor
Monitor blue
screen
PC power cord is loose Check PC power cord whether is loose.
VGA signal cable is loose. Check VGA signal whether is loose.
PC video card is loose. Plug video card again.
PC into protection
Open front cover, if power on light flash
all the time. Press power button 30s,
then restart. If no work, please call
Lenovo: 8008108888
Playing normal,
but appear
system halted
Video card is loose or poor contact Plug video card again
PC crash Restart or system recovery
Start button no
reaction
Connector falls off Please plug in connector tightly
Button breakdown Please change star button
Thumb reverse Gun calibrate reverse
