Wren Kitchens L Corner Base Unit Assembly instructions

FITTING GUIDE
L Corner Base Unit
For Internal Use: CON.INS.002.001_50-WKIN0008_BASE_LCnr_Rev4.indd
Screws for attaching to walls and worktop are not provided as these vary depending
on materials, thickness and construction. Ensure appropriate xings for wall and
worktop construction are used. Please refer to the specialist worktop supplier if
these are required for solid surface worktops.
(H) x8 1 1/4” Screws (B) x82 5/8” Screws
(K) x5 L Bracket - Large (Ff) x10 Fixing Plate
Step 1.
Attach Fixing Plates (Ff) onto cabinets in 3 positions (1), (2), (3) as shown using 4 x 5/8”screws (B)
per plate. Be careful not to interfere with leg positions.
Step 2.
Secure each of the legs into place with
2 x 5/8” screws (B). Ensure legs
are rotated as shown so that part of it
is supporting the end panel.
View from underside
View from rear of unit
Step 3.
Use 2 x 5/8”screws (B) to secure each
of the L brackets (K) to the cabinet at
either side.
Sample cabinet shown
(1)
(3)
(2)
B
BK
B
Ff
Ff
Ff
Ff
Ff
Ff
Page 1
REQUIRED TOOLS

FITTING GUIDE
L Corner Base Unit
For Internal Use: CON.INS.002.001_50-WKIN0008_BASE_LCnr_Rev4.indd
View from rear of unit
Step 6.
Screw into any side units using the 1 1/4”(H) provided to secure
to unit. Screw just to the rear of the hinge plate at the top and
bottom of both sides of the unit.
View from underside
Step 4.
Use 2 x Fixing Plates (Ff) with 4 x 5/8”screws (B) to attach the
corner post to the door frontal.
Sample cabinet shown
Ff
Ff
B
H
Step 5.
The remaining two xing plates (Ff) are to
be used to attach the loose shelf sections
together.
Page 2
Ff
Ff
Ff
Ff
B
